Checkpoint Systems NGL User Manual

P/N 10

094144

Classic Style

Installation Manual

Version *60

Classic Style Installation Manual

Copyright © 2011 by Checkpoint Systems Inc.

Released XX/XX/2013.

Published by:

Checkpoint Systems Inc.

101 Wolf Drive

Thorofare, NJ 08086

Document revision information

Classic Style Installation Manual, version *60

Rev Description Date Author

*60 CR2637C 1/9/2013 Ander Jiang, Chris Zheng

Trademarks

Checkpoint is a registered trademark of Checkpoint Systems, Inc.

Checkpoint, Liberty, Evolve, and VisiPlus are registered trademarks of Checkpoint Systems, Inc. All rights reserved.
Information in this document is subject to change without notice.

Other products © or ® their respective manufacturers or copyright holders.

Companies, names and data used in examples herein are fictitious unless otherwise noted. No part of the contents of
this book may be reproduced or transmitted in any form or by any means without the written permission of the
publisher.

Copyright and Warranty Information

The information in this document is subject to change without notice.

Because of the changing nature of this product information presented in the Classic Style Installation Manual,
Checkpoint Systems, Inc. is not liable for any omissions, misstatements, or other errors of information.

The information presented in this document may not be copied, used or disclosed to others for the purpose of
procurement or manufacturing without the written permission of Checkpoint Systems, Inc. This guide and the
products discussed in this guide are the exclusive property of Checkpoint Systems Inc. Copyright laws of the United
States protect all information and products.

Copyright© 2011 Checkpoint Systems, Inc. All rights reserved.

Classic Style Installation Manual Rev. *60

2 of 27

Important Information to our Users in North America

FCC Regulatory Compliance Statement

Checkpoint Systems, Inc., offers Electronic Article Surveillance (EAS) or Radio Frequency
Identification Products that have been FCC certified or verified to 47 CFR Part 15 Subparts B/C
and/or 47 CFR Part 18. Appropriately, one of the following labels will apply to the approval:

NOTE: This equipment has been tested and found to comply with the limits for a class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.

- OR -

This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) including this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation, which may include intermittent decreases in detection and/or
intermittent increases in alarm activity.

- OR –

NOTE: This equipment has been tested and found to comply with the limits for a
miscellaneous type ISM device, pursuant to Part 18 of the FCC Rules. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio
communications reception, which can be determined by turning the equipment off and on,
please contact Checkpoint Systems, Inc., at 1 [phone] for further assistance.

Classic Style Installation Manual Rev. *60

3 of 27

Industry Canada

Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a
type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce
potential radio interference to other users, the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communication.

This radio transmitter (identify the device by certification number, or model number if Category
II) has been approved by Industry Canada to operate with the antenna types listed below with the
maximum permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated
for that type, are strictly prohibited for use with this device.

Operation is subject to the following two conditions:

(1) This device may not cause interference.

(2) This device must accept any interference, including interference that may cause undesired
operation of the device
.
To reduce potential radio interference to other users, the antenna type and its gain should
be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than
that permitted for successful communication.

Industrie Canada

Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut
fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour
l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son
gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas
l'intensité nécessaire à l'établissement d'une communication satisfaisante.

Le présent émetteur radio (identifier le dispositif par son numéro de certification ou son
numéro de modèle s'il fait partie du matériel de catégorie I) a été approuvé par Industrie
Canada pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain
admissible maximal et l'impédance requise pour chaque type d'antenne. Les types
d'antenne non inclus dans cette liste, ou dont le gain est supérieur au gain maximal
indiqué, sont strictement interdits pour l'exploitation de l'émetteur

Le fonctionnement de l’ appareil est soumis aux deux conditions suivantes:

1. Cet appareil ne doit pas perturber les communications radio, et

Classic Style Installation Manual Rev. *60

4 of 27

2. cet appareil doit supporter toute perturbation, y compris les perturbations qui
pourraient provoquer son dysfonctionnement.

Pour réduire le risque d'interférence aux autres utilisateurs, le type d'antenne et son gain
doivent être choisis de façon que la puissance isotrope rayonnée équivalente (PIRE) ne
dépasse pas celle nécessaire pour une communication réussie.

Equipment Safety Compliance Statement

Checkpoint Systems’ EAS or Radio Frequency Identification products have been designed to be
safe during normal use and, where applicable, certain components of the system or accessory
sub-assemblies have been certified, listed or recognized in accordance with one or more of the
following Safety standards: UL 1012, UL 1037, UL 1310, UL 60950-1, CSA C22.2 No. 205,
CSA C22.2 No. 220, CSA C22.2 No. 223, CSA C22.2 No. 60950-1. Additional approvals may
be pending.

WARNING: Changes or modifications to Checkpoint’s EAS or Radio Frequency Identification
(RFID) equipment not expressly approved by the party responsible for assuring compliance
could void the user’s authority to operate the equipment in a safe or otherwise regulatory
compliant manner.

Classic Style Installation Manual Rev. *60

5 of 27

Important Information to our Users in Europe

CE Regulatory Compliance Statement

Where applicable, Checkpoint Systems, Inc., offers certain Electronic Article Surveillance (EAS)
products that have CE Declarations of Conformity according to R&TTE Directive 99/5/EC.

