Getting Started Guide

Check Point 4000

Appliances

Models: T-120, T-160 and T-180

CP_Toxotai_GettingStartedGuide_41 1CP_Toxotai_GettingStartedGuide_41 1 05 July 2011 1:21:10 PM05 July 2011 1:21:10 PM

All rights reserved. This product and related documentation are protected by copyright and distributed under licensing restricting their use, copying, distribution, and decompilation. No part of this product or related documentation may be reproduced in any form or by any means without prior written authorization of Check Point. While every precaution has been taken in the preparation of this book, Check Point assumes no responsibility for errors or omissions. This publication and features described herein are subject to change without notice.

RESTRICTED RIGHTS LEGEND:

Use, duplication, or disclosure by the government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013 and FAR 52.227-19.

TRADEMARKS:

Refer to the Copyright page (

http://www.checkpoint.com/copyright.html) for a list of our

trademarks.

Refer to the Third Party copyright notices (http://www.checkpoint.com/3rd_party_copyright.html) for a list of relevant copyrights and thirdparty licenses.

CP_Toxotai_GettingStartedGuide_42 2CP_Toxotai_GettingStartedGuide_42 2 05 July 2011 1:21:10 PM05 July 2011 1:21:10 PM

Welcome

Safety, Environmental, and Electronic Emissions Notices Page 3

Safety, Environmental, and Electronic Emissions Notices

Read the following warnings before setting up or using the appliance.

Warning - Do not block air vents. A minimum 1/2-inch clearance is required.

Warning - This appliance does not contain any user-serviceable parts. Do not remove any covers or attempt to gain access to the inside of the product. Opening the device or modifying it in any way has the risk of personal injury and will void your warranty. The following instructions are for trained service personnel only.

To prevent damage to any system board, it is important to handle it with care. The following measures are generally sufficient to protect your equipment from static electricity discharge:

x When handling the board, to use a grounded wrist strap designed for static discharge

elimination.

x Touch a grounded metal object before removing the board from the antistatic bag.

x Handle the board by its edges only. Do not touch its components, peripheral chips, memory

modules or gold contacts.

x When handling processor chips or memory modules, avoid touching their pins or gold edge

fingers.

x Restore the communications appliance system board and peripherals back into the

antistatic bag when they are not in use or not installed in the chassis. Some circuitry on the system board can continue operating even though the power is switched off.

x Under no circumstances should the lithium battery cell used to power the real-time clock be

allowed to short. The battery cell may heat up under these conditions and present a burn hazard.

Warning - DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER. DISCARD USED

%$77(5,(6$&&25',1*727+(0$18)$&785(5¶6,16758&7,216

CP_Toxotai_GettingStartedGuide_43 3CP_Toxotai_GettingStartedGuide_43 3 05 July 2011 1:21:10 PM05 July 2011 1:21:10 PM

Welcome

Page 4

x Disconnect the system board power supply from its power source before you connect or

disconnect cables or install or remove any system board components. Failure to do this can result in personnel injury or equipment damage.

x Avoid short-circuiting the lithium battery; this can cause it to superheat and cause burns if

touched.

x Do not operate the processor without a thermal solution. Damage to the processor can

occur in seconds.

x Class 1 Laser Product Warning

Rack Mount Instructions

The following or similar rack-mount instructions are included with the installation instructions:

1. Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. Therefore, consideration should be given to installing the equipment in an environment compatible with the maximum ambient temperature specified by the manufacturer.

2. Reduced Air Flow - Installation of the equipment in a rack should be such that the amount of air flow required for safe operation of the equipment is not compromised.

3. Mechanical Loading - Mounting of the equipment in the rack should be such that a hazardous condition is not achieved due to uneven mechanical loading.

4. Circuit Overloading - Consideration should be given to the connection of the equipment to the supply circuit and the effect that overloading of the circuits might have on over current protection and supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.

5. Reliable Ear thing - Reliable ear thing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (e.g. use of power strips).

For California:

Perchlorate Material - special handling may apply. See

http://www.dtsc.ca.gov/hazardouswaste/perchlorate

The foregoing notice is provided in accordance with California Code of Regulations Title 22, Division 4.5, Chapter 33. Best Management Practices for Perchlorate Materials. This product, part, or both may include a lithium manganese dioxide battery which contains a perchlorate substance.

Proposition 65 Chemical

Chemicals identified by the State of California, pursuant to the requirements of the California Safe Drinking Water and Toxic Enforcement Act of 1986, California Health & Safety Code s.

25249.5, et seq. ("Proposition 65"), that is "known to the State to cause cancer or reproductive

toxicity" (see http://www.calepa.ca.gov)

WARNING:

CP_Toxotai_GettingStartedGuide_44 4CP_Toxotai_GettingStartedGuide_44 4 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Welcome

Safety, Environmental, and Electronic Emissions Notices Page 5

Handling the cord on this product will expose you to lead, a chemical known to the State of California to cause cancer, and birth defects or other reproductive harm. Wash hands after handling.

