Chengdu Ebyte Electronic Technology E70 User Manual
E70(915T30S)-User Manual-V1.0 Website: www.cdebyte.com/en
E70(915T30S)-User Manual-V1.0
Contents
1. Introduction
1.1 Feature
1.2. Electrical Parameter
2. UART functional description (default)
2.1 Fixed transmission
2.2 Broadcast transmission
2.3 Broadcast address
2.4 Monitoring address
3. Functional description
3.2 Connect to MCU
3.3 Reset
3.4 AUX description
4.Choose antenna
.............................................................................................................................
..............................................................................................................................
.........................................................................................................
...................................................................................
............................................................................................................
.....................................................................................................
.............................................................................................................
...........................................................................................................
............................................................................................................
...............................................................................................................
.................................................................................................................................
...............................................................................................................
......................................................................................................................
10
5. About us................................................................................................................................11
2
2
4
5
5
5
5
5
6
8
9
9
Page 1 of 11 Technical Support : support@cdebyte.com
E70(915T30S)-User Manual-V1.0 Website: www.cdebyte.com/en
1. Introduction
1.1 Feature
E70(915T30S) is wireless UART transceiver module based on the original CC1310 of TI, operating at
907~922.5MHz (Default: 915MHz), TTL level and 3.3V IO port.
The module has the function of data encryption & compression. The data of the module transmitted over
the features randomness. With the rigorous encryption & decryption, data interception becomes pointless.
The function of data compression decreases the transmission time & probability of being interfered, while
improving the reliability & transmission efficiency.
Page 2 of 11 Technical Support : support@cdebyte.com
E70(915T30S)-User Manual-V1.0 Website: www.cdebyte.com/en
No.
Usage
Description
1
Continuous transmission
In this mode, the data transmitting length is unlimited:
Perfectly realize continuous transmission for the highest baud rate
of 115200bps.
2
Fixed-length transmission
Air data rate, FEC and Encryption are configurable by users;
Transmitting data to the receiver in present air data rate with a most
effective way to realize low delay and high respond.
3
Consumption advantage
The receiving current is 14mA, and the stand by current is 4uA.
Battery-powered application is available.
4
WOR
Ultra-low power consumption, suitable for the battery-powered
application. When the module is on the power-saving mode, the
receiving response delay time of module can adjust the power
consumption.
5
Fixed transmission
Module can communicate with other modules which are work in
different channels and addresses, it is easy for networking and
repeater.
For example: module A transmits AA BB CC to module B (address:
0x00 01, channel: 0x80), HEX format is 00 01 80 AA BB CC (00 01
refers to the address of module B, 80 refers to the channel of
module B), then module B receives AA BB CC (only module B).
6
Broadcast transmission
Set the module address as 0xFFFF, then the module can
communicate with other modules in same channel.
7
FEC
It has the feature of FEC (Forward Error Correction）algorithm,with
high coding efficiency & good correction performance. In a sudden
interference, it can correct the interfered data packets proactively, so
that the reliability & transmission range are improved proactively.
Without FEC, those data packets can only be dropped.
8
Parameter saving
The parameter will be saved after users set the parameters and it
won’t be lost if powered-off. After module powered-on again, the
module will work as previous settings.
9
Ultra-small size
24 * 38.5mm, suitable for some application which has strict
limitation for the size.
10
Secondary development
All IO port lead out already for secondary development.
11
Customized Service
If the existing UART module cannot meet customers’
requirements, Ebyte accept customization of appropriate firmware.
Ebyte has provided customized wireless modules to tens of
well-known enterprises. Please contact us for more details.
12
Complete series
CC1310 has different size and packing, in which main difference is
the number of GPIO. Ebyte has completely developed CC1310,
including different size, frequency, power etc.
Page 3 of 11 Technical Support : support@cdebyte.com
E70(915T30S)-User Manual-V1.0 Website: www.cdebyte.com/en
No.
Parameter item
Parameter details
Description
1
Size
24 * 38.5mm
-
2
Weight
4.9g
Average weight
3
Frequency Band
Default: 915MHz
Frequency range: 907~922.5MHz, channel: 32
4
PCB
4-layer
Impedance-matching, lead-free and SMT
5
Connector
1.27mm spacing
SMD
6
Supply voltage
2.6 ~ 5.5V DC
5V is recommended
(Note: the voltage higher than 5.5V is forbidden)
7
Communication
level
Maximum 3.8V
3.3V is recommended
8
Operation Range
6000m
9
Transmitting
power
30dBm
Four optional level: 30, 27, 24, 17dBm
10
Air data rate
2.5kbps
Six optional level: 2.5, 5, 12, 28, 64, 168kbps
11
Standby current
4.0uA
Mode 3 (M0=1, M1=1, M2=1)
12
Transmitting
current
602mA@30dBm
≥1A (recommended)
(the voltage supply is 5V)
13
Receiving current
14mA
Mode 0, Mode 1, Mode 2 （5v power supply）
14
Communication
interface
UART
8N, 8E1, 8O1, eight kinds of UART baud rate, from
1200 to 115200 bps (default: 9600)
15
Driving mode
UART
Can be configured to push-pull/high pull, open-drain.
16
Transmitting
length
Depends on mode
Please refer to the transmission mode
17
Receiving length
Depends on mode
Please refer to the transmission mode
18
Address
65536
Easy for networking, broadcast and fixed transmission
19
WOR
Available
The minimum average power consumption is about
30uA (it fits for battery-powered applications)
20
RSSI
Available
It supports RSSI, refer to contents as follow
21
Antenna type
IPEX/Stamp hole
50Ω characteristic impedance
22
Operating
temperature
-40 ~ +85℃
-
23
Operating
humidity
10% ~ 90%
Relative humidity, no condensation
24
Storage
temperature
-40 ~ +125℃
-
25
Sensitivity
-110dBm@50kbps
Sensitivity has nothing to do with baud rate or timing
1.2. Electrical Parameter
Test condition: clear and open area& 30dBm, antenna
gain: 2dBi，height: 2m，air data rate: 2.5kbps
Page 4 of 11 Technical Support : support@cdebyte.com
