INDUCTION
COOKTOPS
User Manual
MODELS
CHI644BB, CHI944BB
WARNING
WARNING
TIPS & INFORMATION
ENVIRONMENTAL TIPS
TIPS & INFORMATION
ENVIRONMENTAL TIPS
CONGRATULATIONS
Congratulations and thank you for choosing our Induction
Cooktop. We are sure you will nd your new appliance a
pleasure to use and a great asset to your cooking. Before
you use the appliance, we recommend that you read through
the whole user manual which provides a description of the
product and its functions.
To avoid the risks that are always present when you use a
cooking appliance, it is important that the appliance is installed
correctly and that you read the safety instructions carefully to
avoid misuse and hazards. For future reference, please store
this booklet in a safe place.
CONDITIONS OF USE
This appliance is intended to be used in household and
similar applications such as:
• Sta kitchen areas in shops, oces and other
working environments
• Farm houses
• By clients in hotels, motels and other residential
type environments
• Bed and breakfast type environments
CONTENTS
General safety ...........................................................................................3
Installation instructions ........................................................................4
Assembly ....................................................................................................5
Product description ................................................................................7
Operating instructions ..........................................................................9
Helpful hints and tips .......................................................................... 12
Care and cleaning ................................................................................ 14
Environment concerns ....................................................................... 16
Warranty .................................................................................................. 19
Subject to change without notice.
Record model and serial number here:
Model: .....................................................................................................
Serial number: .....................................................................................
The symbols you will see in this booklet have these meanings:
warning
Indicates information concerning your personal safety
caution
Indicates information on how to avoid damaging the appliance
tips & information
Indicates tips and information about use of the appliance
environmental tips
Indicates tips and information about economical and
ecological use of the appliance
tips & information
Important – check for any damage or marks
If you nd the appliance is damaged or marked, you must
report it within 7 days if you wish to claim for damage/
marks under the manufacturer’s warranty. This does not
aect your statutory rights.
environmental tips
Information on disposal for users
• Most of the packing materials are recyclable. Please dispose
of those materials by contacting your local authorities and
ask for the correct method of disposal.
2 CONTENTS Induction Cooktops
general safety
WARNING
WARNING
WARNING
Safety information
For your safety and correct operation of the appliance, read
this manual carefully before the installation and use. Always
keep these instructions with the appliance if you move or sell
it. The users must fully know the operation and safety functions
of the appliance.
Children and vulnerable people safety
warning
Do not let persons, children included, with reduced physical
sensory, reduced mental functions or lack of experience and
knowledge to use the appliance. They must have supervision
or instruction for the operation of the appliance by a person
who is responsible for their safety.
• Keep all packaging away from children. There is the risk
of suocation or injury.
• Keep the children away from the appliance during and
after the operation, until the appliance is cold.
Safety during operation
• Remove all packaging, stickers and layers from the
appliance before the rst use.
• Set the cooking zones to “o” after each use.
• The risk of burns! Do not put objects made of metal,
for example cutlery or saucepan lids, on the surface that
you cook. They can become hot.
• The users with an implanted pacemaker must keep their
upper body minimum 30cm from induction cooking zones
that are activated.
How to prevent damage to the appliance.
• If objects or cookware fall on the glass, the surface
can be damaged.
• Cookware made of cast iron, cast aluminium or with
damaged bottoms can scratch of the glass.
Do not move them on the surface.
• Do not let cookware boil dry to prevent the damage
to cookware and glass .
• Do not use the cooking zones with empty cookware
or without cookware.
• Do not put aluminium foil on the appliance.
warning
If there is a crack on the surface, disconnect power supply
to prevent the electrical shock.
warning
Fire risk! Fats and oils can become hot very quickly
with ignition.
Correct operation
• The appliance is only for domestic use.
• Do not use the appliance as a work or a storage surface.
• Do not put or keep ammable liquids and materials, easy
fusible objects (made of plastic or aluminium) on or near
the appliance.
• Be careful when you connect the appliance to the near
sockets. Other than the connection point in the terminal
block, do not let the electrical supply cord touch the
appliance or hot cookware. Ensure electrical supply cord
is not tangled.
.
Induction Cooktops GENERAL SAFETY 3
installation instructions
TIPS & INFORMATION
WARNING
WARNING
Induction 6.5kW
0
2
:
2
0
tips & information
Before the installation, note down the serial number from the
rating plate. The rating plate of the appliance is on its lower
casing.
Made in China
(240)949163463(21)04609482(20)00
Made in China
(240)949163466(21)04609484(20)00
MODEL:
S NO.:
MODEL:
S NO.:
CHI644BB
CHI944BB
PNC:949163463
50/60Hz04609482
PNC:949163466
50Hz04609484
MMLL::000
6.5 kW
~
MMLL:
~
220 - 240V
5500222
000
220 - 240V
5500222
The Safety Instructions
WARNING
You must read these!
• Make sure that the appliance has not been damaged in
transportation. Do not connect a damaged appliance.
If it is necessary, speak to the supplier.
• Only an authorized servicing technician can install,
connect or repair this appliance. Use only original spare
parts.
• Only use the built-in appliances after you assemble the
appliance into correct built-in units and work surfaces that
align to the standards.
• Do not change the specication of this appliance.
Due to a risk of injury and damage.
• Fully obey the laws, ordinances, directives and standards
in the country where you use the appliance (safety
regulations, recycling regulations, electrical safety rules
etc).
• Keep the minimum distances to other appliances and
units.
• Make sure that the ventilation space of 5mm, under the
benchtop and directly in front of the appliance is free.
The warranty does not cover damages caused by lack of
adequate ventilation.
• Install shock protection, for example install the drawers
only with a protective oor directly below the appliance.
• Do not use an external timer or a separate remote-control
system to operate the appliance.
• Set the cooking zone to “o” after each use. Do not rely
on the pan detector.
• Keep the cut surfaces of the worktop safe from moisture
with a correct sealant.
• Seal the appliance to the worktop with no space between
with a correct sealant.
• Keep the bottom of the appliance safe from steam and
moisture, e.g. from a dishwasher or oven.
• Do not install the appliance adjacent to doors and below
windows, due to risk of cookware being pushed o hot
appliance.
WARNING
Risk of injury from electrical current. Carefully obey the
instructions for electrical connections.
• Make electrical mains terminal free of voltage.
• Install correctly to give shock protection.
• Loose and incorrect plug and socket connections can
make the terminal become too hot.
• A qualied electrician must install the connections in the
clamps correctly.
• Use a strain relief clamp on cable.
• Use the correct mains cable of type H05BB-F Tmax 90°C
(or higher) for a single phase or two phase connection.
• Replace the damaged mains cable with a special cable
(type H05BB-F Tmax 90°C; or higher). Speak to our
Customer Care team.
The appliance must have the electrical installation which lets
you disconnect the appliance from the mains at all poles with
a contact opening width of minimum 3mm. You must have
correct devices to isolate: line protecting cut-outs, fuses (screw
type fuses removed from the holder), earth leakage trips and
contactors.
4 INSTALLATION Induction Cooktops
assembly
1
2
min. 50mm
min. 600mm
min. 50mm
NOTE : The clearance must meet or exceed the minimum
recommended for both the rangehood and cooktop.
Refer to the rangehood installation manual.
1
2
Induction Cooktops ASSEMBLY 5
assembly
CHI644BB
CHI944BB
6 ASSEMBLY Induction Cooktops