Federal Communications Commission (FCC) Statement:

For a Class A digital device or peripheral

Note: This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

For a Class B digital device or peripheral

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

x Reorient or relocate the receiving antenna.

x Increase the separation between the equipment and receiver.

x Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

x Consult the dealer or an experienced radio/TV technician for help.

Information to user:

The user's manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. In cases where the manual is provided only in a form other than paper, such as on a computer disk or over the Internet, the information required by this section may be included in the manual in that alternative form, provided the user can reasonably be expected to have the capability to access information in that form.

CP_Toxotai_GettingStartedGuide_45 5CP_Toxotai_GettingStartedGuide_45 5 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Welcome

Page 6

Canadian Department Compliance Statement:

This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Japan Compliance Statement:

Class A

Class B

European Union (EU) Electromagnetic Compatibility Directive

This product is herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility Directive (2004/108/EC). For the evaluation regarding the Electromagnetic Compatibility (2004/108/EC)

CP_Toxotai_GettingStartedGuide_46 6CP_Toxotai_GettingStartedGuide_46 6 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Welcome

Safety, Environmental, and Electronic Emissions Notices Page 7

This product is in conformity with Low Voltage Directive 2006/95/EC, and complies with the requirements in the Council Directive 2006/95/EC relating to electrical equipment designed for use within certain voltage limits and the Amendment Directive 93/68/EEC.

Product Disposal

This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. For more information about where you can drop off your waste equipment for recycling, please contact your local city office or your household waste disposal service.

CP_Toxotai_GettingStartedGuide_47 7CP_Toxotai_GettingStartedGuide_47 7 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

CP_Toxotai_GettingStartedGuide_48 8CP_Toxotai_GettingStartedGuide_48 8 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Contents

Safety, Environmental, and Electronic Emissions Notices .................................. 3

Introduction ........................................................................................................... 11

Welcome ............................................................................................................11

Check Point 4000 Appliances Overview .............................................................11

Shipping Carton Contents...................................................................................12

Terminology........................................................................................................12

Rack Mounting ...................................................................................................... 15

Rack Mounting Hardware and Tools ...................................................................15

Attaching the Ear Mount Brackets to the Appliance ............................................16

Attaching the Rail Plates ....................................................................................17

Attaching the Appliance Rails to the Appliance ...................................................18

Installing the Appliance in the Rack ....................................................................20

Configuring Check Point 4000 Appliances ......................................................... 21

Powering On.......................................................................................................21

Using the First Time Configuration Wizard .........................................................22

Starting the First Time Configuration Wizard ..................................................23

Welcome ........................................................................................................23

Appliance Date and Time Setup ....................................................................23

Network Connections .....................................................................................24

Routing Table ................................................................................................24

Host, Domain Settings, and DNS Servers ......................................................24

Management Type .........................................................................................24

Summary .......................................................................................................26

Creating the Network Object ...............................................................................26

Advanced Configuration .....................................................................................27

Connecting to the CLI ....................................................................................27

Check Point 4000 Appliances Hardware ............................................................. 29

Front Panel Components ....................................................................................29

Check Point Front 4200 .................................................................................29

Check Point 4600 Front Panel .......................................................................30

Check Point 4800 Front Panel .......................................................................31

Managing Check Point 4000 Appliances Using the LCD Panel ......................32

Expansion Line Cards ....................................................................................33

Hard Disk Drives ............................................................................................34

Rear Panel Components ....................................................................................34

Main Power Switch ........................................................................................34

Redundant Power Supply Units (Check Point 4800) ......................................34

CP_Toxotai_GettingStartedGuide_49 9CP_Toxotai_GettingStartedGuide_49 9 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Customer Replaceable Parts .............................................................................. 34

Power Supply (Check Point 4800) ................................................................. 35

Expansion Line Card ..................................................................................... 37

Restoring Factory Defaults .................................................................................. 39

Restoring Using the WebUI ................................................................................ 39

Restoring Using the Console Boot Menu ............................................................ 40

Restoring Using the LCD Panel .......................................................................... 41

Registration and Support ..................................................................................... 43

Registration ........................................................................................................ 43

Support .............................................................................................................. 43

Where To From Here?........................................................................................ 43

Compliance Information ....................................................................................... 45

Declaration of Conformity ................................................................................... 45

CP_Toxotai_GettingStartedGuide_410 10CP_Toxotai_GettingStartedGuide_410 10 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Page 11

Chapter 1

Introduction

In This Chapter

Welcome 11

Check Point 4000 Appliances Overview 11

Shipping Carton Contents 12 Terminology 12

Welcome

7KDQN\RXIRUFKRRVLQJ&KHFN3RLQW¶V&KHFN3RLQW$SSOLDQFHV:HKRSHWKDW\RXZLOOEH

satisfied with this system and our support services. Check Point products provide your business with the most up to date and secure solutions available today.

