Chauvet DJ Circus 2.0 IRC User manual

Download
User Manual
TABLE OF CONTENTS
1. Before You Begin .......................................................................................................... 3
Claims ....................................................................................................................................................... 3
2. Introduction ................................................................................................................... 5
3. Setup .............................................................................................................................. 7
Fuse Replacement .................................................................................................................................... 7
Power Linking ............................................................................................................................................ 8
Orientation ................................................................................................................................................. 9
Rigging ...................................................................................................................................................... 9
4. Operation ......................................................................................................................10
Starting Address ...................................................................................................................................... 10
4-Channel ................................................................................................................................................ 11
Sound-Active Mode ................................................................................................................................. 12
Automatic Mode ....................................................................................................................................... 12
Master/Slave Mode .................................................................................................................................. 13
Infrared Remote Control (IRC)................................................................................................................. 13
IRC Operation .......................................................................................................................................... 14
5. Technical Information ..................................................................................................15
6. Technical Specifications ..............................................................................................16
Page 2 of 17 Circus™ 2.0 IRC User Manual (Rev. 1)
What Is

Unpacking
Instructions

and check the container to make sure all the
included accessories) appear damaged from
, damage not related to shipping,
Text
1–512
A range of values
50/60
A set of values of which only one can be chosen
Settings
A menu option not to be modified
<ENTER>
A key to be pressed on the product’s control panel
ON
A value to be entered or selected

Symbols

Critical installation, configuration, or operation information. Not damage to the product, or cause harm to the operator.

Disclaimer

are subject to change ity for any errors or

1. BEFORE YOU BEGIN

Included

Claims

Conventions
• Circus™ 2.0 IRC
• Power Cord
• Hanging Bracket with Mounting
Hardware
Carefully unpack the product immediately parts are in the package and are in good condition.
If the box or the contents (the product and shipping, or show signs of mishandling, notify the carrier immediately, not CHAUVET®. Failure to report damage to the carrier immediately may invalidate your claim. In addition, keep the box and contents for inspection.
For other issues, such as missing components or parts or concealed damage, file a claim with CHAUVET® within 7 days of delivery.
Convention Meaning
Symbol Meaning
• Warranty Card
• Quick Reference Guide
The information and specifications contained in this User Manual without notice. CHAUVET® assumes no responsibility or liabil omissions, and reserves the right to revise or recreate this manual at any time. Download the latest version from
© Copyright 2013 CHAUVET®. All rights reserved.
Electronically published by CHAUVET® in the United States of America.
Author Date Editor Date
A. Leon 3/13/13 D. Couppe 3/13/13
following these instructions may make the product not work, cause
Important installation or configuration information. The product may not function correctly if this information is not used.
Useful information.
www.chauvetlighting.com.
Circus™ 2.0 IRC User Manual (Rev. 1) Page 3 of 17
Product at a
x
P
x
P
P
P
P
x
P
x

Safety Notes

Do not touch the product’s housing when operating because it may be very hot.
Glance
Use on Dimmer Outdoor Use Sound-Activated DMX Master/Slave
These notes i nclude important information about the mounting, usage, and maintenance of this product; read before using the product.
• Always connect the product to a grounded circuit to avoid the risk of electrocution.
• Always disconnect the product from the power source before cleaning or replacing
the fuse.
• Avoid direct eye exposure to the light source while the product is on.
• Make sure the power cord is not crimped or damaged.
• Never disconnect the product from power by pulling or tugging on the cord.
• If mounting the product overhead, always secure to a fastening device using a
safety cable.
• Make sure there are no flammable materials close to the product when operating.
•
• Always make sure that the voltage of the outlet to which you are connecting the
product is within the range stated on the decal or rear panel of the product.
• The product is for indoor use only! (IP20) To prevent risk of fire or shock, do not expose the product to rain or moisture.
• Always install the product in a location with adequate ventilation, at least 20 in (50 cm) from adjacent surfaces.
• Be sure that no ventilation slots on the product’s housing are blocked.
• Never connect the product to a dimmer.
• Make sure to replace the fuse with another of the same type and rating.
• Never carry the product from the power cord or any moving part. Always use the
hanging/mounting bracket.
• The maximum ambient temperature (Ta) is 104° F (40° C). Do not operate the product at higher temperatures.
• In the event of a serious operating problem, stop using the product immediately.
• Never try to repair the product. Repairs carried out by unskilled people can lead to
damage or malfunction. Contact the nearest authorized technical assistance center.
• This product is not intended for permanent installation.
Auto Programs Auto-ranging Power Supply Replaceable Fuse User-Serviceable Duty Cycle
• Keep this User Manual for future use. If you sell the product to another user, be sure to give this document to the next owner.
Page 4 of 17 Circus™ 2.0 IRC User Manual (Rev. 1)

