USA
FAMILY SIZE DEEP FRYER
USER GUIDE
®
Now that you have purchased a Chefman® product you
can rest assured in the knowledge that as well as your
1-year parts and labor warranty you have the added
peace of mind of dedicated helplines and web support.
AFTER SALES SUPPORT
888-315-8407
customerwarranty@rjbrands.com
MODEL: RJ07-3SS-T
READ ALL INSTRUCTIONS BEFORE USE
For your safety and continued enjoyment of this product, always read the instruction manual before using.
USA
AFTER SALES SUPPORT
888-315-8407 customerwarranty@rjbrands.com MODEL: RJ07-3SS-T
Contents
1 Introduction
2 Safety Instructions
5 Features
6 Operating Instructions
10 Cleaning and Maintenance
11 Terms and Conditions
12 Warranty Card
USA
AFTER SALES SUPPORT
888-315-8407 customerwarranty@rjbrands.com MODEL: RJ07-3SS-T
Introduction
Congratulations!
You have made an excellent choice with the purchase of this quality Chefman®
product. By doing so you now have the assurance and peace of mind which comes
from purchasing a product that has been manufactured to the highest standards
of performance and safety, supported by the high quality standards of Chefman® .
We want you to be completely satisfied with your purchase so this Chefman®
product is backed by a comprehensive manufacturer’s 1-year warranty and an
outstanding after sales service through our dedicated Helpline.
We hope you will enjoy using your purchase for many years to come.
If you require technical support or in the unlikely event that your purchase is
faulty please telephone our Helpline for immediate assistance. Faulty product
claims made within the 1-year warranty period will be repaired or replaced free of
charge provided that you have satisfactory proof of purchase (keep your receipt).
This guarantee is in addition to your statutory rights. Your statutory rights are
not affected. This limited warranty does not apply in cases of damage caused by
accident, improper use, abuse and force majeure.
This limited warranty will be invalidated if the appliance is tampered with in any way
whatsoever. In case of questions or technical problems please call the following
toll-free help line number: 888-315-8407, Monday – Friday 9am to 5pm EST.
If the appliance has to be returned to us, it must be packed correctly as we cannot
accept any responsibility for damage caused in transit.
1
USA
AFTER SALES SUPPORT
888-315-8407 customerwarranty@rjbrands.com MODEL: RJ07-3SS-TMODEL: RJ07-3SS-T
SAFETY INSTRUCTIONS
IMPORTANT SAFEGUARDS
READ ALL INSTRUCTIONS.
THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY.
WARNING: When using electrical appliances especially when children are present,
basic safety precautions should always be followed to reduce the risk of fire,
electric shock, and/or injury to persons, including the following:
1. Before use, check that the voltage power corresponds to the one shown on the
appliance nameplate.
2. Only connect the appliance to electrical sockets which have a minimum load
of 15A. If the sockets and the plug on the appliance should prove incompatible,
get a professionally qualified technician to replace the socket with a more
suitable one.
3. Do not touch hot surfaces. Use handles or knobs.
4. To protect against electrical shock, do not immerse the temperature controller,
power cord or power plug in water or in any other liquid.
5. Close adult supervision is necessary when any appliance is used by or near
children. Never leave unattended.
6. Unplug the appliance from the outlet when not in use and before cleaning.
Allow appliance to cool before putting on or taking off parts and before cleaning
appliance.
7. Do not operate any electrical appliance with a damaged power cord or power
plug or operate it after the appliance malfunctions, or has been dropped or
damaged in any manner. Return this appliance to nearest authorized service
facility for examination, repair or adjustment.
8. The use of accessory attachments not recommended by the appliance
manufacturer may result in fire, electrical shock or injury to persons.
9. Do not use outdoors or for commercial purposes.
10. Do not let cord hang over edge of table or counter, or allow it to come into
contact with hot surfaces including stove.
11. Do not place appliance on or near a hot gas or electric burner, or in a heated
oven or microwave.
12. Use extreme caution when moving the fryer containing hot oil or any other hot
liquid.
2
USA
AFTER SALES SUPPORT
888-315-8407 customerwarranty@rjbrands.com MODEL: RJ07-3SS-T
SAFETY INSTRUCTIONS (cont'd)
13. Always attach the plug to the appliance first, and then plug cord into the wall outlet.
To disconnect, turn temperature control knob to the "O" position, then remove plug
from the wall outlet.