System Electromagnetic Compatibility (EMC), has been tested and notified through Spectrum
Management Authorities if necessary, using accredited laboratories, whereby, conformity is
declared by voluntarily accepted European Telecommunications Standards Institute (ETSI)
standards EN 301489-3 and EN 300330-2.

NOTE: Certain Electronic Article Surveillance (EAS) equipment have been tested and found to
conform with the CE emission and immunity requirement in Europe. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Under unusual
circumstances, interference from external sources may degrade the system performance, which
may include intermittent decreases in detection and/or intermittent increases in alarm activity.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment experiences frequent interference from external sources or does cause harmful
interference to radio communications reception, which can be determined by turning the
equipment off and on, please contact a Checkpoint Systems representative for further assistance.

Equipment Safety Compliance Statement

Checkpoint Systems Electronic Article Surveillance products have been designed to be safe
during normal use and, where applicable, certain components of the system or accessory sub­assemblies have been declared safe according to the European Low Voltage Directive (LVD) by
being certified, listed, or recognized in accordance with one or more of the following European
safety standards; EN 60950, EN 50364, EN 60742.

WARNING: Changes or modifications to Electronic Article Surveillance equipment not
expressly approved by the party responsible for assuring compliance could void the user’s
authority to operate the equipment in a safe or otherwise regulatory compliant manner additional
approvals may be pending

Classic Style Installation Manual Rev. *60

6 of 27

Table of Contents

T

ABLE OF CONTENTS

INSTALLATION OVERVIEW .................................................................................................. 9

O

VERVIEW

R

EQUIREMENTS

................................................................................................................................... 9

Tools........................................................................................................................................ 9

Parts...................................................................................................................................... 10

I

NSTALLATION OUTLINE

PHYSICAL INSTALLATION .................................................................................................. 11

O

VERVIEW

................................................................................................................................. 11

Aisle Width............................................................................................................................ 11

P

OWER SUPPLY

Placement.............................................................................................................................. 11

A

NTENNA MOUNTING

Mounting Hardware.............................................................................................................. 12

Wire Routing ......................................................................................................................... 13

ANTENNA WIRING.................................................................................................................. 14

O

VERVIEW

G

ENERAL WIRING INSTRUCTION

................................................................................................................................. 14

Wiring between PSB/SSB...................................................................................................... 16

Wiring 24VDC power supply................................................................................................ 17

S

INGLE AISLE WIRING

Secondary antenna (SSB) wiring .......................................................................................... 18

Primary antenna (PSB) wiring ............................................................................................. 20

................................................................................................................... 7

............................................................................................................................ 9

............................................................................................................ 10

.......................................................................................................................... 11

................................................................................................................ 12

................................................................................................ 14

............................................................................................................... 18

ELECTRONICS SETTING....................................................................................................... 22

O

VERVIEW

................................................................................................................................. 22

The Jumper setting for coupler aiming to antenna tuning.................................................... 22

The maximum TX settings allowable for compliance to the FCC/CE .................................. 22

List of Ferrites for Classic Style ........................................................................................... 23

ANTENNA DIMENSIONS ........................................................................................................ 24

C

LASSIC STYLE

PSB/SSB.......................................................................................................... 24

POWER SUPPLIES ................................................................................................................... 25

O

VERVIEW

P

OWER SUPPLY USED IN UNITED STATES

P

OWER SUPPLY USED IN EUROPE

Classic Style Installation Manual Rev. *60

................................................................................................................................. 25

.................................................................................. 25

.............................................................................................. 27

7 of 27

C H A P T E R

1

INTRO D U C T I O N

This Installation Manual details the steps necessary for the proper installation and configuration of
the Classic Style systems.

In this manual, most illustrations and pictures will show the Classic Style as a place of reference,
but it is to be understood that each antenna would be installed in the same manner (unless
otherwise noted).

Classic Style Installation Manual Rev. *60

Classic Style front view Classic Style Side view

Figure 1 Classic Style antenna front and side view

8 of 27

Overview

This chapter is an overview of the installation process:

1. Requirements: Tool and part requirements for a typical installation.

2. Installation Outline: Lists the basic installation steps in sequence.

Requirements

C H A P T E R

2

INSTALL AT I O N O V E RVIEW

Tools

The following tools are required for Classic Style Antenna installations:

 Arrow T-25 Staple Gun
 Diagonal wire cutter
 Hammer drill with 3/16” and 1/2” bits
 Extension cord
 Tape Measure
 Hammer
 Marker, Black Felt
 Ratchet driver with 9/16” socket
 Screwdrivers, mini, regular and #2 Phillips
 Hacksaw
 Utility knife
 Wire Snake
 Wire Strippers
 Wrench, combination end 9/16”
 Classic Style Installation Manual (This manual)
 Tuning Procedure, TR4215 Checkpoint PN 7128336
 Checkpoint Systems Field Service Diagnostic Management Software (DMS version

1.8.31 or later version) installed on a laptop with the appropriate cables. DMS is an

Classic Style Installation Manual Rev. *60

9 of 27