Check Point also delivers worldwide technical services including educational, professional and support services through a network of Authorized Training Centers, Certified Support Partners and Check Point technical support personnel to ensure that you get the most out of your security investment.

For additional information on the Internet Security Product Suite and other security solutions, refer to the Check Point Web site (

http://www.checkpoint.com), or call Check Point at 1(800)

429-4391. For additional technical information about Check Point products, consult the Check Point Support Center (http://supportcenter.checkpoint.com).

Welcome to the Check Point family. We look forward to meeting all of your current and future network, application and management security needs.

Check Point 4000 Appliances Overview

The family of Check Point 4000 Appliances enables organizations to maximize security in highperformance environments such as large campuses or data centers. Combining integrated firewall, IPSec VPN, and intrusion prevention with advanced acceleration technologies, Check

CP_Toxotai_GettingStartedGuide_411 11CP_Toxotai_GettingStartedGuide_411 11 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Shipping Carton Contents

Page 12

Point 4000 Appliances deliver a high-performance security platform capable of blocking application layer threats. Even as new threats appear, Check Point 4000 Appliances maintain or increase performance while protecting the network against attacks.

Key Features:

x Proven, enterprise-class firewall, VPN, and intrusion prevention

x Accelerated security performance, including SecureXL and CoreXL technologies

x Integrated load balancing and dynamic routing for data center reliability levels

x Centrally managed from Security Management Server/Check Point 4000 Appliances or as

a stand alone device

x Automatic security protection updates from SmartDefense Services

This document provides:

x A brief overview of essential Check Point 4000 Appliances concepts and features

x A step by step guide to getting Check Point 4000 Appliances up and running

Note - Screen shots in this guide may apply only to the highest model to which this guide applies.

Shipping Carton Contents

This section describes the contents of the shipping carton.

Item

Description

Appliance

Check Point 4000 Appliance

Rack Mounting Accessories

Hardware mounting kit

Cables

x Power cable

x 1 Standard RJ-45 network cable

x 1 Serial console cable

Documentation

x Quick Start Guide

x Getting Started Guide

x Image Management Guide

x User license agreement

Terminology

The following terms are used in this guide:

CP_Toxotai_GettingStartedGuide_412 12CP_Toxotai_GettingStartedGuide_412 12 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Terminology

Introduction Page 13

x Gateway7KHVHFXULW\HQJLQHWKDWHQIRUFHVWKHRUJDQL]DWLRQ¶VVHFXULW\SROLF\DQGDFWVDVD

security enforcement point.

x Security Policy: The policy created by the system administrator that regulates the flow of

incoming and outgoing communication.

x Security Management Server: The server used by the system administrator to manage

WKHVHFXULW\SROLF\7KHRUJDQL]DWLRQ¶VGDWDEDVHVDQGVHFXULW\SROLFLHVDUHVWRUHGRQWKH

Security Management Server and downloaded to the gateway.

x SmartConsole: GUI applications that are used to manage various aspects of security

policy enforcement. For example, SmartView Tracker is a SmartConsole application that manages logs.

x SmartDashboard: A SmartConsole GUI application that is used by the system

administrator to create and manage the security policy.

x Locally Managed Deployment: When all Check Point components responsible for both

the management and enforcement of the security policy (the Security Management Server and the gateway) are installed on the same machine.

x Centrally Managed Deployment: When the gateway and the Security Management

Server are installed on separate machines.

CP_Toxotai_GettingStartedGuide_413 13CP_Toxotai_GettingStartedGuide_413 13 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

CP_Toxotai_GettingStartedGuide_414 14CP_Toxotai_GettingStartedGuide_414 14 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Page 15

Chapter 2

Rack Mounting

This chapter describes how to mount the appliance in a rack.

Important - Two people are required to install the appliance in a rack in order to prevent any possible damage.

In This Chapter

Rack Mounting Hardware and Tools 15

Attaching the Ear Mount Brackets to the Appliance 16

Attaching the Rail Plates 17

Attaching the Appliance Rails to the Appliance 18 Installing the Appliance in the Rack 20

Rack Mounting Hardware and Tools

You must install rack mounting hardware on the appliance before you can mount it in a rack. This table describes the rack mounting hardware.

Hardware Description

Qty.

Use

Ear mount bracket

Attaches to the appliance front panel. Both ear mount brackets are identical.

Ear mount screws

Secures the ear mount brackets to the appliance front panel. These screw heads are smaller (5 mm).

Appliance rail

Attaches to the appliance. Both rails are identical.

Rail plates

Attaches to the appliance rails. Both plates are identical.

Appliance rail screws

Secures the rail plates to the appliance rails and the rails to the appliance. These screw heads are larger (8 mm).

