Getting Started Manual
55 pgs1.56 Mb0

Check Point 4000, T-120, T-140, T-160, T-180 Getting Started Manual

...
Download
6 November 2012
Getting Started Guide
Check Point 4000
Appliances
Classification: [Protected] | P/N: 704879
© 2012 Check Point Software Technologies Ltd. All rights reserved. This product and related documentation are protected by copyright and
distributed under licensing restricting their use, copying, distribution, and decompilation. No part of this product or related documentation may be reproduced in any form or by any means without prior written authorization of Check Point. While every precaution has been taken in the preparation of this book, Check Point assumes no responsibility for errors or omissions. This publication and features described herein are subject to change without notice.
RESTRICTED RIGHTS LEGEND: Use, duplication, or disclosure by the government is subject to restrictions as set forth in
subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013 and FAR 52.227-19.
TRADEMARKS: Refer to the Copyright page (http://www.checkpoint.com/copyright.html) for a list of our
trademarks. Refer to the Third Party copyright notices
(http://www.checkpoint.com/3rd_party_copyright.html) for a list of relevant copyrights and third­party licenses.
Important Information
Latest Software
We recommend that you install the most recent software release to stay up-to-date with the latest functional improvements, stability fixes, security enhancements and protection against new and evolving attacks.
Latest Documentation
The latest version of this document is at:
http://supportcontent.checkpoint.com/documentation_download?ID=12688
For additional technical information, visit the Check Point Support Center (http://supportcenter.checkpoint.com).
For more about this appliance, see the Check Point 4000 Appliances home page (http://supportcontent.checkpoint.com/solutions?id=sk68681).
Revision History
Date
Description
06 November 2012
Deleted Hard Disk Drives from Front Panel Components (on page 39). You cannot replace the hard disk drive on this appliance .
18 July 2012
Added First Time Wizard for Gaia  Deleted Customer Replaceable Parts
31 October 2011
Updated Flow Control settings in Connecting to the CLI (on page
38) and Restoring Using the Console Boot Menu (on page 48)
15 August 2011
First release of this document
Feedback
Check Point is engaged in a continuous effort to improve its documentation. Please help us by sending your comments
(mailto:cp_techpub_feedback@checkpoint.com?subject=Feedback on Check Point 4000
Appliances Getting Started Guide).
Safety, Environmental, and Electronic Emissions Notices
4 | Check Point 4000 Appliances Getting Started Guide
Safety, Environmental, and Electronic Emissions Notices
Read the following warnings before setting up or using the appliance.
Warning - Do not block air vents. A minimum 1/2-inch clearance is required.
Warning - This appliance does not contain any user-serviceable parts. Do not remove any covers or attempt to gain access to the inside of the product. Opening the device or modifying it in any way has the risk of personal injury and will void your warranty. The following instructions are for trained service personnel only.
To prevent damage to any system board, it is important to handle it with care. The following measures are generally sufficient to protect your equipment from static electricity discharge:
When handling the board, to use a grounded wrist strap designed for static discharge
elimination.
Touch a grounded metal object before removing the board from the antistatic bag.  Handle the board by its edges only. Do not touch its components, peripheral chips, memory
modules or gold contacts.
When handling processor chips or memory modules, avoid touching their pins or gold edge
fingers.
Restore the communications appliance system board and peripherals back into the
antistatic bag when they are not in use or not installed in the chassis. Some circuitry on the system board can continue operating even though the power is switched off.
Under no circumstances should the lithium battery cell used to power the real-time clock be
allowed to short. The battery cell may heat up under these conditions and present a burn hazard.
Warning - DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.
Disconnect the system board power supply from its power source before you connect or
disconnect cables or install or remove any system board components. Failure to do this can result in personnel injury or equipment damage.
Safety, Environmental, and Electronic Emissions Notices
Check Point 4000 Appliances Getting Started Guide | 5
Avoid short-circuiting the lithium battery; this can cause it to superheat and cause burns if
touched.
Do not operate the processor without a thermal solution. Damage to the processor can
occur in seconds.
Class 1 Laser Product Warning
Rack Mount Instructions
The following or similar rack-mount instructions are included with the installation instructions:
1. Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. Therefore, consideration should be given to installing the equipment in an environment compatible with the maximum ambient temperature specified by the manufacturer.
2. Reduced Air Flow - Installation of the equipment in a rack should be such that the amount of air flow required for safe operation of the equipment is not compromised.
3. Mechanical Loading - Mounting of the equipment in the rack should be such that a hazardous condition is not achieved due to uneven mechanical loading.
4. Circuit Overloading - Consideration should be given to the connection of the equipment to the supply circuit and the effect that overloading of the circuits might have on over current protection and supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.
5. Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (e.g. use of power strips).
For California:
Perchlorate Material - special handling may apply. See
http://www.dtsc.ca.gov/hazardouswaste/perchlorate The foregoing notice is provided in accordance with California Code of Regulations Title 22,
Division 4.5, Chapter 33. Best Management Practices for Perchlorate Materials. This product, part, or both may include a lithium manganese dioxide battery which contains a perchlorate substance.
Proposition 65 Chemical Chemicals identified by the State of California, pursuant to the requirements of the California
Safe Drinking Water and Toxic Enforcement Act of 1986, California Health & Safety Code s.
25249.5, et seq. ("Proposition 65"), that is "known to the State to cause cancer or reproductive
toxicity" (see http://www.calepa.ca.gov) WARNING: Handling the cord on this product will expose you to lead, a chemical known to the State of
California to cause cancer, and birth defects or other reproductive harm. Wash hands after handling.
Safety, Environmental, and Electronic Emissions Notices
6 | Check Point 4000 Appliances Getting Started Guide
Federal Communications Commission (FCC) Statement: For a Class A digital device or peripheral
Note: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
For a Class B digital device or peripheral
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Information to user:
The user's manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. In cases where the manual is provided only in a form other than paper, such as on a computer disk or over the Internet, the information required by this section may be included in the manual in that alternative form, provided the user can reasonably be expected to have the capability to access information in that form.
