Chenbro PC71968 User Manual

Capable in a Small Footprint!

!

PC719 Series

www.chenbro.com

PC719 Series

Front Bezel Options

PC71968

PC71931

(Exclusive in UK)

PC71937

(Exclusive in UK)

Front Control : System Reset (Bezel Dependant), IEEE 1394 (Option)

PC719

Optional card reader Slim ODD, Slim FDD,

Removable drive cage Side (bottom)

internal 3.5” bays

1 x bottom 60 mm fan

Optional TFX PSU

Micro ATX Slim Desktop/Tower Chassis

Rear View Inside View Front View

Features & Benefits Specification

•

Support Intel Sandy Bridge platform thermal requirement

•

Support 60mm side(bottom) fan installation and air duct

• Removable drive cage for easy HDD installation
Pre-punched motherboard stand-off for quick installation

•

• Adjustable air duct for different CPU locations

• Built-in washable air filter

• Security provision:

Padlock loop, Kensington slot and intrusion switch

24 25

Model Name

M/B Form Factor

Dimension (D×W×H)

Drive Bay

PSU Form Factor

Indicator

Front Control

System Security

Cooling Fan

Slot Opening

Sheet Metal Material

Metal Thickness

Container Info.

• PC719

• Micro ATX

• 300mm x 90mm x 326mm, 11.8" x 3.5" x 12.8"

• External: Slim ODD x 1, Slim FDD x 0 or 1 (Bezel Dependant)

• Internal: 3.5" x 1

• Card Reader: Optional MS/PRO/CF/MD/SD/MMC/SM x 1

• TFX

• Power Status x 1, HDD Activity x 1

• Power On/Off, USB 2.0 x 2, Audio x 2,

System Reset x 1, IEEE 1394 x 1

• Kensington Slot, Padlock Loop, Optional Intrusion Switch

• Side: 60mm x 1

• Low Prole x 4

• SECC

• 0.6mm

• 20': 1,150, 40': 2,400, 40'H: 2,670