CP_Toxotai_GettingStartedGuide_415 15CP_Toxotai_GettingStartedGuide_415 15 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Attaching the Ear Mount Brackets to the Appliance

Page 16

Rack Mounting Tools

x Philips screwdriver. A magnetic head is recommended to hold screws in place and retrieve

dropped screws. A powered screwdriver is also useful.

Note - Screws to attach the ear mount brackets and rail plates to the rack are not included.

Attaching the Ear Mount Brackets to the Appliance

Attach the two ear mount brackets to the front of the appliance.

Note - The ear mount screws have 5 mm heads.

To attach the ear mount brackets to the appliance:

1. Attach the appliance ear bracket to one side of the appliance using three ear mount screws.

2. Do step 1 again for the other side of the appliance.

CP_Toxotai_GettingStartedGuide_416 16CP_Toxotai_GettingStartedGuide_416 16 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Attaching the Rail Plates

Rack Mounting Page 17

Attaching the Rail Plates

Attach the rail plates to the appliance rails to attach the appliance to the rear vertical rails of the rack.

Item

Description

Appliance rail

Rail plate

Note - The appliance rail screws have 8 mm heads.

To attach the rail plates:

1. Attach a rail plate to an appliance rail using two appliance rail screws.

2. Do step 1 again for the other rail plate and appliance rail.

CP_Toxotai_GettingStartedGuide_417 17CP_Toxotai_GettingStartedGuide_417 17 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Attaching the Appliance Rails to the Appliance

Page 18

This figure displays the assembled rail plate and appliance rail.

Attaching the Appliance Rails to the Appliance

Attach the appliance rails to the sides of the appliance. The rail plates are positioned to connect the appliance rails to the rear of the rack.

Note - The appliance rail screws have 8 mm heads.

CP_Toxotai_GettingStartedGuide_418 18CP_Toxotai_GettingStartedGuide_418 18 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Attaching the Appliance Rails to the Appliance

Rack Mounting Page 19

To attach the appliance rails:

1. Set the appliance rail on the side of the appliance. The ridges on the appliances rails point

to the appliance. This diagram shows the appliance rail and rail plate positioned correctly:

2. Attach the appliance rails to the appliance using three appliance rail screws.

3. Do steps 1 and two again for the other side of the appliance.

CP_Toxotai_GettingStartedGuide_419 19CP_Toxotai_GettingStartedGuide_419 19 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Installing the Appliance in the Rack

Page 20

Installing the Appliance in the Rack

Install the appliance in the rack. It may be necessary to adjust the appliance rails to secure the appliance to the rack.

Important - Two people are required to install the appliance in a rack in order to prevent any possible damage.

To install the appliance in the rack:

1. Attach the ear mount brackets to the front of the rack.

2. Attach the rail plates to the rear of the rack.

3. Confirm that the appliance is stable and secure in the rack.

CP_Toxotai_GettingStartedGuide_420 20CP_Toxotai_GettingStartedGuide_420 20 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Page 21

Chapter 3

Configuring Check Point 4000 Appliances

The workflow for configuring Check Point 4000 Appliances is:

1. Connect the cables and power on the appliance.

2. Use the First Time Configuration Wizard to configure the appliance.

3. Add the Check Point 4000 Appliances object in SmartDashboard and install a policy.

In This Chapter

Powering On 21 Using the First Time Configuration Wizard 22

Creating the Network Object 26

Advanced Configuration 27

Powering On

To power on Check Point 4000 Appliances:

1. Connect the power cable.

2. On the back panel, turn on the Power button to start the appliance.

Note - For the Check Point 4800, when a power supply fails or is not connected to the outlet, an alarm sounds continuously. If you hear the alarm, replace the faulty power supply immediately, and connect the new unit to an A/C outlet ("Removing the Power Supply" on page 36).

CP_Toxotai_GettingStartedGuide_421 21CP_Toxotai_GettingStartedGuide_421 21 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Using the First Time Configuration Wizard

Page 22

3. Wait for the appliance to initialize and boot. The status of the appliance appears on the LCD screen:

The appliance is ready for use when the model number is displayed.

Using the First Time Configuration Wizard

Perform the initial configuration of Check Point 4000 Appliances using the First Time Configuration Wizard.

You can use the following commands at any time:

x Click Quit to exit.

x Click Next to move to the next page of the wizard.

Note - When running the First Time Configuration Wizard, you may not see all the windows that are described in this guide. The windows that appear in the wizard depend on the Check Point 4000 Appliances software image and the selections that you make.

CP_Toxotai_GettingStartedGuide_422 22CP_Toxotai_GettingStartedGuide_422 22 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Using the First Time Configuration Wizard

Configuring Check Point 4000 Appliances Page 23

Starting the First Time Configuration Wizard

To start the First Time Configuration Wizard:

1. Connect a standard network cable to the appliance's management interface and to your management network.

The management interface is marked MGMT. This interface is preconfigured with the IP address 192.168.1.1.