Canadian Department Compliance Statement:
This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Safety, Environmental, and Electronic Emissions Notices
Check Point 4000 Appliances Getting Started Guide | 7
Japan Compliance Statement: Class A
Class B
European Union (EU) Electromagnetic Compatibility Directive
This product is herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility Directive (2004/108/EC). For the evaluation regarding the Electromagnetic Compatibility (2004/108/EC)
This product is in conformity with Low Voltage Directive 2006/95/EC, and complies with the requirements in the Council Directive 2006/95/EC relating to electrical equipment designed for use within certain voltage limits and the Amendment Directive 93/68/EEC.
Safety, Environmental, and Electronic Emissions Notices
8 | Check Point 4000 Appliances Getting Started Guide
Product Disposal
This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. For more information about where you can drop off your waste equipment for recycling, please contact your local city office or your household waste disposal service.
Contents
Important Information ............................................................................................. 3
Safety, Environmental, and Electronic Emissions Notices .................................. 4
Introduction ........................................................................................................... 11
Welcome ............................................................................................................11
Check Point 4000 Appliances Overview .............................................................11
Upgrading the Appliance ................................................................................12
Shipping Carton Contents...................................................................................13
Terminology........................................................................................................13
Rack Mounting ...................................................................................................... 15
4800 Appliances .................................................................................................15
Sliding Rails Hardware ...................................................................................15
Attaching the Appliance Rails ........................................................................16
Preparing Round-Hole Rack Rails .................................................................17
Attaching the Rack Rails ................................................................ ................18
Installing the Appliance in the Rack ...............................................................20
Removing the Appliance ................................................................ ................20
Appliance Air Vents .......................................................................................21
4200, 4400, and 4600 Appliances ......................................................................21
Rack Mounting Hardware and Tools ..............................................................21
Attaching the Ear Mount Brackets to the Appliance .......................................22
Attaching the Rail Plates ................................................................ ................23
Attaching the Appliance Rails to the Appliance ..............................................24
Installing the Appliance in the Rack ...............................................................26
Configuring Check Point 4000 Appliances ......................................................... 27
Powering On.......................................................................................................27
Available Software Images .................................................................................28
Initial Configuration .............................................................................................28
Using the First Time Configuration Wizard on Gaia ............................................29
Starting the Gaia First Time Configuration Wizard .........................................29
Welcome ........................................................................................................29
Available Releases ........................................................................................30
Authentication Details ....................................................................................30
Date and Time Setup .....................................................................................30
Device Name .................................................................................................30
Network Connection.......................................................................................31
Products ........................................................................................................31
Security Management Administrator ..............................................................32
Security Management GUI Clients ................................................................. 32
License Activation .......................................................................................... 33
Dynamically Assigned IP ............................................................................... 33
Secure Internal Communication (SIC) ............................................................ 33
Summary ....................................................................................................... 33
Using the First Time Configuration Wizard on SecurePlatform ........................... 34
Starting the First Time Configuration Wizard .................................................. 34
Welcome ....................................................................................................... 35
Appliance Date and Time Setup .................................................................... 35
Network Connections ..................................................................................... 35
Routing Table ................................................................................................ 35
Host, Domain Settings, and DNS Servers ...................................................... 35
Management Type ......................................................................................... 36
Summary ....................................................................................................... 37
Creating the Network Object .............................................................................. 38
Advanced Configuration ..................................................................................... 38
Connecting to the CLI ................................................................ .................... 38
Check Point 4000 Appliances Hardware ................................ ............................. 39
Front Panel Components .................................................................................... 39
Check Point 4200 Front Panel ....................................................................... 39
Check Point 4400 and 4600 Front Panel ....................................................... 40
Check Point 4800 Front Panel ....................................................................... 41
Using the LCD Panel ..................................................................................... 42
Expansion Line Cards .................................................................................... 44
Rear Panel Components .................................................................................... 44
Main Power Switch ........................................................................................ 45
Redundant Power Supply Units (Check Point 4800) ...................................... 45
Replacing and Upgrading Components .............................................................. 45
Restoring Factory Defaults .................................................................................. 47
Restoring Using the WebUI ................................................................................ 47
Gaia ............................................................................................................... 47
SecurePlatform .............................................................................................. 47
Restoring Using the Console Boot Menu ............................................................ 48
Restoring Using the LCD Panel .......................................................................... 49
Registration and Support ................................................................ ..................... 51
Registration ................................................................ ........................................ 51
Support .............................................................................................................. 51
Where To From Here?........................................................................................ 51
Compliance Information ....................................................................................... 53
Declaration of Conformity ................................................................................... 53
Check Point 4000 Appliances Getting Started Guide | 11
Chapter 1
Introduction
In This Chapter
Welcome 11 Check Point 4000 Appliances Overview 11 Shipping Carton Contents 13 Terminology 13
Welcome
Thank you for choosing Check Point 4000 Appliances. We hope that you will be satisfied with this system and our support services. Check Point products provide your business with the most up to date and secure solutions available today.
Check Point also delivers worldwide technical services including educational, professional and support services through a network of Authorized Training Centers, Certified Support Partners and Check Point technical support personnel to ensure that you get the most out of your security investment.
For additional information on the Internet Security Product Suite and other security solutions, refer to the Check Point Web site (http://www.checkpoint.com), or call Check Point at 1(800) 429-4391. For additional technical information about Check Point products, consult the Check Point Support Center (http://supportcenter.checkpoint.com).
Welcome to the Check Point family. We look forward to meeting all of your current and future network, application and management security needs.
Check Point 4000 Appliances Overview
The Check Point 4000 Appliances enables organizations to maximize security in high­performance environments such as large campuses or data centers. Combining integrated firewall, IPsec VPN, and intrusion prevention with advanced acceleration technologies, Check Point 4000 Appliances delivers a high-performance security platform that can block application layer threats. Even as new threats appear, Check Point 4000 Appliances maintains or increases performance while protecting the network against attacks.
Introduction
12 | Check Point 4000 Appliances Getting Started Guide
This appliance supports the SecurePlatform and Gaia Operating Systems. Gaia is a single, unified network security Operating System that combines the best of Check Point's SecurePlatform and IPSO, the operating system from the Nokia security products. Gaia supports the full portfolio of Check Point Software Blades, Security Gateway and Security Management products.
