6-Port 6Gb/s Mini-SAS Backplane 80H10321711A0
User’s Manual
CHENBRO
6-Port 6Gb/s Mini-SAS Backplane
80H10321711A0
User’s Manual
w w w . c h e n b r o . c o m
September / 2010
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: info@chenbro.com.tw
1
6-Port 6Gb/s Mini-SAS Backplane 80H10321711A0
User’s Manual
Copyright
Copyright © 2010 Chenbro Micom Co., Ltd.. All rights reserved.
Unless otherwise indicated, all materials in this manual are copyrighted by Chenbro Micom Co., Ltd.. All rights
reserved. No part of this manual, either text or image may be used for any purpose other than internal use within
purchasing company. Therefore, reproduction, modification in any form or by any means, electronic, mechanical or
otherwise, for reasons other than internal use, is strictly prohibited without prior written permission.
Chenbro Micom Co., Ltd. reserves the right to make improvement and modification to the products indicated in this
manual at any time. Specifications are therefore subject to change without prior notice.
Information provided in this manual is intended to be accurate and reliable. However, Chenbro Micom Co., Ltd.,
assumes no responsibility for its use, nor for any infringements upon the rights of third parties, which may result from
its use.
Technical Support
Chenbro works hard to offer our customers maximum performance from our chassis. But in case you have
any problem with our product you can find supports from the following resources.
Web Support
Detail information of our products is in our website. You can find technical updates, installation guides, FAQs,
technical specifications and more. Our web address is: www.chenbro.com.
Email Support
You can also fill out the technical support form at our Technical Support page. Your technical issue inquiries will be
sent directly to our support professionals.
Phone Support
You can also contact Chenbro HQ or branch office for immediate support; contact Information is as following:
Chenbro HQ
Tel: 886-2-8226-5500 Tel: 31-40-295-2045 Tel: 1-909-947-3200
Chenbro Europe B.V.
Chenbro Micom (USA) Inc.
w w w . c h e n b r o . c o m
Fax: 886-2-8226-5423 Fax: 31-40-295-2044
Chenbro UK LTD Chenbro China Office
Tel: 44-(0)161-973-8152 Tel: 86 010-6709-1786
Fax: 44-(0)161-962-8653 Fax: 86 010-6709-1786
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: info@chenbro.com.tw
2
Fax : 1-909-947-4300
6-Port 6Gb/s Mini-SAS Backplane 80H10321711A0
User’s Manual
Contents
Copyright..................................................................................................................................... 2
Technical Support ...................................................................................................................... 2
Contents ...................................................................................................................................... 3
Safety Instruction ....................................................................................................................... 4
Revision History ........................................................................................................................ .4
6Gb/s Backplane Specification…………….……………..……………………………………….…..5
Accommodation Chassis………………………………………………………………………….……5
Backplane Layout ................................................................................................................... 6~9
Fabricate sequence……………………………………………………………………..………....10~12
w w w . c h e n b r o . c o m
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: info@chenbro.com.tw
3
6-Port 6Gb/s Mini-SAS Backplane 80H10321711A0
User’s Manual
Safety Instruction
CAUTION:
Informs the user of conditions that might result in damage to hardware, corruption of customer
data or application software, or long-term health hazard to people. A caution always precedes the
information to which it relates.
WARNING:
Alerts the user to conditions that might result in injury or death. A warning always
precedes the information to which it pertains.
Revision History
Date Modifications
September / 30 / 2010 First release
w w w . c h e n b r o . c o m
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: info@chenbro.com.tw
4
6-Port 6Gb/s Mini-SAS Backplane 80H10321711A0
User’s Manual
6Gb/s Backplane Specification
P/N: 80H10321711A0
Host Interface
HDD Interface SAS (15+7+7) and SATA-II (15+7)compatible with 3.5” HDD
Hot-Swap Hard drives can be replaced during the system on
Display
Cooling 3-pin fan connector x 4
Power Connector Standard +5V and +12V 4-pin power connector x 2
Other Connectors
2 x Mini-SAS interface (SFF-8087) for host side (w/lock housing), port
distribution should be “4+2”
LED indicates HDD status (Defined by Chenbro)
Power LED – Blue light (HDD is on)
Access LED –Green flash (HDD is working)
Error indicator – Red light (HDD is abnormal)
2-pin power alarm connector x 1
2-pin alarm mute connector x 1
6-dip function switch for monitoring fan and temp
2-dip SGPIO function switch
4-pin HDD fail connector x 2
7-pin function connector for fan fail LED / power mute LED / global mute
switch
Dimension 257.3 mm (Length) x 80.0 mm (Width) x 2.4 mm (Thickness)
Material FR4 6 layer
Accommodation Chassis
RM21706
w w w . c h e n b r o . c o m
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: info@chenbro.com.tw
5
6-Port 6Gb/s Mini-SAS Backplane 80H10321711A0
User’s Manual
Backplane Layout
Backplane Connectors
Front View
Rear View
[LD011 / LD021 / LD031 / LD041 / LD051 / LD061] : “Blue lights on” indicated hard drive is power on.
