Rosin Flux Dispensing Pen
Flux Type Rosin, Grade WW
ANSI/IPC J-STD-004, Type ROL0
Flash Point (TCC) 54 °F (12 °C)
Vapor Density (air=1) > 1
Appearance Yellow Liquid
Odor Alcohol
No Clean Flux Dispensing Pen
Flux Type Rosin, Grade WW
ANSI/IPC J-STD-004, Type ROL0
Flash Point (TCC) 54 °F (12 °C)
Vapor Density (air=1) > 1
Appearance Slightly Yellow Liquid
Odor Alcohol
Shelf life 5 years
RoHS Compliant
CHEMTRONICS
TDS # CW8000
Technical Data Sheet
CircuitWorks
PRODUCT DESCRIPTION
CircuitWorks Flux D ispensing P ens ar e d esigned
specifically to a pply each type of flux with precision
control. T he R osin F lux D ispensing P en qui ckly
applies a nonc orrosive t ype R f lux. T his flux m eets
MIL-F-14256 E a nd F. T he N o C lean Flux
Dispensing P en p recisely ap plies a p atented
noncorrosive, halide free, organic low s olid no clean
flux. This flux meets Bellcore TR-NWT-000078 and
IPC SF-818 for surface insulation resistance.
Marker pen dispenser provides controlled
and exact application
Minimize excess flux waste
Completely portable package
All fluxes are noncorrosive and halide free
Excellent material compatibility
Fast drying
TYPICAL APPLICATIONS
CircuitWorks Flux Dispensing Pens precisely
dispense flux on:
Printed Circuit Boards
Chip Carriers
Heat Sinks
Surface Mount Device Pads
Switches
Sockets
Flux Dispensing Pens
TYPICAL PRODUCT DATA AND
PHYSICAL PROPERTIES
COMPATIBILITY
CircuitWorks Flux D ispensing P ens ar e generally
compatible with most materials used in the electronics
industry. A s w ith a ny cleaning agent, m aterial
compatibility should be determined on a non-critical
area prior to use.
USAGE INSTRUCTIONS
For industrial use only.
Read MSDS carefully prior to use.
Hold pe n ve rtically a nd br iefly d epress t ip t o start
liquid f low. R ub pe n tip on s urface t o be f luxed.
Wipe t ip on a C ontrolWipe dry w ipe t o r emove
buildup. Flux can be removed with Flux-Off® Rosin,
or No Clean Plus.
CAUTION: Product is Flammable - Do not use near
sources of ignition and energized equipment.
AVAILABILITY
CW8100 9 gm (0.32 oz) No Clean Flux Pen
CW8200 9 gm (0.32 oz) Rosin Flux Pen
TECHNICAL & APPLICATION
ASSISTANCE
Chemtronics provides a t echnical hot line t o a nswer
your technical and application related questions. The
toll free number is: 1-800-TECH-401.
NOTE: This i nformation is believed t o be accurate.
It is in tended for p rofessional e nd us ers h aving t he
skills to evaluate and use the data properly.
CHEMTRONICS does not guarantee t he ac curacy of
the da ta a nd a ssumes no l iability i n c onnection w ith
damages incurred while using it.
Chemtronics, Flux-Off and CircuitWorks are registered
trademarks of Chemtronics. All rights reserved.
ControlWipes is a trademark of Chemtronics. All rights
reserved.
