G 83-13000
User’s Manual
644-0223.00, UK, Februar 2001
1
1 General Advice............................................................................. 2
2 Introduction .................................................................................. 2
3 CyBo@rd...................................................................................... 3
3.1 Basic functions ........................................................................................ 3
3.1.1 Internet keys ............................................................................................................ 3
3.1.2 E-mail / Programs.................................................................................................... 4
3.1.3 Multimedia ............................................................................................................... 5
3.1.4 The Standby key...................................................................................................... 6
3.2 Individual functions of the special keys ................................................... 6
4 KeyMan ........................................................................................ 7
4.1 General information................................................................................. 7
4.2 Dialog box Keyboard Properties.............................................................. 7
4.3 Tab KeyMan ............................................................................................ 8
4.4 Tab Internet ............................................................................................. 9
4.5 Tab E-mail / Programs ............................................................................ 9
4.6 Tab Multimedia ...................................................................................... 10
4.7 Tab Standby / Power............................................................................. 10
4.8 Basic mechanisms for the configuration of special keys ....................... 11
4.8.1 User information .................................................................................................... 11
4.8.2 Configuring the launch of a predefined program ................................................... 11
4.8.3 Configuring the opening of a
file / document 12
4.8.4 Configuring the opening of a directory................................................................... 12
4.8.5 Configuring the calling up of an XPressList........................................................... 13
4.8.6 Configuring the calling up of an Internet page....................................................... 13
4.8.7 Configuring the basic functions of a key................................................................ 14
4.9 Dialog box Configure XPressList........................................................... 14
2
1 General Advice
Cherry’s continual developments ensure products that are fully optimised and as such
reserve the right to make any technical alterations. The establishment of reliability together
with the definition of technical performance
are made according to Cherry’s own requirements for meeting internationally recognised
standards. Requirements outside of these can
be reached through mutual co-operation.
Improper usage, handling, storage and external influences could lead to disturbances and
defects during use. We do not grant or warrant any alterations to our product by the user
in any capacity and do not accept any liability
for unauthorized modifications. All repairs
must be made by Cherry or an officially
appointed organisation or persons. To avoid
danger of explosion, the optional lithium battery may only be exchanged by an expert.
Possible compensation claims against Cherry
or it’s nominated officers whatever the legal
justification including physical or stress related injuries are not possible with the exception of negligence on our behalf, and
governing Product Liability Low.
These notices & operating instructions only
apply to the accompanying products. Further
details of this can be obtained from your local
Cherry dealer or directly from Cherry GmbH.
2 Introduction
The keyboard CyBo@rd fulfils all the
functions of a standard keyboard and is additionally equipped with 19 special function
keys. These keys assist you in the basic operation of Internet and multimedia programs as
well as with Power Management. Accordingly,
the special keys can be classified into the following function groups:
Internet keys
Multimedia keys
Program keys
Standby key
You can configure each of the special keys
individually with the help of the software
KeyMan (Cherry Keyboard Manager) and can
assign a different function offered by the software to the keys. The basic function of the key
is thereby deactivated, but it can be reactivated at any time.
3
The configuration of the special keys with
KeyMan is conducted in tabs within the dialog box Keyboard Properties, which is a
standard dialog box of Microsoft Windows.
3CyBo@rd
3.1 Basic functions
3.1.1 Internet keys
The Internet keys assist you in the operation
of an Internet browser.
If no browser is open, the Internet keys have
the following functions:
• If you press any Internet key, the standard
browser is launched with the preset start
page.
• If the Search key is pressed, the standard
browser is opened with activated Search
window.
• If the Favorites key is pressed, the standard browser is launched with activated
Favorites window.
Opening a further browser instance
If you want to open a second instance of the
browser with the help of the Internet keys, you
must use the key combination CTRL +
Search or CTRL + Start Page.
If a browser has been launched, the Internet
keys fulfil the following functions:
Key Basic function
Browses back to the previous
page.
Browses forward to the next
page.
Aborts the current transmission.
Updates the page opened.
4
To launch the Internet browser
> Press any Internet key.
The standard browser is opened.
To launch a further instance of the Internet
browser
1 Press the CTRL key and keep it pressed.
2 Press the special key or .
A new instance of the Internet browser is
opened.
3.1.2 E-mail / Programs
In their basic functions, the Program keys
open preset programs.
Opens or closes the standard
search function of the browser.