14. Do not use the appliance for other than its intended use.
15. Be sure handles are properly assembled to fryer basket and locked in place.
16. Place the appliance on a hard, flat level surface to avoid interruption of airflow
underneath the fryer.
17. To ensure safe operation, oversized foods must not be inserted into the appliance.
18. Ensure that the lid and tank are completely dry after washing and before use.
19. Never immerse the fryer basket into the hot oil - or drain it - without the fryer
lid in place.
20. The oil level must always be between the Min. and Max. markings.
21. Do not overload the basket. For safety reasons never exceed the maximum quantity.
22. Never operate your fryer without any oil or fat.
23. The cooking times are given as guidelines only.
24. The oil must be filtered regularly and changed after 8 to 12 uses.
25. Do not mix different types of fat or oils.
26. If you use solid vegetable shortening, cut it into pieces and melt it over low heat in
a separate pot beforehand, then slowly pour it into the deep fryer pot. Never pour
shortening directly into the deep fryer pot or basket, as this will lead to deterioration
of the appliance.
27. Never remove the pot while the deep fryer is on.
Warning: This appliance has a polarized plug (one blade is wider than the other). To reduce
the risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If
the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician. Do not attempt to modify the plug in any way.
SHORT CORD INSTRUCTIONS
A short power supply cord is provided to reduce the hazards resulting from
entanglement or tripping over a longer cord. Longer detachable power-supply cords
or extension cords are available and may be used if care is exercised in their use. If a
longer detachable power-supply extension cord is used:
1. The marked electrical rating of the cord set or extension cord should be at least as
SAVE THESE INSTRUCTIONS
3
USA
AFTER SALES SUPPORT
888-315-8407 customerwarranty@rjbrands.com MODEL: RJ07-3SS-TMODEL: RJ07-3SS-T
SAFETY INSTRUCTIONS (cont'd)
great as the electrical rating of the appliance, and:
2. The cord should be arranged so that it will not drape over the countertop or
tabletop where it can be pulled on by children or tripped over unintentionally.
LINE CORD SAFETY TIPS
1. Never pull or yank on cord or the appliance.
2. To insert plug, grasp it firmly and guide it into outlet.
3. To disconnect appliance, grasp plug and remove it from outlet.
4. Before each use, inspect the line cord for cuts and/or abrasion marks. If any
are found, this indicates that the appliance should be serviced and the line cord
replaced. Please return it to an authorized service representative.
5. Never wrap the cord tightly around the appliance, as this could place undue
stress on the cord where it enters the appliance and cause it to fray and break.
DO NOT OPERATE APPLIANCE IF THE LINE CORD SHOWS ANY DAMAGE OR
IF APPLIANCE WORKS INTERMITTENTLY OR STOPS WORKING ENTIRELY.
CAUTION: To ensure continued protection against risk of electric shock, connect to
properly grounded outlets only.
IMPORTANT: During the first few minutes of initial use, you may notice smoke and/
or a slight odor. This is normal and should quickly disappear. It will not recur after
appliance has been used a few more times.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
4
USA
AFTER SALES SUPPORT
888-315-8407 customerwarranty@rjbrands.com MODEL: RJ07-3SS-T
Features
1
4
2
5
3
6
7
8
9
10
1. Basket Handle with Raising and
Lowering Positions
2. Temperature Control Knob
3. Removable Control Unit with Heating
Element
4. Power and Ready Indicator Lights
5. Timer Control Knob
6. Removable Dishwasher-safe Bowl
7. Frying Basket
8. Lid
9. Permanent Aluminum Filter
10. Handle
11. Viewing Window
5
11
USA
AFTER SALES SUPPORT
888-315-8407 customerwarranty@rjbrands.com MODEL: RJ07-3SS-TMODEL: RJ07-3SS-T
Operating Instructions
WARNING:
• Indoor, countertop use only
• Extreme caution must be used when moving fryer containing hot oil
• Be sure handles are properly assembled to basket and locked in place. See
detailed assembly instructions below
• Follow all instructions for removal of moisture/ice and thawing before cooking
• Always cook with lid in closed position, except when frying French fries and high
moisture food. Ensure both the lid and unit are completely dry after washing
and before use
ASSEMBLING THE FRYER BASKETS HANDLES
1. Squeeze handle prongs together and slip the handle prong wings through
the handle prong wing slots.