Key Features:
Proven, enterprise-class firewall, VPN, and intrusion prevention  Accelerated security performance, that includes SecureXL and CoreXL technologies  Integrated load balancing and dynamic routing for data center reliability levels  Centrally managed from Security Management Server/Check Point 4000 Appliances or as
a standalone device
Automatic security protection updates from Check Point
This document provides:
A brief overview of essential Check Point 4000 Appliances concepts and features  A step by step guide to getting Check Point 4000 Appliances up and running
Note - Screenshots in this guide may apply only to the highest model to which this guide applies.
Upgrading the Appliance
You can upgrade these components of the Check Point 4000 Appliances:
Memory DIMMs (4800 only)  LOM card (4800 only)  Appliance firmware
Important - You cannot upgrade the appliance firmware while using the 15 days trial license.
For more information about upgrading the appliance, see the applicable documentation (http://supportcontent.checkpoint.com/solutions?id=sk68681).
4800 Appliance Installing and Removing Memory 4800 and 12000 Appliances Installing and Removing a LOM Card 4000 Appliances Image Management 4000 and 12000 Appliances Mounting Appliances with Sliding Rails
Introduction
Check Point 4000 Appliances Getting Started Guide | 13
Shipping Carton Contents
This section describes the contents of the shipping carton.
Item
Description
Appliance
Check Point 4000 Appliance
Rack Mounting Accessories
Hardware mounting kit
Cables
Power cable  1 Standard RJ-45 network cable  1 Serial console cable
Documentation
Quick Start Guide  Getting Started Guide  Image Management Guide  User license agreement
Terminology
The following terms are used in this guide: Gateway: The security engine that enforces the organization’s security policy and acts as a
security enforcement point.
Security Policy: The policy created by the system administrator that regulates the flow of
incoming and outgoing communication.
Security Management Server: The server used by the system administrator to manage
the security policy. The organization’s databases and security policies are stored on the
Security Management Server and downloaded to the gateway.
SmartConsole: GUI applications that are used to manage various aspects of security
policy enforcement. For example, SmartView Tracker is a SmartConsole application that manages logs.
SmartDashboard: A SmartConsole GUI application that is used by the system
administrator to create and manage the security policy.
Locally Managed Deployment: When all Check Point components responsible for both
the management and enforcement of the security policy (the Security Management Server and the gateway) are installed on the same machine.
Centrally Managed Deployment: When the gateway and the Security Management
Server are installed on separate machines.
Check Point 4000 Appliances Getting Started Guide | 15
Chapter 2
Rack Mounting
In This Chapter
4800 Appliances 15 4200, 4400, and 4600 Appliances 21
This chapter describes how to mount the appliance in a rack.
Important - Two people are required to install the appliance in a rack in order to prevent any possible damage.
4800 Appliances
Use sliding rails to mount 4800 Appliances in a rack.
Sliding Rails Hardware
Rack Mounting
16 | Check Point 4000 Appliances Getting Started Guide
Item
Hardware Description
Qty.
Use
1
Appliance rail
2
Attaches to the sides of the appliance.
Flat-head screws
6
Attaches the appliance rails to the appliance.
2
Rack rail
2
Attaches to the rack.
Round-head screws
4
Attaches the rack rails to the racks.
3
Round-hole rack plates
4
For use with round-hole racks. Attaches the rack rails to racks with round-holes.
Large round-head screws
12
Attaches the round-hole rack plates to the racks.
Rack Mounting Tools
Philips screwdriver. We recommend a screwdriver with a magnetic head to hold screws and retrieve dropped screws.
Attaching the Appliance Rails
Use three flat-head screws to attach each appliance rail to the side of the appliance.
The appliance rail for the right-side of the appliance is marked RH.  The appliance rail for the left-side of the appliance is marked LH.
Item
Description
1
End of appliance rail with round hole.
Rack Mounting
Check Point 4000 Appliances Getting Started Guide | 17
Item
Description
2
Front of appliance.
To attach the appliance rails:
1. Set the right-side appliance rail on the right-side of the appliance.
The flatter side of the appliance rail faces the appliance.  The end of the appliance rail with the round hole points away from the appliance.  For a 2U appliance, the appliance rail uses the lower row of holes on the appliance.
2. Use three flat-head screws to attach the appliance rail to the appliance.
3. Do steps 1 and 2 again for the left side of the appliance.
Preparing Round-Hole Rack Rails
Use the four round-hole rack plates to attach the rack rail to the rack.
To attach the round-hole rack plates:
1. Align the round-hole rack plate on the rack. Make sure that the round holes face the rack.
2. Use three large round-head screws to attach the round-hole rack plate to the rack. Make sure that you use the same rack number for all the round-hole rack plates.
3. Do steps 1 - 2 again for the other round-hole rack plates.
Rack Mounting
18 | Check Point 4000 Appliances Getting Started Guide
Attaching the Rack Rails
Attach the rack rails to the rack. If you are using round-hole racks, make sure that the round­hole rack plates are attached. For more about attaching round-hole rack plates, see Preparing Round-Hole Rack Rails (on page 17).
The rack rail for the left-side of the rack is marked LH.  The rack rail for the right-side of the rack is marked RH.
Item
Description
1
Inner clips. Press on these clips to detach the rack rail from the rack.
2
Yellow locking piece. When engaged, locks the front of the rack rail and you cannot detach it from the rack.
Note - Disengage the yellow locking piece before you attach the rack rails to the rack. When this piece is engaged, you cannot insert the front of the rack rail into the rack.
To attach the rack rails to the rack:
1. From the front left-side of the rack, align the front of the left rack rail with the rack number.
The front of the rack rail is marked with the word FRONT.  Make sure that the sliding rail faces the inside of the rack.  To detach the rack rail from the rack, use your thumbs to press the inner clips and
move the rack rail away from the rack.
Rack Mounting
Check Point 4000 Appliances Getting Started Guide | 19
2. Insert the front of the left rack rail into the rack until it clicks into place.
3. From the rear of the rack, align the rear of the rack rail with the same rack number. The rear of the rack rail is marked with the word REAR.