2. Connect to the management interface by connecting from a computer on the same network subnet as the management interface (for example, with IP address 192.168.1.x and net mask 255.255.255.0). This can be changed later through the WebUI.

3. To access the administration interface, initiate a connection from a browser to the default administration IP address: https://192.168.1.1:4434.

Note - Pop-ups must always be allowed on https://<appliance_ip_address>.

The login page appears.

4. Log in to the system using the default login name/password: admin/admin and click Login.

Note - The features configured in the wizard are accessible after completing the wizard via the WebUI menu. The WebUI menu can be accessed by navigating to https://<appliance_ip_address>:4434.

5. Change the administrator password, as prompted. The default password gives you access to the appliance. For security purposes, you must change it to a more secure password.

In the Password recovery login token section, you can download a Login Token that you can use if you forget the password. We highly recommended to save and safely store the password recovery login token file.

6. The First Time Configuration Wizard runs.

The First Time Configuration Wizard presents windows that help you to configure the appliance.

Welcome

The Welcome page summarizes the steps of the First Time Configuration Wizard.

Appliance Date and Time Setup

Configure date and time in the Date and Time Setup page. Click Apply.

CP_Toxotai_GettingStartedGuide_423 23CP_Toxotai_GettingStartedGuide_423 23 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Using the First Time Configuration Wizard

Page 24

Network Connections

Configure the network connections in the Network Connections page.

You can modify the Management IP address and connectivity is preserved. A secondary interface is created automatically to preserve connectivity. This interface can be removed after the wizard is completed in the Network > Network Connections page after the wizard is completed.

Routing Table

Configure the routing settings on the Routing Table page.

Host, Domain Settings, and DNS Servers

Set the Host, Domain and DNS Servers in the Host, Domain Settings, and DNS Servers page.

The host name must start with a letter and cannot be named com1, com2....com9.

In the DNS section, set the DNS servers for the appliance.

Management Type

Set how the appliance is managed in the Management Type page.

CP_Toxotai_GettingStartedGuide_424 24CP_Toxotai_GettingStartedGuide_424 24 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Using the First Time Configuration Wizard

Configuring Check Point 4000 Appliances Page 25

x Locally Managed - The simplest deployment, where the appliance includes Security

Management server functionality and manages the Security Policy.

x Centrally Managed - A more complex deployment, where the appliance is managed by a

Security Management server on a different machine.

Locally Managed Deployment

This section describes how to configure the appliance for locally managed deployment.

Check Point 4000 Appliances Cluster

Configure the cluster type. If you select This appliance is part of a Check Point 4000 Appliances Cluster, the options are:

x Primary cluster member

x Secondary cluster member

For information about clusters, see the ClusterXL Administration Guide (http://supportcenter.checkpoint.com) for your Check Point version.

Web/SSH and GUI Clients Configuration

Define the clients that are allowed to connect to the appliance using a web browser or SSH client. These clients can manage the appliance using a web or SSH connection.

You can define a Host according to Hostname or IP address. Enter a comma-separated list of IP addresses from which you manage the appliance. Enter Any to manage the appliance from anywhere.

Note - You should not use the Any value for security reasons.

After you complete the First Time Configuration Wizard, more options are available using the

WebUI menu.

Download SmartConsole Applications

Configuring a security policy requires you to install the SmartConsole applications. In the Download SmartConsole Applications window, you can download SmartConsole and install it on Windows machines.

The release notes of your Check Point version in the Check Point Support Center (http://supportcenter.checkpoint.com), lists compatible Windows operating systems for SmartConsole.

Centrally Managed Deployment

This section describes how to configure the appliance for centrally managed deployment.

CP_Toxotai_GettingStartedGuide_425 25CP_Toxotai_GettingStartedGuide_425 25 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Creating the Network Object

Page 26

Gateway Type

Configure the gateway type for a Centrally Managed appliance. Choose one of:

x Standard Gateway

x This Gateway is a member of a cluster

x This Gateway uses a dynamically assigned IP

Web/SSH and GUI Clients Configuration

Define the clients that are allowed to connect to the appliance using a web browser or SSH client. These clients can manage the appliance using a web or SSH connection.

You can define a Host according to Hostname or IP address. Enter a comma-separated list of IP addresses from which you manage the appliance. Enter Any to manage the appliance from anywhere.

Note - You should not use the Any value for security reasons.

After you complete the First Time Configuration Wizard, more options are available using the

WebUI menu.

SIC Setup

Configure the SIC (Secure Internal Communication) settings for a Centrally Managed appliance. Enter a SIC Activation Key. The same key is used by the gateway object in SmartDashboard.

Summary

The Summary page opens.

Click Finish to complete the First-Time Configuration Wizard. You can login to the appliance after several minutes.