2. INTRODUCTION

Overview

Display
Control Buttons
DMX In
DMX Out
Safety Loop
Microphone
Microphone Sensitivity
Power Out
Fuse Holder
Power In
LED Pods
Front View
IRC Remote
Receiver
Adjustment Knob
Back Panel View
Circus™ 2.0 IRC User Manual (Rev. 1) Page 5 of 17
SMD Strobe LEDs
(white)

Dimensions

13 in/330 mm
14.7 in/373 mm
7.8 in/200 mm
Page 6 of 17 Circus™ 2.0 IRC User Manual (Rev. 1)

AC Power

ranging power supply and it can work with an input
circuit breaker, power outlet, and
’s back panel, or
’s specifications chart. The listed current rating indicates the
(circuit breaker or fuse). Make
an appropriate electrical ground to avoid the risk of
a rheostat (variable resistor) or dimmer circuit, even
Fuse
Installed fuse (held by plastic clip)
Spare fuse holder
(inside safety cap)
Safety cap

3. SETUP

The Circus™ 2.0 IRC has an auto­voltage range of 100~240 VAC, 50/60 Hz.
To determine the product’s power requirements ( wiring), use the current value listed on the label affixed to the product refer to the product product’s average current draw under normal conditions.
Always connect the product to a protected circuit sure the product has electrocution or fire.
Never connect the product to if the rheostat or dimmer channel serves only as a 0–100% switch.
Replacement
Disconnect the product from power before replacing the fuse.
1. Disconnect the product from power.
2. Wedge the tip of a flat-head screwdriver into the slot of the fuse holder.
3. Pry the fuse holder out of the housing.
4. Remove the blown fuse from the holder.
5. Replace with a fuse of the exact same type and rating.
6. Insert the fuse holder back in place and reconnect power.
A spare fuse is not included; however, the safety cap has room for a spare.
Always replace a blown fuse with another of the same type and rating.
Circus™ 2.0 IRC User Manual (Rev. 1) Page 7 of 17

Power Linking

Power Linking
The power linking diagram shown above corresponds to the North American
in other markets, you must
consult with the local CHAUVET® distributor as power linking connectors and
1st Product
2nd Product
3rd Product
Additional Products
The product provides power linking via the Edison outlet located in the back of the unit.
Diagram
You can power link up to 42 Circus™ 2.0 IRC units on 120 VAC or up to 78 Circus™ 2.0 IRC units on 230 VAC.
version of the product ONLY! If using the product requirements may differ in your country or region.
Page 8 of 17 Circus™ 2.0 IRC User Manual (Rev. 1)

Mounting

, read and follow the safety recommendations indicated in
may be mounted in any position; however, make sure adequate
Mount the
always consider the length of the
knobs allow for directional adjustment when aiming the
Mounting Bracket
Safety Cable
Clamp
Mounting Bracket
Adjustment Knob (2x)
Before mounting the product the Safety Notes.

Orientation

The Circus™ 2.0 IRC ventilation is provided around the produc t.

Rigging

• Before deciding on a location, always make sure there is easy access to the product for maintenance and programming .
• Make sure that the structure or surface onto which you are mounting the product can support the product’s weight (see the Technical Specifications
).
• When mounting the product overhead, always use a safety cable. product securely to a rigging point, such as an elevated platform or a truss.
• When rigging the product onto a truss, you should use a mounting clamp of appropriate weight capacity .
• When po wer linking m ultiple products, you must power linking cable and mount the products close enough for the cable to reach.
• The bracket adjustment product to the desired angle. Only loosen or tighten the bracket knobs manually. Using tools could damage the knobs.
Mounting Diagram
Circus™ 2.0 IRC User Manual (Rev. 1) Page 9 of 17

Control Panel
Operation

To access the control panel functions, use the four buttons located underneath the
<ENT>

Menu Map

Configuration
When selecting a starting DMX address, always consider the number of DMX channels
choose a starting address that is too high, you could
DMX mode, which
download the DMX Primer from