Opens or closes the Favorites
archive in the browser.
Calls up the Start Page of the
browser.
Key Basic function
Opens an XPressList displaying
the e-mail programs installed on
your computer. You can select
and launch a program from this
XPressList.
Key Basic function
To call up an e-mail program
When called up for the first time
When the key is pressed for the first time, the
dialog box Search Disk is opened, and the
local drives are searched for designated email programs. After searching is completed,
the dialog box Configure XPressList is opened. Here, you can save and configure the
programs found.
1 Press the special key .
A configured XPressList for the key is
opened.
2 Mark the desired program by clicking on it
with the left mouse button or by pressing
the key repeatedly.
3 Press the Enter key.
- OR -
KeyMan currently supports the
following e-mail programs:
• AOL Instant Messenger
• Lotus Notes R5
• Microsoft Exchange
• Microsoft Outlook
• Microsoft Outlook Express
• MSN Messenger Service
• Netscape Messenger
• QUALCOMM Eudora 5.0
Opens the folder My Computer
in the Windows Explorer.
Launches the Windows calculator.
Key Basic function
5
Double-click on the desired program.
The selected program is opened.
To open the My Computer folder
> Press the special key .
The Windows Explorer is opened with all
drives and directories of the My Computer
folder.
To call up the calculator
> Press the key.
The Windows calculator is opened.
3.1.3 Multimedia
The Multimedia keys assist you in the operation of multimedia programs.
KeyMan currently supports the following multimedia programs:
• Creative CD-Player
• Intervideo WinDVD V2.2
• Real Player 7 Basic
• Winamp V2.64
• Windows CD Player
• Windows Media Player
• Windows Media Player 2
• Windows Media Player 7
• XingMPEG Player V3.30
• Yahoo! Player
The processes triggered by the keys relate to
the multimedia program that is focussed on or
was most recently active.
If a multimedia program has already been
started but is inactive, and you press the
Media key, this program is activated.
The Multimedia keys fulfil the following basic
functions:
Key Basic function
Opens an XPressList of existing
multimedia programs, from which
you can make a selection.
When the XPressList is open,
the key directs the focus to the
next element in the XPressList.
Starts or aborts the current
media playback.
Pauses the media playback.
If you briefly press the key and
release it, it calls up the previous title. If the media player is
activated, the title is automatically played.
The following function is only
used with the KeyMan software
If the key is pressed for a longer
period, it activates scan previous.
If you briefly press the key and
release it, it calls up the next title.
If the media playback is activated, the title is automatically
played.
The following function is only
used with the KeyMan software
If the key is pressed for a longer period, it activates scan next.
Reduces the global volume. This
setting has an effect on all media
programs used on the PC.
6
To call up a multimedia program
When called up for the first time
When the key is pressed for the first time, the
dialog box Search Disk is opened, and the
local drives are searched for designated email programs. After searching is completed,
the dialog box Configure XPressList is ope-
ned. Here, you can save and configure the
programs found.
1 Press the key.
A configured XPressList for the media playback is opened.
2 Mark the desired program by clicking on it
with the left mouse button or by pressing
the key repeatedly.
3 Press the Enter key.
- OR -
Double-click on the desired program.
The selected program is opened.
3.1.4 The Standby key
The Standby key
If the Standby key is briefly pressed and
released, the PC switches into Standby Mode.
If the PC does not support the Standby Mode,
the key activates the screen saver that is cur-
Increases the global volume.
This setting has an effect on all
media programs used on the PC.
Switches the sound off or on. If
you switch the sound off and
then on again, the preset volume
remains unchanged.
Key Basic function
rently set.
3.2 Individual functions of the special
keys
You can individually assign selected functions
to all Internet, Multimedia and Program keys
as well as to the Standby key. The configuration of the keys is performed with KeyMan in
the various tabs in the dialog box Keyboard
Properties.
Instructions to configure the keys
Detailed instructions on the configuration of
the keys can be found in the description of the
basic mechanisms of KeyMan in Chapter 4.8.
Each Internet, Multimedia and Program key
can be assigned one of the following
functions:
The Standby key can be individually assigned the following functions:
Option Function of the key
Predefined program
Launches a program.
File/document Opens a file.
Directory Opens up a window dis-
playing the contents of a
directory in the Windows
Explorer.
XPressList Opens up an XPressList
with individually defined
programs, files, directories
and/or Internet pages, from
which you can make a selection.