(1)
(2) [LD012 / LD022 / LD032 / LD042 / LD052 / LD062] :
“Green lights flash” indicated hard drive is working.
w w w . c h e n b r o . c o m
“Red lights on” indicated hard drive is abnormal or malfunction.
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: info@chenbro.com.tw
6
6-Port 6Gb/s Mini-SAS Backplane 80H10321711A0
User’s Manual
(3) [JF1 / JF2 / JF3 / JF4] : Fan connector (3pin)
Pin Number
1 GND
2 12V
(4) [CN01 / CN02] : Power connector (+5V and +12V 4pin)
3 FAN Clock Input
Pin Number Descriptions
1 12V
2 GND
3 GND
(5)
[J15] : Alarm mute connector (To redundant power supply)
4 5V
Descriptions
(6) [J14] : Power supply abnormal alarm connector (From redundant power supply)
(7)
[CN03 / CN6] : Reserved for Chenbro use only.
[SW1] : Fan and Temp function switch.
(8)
Pin Number Monitor On Off
1 Fan1 Enable Disable
w w w . c h e n b r o . c o m
2 Fan2 Enable Disable
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: info@chenbro.com.tw
3 Fan3 Enable Disable
4 Fan4 Enable Disable
5 TEMP 65 degC 55 degC
6 NC NC
7
6-Port 6Gb/s Mini-SAS Backplane 80H10321711A0
User’s Manual
(9) [SW2] : SGPIO function switch.
(10)
[J4 / J7] : HDD fail connector (From raid card)
Pin Number SGPIO On Off
1 SGPIO Active
2 SGPIO Fail Enable Disable
Enable Disable
Pin
Define HDD 4 HDD 3 HDD 2 HDD 1
[J12] : Connector of fan fail LED & Power temp fail LED & Global mute switch
(11)
(12) [CN011 / CN021 / CN031 / CN041 / CN051 / CN061] :
Pin
Define
Pin
Defin
e
Pin 5 6 7 8
Defin
e
4 3
8 7
N/A N/A HDD 6 HDD 5
1 2
FAN FAIL
LED +
GLOBAL
MUTE
SWITCH +
FAN FAIL
LED -
GLOBAL
MUTE
SWITCH -
2 1
6
POWER / TEMP
FAIL LED +
5
3 4
GND Key pin
POWER / TEMP
FAIL LED -
To connect with hard drives (22-pin SATA-II or 29-pin SAS).
The CN011 & CN021 & CN031 & CN041 are controlled by MiniSAS CN1.
The CN051 & CN061 are controlled by MiniSAS CN2.
w w w . c h e n b r o . c o m
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: info@chenbro.com.tw
8
6-Port 6Gb/s Mini-SAS Backplane 80H10321711A0
User’s Manual
Pin
Descriptions
NO.
Pin
Descriptions
NO.
S1 GND P1 NC
S2 RP P2 NC
S3 RN P3 NC
S4 GND P4 GND
S5 TN P5 POWER ENABLE
S6 TP P6 GND
S7 GND P7 5V PRE-CHARGE
S8 NC P8 5V
S9 NC P9 5V
S10
S11
S12
S13
S14
NC P10
NC P11
NC P12
NC P13
NC P14
GND
ACCESS SIGNAL
GND
12V PRE-CHARGE
12V
P15
12V
w w w . c h e n b r o . c o m
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: info@chenbro.com.tw
9
6-Port 6Gb/s Mini-SAS Backplane 80H10321711A0
User’s Manual
Fabricate sequence
1. Screw the backplane with the bracket.
CN1
CN2
Note: HDD grouping definition responds to above blue mark
2. Screw the backplane bracket with the hard drive cage.
w w w . c h e n b r o . c o m
The front LED board is connected with the fan fail LED & power temp LED & global mute
3.
switch to backplane.
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: info@chenbro.com.tw
[J12]
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
10
6-Port 6Gb/s Mini-SAS Backplane 80H10321711A0
User’s Manual
The middle fans and power are connected to the header on backplane.
4.
& CN01 / CN02]
[ JF1 / JF2 /JF3 / JF4
w w w . c h e n b r o . c o m
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: info@chenbro.com.tw
11
6-Port 6Gb/s Mini-SAS Backplane 80H10321711A0
User’s Manual
5.
The Mini-SAS connectors are connected with the Mini-SAS cables.
[CN1 / CN2]
w w w . c h e n b r o . c o m
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: info@chenbro.com.tw
12
