Chauvin Arnoux C.A 848 User Manual

1
C.A 848
Thermo-hygromètre
Thermo-hygrometer
Thermo-Hygrometer
Termoigrometr o
Termohigrómetro
FRANÇAIS ENGLISH DEUTSCH ITALIANO ESPAÑOL
Notice de fonctionnement User's manual Bedienungsanleitung Libretto d'Istruzioni
Manual de Instrucciones
7
Thank you for purchasing a C.A 848 thermo-hygrometer. This digital thermo-hygrometer is lightweight and especially easy to use. It is equipped with a highly sensitive capacitive sensor for measuring hygrometry and a RTD (Pt100) probe class A for measuring temperature. The screen display indicates both hygrometry and temperature.
To obtain the best possible service from your instrument:
Read these operating instructions carefully.
Comply with the conditions of use.
PRECAUTIONS FOR USE
If the instrument is subjected to strong ambient temperature variations, wait 20 minutes after stabilization before resuming measurement.
Comply with the environmental conditions.
Never take measurements in atmospheres polluted by
solvents, acetone for example, as this may damage the sensor.
GUARANTEE
Unless otherwise stated, our guarantee is effective for twelve months following the date of supply of the equipment (extract
from our General Sales Conditions, available on request).
ENGLISH
8
CONTENTS
1. CONTROLS PRESENTATION ........................................ 8
2. OPERATING ..................................................................... 9
3. SPECIFIC FUNCTIONS .................................................... 9
4. SPECIFICATIONS .......................................................... 10
5. MAINTENANCE ............................................................. 10
6. TO ORDER ...................................................................... 11
1. CONTROLS PRESENTATION
1. Units selection button
2. MIN / MAX function activation button
3. Validation b utton
4. ON / OFF and escape function button
5. Measurement freezing button
9
2. OPERATING
2.1 Language selection
When the device is off, keep the OK button pressed and then press the ON / OFF button. Press HOLD to validate English or press SELECT to validate French.
2.2 Measurement procedure
1. Activate the device by pressing the ON / OFF button.
2. Choose the desired measurement unit for temperature.
3. Wait a few seconds for the measurements to stabilise.
4. If necessary, freeze the display by pressing HOLD.
3. SPECIFIC FUNCTIONS
3.1 Choosing the measurement units
Press SELECT to enter the menu. Scroll down the temperature measurement units (°C, °F, K) by pressing SELECT. Press OK to validate your choice.
3.2 Minimum and maximum values
For ambient temperature, press MIN / MAX one time to display the values min "m" and max "M". Press a second time to display the values for hygrometry. To escape this function, press ON / OFF / ESC.
3.3 Freezing the measurement
To freeze the measurement on the screen, press HOLD. To escape, press HOLD again.
3.4 Dew point temperature
To display the dew point temperature with the ambient temperature, press OK once. Press twice to display dew point temperature and hygrometry. Press 3 times to come back to display ambient temperature and hygrometry.
10
4. SPECIFICATIONS
Metrological specifications
Technical features
Conditions of use: 0 to 50°C; < 85 % RH
neutral gas
Storage conditions: 0 to 50°C; 15 to 85 % RH Power supply: 1 alkaline battery, 9V 6LR6
Device shuts off automatically after 30 minutes.
Dimensions and weight
Instrument: 145 x 75 x 34 mm Cable: L = 450 mm, extension up to 2.4 m Probe: Ø = 13 mm, L = 110 mm Display: 2 lines of 12 characters
38 x 12 mm
Weight: 190 g
Conformity
Electromagnetic Compatibility: complies with NF EN 61326-1.
5. MAINTENANCE
5.1 Cleaning
Clean the casing with a cloth and a little soapy water. Clean off with a damp cloth.
5.2 Changing battery
- Remove the protective covering
- Remove the battery cover
- Insert a 9V battery
- Replace the battery cover
- Replace the protective covering.
5.3. Metrological verification
It is essential that all measuring instruments are regularly calibrated.
For checking and calibration of your instrument, please contact our accredited laboratories (list on request) or the CHAUVIN ARNOUX subsidiary or your local agent.
Measurement range Resolution Accuracy Measurement units Hygrom e t ry 5 to 95% RH 0.1 %R H ± 2% R + 1. 8 % RH % RH Ambi en t temperature
-20 to +80°C
0.1°C
± 2% R + 0,3 °C °C, °F, K
Dew point temperature
-20 to +80°C
0.1°C
± 2% R + 0,3 °C °C, °F, K
11
5.4 Repairs
■■
■■
Repairs under guarantee and outside guarantee.
Please return the product to your distributor.
6. T O ORDER
C.A 848 ................................................................. P01.1563.03
Accessories:
Telescopic extension ........................................... P01.1020.12