Internet page Opens an Internet page.
7
If the Standby key is pressed for longer than
one second, KeyMan initiates a process whe-
reby your PC is powered down after a preset
time. You set this time, which is displayed
during the process as a countdown, in the dialog box Keyboard Properties in the tab
Power.
Automatic power-down of the PC
After the countdown has been completed, the
PC is powered down without your having to
confirm this process further.
Aborting the countdown
You can abort the countdown, if you press the
ESC key and release the Standby key before
the countdown is completed.
If you merely release the Standby key before
the countdown is completed, the function that
has been set with KeyMan is carried out.
Restoring the basic functions of the keys
You can reassign the basic function to each
key that you have individually configured.
Option Function of the key
Start screen
saver
Starts the screen saver
that is currently set.
Log off user Opens a dialog box in
which you are asked if you
wish to log off.
Call up Quit
Windows dialog
Opens the Quit Windows
dialog box.
4KeyMan
4.1 General information
Program elements of KeyMan on the screen
After the installation of the KeyMan software,
the symbol appears in the task bar. If you
double-click on this symbol, the dialog box
Keyboard Properties is opened. If you click
once on this symbol, a context menu is opened, which allows you to hide the symbol, call
up the Online Help or open the dialog box
Keyboard Properties.
Furthermore, the entry Cherry Keyboard
Manager appears under Start | Programs.
This entry opens a group that enables you to
call up the Online Help, open the dialog box
Keyboard Properties and to start or quit the
Cherry Keyboard Manager (KeyMan).
The function User Information
If you press one of the special keys, user
information appears at the lower right-hand
side of the screen. This user information tells
you which function is performed by the key.
4.2 Dialog box Keyboard Properties
The configuration of the special keys is conducted in tabs in the dialog box Keyboard
Properties, which is a standard dialog box of
Microsoft Windows.
To open the dialog box Keyboard
Properties
1 Double-click on the symbol in the task
bar.
The dialog box Keyboard Properties is
opened.
- OR -
8
Select Start | Programs | Cherry
Keyboard Manager | Settings.
The dialog box Keyboard Properties is
opened.
- OR -
Select Start | Settings | Control Panel.
The window Control Panel is opened.
2 Double-click on the symbol Keyboard.
The dialog box Keyboard Properties is
opened.
4.3 Tab KeyMan
In the tab KeyMan you can perform the following settings:
• You can determine whether a symbol for
the KeyMan software is to be displayed in
the task bar. With the help of this symbol
you can call up the dialog box Keyboard
Properties and perform the settings for the
KeyMan software.
• You can determine whether user information is to be displayed when one of the special keys is pressed.
• You can determine how long the user information is to be displayed on screen.
• You can initiate a search of the local drives
of your PC for e-mail programs supported
by KeyMan. All e-mail programs found are
displayed in a list. You can configure this
list in the dialog box Configure XPres-
sList.
• You can initiate a search of the local drives
of your PC for multimedia programs supported by KeyMan. All multimedia programs found are displayed in a list. You
can configure this list in the dialog box
Configure XPressList.
To determine that the KeyMan symbol is
displayed in the task bar
1 In the group Task Bar activate the control
box Display symbol in the task bar.
2 Click on the button Accept.
- OR -
Click on the button OK.
The setting is saved.
To determine that user information is
displayed when a special key is pressed
1 In the group User Information activate the
control box Display user information.
2 Set the Display duration in the spin box to
determine how long the user information is
displayed on screen after you have pressed a key.
3 Click on the button Adopt.
- OR -
Click on the button OK.
The setting is saved.
To search local drives for e-mail programs
During this search process, KeyMan can perform no other action. If you abort the process,
the dialog box Configure XPressList is opened, in which all the programs found up to that
point are listed.
1 In the group Applications click on the but-
ton E-mail.
The dialog box Search Disk is opened. As
soon as the process has ended, the dialog
box Configure XPressList appears. If the
programs supported by KeyMan have been
found, they are displayed in the list.
9
2 Configure the programs found.
- OR -
Click on the button OK.
The dialog box Configure XPressList is
closed. The tab KeyMan appears in the
foreground.
- OR -
Should you not wish to save the results of
the search procedure, click on the button
Cancel.
The dialog box Configure XPressList is
closed. If an XPressList had already been
drawn up prior to the search procedure, this
XPressList remains unchanged.