4. Insert the rear of the left rack rail into the rack until it clicks into place.
5. From the rear of the rack, use a round-head screw to secure the rack rail to the rack.
6. From the front of the rack, do these steps. a) Use a round-head screw to secure the rack rail to the rack. b) Slide the yellow locking piece toward the front of the rack.
Rack Mounting
20 | Check Point 4000 Appliances Getting Started Guide
This piece locks the inner clips and does not let you detach the front of the rack rail from the rack.
7. Do steps 1 through 6 again for the right rack rail.
Installing the Appliance in the Rack
Install the appliance in the sliding rails in the rack.
Important - The appliance is heavy and it is necessary to use two people to hold and install the appliance in the rack to prevent personal injury and damage to the appliance.
To install the appliance in the rack:
1. Set the appliance until the appliance rails are level with the rack rails.
2. Move the appliance into the rack until the sliding rails click. The sliding rails are locked.
Removing the Appliance
Unlock the sliding rails to remove the appliance from the rack.
Important - The appliance is heavy and it is necessary to use two people to hold and install the appliance in the rack to prevent personal injury and damage to the appliance.
Item
Description
1
Release clip
2
Rear of rack rail
To remove the appliance from the rack:
1. Move the appliance away from the rack as far as possible.
2. On the appliance rail, push the release lever and move the appliance away from the rack rail.
Rack Mounting
Check Point 4000 Appliances Getting Started Guide | 21
3. Push the release clips and move the rack rails into the rack as far as possible.
Appliance Air Vents
Make sure that the appliance air vents have sufficient airflow when the appliance is mounted in a rack.
Important - If the appliance vents are blocked, the appliance can become too hot and can be damaged.
The rails do not block air flow to the appliance. These appliances are specifically designed to install with these rails. They have been tested in extreme conditions and meet all specifications and requirements.
4200, 4400, and 4600 Appliances
Use fixed rails to mount 4200, 4400, and 4600 Appliances in a rack.
Rack Mounting Hardware and Tools
You must install rack mounting hardware on the appliance before you mount it in a rack.
Hardware Description
Qty.
Use
Ear mount bracket
2
Attaches to the appliance front panel. Both ear mount brackets are identical.
Ear mount screws
6
Secures the ear mount brackets to the appliance front panel. These screw heads are smaller (5 mm).
Appliance rail
2
Attaches to the appliance. Both rails are identical.
Rail plates
2
Attaches to the appliance rails. Both plates are identical.
Appliance rail screws
14
Secures the rail plates to the appliance rails and the rails to the appliance. These screw heads are larger (8 mm).
Rack Mounting
22 | Check Point 4000 Appliances Getting Started Guide
Rack Mounting Tools
Philips screwdriver. A magnetic head is recommended to hold screws in place and retrieve
dropped screws. A powered screwdriver is also useful.
Note - Screws to attach the ear mount brackets and rail plates to the rack are not included.
Attaching the Ear Mount Brackets to the Appliance
Attach the two ear mount brackets to the front of the appliance.
Note - The ear mount screws have 5 mm heads.
To attach the ear mount brackets to the appliance:
1. Attach the appliance ear bracket to one side of the appliance using three ear mount screws.
2. Do step 1 again for the other side of the appliance.
Rack Mounting
Check Point 4000 Appliances Getting Started Guide | 23
Attaching the Rail Plates
Attach the rail plates to the appliance rails to connect the appliance to the rear vertical rails of the rack.
Item
Description
1
Appliance rail
2
Rail plate
Note - The appliance rail screws have 8 mm heads.
To attach the rail plates:
1. Attach a rail plate to an appliance rail using two appliance rail screws.
Rack Mounting
24 | Check Point 4000 Appliances Getting Started Guide
2. Do step 1 again for the other rail plate and appliance rail.
Attaching the Appliance Rails to the Appliance
Attach the appliance rails to the sides of the appliance. Align the rail plates to connect the appliance rails to the rear of the rack.
Note - The appliance rail screws have 8 mm heads.
Rack Mounting
Check Point 4000 Appliances Getting Started Guide | 25
To attach the appliance rails:
1. Set the appliance rail on the side of the appliance. The ridges on the appliance rails point to the appliance.
2. Attach the appliance rails to the appliance using three appliance rail screws.
3. Do steps 1 and 2 again for the other side of the appliance.
Rack Mounting
26 | Check Point 4000 Appliances Getting Started Guide
Installing the Appliance in the Rack
Install the appliance in the rack. It may be necessary to adjust the appliance rails to secure the appliance to the rack.
Important - Two people are required to install the appliance in a rack in order to prevent any possible damage.
To install the appliance in the rack:
1. Attach the ear mount brackets to the front of the rack.
2. Attach the rail plates to the rear of the rack.
3. Confirm that the appliance is stable and secure in the rack.
Check Point 4000 Appliances Getting Started Guide | 27
Chapter 3
Configuring Check Point 4000 Appliances
In This Chapter
Powering On 27 Available Software Images 28 Initial Configuration 28 Using the First Time Configuration Wizard on Gaia 29 Using the First Time Configuration Wizard on SecurePlatform 34 Creating the Network Object 38 Advanced Configuration 38
The workflow for configuring Check Point 4000 Appliances is:
1. Connect the cables and power on the appliance.
2. Use the First Time Configuration Wizard to configure the appliance.
3. Add the Check Point 4000 Appliances object in SmartDashboard and install a policy.
Powering On
To power on Check Point 4000 Appliances:
1. Connect the power cable.
2. On the back panel, turn on the Power button to start the appliance.
Note - For the Check Point 4800, when a power supply fails or is not connected to the outlet, an alarm sounds continuously. If you hear the alarm, replace the faulty power supply immediately, and connect the new unit to an A/C outlet.
Configuring Check Point 4000 Appliances
28 | Check Point 4000 Appliances Getting Started Guide
3. Wait for the appliance to initialize and boot. The status of the appliance appears on the LCD screen:
The appliance is ready for use when the model number is displayed.
Available Software Images
Check Point 4000 Appliances comes with multiple software images. Select the software image that you want to use.
Reverting to a software image takes a few minutes. To follow the progress and see when the appliance is ready, connect to the appliance using a serial console.
For more about software images, see the Check Point 4000 Appliances home page (http://supportcontent.checkpoint.com/solutions?id=sk68681).
