CHERRY B.UNLIMITED AES

Models may vary from the image shown

Secure data transmission and a reliable power supply

The wireless desktop set CHERRY B. UNLIMITED AES combines secure data transmission and an advanced energy supply in a design which has been thought through to the very last detail. For high professional requirements and security both at home and in the workplace.

Key benefits

• Data transmission using 128-bit encryption, complying to Advanced Encryption Standard (AES)

• USB cable charging function for both keyboard & mouse even when in use

• High-quality, pre-charged NiMH batteries from GP with a very low self-discharge

• Almost interference-free wireless 2.4 GHz technology (range of up to 10 metres)

• 3-button mouse: infrared sensor and adjustable resolution (1,000/2,000 dpi) with ergonomic side panels

• Multi-station capability operation of several wireless products in one room

• Easy to install, requiring no technical knowledge

• Mini USB receiver

• Keyboard awarded the "Blauer Engel" environmental seal

Technical Data:

Layout (country or language):

Product dependant, see table "Models"

Housing colour:

Product dependant, see table "Models"

Key colour:

Product dependant, see table "Models"

Weight (product):

approx. 883 g (keyboard with batteries), approx. 145 g (mouse with batteries), approx. 6 g (receiver)

Total weight (with packaging):

approx. 1304 g

Transmission range:

approx. 10 m

Frequency range:

2.400 GHz - 2.4835 GHz

Storage Temperature:

-20°C to 65°C

Operating Temperature:

0°C to 40°C

Current Consumption:

typ. 3 mA (keyboard), typ. 10 mA (mouse), typ. 30 mA (receiver)

Interface:

• USB

Connection sockets:

• Low voltage socket for USB charging cable

Product approvals:

• c-tick

• UL

• CE

• FCC

• TÜV/GS

System requirements:

• USB port for wireless receiver (second free USB port for using the charger cable during operation)

Delivery Volume:

• 1 signal receiver

• USB charger cable

• Operating instructions in hard copy

• 1 optical wireless mouse

• 1 wireless keyboard

• 2 LSD NiMH batteries (type AAA)

• 2 LSD NiMH batteries (type AA)

Dimensions (product):

approx. 460 x 165 x 15 mm (keyboard), approx. 115 x 60 x 35 mm (mouse), approx. 42 x 18 x 8 mm (receiver)

Packaging dimensions:

approx. 570 x 170 x 45 mm

Mouse:

• Scanning: Infrared

• Resolution: 1000 / 2000 dpi (adjustable)

• Number of Keys: 3

• Mouse wheel design: Scroll wheel with key function

• Design: Symmetrical

• Connection: wireless

• Housing colour: Product dependant, see table "Models"

• Key colour: Product dependant, see table "Models"

Keyboard:

• Key technology: SX

• Service life, standard key: > 10 million key operations

• Inscription layout: Standard

• Number of Keys: Product dependant, see table "Models"

Packaging Unit:

• Number of products in the master package: 6

• Number of master packages per pallet: 24

Warranty:

2 years

1/3

Errors, technical changes and delivery possibilities excepted. Technical information refers only to the specifications of the products. Features may differ from the information provided.