Note - You should backup the system configuration. The Backup and Restore window can be accessed via the WebUI interface, Appliance

> Backup and Restore.

Creating the Network Object

Configure the Check Point 4000 Appliances as a gateway object in the Security Management Server database.

CP_Toxotai_GettingStartedGuide_426 26CP_Toxotai_GettingStartedGuide_426 26 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Advanced Configuration

Configuring Check Point 4000 Appliances Page 27

To create the network object in SmartDashboard:

1. Launch SmartDashboard.

2. Configure a new gateway object for the appliance.

3. Enter the IP address for the appliance.

4. For a centrally managed installation, establish Secure Internal Communication (SIC) using the activation key entered in the First Time Configuration Wizard.

5. Configure the topology.

6. Install the security policy.

Advanced Configuration

Advanced configuration can be done using the sysconfig menu which can be accessed using the command line interface only. For example, configuring the appliance to be a DHCP server.

Note - The sysconfig menu is only available after running the First Time Configuration Wizard in the WebUI.

CLI access can be obtained by console connection or through SSH.

Connecting to the CLI

You can connect to the command line interface of Check Point 4000 Appliances using:

x The provided serial console cable (DTE to DTE) and terminal emulation software such as

HyperTerminal (from Windows) or Minicom (from Unix/Linux systems).

Connection parameters for the appliance are: 9600bps, no parity, 1 stop bit (8N1).

x An SSH connection to the management interface (if SSHD is configured).

CP_Toxotai_GettingStartedGuide_427 27CP_Toxotai_GettingStartedGuide_427 27 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

CP_Toxotai_GettingStartedGuide_428 28CP_Toxotai_GettingStartedGuide_428 28 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Page 29

Chapter 4

Check Point 4000 Appliances Hardware

This chapter provides instructions for installing and removing hardware components on Check Point 4000 Appliances.

In This Chapter

Front Panel Components 29

Rear Panel Components 34

Customer Replaceable Parts 34

Front Panel Components

This section describes the features and components located on the appliance front panel.

Check Point Front 4200

Item

Description

Expansion line card slot

CP_Toxotai_GettingStartedGuide_429 29CP_Toxotai_GettingStartedGuide_429 29 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Front Panel Components

Page 30

Item

Description

Built in Ethernet ports (LAN1 - LAN3)

Management configuration port - Ethernet connection to a remote management workstation

USB ports

Console port - A serial connection to the appliance using a terminal emulation program such as HyperTerminal

Power indicator LED

LCD display screen

Keypad

Check Point 4600 Front Panel

Item

Description

Expansion line card slot

Built in Ethernet ports (LAN1 - LAN7)

Management configuration port - Ethernet connection to a remote management workstation

USB ports

Console port - A serial connection to the appliance using a terminal emulation program such as HyperTerminal

Power indicator LED

CP_Toxotai_GettingStartedGuide_430 30CP_Toxotai_GettingStartedGuide_430 30 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Front Panel Components

Check Point 4000 Appliances Hardware Page 31

Item

Description

LCD display screen

Keypad

Check Point 4800 Front Panel

Item

Description

Expansion line card slot

LOM Port

Built in Ethernet ports (LAN1 - LAN7)

Management configuration port - Ethernet connection to a remote management workstation

USB ports

Console port - A serial connection to the appliance using a terminal emulation program such as HyperTerminal

Power indicator LED

LCD display screen

Keypad

CP_Toxotai_GettingStartedGuide_431 31CP_Toxotai_GettingStartedGuide_431 31 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Front Panel Components

Page 32

Managing Check Point 4000 Appliances Using the LCD Panel

The appliance has an LCD panel that can be used to perform basic management operations. The management IP address, netmask, and default gateway of the appliance can be configured. The appliance can also be rebooted.

Menu Options

Sub-menu

Purpose

Network

DHCP

Enable or disable IP address allocation using DHCP

Set Mgmt IP

Set the management interface IP address

(cannot be edited when DHCP is enabled)

Set Netmask

Set the management interface network mask

(cannot be edited when DHCP is enabled)

Set Default GW

Set the management interface default gateway

(cannot be edited when DHCP is enabled)

System

Reboot

Reboot the appliance

LCD Panel Keys

Press

Enter the main menu

Navigate the menu

Change a number

Select a menu option

Go back to previous menu

CP_Toxotai_GettingStartedGuide_432 32CP_Toxotai_GettingStartedGuide_432 32 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Front Panel Components

Check Point 4000 Appliances Hardware Page 33

When Entering an IP Address

Press

Enter the grub menu

Move to the next digit

Move back to the previous digit

Approve the change

when the cursor is located on the last digit

Cancel the IP change

when the cursor is located on the first digit

Change current digit

Expansion Line Cards

Check Point 4000 Appliances contain one optional expansion slot that accommodates coldswappable network line cards. There are different types of expansion line cards which contain two, four, or eight ports. These types of expansion line cards are currently available:

