600-900 Canopy Installation and Operation Manual
The instructions in this manual are for cooker hood models: CS601S,CS602S, CS902S, CS901S, WRF600, WRF600CS, WRF900CS,
WRG630CW,WRG630CS,WRG930CW,WRG930CS,RCD690S,RCD990S
These cooker hoods are domestic appliances which have been manufactured and tested to comply with Australian and New Zealand
Standard AS/NZS 3350.2.31.
These appliance are intended to be used in household and similar applications such as: Staff kitchen areas in shops, ofces and other
working environments; Farm Houses; By clients in hotels, motels and other residential type environments; Bed and breakfast type
environments.
Safety Warnings
This appliance is not intended for used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Ensure the cooker hood is switched off before carrying out maintenance, to avoid any possibility of electric shock.
Grease lters must be removed every four weeks (maximum) for cleaning to reduce the risk of re.
Do not amb’e under the cooker hood.
This cooker hood is not recommended for barbeques.
The exhaust air from the cooker hood must not be discharged into any heating ue, which may carry combustion products from other sources.
Exhaust air must not be discharged into a wall cavity, unless the cavity is designed for the purpose.
There must be adequate ventilation of the room when the cooker hood is used at the same time as appliances burning gas or other fuels.
Always cover lit gas burners with pots or pans when the cooker hood is in use.
Always switch off gas burners before you remove pots or pans.
CAUTION: Accessible parts may become hot when used with cooking appliance.
Regulations concerning the discharge of air have to be fullled.
Cleaning
Wipe the cooker hood body and ue with a sponge or soft cloth soaked in warm soapy water. Do not use oven cleaners or other abrasive materials.
Electrical Connection
Check that the mains voltage matches with the voltage on the data plate inside the cooker hood.
Check that the installation complies with standards of local gas and electricity authorities.
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualied person in order to avoid a hazard.
Accessories
Use 125mm round exhaust ducting for best performance.
When using exible duct always install duct with the wire helix pulled taut to minimise pressure loss.
Try to keep exhaust duct short and straight.
Keep bends in the exhaust duct to a minimum.
Do not reduce the size or restrict exhaust duct.
INSTALLATION OPTIONS
DUCTING ACCESSORIES
Roof cowl
AR125RC
Flue
1200mm length
AR125F
Wall vent
(includes 400mm of flue)
AR125WV
90º bend
AR125B
Flashing
Not Supplied
AR500FS
AR125FD
Alternative flue connection
1 metre flexible duct with joiners
AR500RK
Part Numbers: Description:
AR125RC
AR125B
AR125F
AR125FD
AR125VW
AR500FS
AR500RK
AR500CF
Top Exhaust
to atmosphere
Rear Exhaust
to atmosphere
Recirculating
Installation
Side Exhaust
to atmosphere
Roof Cowl
90º Bend
Flue 1200mm Long
Flexible Duct - 1 Metre Long When Expanded
Wall Vent Kit
Extra Length Flue Cover 1100mm Length Brushed Stainless Steel
Recirculating Kit
Replacement Carbon Filters
Page 1
Warning: Failure to install the screws or xing device in accordance with these instructions may result in electrical hazards.
COMPONENTS LIST
1 body assembly with grease lters
(900-3 grease lters / 600-2 grease lters)
1 telescopic ue cover set
2 cover ue mounting brackets
1 instruction book
1 plastic bag containing screws for xing
telescopic ue covers
1 plastic duct transition: oblong to round
COMPONENTS NOT INCLUDED
Fixings required to attach cover ue
mounting brackets to wall
Fixings required to attach the cooker hood
to wall
INSTALLING THE COOKER HOOD
Before installing the cooker hood, peel off any
protective plastic covering.
Remove polystyrene packaging from inside
behind fan motor.
(Diagrams C )
20
A
165
222
470(max)
540
1240
230
max)
(
C
245
DIMENSIONS ARE IN MILLIMETRES
B
490
38
303
600/900
65 65
75
500
NOTE:
Some installations may require telescopic
ue cover cut to length. Cut with tin snips or
a ne-tooth hack saw blade, taking care not
to distort or dent ue cover.
The maximum space between the wall and
screw top is 5mm.
Diagram B:
Recommended working heights.
Cover ue mounting bracket locations.
Telescopic cover ue xing points.
75
303
Hood base
NOTE:
If the instructions of the hob
specify a greater distance than
the minimum, then that shall
be the minimum height for the
installation
Page 2
203203
(600 model)
(600 model)
600 models as per this diagram with these dimensions the only variables
C
L
MINIMUM:
600 electric
650 gas
MAXIMUM:
800 mm
Top of hob
RECOMMENDED INSTALLATION SEQUENCE COOKER HOOD OPERATION
Diagram D
Install cooker hood body.