2. Pull handle back toward you squeezing and rotating slightly from one side to
the other to lock the handle prongs into place.
Note: To remove handle for cleaning and storage simply reverse the process.
CAUTION: ALWAYS CHECK BASKET HANDLES TO ENSURE THAT THE HANDLES
ARE SECURED BEFORE COOKING WITH HOT OIL. THIS WILL HELP PREVENT
AGAINST PERSONAL INJURY.
Handle
Prongs
Handle
Prongs
Wings
Handle
Prongs
Wings
Slots
6
USA
AFTER SALES SUPPORT
888-315-8407 customerwarranty@rjbrands.com
Operating Instructions (cont'd)
USING YOUR DEEP FRYER FOR THE FIRST TIME
1. Remove the lid and clean it with a damp cloth. Dry thoroughly.
2. Remove the basket, the control unit and the bowl
3. Clean the frying basket and the bowl with a sponge and soapy water or
put them in the dishwasher.
4. Clean the control unit and the heating element with a damp cloth.
5. Dry all components thoroughly.
6. Place the bowl and the heating element in position
NOTE:
• Do not immerse the removable control unit with the heating element
in water.
• Never wash the lid in the dishwasher.
• Make sure that the control unit is correctly positioned, otherwise the
fryer cannot function.
HOW TO USE YOUR DEEP FRYER
1. Fill the bowl with oil.
2. The oil level should always be between the MIN and MAX level of the
bowl. Do not exceed the maximum fill line as boiling oil may overflow
during frying and can cause severe burns.
3. For best results, we recommend vegetable oil.
4. If you use solid vegetable shortening, cut it into small pieces and melt it
in a separate pan. Pour the melted shortening into the fryer bowl.
5. Never melt the shortening on the heating element or in the frying
basket
6. After the bowl has been filled with oil, put the lid on the fryer and plug
in the appliance without the frying basket. The power indicator light will
turn on. Turn the temperature control knob to the desired temperature,
set timer to desired time and the fryer will begin to heat.
7. When loading the basket be sure to remove excess water, ice or frost
from food.
8. Fill the basket before placing it in the deep fryer. Do not overfill the
basket.
9. Reduce the quantities for frozen foods.
7
MODEL: RJ07-3SS-T
Operating Instructions (cont'd)
10. When the oil reaches your desired temperature, lower the basket into
the oil.
11. At the end of cooking time, switch off the fryer by turning both control
knobs to the "0" position. Lift the handle up to raise the basket until it is
fully above the oil. Allow excess oil to drain by letting the basket remain on
the hook for a moment.
12. Remove the lid and the basket, and serve the food.
13. Put the lid on the fryer when it is not in use.
14. To use a second time, correct the oil level if necessary, then follow the
instructions from the beginning.
15. When you have finished frying, unplug the deep fryer.
16. Allow the oil to cool completely in the fryer (approx. 3 hours).
17. Only move the fryer using the carrying handles.
NOTE:
• Never use different types of oil at the same time, as this may cause the oil
to overflow.
• The oil level must always be kept between the min/max markers. Check
the level each time before frying, and add some of the same type of oil if
necessary.
TABLE OF OIL/SOLID VEGETABLE FAT LEVELS
LITERS OIL SOLID VEGETABLE FAT
3 L
4 L
AFTER SALES SUPPORT
Minimum 10 CUPS / 2.5L 4.95 lb / 2250 g
Maximum 12 CUPS / 3L 5.95 lb / 2700 g
Minimum 14 CUPS / 3.5L 6.95 lb / 3150 g
Maximum 16 CUPS / 4L 7.95 lb / 3600 g
8
USA
888-315-8407 customerwarranty@rjbrands.com MODEL: RJ07-3SS-T
USA
AFTER SALES SUPPORT
888-315-8407 customerwarranty@rjbrands.com MODEL: RJ07-3SS-T
Operating Instructions (cont'd)
TABLE OF COOKING TIMES
The following cooking times are a guide only. They may vary depending on the size
of the food, the amount of food, individual preferences, and the voltage. Cooking
Tip: To prevent food from sticking together, do not use the basket when cooking
battered foods or doughnuts.