Model

Description

CPAP-ACC-2-10F

2 Port 10GBase-F SFP+ (without transceivers)

CPAP-ACC-4-1C

4 Port 10/100/1000Base-T RJ-45

CPAP-ACC-4-1C-BP

4 Port 10/100/1000Base-T RJ-45 bypass

CPAP-ACC-4-1F

4 Port 1000Base-F SFP (without transceivers)

CPAP-ACC-4-1F-BP

4 Port 1000Base-F SFP bypass (without transceivers)

CPAP-ACC-8-1C

8 Port 10/100/1000Base-T RJ-45

CP_Toxotai_GettingStartedGuide_433 33CP_Toxotai_GettingStartedGuide_433 33 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Rear Panel Components

Page 34

Hard Disk Drives

The appliance contains one hard disk drive that is not hot-swappable. You must power off the appliance before removing or installing a hard disk drive.

Rear Panel Components

This section describes components located on the rear panel of the appliance.

Main Power Switch

The main power switch controls power to the entire unit.

Redundant Power Supply Units (Check Point 4800)

The Check Point 4800 has an optional redundant power supply unit. Located at the left rear of the appliance, two hot-swappable power supply units give built-in power redundancy. Each power supply connects to an electrical outlet.

For appliances that are provisioned with one power supply unit, use the placeholder unit in the other power supply slot. This diagram shows the 4800 model with the placeholder unit:

Note - If both power supply slots are not populated, a continuous alarm sounds.

If a power supply fails or is not connected to the outlet, an alarm sounds continuously.

Customer Replaceable Parts

To ensure maximum availability and ease of maintenance, the Check Point 4000 Appliances contain the following customer replaceable parts:

4200/4600

4800

Power supply slots

n/a

Expansion line card

Optional

CP_Toxotai_GettingStartedGuide_434 34CP_Toxotai_GettingStartedGuide_434 34 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Customer Replaceable Parts

Check Point 4000 Appliances Hardware Page 35

Unless directed to do so by Check Point technical support, customers are prohibited by warranty and support agreements from replacing any parts. Customers are prohibited from opening the appliance case under any circumstances.

Power Supply (Check Point 4800)

The Check Point 4800 appliance has an optional redundant power supply. This section explains how to remove and install a power supply or placeholder unit.

Note - If both power supply slots are not populated, a continuous alarm sounds.

Item

Description

Power supply unit

Extraction handle

Release lever

Power cord socket

Power switch

CP_Toxotai_GettingStartedGuide_435 35CP_Toxotai_GettingStartedGuide_435 35 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Customer Replaceable Parts

Page 36

Removing the Power Supply

This section describes how to remove a power supply or placeholder unit from a Check Point 4800 appliance.

To remove a power supply unit:

1. If the alarm sounds, press the red alarm button to the right of the power supply. The alarm stops.

2. Remove the power cord from the power supply unit.

3. Engage and hold the release lever on the power supply or placeholder unit.

4. Pull the extraction handle to remove the power supply or placeholder unit.

Note - Remove the power supply unit with the extraction handle to prevent any possible damage.

Installing the Power Supply

This section describes how to install a power supply or placeholder unit into a Check Point 4800 appliance.

To install a replacement power supply:

1. Insert the power supply or placeholder unit into the power supply slot.

2. Push the power supply or placeholder unit until the release lever clicks.

3. Insert the power cord into the power supply socket. Make sure that the green LED is illuminated.

CP_Toxotai_GettingStartedGuide_436 36CP_Toxotai_GettingStartedGuide_436 36 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Customer Replaceable Parts

Check Point 4000 Appliances Hardware Page 37

Expansion Line Card

This section presents the procedures for removing and installing an expansion line card unit. There are two types of expansion cards that can be installed: Ethernet or Fiber Optic ports. The built-in Ethernet ports (LAN1 - LAN8) are not customer replaceable.

Important - Make certain that you are electromagnetically grounded when performing the following procedures. Static electricity can damage the appliance.

Installing Expansion Line Cards

To install an expansion line card:

1. Power off the appliance and remove the power cords from the power supply units.

2. Loosen the retaining screws on either side of the metal cover on the front of the appliance.

3. Holding the screws, remove the metal cover.

4. Insert the expansion line card into the expansion slot.

5. Push until the card clicks into place.

6. Tighten the retaining screws on either side of the expansion line card.

Removing Expansion Line Cards

To remove an expansion line card:

1. Power off the appliance and remove the power cords from the power supply units.

2. Loosen the retaining screws on either side of the expansion line card.

3. Holding the screws, pull the expansion line card out of the expansion slot.

4. Place the metal cover over the expansion slot.

5. Tighten the screws on either side of the metal cover.

CP_Toxotai_GettingStartedGuide_437 37CP_Toxotai_GettingStartedGuide_437 37 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Customer Replaceable Parts

Page 38

CP_Toxotai_GettingStartedGuide_438 38CP_Toxotai_GettingStartedGuide_438 38 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Page 39

Chapter 5

Restoring Factory Defaults

As part of the troubleshooting process, it may be necessary to restore the appliance to its factory default settings.