To search local drives for multimedia
programs
During this search process, KeyMan can perform no other action. If you abort the process,
the dialog box Configure XPressList is ope-
ned, in which all programs found up to that
point are listed.
1 In the group Applications click on the but-
ton Multimedia.
The dialog box Search Disk is opened. As
soon as the process has ended, the dialog
box Configure XPressList appears. If the
multimedia programs supported by KeyMan
have been found, they are displayed in the
list.
2 Configure the programs found.
- OR -
Click on the button OK.
The dialog box Configure XPressList is
closed. The tab KeyMan appears in the
foreground.
- OR -
Should you not wish to save the results of
the search procedure, click on the button
Cancel.
The dialog box Configure XPressList is
closed. If an XPressList had already been
drawn up prior to the search procedure, this
XPressList remains unchanged.
4.4 Tab Internet
In the tab Internet you can assign individual
functions to the special keys, which, in their
standard functions, assist you in the operation
of an Internet browser .
The individually configured keys can:
• launch a program;
• open a file;
• display a window with the contents of a
directory;
• call up an XPressList of individually configured programs, files, directories and/or
Internet pages, from which you can make a
selection;
• call up an Internet page.
Basic functions of a special key
When you assign an individual function to a
key, you overrule the basic function of this
key. If you wish to reimplement the basic
function of this key, you can restore it.
4.5 Tab E-mail / Programs
In the tab E-mail / Programs you can assign
individual functions to the special keys, which,
in their basic functions, open up an XPressList of predefined e-mail programs, the folder My Computer or the Windows calculator.
The individually configured keys can:
10
• launch a program;
• open a file;
• display a window with the contents of a
directory;
• call up an XPressList of individually configured programs, files, directories and/or
Internet pages, from which you can make a
selection;
• call up an Internet page.
Basic functions of a special key
When you assign an individual function to a
key, you overrule the basic function of this
key. If you wish to reimplement the basic
function of this key, you can restore it.
4.6 Tab Multimedia
In the tab Multimedia you can assign individual functions to the special keys, which, in
their standard functions, assist you in the operation of a media program.
The individually configured keys can:
• launch a program;
• open a file;
• display a window with the contents of a
directory;
• call up an XPressList of individually configured programs, files, directories and/or
Internet pages, from which you can make a
selection;
• call up an Internet page.
Basic functions of a special key
When you assign an individual function to a
key, you overrule the basic function of this
key. If you wish to reimplement the basic
function of this key, you can restore it.
4.7 Tab Standby / Power
In the tab Standby / Power you can perform
settings for the functions of the Standby key.
In its basic function, the Standby key switches the PC into the Standby Mode, assuming that the hardware of your PC and the
BIOS settings support the Standby Mode. The
PC consumes less power in this state.
In addition, you can determine that the key:
• activates the screen saver that is currently
set;
• opens a dialog box in which you can log off
from the PC system;
• opens the dialog box Quit Windows, in
which you can choose to power down the
PC.
To configure the Standby Mode
1 In the group Settings for Standby Key
activate the option Switch computer in
Standby Mode.
2 Click on the button Adopt.
- OR -
Click on the button OK.
The configuration of the key is saved.
To configure the calling up of the screen
saver
1 In the group Settings for Standby Key
activate the option Call up screen saver.
2 If you wish to select a screen saver, click on
the button Configure and select the desired screen saver from the dialog box Dis-
play Properties in the tab Screen Saver.
3 Click on the button Adopt.
- OR -
11
Click on the button OK.
The configuration of the key is saved.
To configure the function Log Off User
1 In the group Settings for Standby Key
activate the option Log off user.
2 Click on the button Adopt.
- OR -
Click on the button OK.
The configuration of the key is saved.
To configure the function Quit Windows
1 In the group Settings for Standby Key
activate the option Call up Quit Windows
dialog.
2 Click on the button Adopt.
- OR -
Click on the button OK.
The configuration of the key is saved.
4.8 Basic mechanisms for the configuration of special keys
4.8.1 User information
When you press a special key, user information appears at the lower right-hand side of the
screen. This user information tells you which
function is performed by the key.
In the dialog boxes Configure XPressList
and Settings you can register in the input field
User information the content that apppears
on pressing a special key.
In the tab KeyMan in the group User Information, you can determine whether and for how
long the user information is displayed.