4. OPERATION

display.
Button Function
<MENU>
<UP>
<DOWN>
Mode Programming Steps Description
DMX Address 4-CH d 1–d512
Standalone Sound SNd
Sound/Speed S-- S 1–S100
Standalone
Auto-Configure
Infrared (IRC Mode) SEr
Selects an operation mode or to backs out of the current menu option
Scrolls up the list of options or selects a higher value Scrolls down the list of options or selects a lower value Activates a menu option or a selected value
AUTO
oN
oFF
Selects the DMX starting address Sound-Active standalone mode Sound sensitivity in Sound-Active mode
Speed in automatic programs Standalone automatic programs
Turns infrared for remote control on or off
Set the product in DMX mode to control with a DMX controller.
(DMX)
1. Connect the product to a suitable power outlet.
2. Turn the product on.
3. Connect a DMX cable from the DMX output of the DMX controller to the DMX input socket on the product.

Starting Address

the selected DMX mode uses. If you restrict the access to some of the product’s channels.
The Circus™ 2.0 IRC uses up to 4 DMX channels in its 4-channel defines the highest configurable address to 509.
If unfamiliar with DMX or DIP switches,
www.chauvetlighting.com.
To select the starting address, do the following:
1. Press <MENU> repeatedly until 4-CH shows on the display.
2. Press <ENT>.
3. Use <UP> or <DOWN> to select the starting address.
4. Press <ENT>.
Page 10 of 17 Circus™ 2.0 IRC User Manual (Rev. 1)

DMX Channel Modes, Assignments, and Values

000 ó 015
238 ó 255
No function
Sound-Active mode
2
Speed
000 ó 255
Automatic program speed (slow to fast)
000 ó 015 016 ó 255
No function Pods automatic strobe speed (slow to fast)
000 ó 015
No function When Channel 1 is 000–237

4-Channel

Channel Function Value Setting
1 Program/Mode
016 ó 021 022 ó 027 028 ó 033 034 ó 039 040 ó 045 046 ó 051 052 ó 057 058 ó 063 064 ó 069 070 ó 075 076 ó 081 082 ó 087 088 ó 093 094 ó 099 100 ó 105 106 ó 111 112 ó 117 118 ó 123 124 ó 129 130 ó 135 136 ó 141 142 ó 147 148 ó 153 154 ó 159 160 ó 165 166 ó 171 172 ó 177 178 ó 183 184 ó 189 190 ó 195 196 ó 201 202 ó 207 208 ó 213 214 ó 219 220 ó 225 226 ó 231 232 ó 237
Automatic 1 Automatic 2 Automatic 3 Automatic 4 Automatic 5 Automatic 6 Automatic 7 Automatic 8 Automatic 9 Automatic 1 0 Automatic 1 1 Automatic 1 2 Automatic 1 3 Automatic 1 4 Automatic 1 5 Automatic 1 6 Automatic 17 Automatic 1 8 Automatic 1 9 Automatic 2 0 Automatic 2 1 Automatic 2 2 Automatic 2 3 Automatic 2 4 Automatic 2 5 Automatic 2 6 Automatic 2 7 Automatic 2 8 Automatic 2 9 Automatic 3 0 Automatic 3 1 Automatic 3 2 Automatic 3 3 Automatic 3 4 Automatic 3 5 Automatic 3 6 Automatic 37
3 Pods Strobe Speed
4 SMD Strobe Speed
Circus™ 2.0 IRC User Manual (Rev. 1) Page 11 of 17
016 ó 255
SMD strobe speed (slow to fast)
Configuration
Static,
s in
standalone mode may transmit DMX signals that could interfere with the DMX
Note: You can also set the microphone sensitivity in Sound-Active mode using sensitivity knob until the product starts responding to the beat of the music.
, follow the
(Standalone)
Set the product in one of the standalone modes to contr ol without a DMX controller.
1. Connect the product to a suitable power outlet.
2. Turn the product on.
Never connect a product that is operating in any standalone mode (either Automatic, or Sound) to a DMX string connected to a DMX controller. Product
signals from the controller.
Sound-Active
Mode
To enable the Sound-Active mode and select sound sensitivity, do the following:
1. Press <MENU repeatedly until SNd shows on the display.
2. Press <ENT> to activate the Sound-Active mode.
3. Press <MENU> until S-- shows on the display.
4. Use <UP> or <DOWN> to select the sound sensitivity from S 1 to S100 (low to high).
5. Press <ENT>.
the microphone sensitivity knob. Turn the music on and adjust the microphone
The product will only respond to low frequencies of music (bass and drums).

