and tighten with a wrench. Be very careful not to
M12-098
Model # 6012
INSTRUCTIONS
1. Thread the faucet body and pillars together
damage the finish of the faucet.
2. Apply tape or putty to both ends of the hot
and cold supply nipples. Thread the supply
nipples into the pillars and secure the faucet to
the rim of the bathtub using the large lock nuts.
3. Install a washer in the cradle nut and thread
the cradle onto the faucet body. Tighten with a
wrench. Be very careful not the damage the
finish of the faucet.
4. Install washers in each end of the hose and
attach the hose to the cradle and shower head.
Be careful not to over tighten.
5. Connect the water supply nipples to the water
supply lines.
6. Allow hot and cold water to run for one
minute each. Check for leaks, especially at the
connection to the supply lines and at both ends
of the pillars.
CARE AND MAINTENANCE
Minimum Maintenance is required to maintain product
finish. With proper maintenance your CHEVIOT Faucet
will continually look like new. Special care should be
taken when cleaning your faucet and the following
suggestions should help extend your faucet life.
a) Cleaning should be done regularly using a soft
cotton cloth and warm water, then towel dry.
b) Do not use cleaners that contain abrasives or harsh
chemicals; Care should be taken in selecting cleaning
supplies. Many cleaners contain detergents, ammonia,
or other corrosive solvents that could damage your
faucet finish.
c) occasionally clean with a non-abrasive wax polish.
Tel : (800)-444-5969
www.cheviotproducts.com
