QUICK START GUIDE
Thank you for purchasing
the Cheetah C550.
You made a smart choice!
The Cheetah C550 is a GPS driver safety system
to help protect you and your family, as well as
your licence. It will alert you to speed and red light
camera locations and many other driving hazards,
to help you stay safe and ticket free.
Warranty registration and database updates
Please visit www.SpeedCheetah.com to register and update your C550.
2
Suggested fitting locations
The C550 is small enough to install
in a number of dierent locations.
If you install above the rear view
mirror, you can tuck the power
cable under the trim panels around
the glass and down the A-pillar.
Alternatively, you can mount the
C550 on your dash using the
supplied magnetic mount.
Switching on for the first time
Insert the power plug into the vehicle’s cigarette lighter socket, then connect the other end
to the C550’s 12v power socket. There is an illuminated ON / OFF button on the power plug.
All the LEDs will light up briefly, before displaying the database version number
Once the C550 is receiving a good GPS signal, the display will show the current time and
your driving speed.
Trinity database
The C550 is Cheetah’s newest and most advanced GPS speed and red light camera detector,
designed to fully maximise the potential of our Trinity 2.0 database, so it provides the widest
and most detailed range of voice alerts of any GPS driver safety system on the market.
We recommend purchasing a Membership Package to keep up to date with the very latest
cameras. Updating your C550 with the latest Trinity database releases via your PC is easy.
If you have any questions, please visit www.speedcheetah.com for help and support.
3
C550 special features
Individually configurable audio for each dierent type of alert to suit your preferences.
Custom alert distances – select dierent warning distances for dierent types of camera.
Adjustable screen brightness.
Dark mode – for stealth installations, or for night time driving, the display will
only light up during an alert.
Alert mute – quickly switch o / on the audio for the current alert.
Alert cancel – quickly cancel the current alert if required.
Whisper mode – keeps the C550 quiet if you are under known speed limits.
Adjustable alert speed limit tolerance – increase the overspeed alert activation speed
to suit your driving style.
Variable warning distance – automatically reduces the alert distance at slower speeds.
Personal speed limit – will play a tone each time you exceed your preset speed.
Personal locations – store up to 64 of your own locations.
Database update reminder – if you forget to update for 6 weeks, your C550
will occasionally remind you.
Optional Silent start up.
Demo mode.
Power up via PC to allow adjustment of settings.
4
Box contents
1 x C550
1 x power cord
1 x USB cable
1 x Magnetic dash mount
1 x Windshield mount
1 x Quick start guide
Hardware description
A Power in 12v
B micro USB socket
C Speaker
D Windshield bracket location
E Magnetic dash mount location (underneath)
F External GPS antenna socket
G Headphone socket
E
A
D
F
G
B
C
5