FRESH FOOD
French fries* (maximum capacity 3L)
French fries* (maximum capacity 4L)
QUANTITY TEMP TIME
800 g / 10 cups /1.8 lb
1 kg / 12 cups /2.2 lb
French fries (optimal quantity 3L) 400 g / 5 cups /0.9 lb
French fries (optimal quantity 4L) 500 g / 6 cups /1.1 lb
Fried chicken (leg portion)
4 pieces
Fried mushrooms 300 g / 3.5 cups /0.7 lb
Onion rings 300 g / 3.5 cups /0.7 lb
Breaded fish fillets 2 pieces
Fried calamari 500 g / 6 cups /1.1 lb
Fried shrimp 500 g / 6 cups /1.1 lb
Apple fritters 4 pieces
* in 2 cycles
FROZEN FOOD
French fries (maximum capacity 3L)
French fries (maximum capacity 4L)
QUANTITY TEMP TIME
600 g / 7 cups /1.3 lb
750 g / 9 cups /1.65 lb
French fries (optimal quantity 3L) 300 g / 3.5 cups /0.7 lb
French fries (optimal quantity 4L) 375 g / 4.5 cups /0.8 lb
Fried chicken (leg portion)
Chicken nuggets (3L)
4 pieces
1 kg / 12 cups /2.2 lb
Chicken nuggets (4L) 1.2 kg / 14 cups /2.6 lb
Fried mushrooms
300 g / 3.5 cups /0.7 lb
Onion rings 300 g / 3.5 cups /0.7 lb
Battered cod filets 2 pieces
Fish fingers 5 pieces
Fried calamari 500 g / 6 cups /1.1 lb
Fried shrimp 500 g / 6 cups /1.1 lb
170ºC/340ºF
170ºC/340ºF
170ºC/340ºF
170ºC/340ºF
190ºC/375ºF +/- 5-8 min.
190ºC/375ºF +/- 8-10 min.
180ºC/356ºF +/- 15-17 min.
150ºC/302ºF +/- 6-8 min.
170ºC/340ºF +/- 4-5 min.
170ºC/340ºF +/- 6-8 min.
170ºC/340ºF +/- 5-6 min.
170ºC/340ºF +/- 5-6 min.
170ºC/340ºF +/- 5-6 min.
190ºC/375ºF +/- 8-10 min
190ºC/375ºF +/- 10-12 min
190ºC/375ºF +/- 5-7 min.
190ºC/375ºF +/- 5-7 min.
190ºC/375ºF +/- 14-15 min.
190ºC/375ºF +/- 6-9 min.
190ºC/375ºF +/- 6-9 min.
190ºC/375ºF +/- 5-6 min.
190ºC/375ºF +/- 3-5 min.
190ºC/375ºF +/- 6-7 min.
190ºC/375ºF +/- 5-7 min.
190ºC/375ºF +/- 4-5 min.
190ºC/375ºF +/- 4-5 min.
+/- 8-1 0min.
+/- 6-8 min.
+/- 9-11 min.
+/- 7-9 min.
9
USA
AFTER SALES SUPPORT
888-315-8407 customerwarranty@rjbrands.com MODEL: RJ07-3SS-TMODEL: RJ07-3SS-T
Cleaning and Maintenance
1. You may store the oil or fat in the fryer or in a separate airtight container.
2. Do not pour used oil into the sink. Leave it to cool and throw it away with
the household waste – according to the local community regulations.
3. Crumbs that break away from food tend to burn and alter the quality of the
oil more rapidly. Over time, this increases the risk of the oil’s catching fire.
For this reason, filter the oil regularly.
NOTE: We recommend changing the oil after a maximum of 8 to 12 uses.
CLEANING YOUR FRYER
1. Remove the control unit and heating element and clean both parts with a
damp cloth or sponge.
2. Clean the lid using a sponge and soapy water. Rinse and dry carefully.
3. The bowl and the frying basket are dishwasher safe or can be immersed in
soapy water.
4. Ensure that all components are dry before placing them back inside the
fryer.
5. The lid is fitted with a permanent metallic filter. This filter does not need to
be replaced.
NOTE:
• Never immerse the control unit with the heating element in water and never
wash it under running water.
• Never wash the lid in the dishwasher.
