70 cm 4 zone ceramic cooktop.
RRP AUS $749.00
CHC744BA
CHC744BA - 4 zone ceramic cooktop
Product Details
FEATURES
Trimless black ceramic glass Stylish ceramic cooktop 4 ribbon elements Rotary controls
Residual heat indicator
Indicates which area is too
hot to comfortably touch.
Remains on if ceramic
surface is above 40c
BENEFITS
Contemporary and functional
The Chef range of cooking appliances has all the features you
need in a design that you'll love
Easy to use rotary controls
Rotary controls with stepped settings make it easy to use and
easy to determine the heat needed
Ceramic finish
Stylish ceramic surface for a clean finish to your kitchen
design
CHC744BA
CHC744BA - 4 zone ceramic cooktop
Specifications
PRODUCT PROFILE
Domestic warranty details
(yrs)
2
Cooktop type ceramic
Materials/Colour black ceramic glass
Knob finish black
DIMENSIONS
Total product height (mm) 46
Total product width (mm) 700
Total product depth (mm) 515
Cut out width (mm) 560
Cut out depth (mm) 490
CONTROLS
Controls of Cooktops knob
Position of controls right
Indicators/display residual heat warning
lamps
ELEMENTS/BURNERS
LEFT FRONT ZONE
Left front zone ceramic
Left front Watts 1800
Left front number of
cooking zones
1
LEFT REAR ZONE
Left rear zone ceramic
RIGHT FRONT ZONE
Right front zone ceramic
CHC744BA
CHC744BA - 4 zone ceramic cooktop
Left rear watts 1200
Left rear number of cooking
zones
1
Right front Watts 1200
Right front number of
cooking zones
1
RIGHT REAR ZONE
Right rear zone ceramic
Right rear watts 1800
Right rear number of
cooking zones
1
ELECTRICAL SPECIFICATIONS
Connected load KW 6.0
Maximum current rating
(amps)
25
Type of connection hardwired
CHC744BA
CHC744BA - 4 zone ceramic cooktop
ELECTROLUX HOME PRODUCTS AUSTRALIA
telephone: 1300 363 640
fax: 1800 350 067
email: customercare@electrolux.com.au
web: www.electrolux.com.au
ELECTROLUX HOME PRODUCTS NEW ZEALAND
telephone: 09 573 2230
fax: 09 573 2221
email: customercare@electrolux.co.nz
web: www.electrolux.co.nz
Terms and Conditions
IMPORTANT
This is a guide of product dimensions only. For complete installation instructions, refer to the manual provided with product.
PRODUCT INFORMATION
The descriptors and illustrations in this publication apply to the specific products and models described as at the date of issue. Under our policy of
continuous productdevelopment, product specifications may change without notice. Prospective purchasers should therefore check with their retailer to
ensure this publication correctly describes theproducts that are being offered for sale. All information supplied is to be used for general reference
purposes only and is on the understanding that Electrolux Home Products PtyLtd (Australia) and Electrolux (NZ) Ltd (New Zealand) will not be liable for
any loss, liability or damage of whatever kind arising as a result of reliance on such information. Colours ofproducts illustrated are as close as printing
limitations allow. Electrolux will at all times comply with its obligations pursuant to law including Trade Practices (Australian Consumer Law) Act and
Regulations.
WARRANTY
This warranty only applies to Appliances purchased and used in Australia or New Zealand and used in normal domestic applications and is in addition to
(and does not exclude, restrict, or modify in any way) any non-excludable statutory warranties in Australia or New Zealand. All warranties are subject to the
conditions set out in the warranty card accompanying the product when purchased.