You can restore your appliance to the factory default image using one of the following methods:

x Using the WebUI

x Through the console boot menu

x Using the LCD panel

Important - Restoring factory defaults deletes all information on the appliance.

In This Chapter

Restoring Using the WebUI 39

Restoring Using the Console Boot Menu 40

Restoring Using the LCD Panel 41

Restoring Using the WebUI

To restore the appliance to its default factory configuration using the WebUI:

1. In a Web browser, navigate to https://<appliance_ip_address>:4434

2. Log in to the WebUI of the appliance using your administrator username and password.

3. In the WebUI, click Appliance > Image Management.

The Image Management window opens:

4. Select the relevant image version you wish to revert to.

5. Click Revert.

CP_Toxotai_GettingStartedGuide_439 39CP_Toxotai_GettingStartedGuide_439 39 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Restoring Using the Console Boot Menu

Page 40

Restoring Using the Console Boot Menu

To restore the appliance to its default factory configuration using the console boot menu:

1. Connect the supplied DB9 serial cable to the console port on the front of the appliance.

2. Connect to the appliance using a terminal emulation program such as Microsoft HyperTerminal, the program used here.

3. In the HyperTerminal Connect To window, select a port from the Connect using list. Define the port settings: 9600 BPS, 8 bits, no parity, 1 stop bit.

4. From the Flow control list, select Hardware.

5. Click, Call > Call to connect to the appliance.

6. Switch on the appliance. The appliance begins the boot process and status messages appear in HyperTerminal.

7. During the boot process, text similar to that shown below appears:

8. At this point, you have approximately four seconds to hit any key to activate the Boot menu.

9. The Boot menu opens. Scroll to the relevant Reset to factory defaults image and press Enter.

CP_Toxotai_GettingStartedGuide_440 40CP_Toxotai_GettingStartedGuide_440 40 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Restoring Using the LCD Panel

Restoring Factory Defaults Page 41

Restoring Using the LCD Panel

To restore the appliance to its default factory configuration using the LCD Panel keys:

1. Reboot or power on the appliance.

2. When the countdown begins, press any of the arrow keys.

The Boot menu appears.

3. Using the arrow buttons, scroll to the relevant default factory image.

4. Press

5. Confirm the reset by pressing . Pressing any other button causes the Action Canceled message to display:

At this point, pressing any key returns you to the boot menu.

6. Once you have confirmed the reset, wait for the appliance to restore the factory image. While the appliance is restored to the default image, this message is continuously displayed: Reverting image don't turn off.

After the appliance is restored to its default factory configuration, the appliance reboots and the initializing message appears.

CP_Toxotai_GettingStartedGuide_441 41CP_Toxotai_GettingStartedGuide_441 41 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

CP_Toxotai_GettingStartedGuide_442 42CP_Toxotai_GettingStartedGuide_442 42 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Page 43

Chapter 6

Registration and Support

In This Chapter

Registration 43

Support 43

Where To From Here? 43

Registration

The appliance requires a product-specific Check Point license. Obtain a license and register at the Check Point Appliance Registration site (

http://register.checkpoint.com/cpapp).

Support

For additional technical information about Check Point products, consult the Check Point Support Center (http://supportcenter.checkpoint.com).

Where To From Here?

You have now learned the basics that you need to get started. The next step is to obtain more advanced knowledge of your Check Point software.

Check Point documentation is available on the Check Point Support Center (http://supportcenter.checkpoint.com).

Be sure to also use the Online Help when you are working with the Check Point SmartConsole clients.

CP_Toxotai_GettingStartedGuide_443 43CP_Toxotai_GettingStartedGuide_443 43 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

CP_Toxotai_GettingStartedGuide_444 44CP_Toxotai_GettingStartedGuide_444 44 05 July 2011 1:21:11 PM05 July 2011 1:21:11 PM

Page 45

Appendix A

Compliance Information

This appendix contains declaration of conformity, compliance, and related regulatory information.

In This Appendix

Declaration of Conformity 45

Declaration of Conformity

0DQXIDFWXUHU¶V1DPH

Check Point Software Technologies Ltd.

0DQXIDFWXUHU¶V$GGUHVV

5 Ha'Solelim Street, Tel Aviv 67897, Israel

Declare that under our sole responsibility the products

Model Number:

T-120, T-160, and T-180

Product Options:

All

Date First Applied:

July, 2011

Conforms to the following Product Specifications:

EMC

FCC, 47 CFR, Part 15, Class A