4.8.2 Configuring the launch of a predefined program
You can link a special key with any particular
program. When you press the key, the program is started.
To configure the launch of a program
1 In the group Keys of the Function Block
activate the option of the key to which you
wish to assign a new function.
2 In the group Functionality activate the
option Predefined program.
3 Click on the button Configure.
The dialog box Settings is opened.
4 In the input field Object register the path of
the program which you wish to assign to the
key.
- OR -
Search for the program by clicking on the
button alongside the input field
Object.
5 If the program is launched with parameters,
register the corresponding parameters in
the input field Command line parameters.
6 In the input field User information register
a name for the new function of the key.
This name appears at the lower right-hand
side of the screen when you press the key.
7 Click on the button OK.
The dialog box Settings is closed, the dialog box Keyboard Properties moves into
the foreground.
8 Click on the button Adopt.
- OR -
Click on the button OK.
The configuration of the key is saved.
12
4.8.3 Configuring the opening of a
file / document
You can link a special key to a particular file.
When you press the key, the file is opened.
However, a program capable of opening the
file must be installed on your PC and this program must be linked with the file type.
To configure the opening of a file
1 In the group Keys of the Function Block
activate the option of the key to which you
wish to assign a new function.
2 In the group Functionality activate the
option File/document.
3 Click on the button Configure.
The dialog box Settings is opened.
4 In the input field Object register the path of
the file which you wish to assign to the key.
- OR -
Search for the program by clicking on the
button alongside the input field
Object.
5 In the input field User information register
a name for the new function of the key.
This name appears at the lower right-hand
side of the screen when you press the key.
6 Click on the button OK.
The dialog box Settings is closed; the dialog box Keyboard Properties moves into
the foreground.
7 Click on the button Adopt.
- OR -
Click on the button OK.
The configuration of the key is saved.
4.8.4 Configuring the opening of a directory
You can link a special key with any particular
directory in the Windows Explorer. When the
key is pressed, a window of the Windows
Explorer is opened in which all sub-directories
and/or files found in this directory are displayed.
To configure the opening of a directory
1 In the group Keys of the Function Block
activate the option of the key to which you
wish to assign a new function.
2 In the group Functionality activate the
option Directory.
3 Click on the button Configure.
The dialog box Settings is opened.
4 In the input field Object register the path of
the directory which you wish to assign to the
key.
- OR -
Search for the directory by clicking on the
button alongside the input field Object.
5 In the input field User information register
a name for the new function of the key.
This name always appears at the lower
right-hand side of the screen when you
press the key.
6 Click on the button OK.
The dialog box Settings is closed; the dialog box Keyboard Properties moves into
the foreground.
7 Click on the button Adopt.
- OR -
Click on the button OK.
The configuration of the key is saved.
13
4.8.5 Configuring the calling up of an
XPressList
You can link a special key with an XPressList.
When you press the key, the XPressList is
opened, and you can select one of the elements displayed.
An XPressList can contain one of the following elements
• Programs
•Files
• Directories
• Internet pages
If the XPressList only comprises a single element (program, file, directory or Internet
page), the XPressList is not opened, and the
function of the sole element is carried out
immediately.
To configure the calling up of an
XPressList
1 In the group Keys of the Function Block
activate the option of the key to which you
wish to assign a new function.
2 In the group Functionality activate the
option XPressList.
3 Click on the button Configure.
The dialog box Configure XPressList is
opened.
4 Draw up an XPressList of desired pro-
grams, files, directories and/or Internet
pages.
5 Click on the button OK.
The dialog box Configure XPressList is
closed; the dialog box Keyboard Proper-
ties moves into the foreground.
6 Click on the button Adopt.
- OR -
Click on the button OK.
The configuration of the key is saved.
4.8.6 Configuring the calling up of an
Internet page
You can link a special key with any particular
Internet page. When the key is pressed, the
Internet page is opened in your standard
browser.
To configure the calling up of an Internet
page
1 In the group Keys of the Function Block
activate the option of the key to which you
wish to assign a new function.
2 In the group Functionality activate the
option Internet page.
3 Click on the button Configure.
The dialog box Settings is opened.
4 In the input field Object register the address
of the Internet page that you wish to assign
to the key.
5 In the input field User information register
a name for the new function of the key.
This name appears at the lower right-hand
side of the screen when you press the key.