• Do not store your deep fryer outside.
10
USA
AFTER SALES SUPPORT
888-315-8407 customerwarranty@rjbrands.com MODEL: RJ07-3SS-T
Terms and Conditions
CHEFMAN LLC warrants, subject to the conditions stated below, that from the date of purchase, this product will
be free from mechanical defects for a period of ONE (1) year. CHEFMAN LLC, at its option, will repair or replace
this product found to be defective during the warranty period. Should this product become defective by reason
of improper workmanship or material defect during the specified warranty period, CHEFMAN LLC will repair or
replace the same effecting all necessary parts replacements for a period of three years from the date of purchase.
Transportation charges on parts, or products in whole, submitted for repair or replacement, under this warranty,
must be borne by the purchaser.
This warranty is available to consumers only. You are a consumer if you own a CHEFMAN® FAMILY SIZE DEEP
FRYER that was purchased at retail for personal, family or household use. Except as otherwise required under
applicable law, this warranty is not available to retailers or other commercial purchasers or owners.
CONDITIONS: This warranty is valid for the original USA retail purchaser from the date of initial retail purchase
and is not transferable. Keep the original sales receipt. Proof of purchase is required to obtain warranty service or
replacement. Dealers, service centers, or retail stores do not have the right to alter, modify or in any way, change the
terms and conditions of this warranty. Warranty registration is not necessary to obtain warranty on CHEFMAN LLC
Products. Save your proof of purchase receipt.
ABOUT YOUR PRODUCT WARRANTY: Most warranty repairs are handled routinely, but sometimes requests for
warranty service may not be appropriate. For example, warranty service would NOT apply if the product damage
occurred because of misuse, lack of routine maintenance, shipping, handling, warehousing or improper installation.
Similarly, the warranty is void if the manufacturing date or the serial number on the product has been removed or
the equipment has been altered or modified. During the warranty period, the authorized service dealer, at its option,
will repair or replace any part that, upon examination, is found to be defective under normal use and service.
NORMAL WEAR: This warranty does not cover normal wear of parts or damage resulting from any of the following:
negligent use or misuse of the product; improper voltage or current; use contrary to the operation instructions;
deviation from instructions regarding storage and transportation; repair or alteration by anyone other than
CHEFMAN LLC or an authorized service center. Further, the warranty does not cover Acts of God, such as fire,
flood, hurricanes and tornadoes. CHEFMAN LLC shall not be liable for any incidental or consequential damages
caused by the breach of any express or implied warranty. Except to the extent prohibited by applicable law, any
implied warranty of merchantability or fitness for a particular purpose is limited in duration to the duration of the
above warranty. Some states, provinces or jurisdictions do not allow the exclusion or limitation of incidental of
consequential damages or limitations on how long an implied warranty lasts, so the above limitations or exclusion
may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from
state to state or province to province.
HOW TO OBTAIN WARRANTY SERVICE: If your CHEFMAN® FAMILY SIZE DEEP FRYER should prove to be defective
within the warranty period, we will repair it, or if we think necessary, replace it. To obtain warranty service,
simply call our toll-free number 1-888-315-8407 Ext: 400 for additional information from our Customer Service
Representatives, or send the defective product to Customer Service at Chefman, 873 Route 45, Suite 101, New City,
NY 10956.
To facilitate the speed and accuracy of your return, please enclose $10.00 for shipping and handling of the product.
Please only pay by money order.
This warranty is effective for the time periods listed above and subject to the conditions provided for within this
policy.
CHEFMAN is a registered trademark of PLUS ITS CHEAP, LLC.
11
USA
AFTER SALES SUPPORT
888-315-8407 customerwarranty@rjbrands.comMODEL: RJ07-3SS-T
Warranty Card
Description of malfunction:
FAMILY SIZE DEEP FRYER
Your details:
Name
Address
E mail
Date of purchase*
* We recommend you keep the receipt with this warranty card
Location of purchase
®
Return your completed warranty card to:
RJ Brands
873 Route 45
Suite 101
New City, New York
10956
AFTER SALES SUPPORT
USA
888-315-8407
customerwarranty@rjbrands.com
MODEL: RJ07-3SS-T
Phone lines available Monday to Friday, 9am-5pm EST
1-YEAR LIMITED WARRANTY
Follow Us
®
Loading...