Note - Gaia is available for R75.40 and higher.
Initial Configuration
Do the initial configuration of the appliance with the First Time Configuration Wizard. There are different First Time Configuration Wizard options for the Gaia and the
SecurePlatform operating system. Go to the applicable section:
Using the First Time Configuration Wizard on Gaia (on page 29)  Using the First Time Configuration Wizard on SecurePlatform (on page 34)
Configuring Check Point 4000 Appliances
Check Point 4000 Appliances Getting Started Guide | 29
Using the First Time Configuration Wizard on Gaia
Use the First Time Configuration Wizard to do the initial configuration of the Gaia appliance.
Note - The pages that you see in the wizard depend on the software image and the options you select. You will not see all the pages that are in this section.
Starting the Gaia First Time Configuration Wizard
To start the First Time Configuration Wizard:
1. Connect a standard network cable to the appliance management interface and to your management network.
The management interface is marked MGMT. This interface is preconfigured with the IP address 192.168.1.1.
2. Connect to the management interface from a computer on the same network subnet. For example: IP address 192.168.1.x and net mask 255.255.255.0. This can be
changed in the WebUI, after you complete the First Time Configuration Wizard.
3. To access the management interface, open a connection from a browser to the default management IP address: https://192.168.1.1
4. The login page opens. Log in to the system using the default username and password: admin and admin
5. Click Login.
Note - The features configured in the First Time Configuration Wizard are accessible after completing the wizard using the WebUI menu. The WebUI menu can be accessed by navigating to https://<appliance_ip_address>.
6. The First Time Configuration Wizard runs.
Welcome
The Welcome page summarizes the steps of the First Time Configuration Wizard.
Configuring Check Point 4000 Appliances
30 | Check Point 4000 Appliances Getting Started Guide
Available Releases
The appliance comes with different software images. Select the software image that you want to install. You can change to another software image after the First Time Configuration Wizard is completed.
If you select a SecurePlatform software image, use the SecurePlatform First Time Configuration Wizard to configure the appliance.
Authentication Details
The default password gives you access to the appliance. For security purposes, change it to a more secure password.
Date and Time Setup
Set the system time and date for the appliance:
Manually  From a time server, using Network Time Protocol (NTP)
Device Name
Set the host name, domain name, and DNS servers for IPv4 addresses. The host name must
start with a letter and cannot be named com1, com2....com9.
You can use the Gaia WebUI to configure IPv6 DNS servers.
Configuring Check Point 4000 Appliances
Check Point 4000 Appliances Getting Started Guide | 31
Network Connection
Connection Information - Configure the IPv4 interface information for the management interface. You can change the Management IP address. Connectivity is maintained with an automatically created secondary interface. After you complete the First Time Configuration Wizard, you can remove this interface in the Interface Management > Network Interfaces page.
DHCP Server - You can configure the Gaia appliance to be a Dynamic Host Configuration Protocol (DHCP) server.
To define a DHCP server on the Gaia appliance MGMT interface:
1. In DHCP Server, select Enabled.
2. Define the IP Pool. This is the range of IPv4 addresses that the server assigns to hosts.
Products
Products
Select the Gaia products that are installed on the appliance.
Advanced
Use these options to configure an appliance that is a cluster member or in a High Availability deployment.
Unit is part of a cluster - the options are:
ClusterXL - For more about ClusterXL configurations, see the applicable version of the
ClusterXL Administration Guide.
Configuring Check Point 4000 Appliances
32 | Check Point 4000 Appliances Getting Started Guide
VRRP - For more about VRRP clusters, see the applicable version of the Gaia
Administration Guide.
Define Security Management as - In a Management High Availability deployment, define
this Security Management server as Primary or Secondary. For more about Management High Availability, see the applicable version of the Security Management Administration Guide.
Search for these guides in the Support Center (http://supportcontent.checkpoint.com/solutions?id=sk76540).
Security Management Administrator
Note - You only see this page when the Gaia appliance is a Security Management server.
Define the name and password of an administrator that can connect to the Security Management server using SmartConsole clients.
Security Management GUI Clients
Note - You see this page when the appliance is a Security Management.
Configuring Check Point 4000 Appliances
Check Point 4000 Appliances Getting Started Guide | 33
Define the clients that are allowed to connect to the appliance using a web browser or SSH client. These clients can manage the appliance using a web or SSH connection. For security reasons, we recommend that you do not use the Any IP address option.
License Activation
If you have a license for the appliance, you can automatically add the license to the appliance. If you need to obtain a license, visit the User Center (https://usercenter.checkpoint.com).
Select Activate later to use the limited trial license. This license is not permanent and expires.
To activate a license:
1. For a Security Gateway in a distributed configuration, enter the IP address of the Security Management server.
2. If there is a proxy server, select Use a proxy server and enter the settings.
3. Click Activate License.
Dynamically Assigned IP
Note - You see this page when the appliance is a Security Gateway.
A Dynamically Assigned IP (DAIP) gateway is a gateway where the external interface IP address is assigned dynamically by the ISP.
Select this option if this Security Gateway uses dynamically assigned IP addresses.
Secure Internal Communication (SIC)
Define the Secure Internal Communication (SIC) Activation Key. The same key is used by the gateway object in SmartDashboard.
Summary
Click Finish to complete the First Time Configuration Wizard and configure the appliance. You can log in to the WebUI after some minutes.
Note - We recommend that you back up the system configuration. You can use the Gaia add backup command.
Configuring Check Point 4000 Appliances
34 | Check Point 4000 Appliances Getting Started Guide
Using the First Time Configuration Wizard on SecurePlatform
Do the initial configuration of the SecurePlatform appliance with the First Time Configuration Wizard.
Note - The pages that you see in the wizard depend on the software image and the options you select. You will not see all the pages that are in this section.
Starting the First Time Configuration Wizard
To start the First Time Configuration Wizard:
1. Connect a standard network cable to the appliance's management interface and to your management network.
The management interface is marked MGMT. This interface is preconfigured with the IP address 192.168.1.1.
2. Connect to the management interface, from a computer on the same network subnet as the management interface.
For example: IP address 192.168.1.x and netmask 255.255.255.0. This can be changed in the WebUI.