6 Click on the button OK.
The dialog box Settings is closed; the dialog box Keyboard Properties moves into
the foreground.
7 Click on the button Adopt.
- OR -
Click on the button OK.
The configuration of the key is saved.
14
4.8.7 Configuring the basic functions
of a key
You can reassign the basic functions to every
key that you have individually configured. The
key then fulfils the default functions that were
preset after the installation of KeyMan.
To configure the basic functions of a key
1 In the group Keys of the Function Block
activate the option of the key whose basic
function you wish to restore.
2 In the group Functionality activate the
option Basic function.
3 Click on the button Adopt.
- OR -
Click on the button OK.
The configuration of the key is saved.
4.9 Dialog box Configure XPressList
The dialog box Configure XPressList offers
you the following possibilities of configuring an
XPressList that has already been compiled:
• You can add elements to the XPressList.
• You can delete individual elements from
the XPressList.
• You can deactivate individual elements in
the XPressList or reactivate them. When
you deactivate an element, it remains part
of the XPressList but is not visible when the
XPressList is called up via a special key. It
can therefore not be selected.
• You can modify the order of the elements.
To add an element to an XPressList
1 In the group Add Element click on the but-
ton of the type an element of which you
wish to add to the XPressList.
The dialog box Settings is opened.
2 In the input field Object register the path of
the desired element.
- OR -
Search for the element by clicking on the
button alongside the field Object.
3 If you select a program that is launched with
parameters, register the parameters in the
input field Command line parameters.
4 In the input field User information register
a name for the element in the XPressList.
The element will appear in the XPressList
under this name.
5 Click on the button OK.
The dialog box Settings is closed; the dia-
log box Configure XPressList moves into
the foreground. The selected element
appears in the list.
6 In the input field User information register
a designation for the XPressList.
When you press the key to which the XPressList has been assigned, this designation
appears at the lower right-hand side of the
screen as user information.
7 Click on the button OK.
The dialog box Configure XPressList is
closed; the dialog box Keyboard Proper-
ties moves into the foreground.
8 Click on the button Adopt.
- OR -
Click on the button OK.
The XPressList is saved.
To deactivate an element in an XPressList
1 Click on the control box to the left of the list
element you wish to deactivate.
The tick of the selected element is deleted
from the control box.
15
2 Click on the button OK.
The dialog box Configure XPressList is
closed; the dialog box Keyboard Proper-
ties moves into the foreground.
3 Click on the button Adopt.
- OR -
Click on the button OK.
The XPressList is saved.
To deactivate all elements in an XPressList
1 In the group All Elements click on the but-
ton Deactivate.
The ticks of all elements are deleted from
the control boxes.
2 Click on the button OK.
The dialog box Configure XPressList is
closed; the dialog box Keyboard Proper-
ties moves into the foreground.
3 Click on the button Adopt.
- OR -
Click on the button OK.
The XPressList is saved.
To activate an element in an XPressList
1 Click on the control box to the left of the list
element you wish to activate.
A tick appears in the control box of the element.
2 Click on the button OK.
The dialog box Configure XPressList is
closed; the dialog box Keyboard Proper-
ties moves into the foreground.
3 Click on the button Adopt.
- OR -
Click on the button OK.
The XPressList is saved.
To activate all elements in an XPressList
1 In the group All Elements click on the but-
ton Activate.
Ticks appear in the control boxes of all elements.
2 Click on the button OK.
The dialog box Configure XPressList is
closed; the dialog box Keyboard Proper-
ties moves into the foreground.
3 Click on the button Adopt.
- OR -
Click on the button OK.
The XPressList is saved.
To delete an element from an XPressList
1 Mark the element you wish to delete.
2 In the group Selected Element click on the
button Delete.
3 Click on the button OK.
The dialog box Configure XPressList is
closed; the dialog box Keyboard Proper-
ties moves into the foreground.
4 Click on the button Adopt.
- OR -
Click on the button OK.
The selected element is deleted.
To rearrange the order of the elements
1 Mark the element in the XPressList that you
wish to move.
2 If you wish to move the element upwards,
click on the button .
- OR -
If you wish to move the element
downwards, click on the button .
16
3 Click on the button OK.
The dialog box Configure XPressList is
closed; the dialog box Keyboard Proper-
ties moves into the foreground.
4 Click on the button Adopt.
- OR -
Click on the button OK.
The XPressList is saved.
Loading...