Determine working height, mark
wall to suit.
Install cover ue mounting
brackets.
Diagram E
Fix duct transition to cooker hood
body.
Install internal exhaust duct to suit
installation type.
E
D
IMPORTANT:
during transportation. Ensure that lamps are tightened rmly
into the socket before power is applied.
Best results are obtained by using a low fan speed for normal
conditions and a high fan speed when odours are more
concentrated. Turn the hood on a few minutes before you start
cooking. It should by left on after cooking for about 15 minutes or
until all odours have disappeared.
The Edison Screw lamps may have come loose
3
2
0
0
Slide switch controls:
Light switch:
Extractor fan switch:
Slide position I:
Slide position 2:
Slide position 3:
- - - - - - - - - - - - - -
- - - - - - - - - - - -
- - - - - - - - - - - -
- - - - - - - - - - - -
- - - - - - - -
This switch is used to turn the
light tted in the hood on and off.
Used to select fan speeds.
Fan speed Low
Fan speed Medium
Fan speed High
Press button switch controls
Light switch: Depress
light button to turn light
ON. Press light button to
turn light OFF.
F
G
F
Diagram(s) F
Install bottom section of
telescopic ue cover.
Extractor fan switch
interlocked switching:
Select a fan speed,
depress button to turn
fan ON. Press button (O)
to turn fan OFF.
NOTE:
This product is tted with a safety cutout device. If the cooker hood
is installed to close to the cooktop, ambe cooking, operating the
cooktop without cooking utensils and blocked lters may activate
the safety cutout device. if the hood stops during operation, correct
the faults and allow time for the safety cutout device to reset, the
cooker hood will then function correctly.
Replacing lamps:
Ensure the appliance is switched off before carrying out
maintenance, to avoid any possibility of electric shock. Remove
grease lter to replace lamp. Replace with 40W (maximum) E14
candle lamp.
Diagram G
Install top section of
telescopic ue cover.
Maintenance:
Clean grease lters
every three to four weeks
maximum.
Greasy lters are a re
risk.
Remove the grease lters,
soak and agitate in hot
soapy water.
Rinse, drain and shake
well before replacing
lters.
Do not use oven cleaners
or other caustic materials.
Page 3
Warranty
FOR SALES IN AUSTRALIA AND NEW ZEALAND
APPLIANCE: RANGEHOOD
This document sets out the terms and conditions of the product
warranties for Electrolux Appliances. It is an important document.
Please keep it with your proof of purchase documents in a safe place for
future reference should you require service for your Appliance.
1. In this warranty
(a) ‘acceptable quality’ as referred to in clause 10 of this warranty has the
same meaning referred to in the ACL;
(b) ‘ACL’ means Trade Practices Amendment (Australian Consumer
Law) Act (No.2) 2010;
(c) ‘Appliance’ means any Electrolux product purchased by you
accompanied by this document;
(d) ‘ASC’ means Electrolux’ authorised serviced centres;
(e) ‘Electrolux’ means Electrolux Home Products Pty Ltd of 163
O’Riordan Street, Mascot, NSW 2020, ABN 51 004 762 341 in respect
of Appliances purchased in Australia and Electrolux (NZ) Limited of 3-5
Niall Burgess Road, Mount Wellington, in respect
of Appliances purchased in New Zealand;
(f) ‘major failure’ as referred to in clause 10 of this warranty has the same
meaning referred to in the ACL and includes a situation when an
Appliance cannot be repaired or it is uneconomic for Electrolux, at its
discretion, to repair an Appliance during the Warranty Period;
(g) ‘Warranty Period’ means:
(i) where the Appliance is used for personal, domestic or household
use (i.e. normal single family use) as set out in the instruction
manual, the Appliance is warranted against manufacturing defects
in Australia for 24 months and in New Zealand for 24 months,
following the date of original purchase of the Appliance;
(ii) where the Appliance is used for commercial purposes (including
being used to directly assist a business or where the Appliance is
used in a multi-family communal or share type environment), the
Appliance will then be warranted against manufacturing defects in
Australia for 3 months and in New Zealand for 3 months, following
the date of original purchase of the Appliance.
(h) ‘you’ means the purchaser of the Appliance not having purchased the
Appliance for re-sale, and ‘your’ has a corresponding meaning.
2. This warranty only applies to Appliances purchased and used in Australia
or New Zealand and is in addition to (and does not exclude, restrict, or
modify in any way) any non-excludable statutory warranties in Australia or
New Zealand.