3. To access the management interface, open a connection from a browser to the default management IP address: https://192.168.1.1:4434.
Note - Pop-ups must always be allowed on https://<appliance_ip_address>.
The login page opens.
4. Log in to the system using the default login name/password: admin/admin and click Login.
Note - The features configured in the wizard are accessible after completing the wizard via the WebUI menu. The WebUI menu can be accessed by navigating to https://<appliance_ip_address>:4434.
5. Change the administrator password, as prompted. The default password gives you access to the appliance. For security purposes, you must change it to a more secure password.
In the Password recovery login token section, download a Login Token to use if you forget the password. We recommend that you save the password recovery login token file in a safe storage.
Configuring Check Point 4000 Appliances
Check Point 4000 Appliances Getting Started Guide | 35
6. The First Time Configuration Wizard runs.
Welcome
The Welcome page summarizes the steps of the First Time Configuration Wizard.
Appliance Date and Time Setup
Configure date and time in the Date and Time Setup page. Click Apply.
Network Connections
Configure the network connections in the Network Connections page.
You can change the Management IP address. Connectivity is maintained with an automatically created secondary interface. You can remove this interface after you complete the First Time Configuration Wizard in the Network > Network Connections page.
Routing Table
Configure the routing settings on the Routing Table page.
Host, Domain Settings, and DNS Servers
Set the Host, Domain and DNS Servers in the Host, Domain Settings, and DNS Servers page.
The host name must start with a letter and cannot be named com1, com2....com9.
In the DNS section, set the DNS servers for the appliance.
Configuring Check Point 4000 Appliances
36 | Check Point 4000 Appliances Getting Started Guide
Management Type
Set how the appliance is managed in the Management Type page. Locally Managed Deployment: The appliance is a Security Gateway and a Security
Management server. The Security Management server manages the Security Policy that is enforced by the Security Gateway.
Centrally Managed Deployment: The appliance is a Security Gateway, without a Security
Management server. The Security Gateway is managed by a remote Security Management server.
Locally Managed Deployment
This section describes how to configure the appliance for locally managed deployment.
Check Point Cluster
Configure the cluster type. If you select This appliance is part of a Check Point 4000 Appliances Cluster, the options are:
Primary cluster member Secondary cluster member
For information about clusters, see the ClusterXL Administration Guide (http://supportcenter.checkpoint.com) for your Check Point version.
Web/SSH and GUI Clients Configuration
Define the clients that are allowed to connect to the appliance using a web browser or SSH client. These clients can manage the appliance using a web or SSH connection.
You can define a Host according to Hostname or IP address. Enter a comma-separated list of IP addresses from which you manage the appliance. Enter Any to manage the appliance from anywhere.
Note - Do not use the Any value for security reasons.
After you complete the First Time Configuration Wizard, more options are available using the WebUI menu.
SIC Setup
Configure the SIC (Secure Internal Communication) settings for a Centrally Managed appliance. Enter a SIC Activation Key. The same key is used by the gateway object in SmartDashboard.
Configuring Check Point 4000 Appliances
Check Point 4000 Appliances Getting Started Guide | 37
Download SmartConsole Applications
Configuring a security policy for a Locally Managed Check Point 4000 Appliances (configured in the Management Type page) requires you to install the SmartConsole applications. In the Download SmartConsole Applications window, you can download SmartConsole and install it on Windows machines.
The release notes of your Check Point version in the Check Point Support Center (http://supportcenter.checkpoint.com), lists compatible Windows operating systems for SmartConsole.
Centrally Managed Deployment
This section describes how to configure the appliance for centrally managed deployment.
Web/SSH and GUI Clients Configuration
Define the clients that are allowed to connect to the appliance using a web browser or SSH client. These clients can manage the appliance using a web or SSH connection.
You can define a Host according to Hostname or IP address. Enter a comma-separated list of IP addresses from which you manage the appliance. Enter Any to manage the appliance from anywhere.
Note - Do not use the Any value for security reasons.
After you complete the First Time Configuration Wizard, more options are available using the WebUI menu.
Gateway Type
Configure the gateway type for a Centrally Managed Check Point 4000 Appliances.
SIC Setup
Configure the SIC (Secure Internal Communication) settings for a Centrally Managed appliance. Enter a SIC Activation Key. The same key is used by the gateway object in SmartDashboard.
Summary
The Summary page opens. Click Finish to complete the First Time Configuration Wizard. You can log in to the appliance
after some minutes.
Note - You should back up the system configuration. Open the WebUI interface and go to Appliance > Backup and Restore.
Configuring Check Point 4000 Appliances
38 | Check Point 4000 Appliances Getting Started Guide
Creating the Network Object
Configure the Check Point 4000 Appliances as a gateway object in the Security Management Server database.
To create the network object in SmartDashboard:
1. Launch SmartDashboard.
2. Configure a new gateway object for the appliance.
3. Enter the IP address for the appliance.
4. For a centrally managed installation, establish Secure Internal Communication (SIC) using the activation key entered in the First Time Configuration Wizard.
5. Configure the topology.
6. Install the security policy.
Advanced Configuration
Advanced configuration on Gaia
Advanced configuration on Gaia can be done using the WebUI or the CLI.
Advanced configuration on SecurePlatform
Advanced configuration on SecurePlatform can be done using the sysconfig menu from the CLI.
Note - The sysconfig menu is only available after running the First Time Configuration Wizard in the WebUI.
Connecting to the CLI
After you complete the First Time Configuration Wizard, you can connect to the CLI (command line interface) of a Check Point 4000 Appliances using:
The provided serial console cable (DTE to DTE)  Terminal emulation software such as HyperTerminal and PuTTY (from Windows), or
Minicom (from Unix/Linux systems).
Connection parameters for the appliance are: 9600 bps, no parity, 1 stop bit (8N1).  Set the Flow Control to None.
An SSH connection to the management interface (if SSHD is configured).
Check Point 4000 Appliances Getting Started Guide | 39
Chapter 4
Check Point 4000 Appliances Hardware
In This Chapter
Front Panel Components 39 Rear Panel Components 44 Replacing and Upgrading Components 45
Front Panel Components
This section describes the features and components located on the appliance front panel.
