Chef EHC657U, CHE654SC, CHE655SC User Manual
User manual
Induction Hob
CHE654SC
CHE655SC
EHC65 U
7
Contents
Safety information 2
Installation instructions 3
Product description 6
Operating instructions 7
Helpful hints and tips 7
Care and cleaning 8
What to do if… 9
Environment concerns 9
Warranty 10
Subject to change without notice.
Safety information
For your safety and correct operation
of the appliance, read this manual
carefully before the installation and use.
Always keep these instructions with the
appliance also if you move or sell it.
The users must fully know the operation and safety functions of the appliance.
Children and vulnerable people safety
Warning! Do not let persons, children
included, with reduced physical
sensory, reduced mental functions or
lack of experience and knowledge to
use the appliance. They must have
supervision or instruction for the
operation of the appliance by a person
who is responsible for their safety.
• Keep all packaging away from children.
There is the risk of suffocation or injury.
• Keep the children away from the appliance during and after the operation, until
the appliance is cold.
Safety during operation
• Remove all packaging, stickers and layers from the appliance before the first
use.
• Set the cooking zones to "off" after each
use.
• The risk of burns! Do not put the objects
made of metal, for example cutlery or
saucepan lids, on the surface that you
cook. They can become hot.
• The Users with an implanted pacemaker
must keep their upper body minimum 30
cm from induction cooking zones that are
activated.
Warning! Fire risk! Too hot fats and
oils can occur with ignition very quickly.
Correct operation
• Always monitor the appliance during operation.
• The appliance is only for domestic use!
• Do not use the appliance as a work or a
storage surface.
• Do not put or keep very flammable liquids
and materials, easy fusible objects (made
of plastic or aluminium) on or near the
appliance.
• Be careful when you connect the appliance to the near sockets. Do not let the
electricity bonds touch the appliance or
hot cookware. Do not let the electricity
bonds to tangle.
How to prevent a damage to the
appliance.
• If the objects or cookware fall on the
glass, the surface can be damaged.
• Cookware made of cast iron, cast aluminium or with damaged bottoms can
cause scratch of the glass. Do not move
them on the surface.
• Do not let cookware boil dry to prevent
the damage to cookware and glass .
• Do not use the cooking zones with empty
cookware or without cookware.
• Do not put the aluminium foil on the appliance.
• Make sure that the airflow space of 5 mm
between the worktop and front of the unit
below it stays opened.
Warning! If there is a crack on the
surface, disconnect power supply
to prevent the electrical shock.
2
each use. Do not rely on the pan
Set the cooking zone to “off” after
•
• The electrical mains terminal is live.
separate remote-control system to
Do not use an external timer or a
Installation instructions
Before the installation, note down
the serial number (Ser. Nr.) from the
rating plate. The rating plate of the
appliance is on its lower casing.
PNC: 949163195
Made in China Model: CHE654S
APP NO.: 55GADE8AU
AU APP NO.: S/91
S NO.: 50Hz 6.9 KW
220 - 240 V AC
~ 220 - 240 V
PNC: 949163202
Made in China Model: CHE655S
APP NO.: 55 GAD EC AU
AU APP NO.: S/91
S NO.: 50Hz 6.9 KW
220 - 240 V AC
~ 220 - 240 V
The Safety Instructions
Warning! You must read these!
• Make sure that the appliance is not damaged because of transportation. Do not
connect a damaged appliance. If it is
necessary, speak to the supplier.
• Only an authorized servicing technician
can install, connect or repair this appliance. Use only original spare parts.
• Only use the built-in appliances after you
assemble the appliance into correct builtin units and work surfaces that align to
the standards.
• Do not change the specifications or
change this product. Risk of injury and
damage to the appliance.
• Fully obey the laws, ordinances, directives and standards in force in the country where you use the appliance (safety
regulations, recycling regulations, electrical safety rules etc.)!
• Keep the minimum distances to other appliances and units!
• Install shock protection, for example install the drawers only with a protective
floor directly below the appliance!
• Keep safe the cut surfaces of the worktop from moisture with a correct sealant!
• Seal the appliance to the work top with
no space between with a correct sealant!
• Keep safe the bottom of the appliance
from steam and moisture, e.g. from a
dishwasher or oven!
• Do not install the appliance adjacent to
doors and below windows! If not, when
you open the doors or windows they can
push off hot cookware from the appliance.
Warning! Risk of injury from electrical
current. Carefully obey the instructions
for electrical connections.
• Make electrical mains terminal free of
voltage.
• Install correctly to give shock protection.
• Loose and incorrect plug and socket
connections can make the terminal become too hot.
• A qualified electrician must install the
connections in the clamps correctly.
• Use a strain relief clamp on cable.
• Use the correct mains cable of type
H05BB-F Tmax 90°C (or higher) for a single phase or two phase connection.
• Replace the damaged mains cable with a
special cable (type H05BB-F Tmax 90°C;
or higher). Speak to your local Service
Centre.
The appliance must have the electrical installation which lets you disconnect the appliance from the mains at all poles with a
contact opening width of minimum 3 mm.
You must have correct devices to isolate:
line protecting cut-outs, fuses (screw type
fuses removed from the holder), earth leakage trips and contactors.
3
operate the appliance.
detector
•
PNC: 94916314
Made in China Model: EHC65 U
APP NO.: 55 GAD EC AU
AU APP NO.: S/91
S NO.: 50Hz 6.9 KW
220 - 240 V AC
~ 220 - 240 V
7
7
Assembly
min.
50mm
min.
50mm
min.
500mm
min.
5mm
1
2
4
=
=
490
+1
mm
560
+1
mm
600mm
R 5mm
min.
25 mm
min.
5 mm
min.
20 mm
min.
38 mm
min.
5 mm
5
