Cherry G80-3816LWBGB-2 Product Data Sheet

CHERRY MX BOARD 1.0 BACKLIGHT

Models may vary from the image shown

The ideal keyboard for avid writers complete with MX
switches and palm rest

The CHERRY MX BOARD 1.0 BACKLIGHT – fast, precise,
proven CHERRY quality.
Durable CHERRY MX switches with consistent linear or
tactile operating feel and the support of the palm rest provide
comfort and ergonomics when working. High-speed key
recognition accurately captures every keystroke, even with
fast typing.
Sturdy mounting feet enable a perfect adjustment in 3 steps
with a non-slip grip. The adjustable, white key illumination
means the keys can be read clearly even in challenging
visibility conditions.
All inputs are reliably and precisely executed, and input
errors are prevented thanks to anti-ghosting and full n-key
rollover.
Frequent number inputs can be performed easily via the
numeric keypad; the switchable Win key lockout enables the
keyboard to be used for pleasure on the computer after work
as well.
The CHERRY MX BOARD 1.0 BACKLIGHT - the
high-performance keyboard for people who type quickly or
write a lot.

Key benefits

• Anti-ghosting - no inputting errors

• Corded keyboard with CHERRY MX switches and palm rest

• CHERRY MX technology - Gold Crosspoint precision
switches for all keys "Made in Germany"

• Uncompromisingly fast thanks to CHERRY MX and
high-speed key recognition

• Abrasion-resistant, laser-etched keycaps

• Full N-Key rollover - all keys are read simultaneously

• WIN key lockout

• Dimmable, white backlighting with several lighting modes

• Additional feet for non-slip grip and custom height adjustment
in 3 steps

• Illuminated USB plug and elegant logo application

Technical Data:

Layout (country or language):

Product dependant, see table "Models"

Housing colour:

black

Key colour:

black

Weight (product):

approx. 1165 g

Total weight (with packaging):

approx. 1510 g

Cable Length:

approx. 1.80 m

Storage Temperature:

-20°C to 60°C

Operating Temperature:

0°C to 50°C

Current Consumption:

max. 500 mA

Interface:

• USB

Product approvals:

• CE

• KCC

• WHQL

System requirements:

• USB connection

Delivery Volume:

• CHERRY MX BOARD 1.0 BACKLIGHT

• Wrist rest

• Operating instructions in hard copy

Dimensions (product):

approx. 470 x 165 x 25 mm (keyboard), approx. 470 x 95 x
25 mm (wrist rest)

Packaging dimensions:

approx. 520 x 200 x 48 mm

Keyboard:

• Key technology: Product dependant, see table "Models"

• Service life, standard key: > 50 million key operations

• Operation characteristics: Product dependant, see table
"Models"

• Inscription technology: Laser

• Inscription layout: Standard

• Number of Keys: 105+4

• Number of additional keys: 4

Packaging Unit:

• Number of products in the master package: 7

Warranty:

2 years
Errors, technical changes and delivery possibilities excepted.

Technical information refers only to the specifications of the
products. Features may differ from the information provided.

© Cherry GmbH • Cherrystraße • 91275 Auerbach/OPf. • Germany
Tel [phone] • Fax [phone] • [e-mail] • www.cherry.co.uk • 2018-11-20

1/3

Models:

(possible country/layout versions, others available on request)

Product name Order number EAN code Layout (country or

language)

1 MX BOARD 1.0 BACKLIGHT G80-3816LWBCH-2 4025112089923 Switzerland MX-Silent RED SWITCH SILENT

2 MX BOARD 1.0 BACKLIGHT G80-3816LWBDE-2 4025112089169 Germany MX-Silent RED SWITCH SILENT

3 MX BOARD 1.0 BACKLIGHT G80-3816LWBES-2 4025112089190 Spain MX-Silent RED SWITCH SILENT

4 MX BOARD 1.0 BACKLIGHT G80-3816LWBFR-2 4025112089176 France MX-Silent RED SWITCH SILENT

5 MX BOARD 1.0 BACKLIGHT G80-3816LWBGB-2 4025112089183 UK MX-Silent RED SWITCH SILENT

6 MX BOARD 1.0 BACKLIGHT G80-3816LWBPN-2 4025112089206 Pan-Nordic MX-Silent RED SWITCH SILENT

7 MX BOARD 1.0 BACKLIGHT G80-3816LXBCH-2 4025112089916 Switzerland MX BROWN SWITCH

8 MX BOARD 1.0 BACKLIGHT G80-3816LXBDE-2 4025112089077 Germany MX BROWN SWITCH

9 MX BOARD 1.0 BACKLIGHT G80-3816LXBES-2 4025112089107 Spain MX BROWN SWITCH

10 MX BOARD 1.0 BACKLIGHT G80-3816LXBFR-2 4025112089084 France MX BROWN SWITCH

11 MX BOARD 1.0 BACKLIGHT G80-3816LXBGB-2 4025112089091 UK MX BROWN SWITCH

12 MX BOARD 1.0 BACKLIGHT G80-3816LXBPN-2 4025112089114 Pan-Nordic MX BROWN SWITCH

Key technology Operation

characteristics ¹

Linear (45 cN)

Linear (45 cN)

Linear (45 cN)

Linear (45 cN)

Linear (45 cN)

Linear (45 cN)

Pressure point (55cN)

Pressure point (55cN)

Pressure point (55cN)

Pressure point (55cN)

Pressure point (55cN)

Pressure point (55cN)