Check Point 4200 Front Panel
Item
Description
1
Expansion line card slot
2
Built in Ethernet ports (ETH1 - ETH3)
3
Management configuration port - Ethernet connection to a remote management workstation
Check Point 4000 Appliances Hardware
40 | Check Point 4000 Appliances Getting Started Guide
Item
Description
4
USB ports
5
Console port - A serial connection to the appliance using a terminal emulation program such as HyperTerminal or PuTTY
6
Power indicator LED
7
LCD display screen
8
Keypad
Check Point 4400 and 4600 Front Panel
Item
Description
1
Expansion line card slot
2
Built in Ethernet ports (ETH1 - ETH7)
3
Management configuration port - Ethernet connection to a remote management workstation
4
USB ports
5
Console port - A serial connection to the appliance using a terminal emulation program such as HyperTerminal or PuTTY
6
Power indicator LED
7
LCD display screen
8
Keypad
Check Point 4000 Appliances Hardware
Check Point 4000 Appliances Getting Started Guide | 41
Check Point 4800 Front Panel
Item
Description
1
Expansion line card slot
2
LOM Port
3
Built in Ethernet ports (ETH1 - ETH7)
4
Management configuration port - Ethernet connection to a remote management workstation
5
USB ports
6
Console port - A serial connection to the appliance using a terminal emulation program such as HyperTerminal or PuTTY
7
Power indicator LED
8
LCD display screen
9
Keypad
Lights Out Management
The Check Point Lights Out Management (LOM) is an optional card that you can use with Check Point appliances. You can remotely control Check Point appliances using a dedicated management channel. Lights Out Management can also work when the appliance is turned off or not responding.
For more about using Lights Out Management, see the 4800 and 12000 Appliances Lights Out Management Administration Guide (http://supportcenter.checkpoint.com).
Check Point 4000 Appliances Hardware
42 | Check Point 4000 Appliances Getting Started Guide
Using the LCD Panel
The appliance has an LCD panel that you can use to do basic management operations. You can enable DHCP. You can configure the management IP address, netmask, and default gateway of the appliance. You can reboot the appliance.
Menu Options
Menu
Sub-menu
Purpose
Network
DHCP
Enable or disable DHCP for the management interface.
Set Mgmt IP
Set the management interface IP address.
Set Netmask
Set the management interface network mask. Set Default GW
Set the management interface default gateway.
System
Reboot
Reboot the appliance.
LCD Panel Keys
To
Press
Enter the main menu
Navigate the menu
or
Change a number
or
Select a menu option
Go back to previous menu
Check Point 4000 Appliances Hardware
Check Point 4000 Appliances Getting Started Guide | 43
When Entering an IP Address
To
Press
Enter the grub menu
or
Move to the next digit
Move back to the previous digit
Approve the change
when the cursor is located on the last digit
Cancel the IP change
when the cursor is located on the first digit
Change current digit
or
Configuring Management DHCP
You can use the LCD panel to enable or disable DHCP on the management interface.
To configure management DHCP using the LCD panel:
1. Press Enter . The panel shows Select > Network.
2. Press Enter . The panel shows Network > DHCP.
3. Press Enter . The panel shows that DHCP is enabled or disabled.
4. Press Up .
If DHCP was disabled - DHCP is enabled on the management interface.  If DHCP was enabled - DHCP is disabled on the management interface.
Configuring Management IP Addresses
You can use the LCD panel to configure these management interface IP addresses for the appliance:
Check Point 4000 Appliances Hardware
44 | Check Point 4000 Appliances Getting Started Guide
Management IP address  Subnet netmask  Default gateway
To configure the management IP address using the LCD panel:
1. Press Enter . The panel shows Select > Network.
2. Press Enter . The panel shows Network > DHCP.
3. Press Down . The panel shows Network > Set Mgmt IP.
4. Press Enter . The panel shows the management interface IP address.
5. Configure the management interface IP address.
a) Press Up or Down, or , to change the digit.
b) Press Right or Enter, or , to move to the next digit. c) When the panel shows the correct IP address, move the cursor to the last digit and
press Enter .
The panel shows Network > Set Mgmt IP.
6. Do steps 3 - 5 again for the subnet netmask and the default gateway IP address.
7. Press Esc until the panel shows the appliance logo.
Expansion Line Cards
There are different expansion line cards that you can use with the appliance. For more about the expansion line cards, see the Check Point 4000 Appliances home page (http://supportcontent.checkpoint.com/solutions?id=sk68681).
Rear Panel Components
This section describes components located on the rear panel of the appliance.
Check Point 4000 Appliances Hardware
Check Point 4000 Appliances Getting Started Guide | 45
Main Power Switch
The main power switch controls power to the entire unit.
Redundant Power Supply Units (Check Point 4800)
The Check Point 4800 has an optional redundant power supply unit. Located at the left rear of the appliance, two hot-swappable power supply units give built-in power redundancy. Each power supply connects to an electrical outlet.
For appliances that are provisioned with one power supply unit, use the placeholder unit in the other power supply slot. This diagram shows the 4800 model with the placeholder unit:
Note - If both power supply slots are not populated, a continuous alarm sounds.
If a power supply fails or is not connected to the outlet, an alarm sounds continuously.
Replacing and Upgrading Components
The Check Point 4000 Appliances has parts that you can easily replace to minimize downtime. There are also upgrade components that you can install on the appliance. These are the parts and components that can be used with the appliance:
Sliding rails  Line cards  Power supplies (4800 only)  System memory (4800 only)  LOM card (4800 only)
For more information about installing these parts and components, see the appliance home page (http://supportcontent.checkpoint.com/solutions?id=sk68681).
Unless directed to do so by Check Point technical support, you are prohibited by warranty and support agreements from replacing any parts.
Check Point 4000 Appliances Getting Started Guide | 47
Chapter 5
Restoring Factory Defaults
In This Chapter
Restoring Using the WebUI 47 Restoring Using the Console Boot Menu 48 Restoring Using the LCD Panel 49
If necessary, restore the appliance to its factory default settings.
Important - If you restore factory defaults, all information on the appliance is deleted.