3. During the Warranty Period Electrolux or its ASC will, at no extra charge
if your Appliance is readily accessible for service, without special
equipment and subject to these terms and conditions, repair or replace
any parts which it considers to be defective. Electrolux or its ASC may use
remanufactured parts to repair your Appliance. You agree that any replaced
Appliances or parts become the property of Electrolux. This warranty does
not apply to light globes, batteries, filters or similar perishable parts.
4. Parts and Appliances not supplied by Electrolux are not covered by
this warranty.
5. You will bear the cost of transportation, travel and delivery of the Appliance
to and from Electrolux or its ASC. If you reside outside of the service area,
you will bear the cost of:
(a) travel of an authorised representative;
(b) transportation and deliver y of the Appliance to and from
Electrolux or its ASC,
In all instances, unless the Appliance is transpor ted by Electrolux or an
Electrolux authorised representative, the Appliance is transported at the
owner’s cost and risk while in transit to and from Electrolux or its ASC.
6. Proof of purchase is required before you can make a claim under
7. You may not make a claim under this warranty unless the defect claimed
(a) the Appliance is damaged by:
(i) accident
(ii) misuse or abuse, including failure to properly maintain or service
(iii) normal wear and tear
(iv) power surges, electrical storm damage or incorrect power supply
(v) incomplete or improper installation
(vi) incorrect, improper or inappropriate operation
(vii) insect or vermin infestation
(viii) failure to comply with any additional instructions supplied with the
(b) the Appliance is modified without authority from Electrolux in writing;
(c) the Appliance’s serial number or warranty seal has been removed
(d) the Appliance was ser viced or repaired by anyone other than
8. This warranty, the contract to which it relates and the relationship between
9. To the extent permitted by law, Electrolux excludes all warranties and
10. For Appliances and services provided by Electrolux in Australia,
11. At all times during the Warranty Period, Electrolux shall, at its discretion,
12. For Appliances and services provided by Electrolux in New Zealand, the
13. To enquire about claiming under this warranty, please follow these steps:
(a) carefully check the operating instructions, user manual and the terms
(b) have the model and serial number of the Appliance available;
(c) have the proof of purchase (eg an invoice) available;
(d) telephone the numbers shown below.
14. You accept that if you make a warranty claim, Electrolux and its ASC may
this warranty.
is due to faulty or defective parts or workmanship. Electrolux is not liable in
the following situations (which are not exhaustive):
Appliance;
or defaced;
Electrolux, an authorised repairer or ASC.
you and Electrolux are governed by the law applicable where the Appliance
was purchased. Where the Appliance was purchased in New Zealand for
business purposes the Consumer Guarantee Act does not apply.
liabilities (other than as contained in this document) including liability for
any loss or damage whether direct or indirect arising from your purchase,
use or non use of the Appliance.
the Appliances come with a guarantee by Electrolux that cannot be
excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any
other reasonably foreseeable loss or damage. You are also entitled to
have the Appliance repaired or replaced if the Appliance fails to be of
acceptable quality and the failure does not amount to a major failure.
The benefits to you given by this warranty are in addition to your other
rights and remedies under a law in relation to the Appliances or ser vices
to which the warranty relates.
determine whether repair, replacement or refund will apply if an Appliance
has a valid warranty claim applicable to it.
Appliances come with a guarantee by Electrolux pursuant to the provisions
of the Consumer Guarantees Act, the Sale of Goods Act and the Fair
Trading Act.
of this warranty;
exchange information in relation to you to enable Electrolux to meet its
obligations under this warranty.
Page 4
Before calling for service, please ensure that the steps listed in point 13 above have been followed.
FOR SERVICE
or to find the address of your nearest
state service centre in Australia
PLEASE CALL 13 13 49
For the cost of a local call (Australia only)
FOR SERVICE
or to find the address of your nearest
authorised service centre in New Zealand
FREE CALL 0800 10 66 10
(New Zealand only)
GRH_Warr_Apr11
Important Notice
SERVICE AUSTRALIA
ELECTROLUX HOME PRODUCTS
www.electrolux.com.au
SERVICE NEW ZEALAND
ELECTROLUX HOME PRODUCTS
www.electrolux.co.nz
Part Number: 342 001 593, Issue B
FOR SPARE PARTS
or to find the address of your nearest
state spare parts centre in Australia
PLEASE CALL 13 13 50
For the cost of a local call (Australia only)
FOR SPARE PARTS
or to find the address of your nearest
state spare parts centre in New Zealand
FREE CALL 0800 10 66 20
(New Zealand only)
Loading...