Automatic Mode

To enable the Automatic mode and select the automatic program speed instructions below:
1. Press <MENU> repeatedly until AUTO shows on the display.
2. Press <ENT> to activate the automatic programs.
3. Press <MENU> until S-- shows on the display.
4. Use <UP> or <DOWN> to select the automatic program speed from S 1 to S100 (fast to slow).
5. Press <ENT>.
Page 12 of 17 Circus™ 2.0 IRC User Manual (Rev. 1)
Master/Slave
unit (the “master”) to control
units (the “slaves”) without the need of a
all the slave units before connecting the master unit to the DMX
Never connect a DMX controller to a DMX string configured for Master/Slave
may interfere with the signals from the
Infrared Remote
The Circus™ 2.0 IRC is fully compatible with the Infrared Remote Control (IRC) from
The Master/Slave mode allows a single Circus™ 2.0 IRC
Mode
the actions of one or more Circus™ 2.0 IRC DMX controller. The master unit will be set to operate in either Automatic or Sound­Active mode, while the slave units will be set to operate from DMX starting address d 1. Once set and connected, the slave units will operate in unison with the master unit.
Configure the units as indicated below.
Slave units:
1. Set the DMX address to d 1.
2. Connect the DMX input of the first slave unit to the DMX output of the master unit.
3. Connect the DMX input of the subsequent slave units to the DMX output of the previous slave unit.
4. Finish setting and connecting all the slave units.
Master unit:
1. Set the master unit to operate in either Sound-Active or Automati c mode.
2. Make the master unit the first unit in the DMX daisy chain.
• Configure
daisy chain.
•
operation because the controller master unit.
• Do not connect more than 31 slave units to the master unit.
Control (IRC)
CHAUVET®. To enable usage with the IRC, do the following:
1. Press <MENU> repeatedly until SEr shows on the display.
2. Press <ENT> to accept.
3. Press <UP> or <DOWN> to select oN or oFF.
4. Press <ENT>.
Circus™ 2.0 IRC User Manual (Rev. 1) Page 13 of 17

IRC Operation

Note: Make sure to point the IRC directly at the receiver on the product.
Automatic Mode
Automatic mode will enable you to run the automatic programs on the
product.
To turn on Automatic mode:
1. Press <AUTO> on the IRC.
2. Press <+> or <–> to choose between any different auto programs.
To adjust the speed of the automatic program:
1. Press <SPEED> on the IRC.
2. Press <%>.
3. Press <+> or <–> to either increase or decrease the speed of the program.
Sound-Active Mode
Sound-Active mode will enable the product to respond to the music. To turn on Sound Active mode:
1. Press <SOUND> on the IRC.
To adjust sound sensitiv ity in Sound-A ctiv e mode :
1. Press <SENSITIVITY> on the IRC.
2. Press <%>.
3. Press <+> or <–> to either increase or decrease sound sensitivity.
Miscellaneous Operation
To adjust the strobe rate of the program:
1. Press <STROBE> on the IRC.
2. Press <+> or <–> to increase or decrease the strobe rate.
3. Press <STROBE> again to turn off the strobe.
To change the switching effect of the program:
1. Press <FADE/SNAP> on the IRC. Fade will slowly switch the effect. Snap will rapidly switch the effect.
To black out the lights:
1. Press <BLACK OUT> on the IRC. This will turn off all the lights until the button is pressed again.
Note: The IRC will not respond to any inputs when Black Out is activated. If the remote does not respond when a button is pressed, try pressing <BLACK OUT>. You may have inadvertently activated Black Out.
Page 14 of 17 Circus™ 2.0 IRC User Manual (Rev. 1)
Product
up reduces light output performance and can cause overheating. This can
To maintain optimum performance and
sage and
surfaces carefully after cleaning