Restoring Using the WebUI
Use the WebUI of the applicable operating system to restore the appliance to the factory default settings. You can select one of the software images that are available on the appliance.
Gaia
Use the Gaia WebUI to restore the default factory settings.
To restore a Gaia appliance with the WebUI:
1. Open an Internet browser to the management IP address, https://<appliance_ip_address>
2. Log in to the WebUI of the appliance using the administrator username and password.
3. In the WebUI, click Maintenance > Factory Defaults. The Factory Defaults window opens.
4. Select the image version that you are restoring.
5. Click Apply.
SecurePlatform
Use the SecurePlatform WebUI to restore the default factory settings.
Restoring Factory Defaults
48 | Check Point 4000 Appliances Getting Started Guide
To restore a SecurePlatform appliance with the WebUI:
1. Open Internet Explorer and navigate to the management IP address, https://<appliance_ip_address>:4434
2. Log in to the WebUI of the appliance using the administrator username and password.
3. In the WebUI, click Appliance > Image Management. The Image Management window opens.
4. Select the image version that you are restoring.
5. Click Revert.
Restoring Using the Console Boot Menu
To restore the appliance to its default factory configuration using the console boot menu:
1. Connect the supplied DB9 serial cable to the console port on the front of the appliance.
2. Connect to the appliance using a terminal emulation program such as Microsoft HyperTerminal or PuTTY.
3. Configure the terminal emulation program:
In the HyperTerminal Connect To window, select a port from the Connect using list.  In PuTTY select the Serial connection type.
4. Define the serial port settings: 9600 BPS, 8 bits, no parity, 1 stop bit.
5. From the Flow control list, select None.
6. Connect to the appliance.
7. Turn on the appliance.
8. The appliance initializes and status messages are shown in the terminal emulation program.
Restoring Factory Defaults
Check Point 4000 Appliances Getting Started Guide | 49
9. When this message is shown, you have approximately four seconds to hit any key to activate the Boot menu.
10. From the Boot menu, select the relevant Reset to factory defaults image.
11. Press Enter.
Restoring Using the LCD Panel
To restore the appliance to its default factory configuration using the LCD Panel keys:
1. Reboot or power on the appliance.
2. When the countdown begins, press any of the arrow keys.
The Boot menu appears.
3. Using the arrow buttons, scroll to the relevant default factory image.
4. Press .
5. Confirm the reset by pressing .
Restoring Factory Defaults
50 | Check Point 4000 Appliances Getting Started Guide
Pressing any other button causes the Action Canceled message to display:
At this point, pressing any key returns you to the boot menu.
6. Once you have confirmed the reset, wait for the appliance to restore the factory image. While the appliance is restored to the default image, this message is continuously displayed: Reverting image don't turn off.
After the appliance is restored to its default factory configuration, the appliance reboots and the initializing message appears.
Check Point 4000 Appliances Getting Started Guide | 51
Chapter 6
Registration and Support
In This Chapter
Registration 51 Support 51 Where To From Here? 51
Registration
The appliance requires a product-specific Check Point license. Get a license and register at the Check Point Appliance Registration site (http://register.checkpoint.com/cpapp).
Connect to the WebUI of the appliance to find the MAC address that is required to obtain a license.
Gaia - From Advanced mode, select Maintenance > Licenses.  SecurePlatform - Select Information > Appliance Status.
Support
For additional technical information about Check Point products, consult the Check Point Support Center (http://supportcenter.checkpoint.com).
Where To From Here?
You have the basics to get started. The next step is to get more advanced knowledge of your Check Point software.
Check Point documentation is available on the Check Point Support Center (http://supportcenter.checkpoint.com).
Be sure to also use the Online Help when you are working with the Check Point SmartConsole clients.
Check Point 4000 Appliances Getting Started Guide | 53
Appendix A
Compliance Information
This appendix contains declaration of conformity, compliance, and related regulatory information.
In This Appendix
Declaration of Conformity 53
Declaration of Conformity
Manufacturer’s Name:
Check Point Software Technologies Ltd.
Manufacturer’s Address:
5 Ha'Solelim Street, Tel Aviv 67897, Israel
Declare that under our sole responsibility the products
Model Number:
T-120, T-140, T-160, and T-180
Product Options:
All
Date First Applied:
July, 2011
Conforms to the following product specifications:
EMC
FCC, 47 CFR, Part 15, Class A
Information Technology Equipment - Radio Disturbance Characteristics
VCCI V-3, Class A
Information Technology Equipment - Radio Disturbance Characteristics
AS/NZS CISPR22, Class A
Information Technology Equipment - Radio Disturbance Characteristics
ICES-003, Class A
Information Technology Equipment - Radio Disturbance Characteristics
Compliance Information
54 | Check Point 4000 Appliances Getting Started Guide
CISPR22
Information Technology Equipment - Radio Disturbance Characteristics
EN55022, Class A
Information Technology Equipment - Radio Disturbance Characteristics
EN 61000-3-2
Information Technology Equipment - Harmonics Characteristics
EN61000-3-3
Information Technology Equipment - Flicker Characteristics
EN 55024
Information Technology Equipment - Immunity Characteristics
EN61000-4-2
Information Technology Equipment - Electrostatic Discharge Immunity
EN61000-4-3
Information Technology Equipment - Radiated RF Immunity
EN61000-4-4
Information Technology Equipment - Fast Transient Immunity
EN61000-4-5
Information Technology Equipment - Surge Immunity
EN61000-4-6
Information Technology Equipment - Conducted RF Immunity
EN61000-4-11
Information Technology Equipment - Voltage Dips and Short Interruptions Immunity
Safety
CAN/CSA, C22.2 No. 60950­1-07
Safety of Information Technology Equipment
UL 60950-1:2007 second edition
Safety of Information Technology Equipment EN 60950-1:2006/A11:2009
Safety of Information Technology Equipment
The product herewith complies with the requirements of the EU Directive 2006/95/EC and the EMC Directive 2004/108/EC
Date and Place of issue: July, 2011, Tel Aviv, Israel
Compliance Information
Check Point 4000 Appliances Getting Started Guide | 55
FCC Notice (US)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
Caution Any changes or modifications not expressly approved by the grantee of this device could void
the user’s authority to operate the equipment.