5. TECHNICAL INFORMATION

Dust build-
Maintenance
lead to reduction of the light source’s life. minimize wear, clean the product at least twice a month. However, u environmental conditions contribute to increased cleaning frequency.
To clean the product, follow the instructions below:
• Unplug the product from power.
• Wait until the product is at room temperature.
• Use a vacuum (or dry compressed air) and a soft brush to remove dust collected on
external surfaces.
• Clean all external optics and transparent surfaces with a mild soap solution, ammonia-free glass cleaner, or isopropyl alcohol.
• Apply the solution directly to a soft, lint-free cotton cloth or a lens cleaning tissue.
• Softly wipe any dirt or grime to the outside edges of the external opti cs or
transparent surface.
• Gently polish the external optics and transparent surfaces until they are free of haze and lint.
Always dry the external optics and transparent them.
Circus™ 2.0 IRC User Manual (Rev. 1) Page 15 of 17
Dimensions and
Length
Width
Height
Weight
14.7 in (373 mm)
7.8 in (200 mm)
13 in (330 mm)
8.5 lbs ( 3.8 kg)
Note: Dimensions in inches rounded to the nearest decimal digit.
Power
Power Supply Type
Range
Voltage Selection
Switching (internal)
100~240 V, 50/60 Hz
Auto-ranging
Parameter
120 V, 60 Hz
230 V, 50 Hz
Consumption
23 W
25 W
Operating current
0.2 A
0.1 A
Power linking current (units)
8 A (42 units)
8 A (78 units)
Fuse
T 1 A, 250 V
T 1 A, 250 V
Power I/O
U.S./Worldwide
UK/Europe
Power input connector
IEC
IEC
Power output connector
Edison
IEC
Power cord plug
Edison (U.S.)
Local plug
Light Source
(LED Pods)
Type
Power
Lifespan
LED
0.25 W
100,000 hours
Color
Quantity
Current
Red
80
20 mA
Green
80
20 mA
Blue
80
20 mA
White
40
20 mA
Amber
40
20 mA
Light Source
Type
Power
Lifespan
SMD LED
60 mA
50,000 hours
Color
Quantity
Current
White
25
60 mA
Photo Optic
Parameter
Coverage angle
55°
Strobe Rate
0–30 Hz
Thermal
Maximum External Temp.
Cooling System
104° F (40° C)
Convection
DMX
I/O Connectors
Connector Type
Channel Range
3-pin XLR
Sockets
4
Ordering
Product Name
Item Code
UPC Number
Circus™ 2.0 IRC
03050649
781462209971

6. TECHNICAL SPECIFICATIONS

Weight
(SMD Strobe LEDs)
Page 16 of 17 Circus™ 2.0 IRC User Manual (Rev. 1)
, United Kingdom, or Ireland, contact your distributor of
s to

Returns

Support office and request a Return
. Be prepared to
number, and a brief description of the cause for the
You must send the merchandise prepaid, in its original box, and with its original packing
the following information on a piece of paper
properly. Any shipping damage resulting from inadequate
reserves the right to use its own discretion to repair or replace

Contact Us

Fax: +44 (0)1773 511110
Email: tech@chauvetlighting.com
www.chauvetlighting.com
www.chauvetlighting.co.uk
To return a product or reques t supp ort :
• In the U.S., contact CHAUVET® World Headquarters.
• In the UK or Ireland, contact CHAUVET® Europe Ltd.
• In any other country, DO NOT contact CHA UV E T®. Contact your distributor. See
www.chauvetlighting.com
for distributors outside the U.S., United Kingdom, or
Ireland.
If you live outside the U.S. record and follow their instructions on how to return CHAUVET® product them. Visit our website for contact details.
Call the corresponding CHAUVET® Technical Merchandise Authorization (RMA) number before shipping the product provide the model number, serial return.
and accessories. CHAUVET® will not issue call tags. Clearly label the package with the RMA number. CHAUVET® will refuse any product
returned without an RMA number.
Write the RMA number on a properly affixed label. DO NOT write the RMA number directly on the box.
Before sending the product, clearly write and place it inside the box:
• Your name
• Your address
• Your phone number
• The RMA number
• A brief description of the problem
Be sure to pack the product packaging will be your responsibility. FedEx packing or double-boxing are recommended.
CHAUVET® returned product(s).
World Headquarters
CHAUVET® General Information
Address: 5200 NW 108th Avenue Sunrise, FL 33351 Voice: (954) 577-4455 Fax: (954) 929-5560 Toll free: (800) 762-1084
Technical Support
Voice: (954) 577-4455 (Press 4)
Fax: (954) 756-8015
United Kingdom & Ireland
CHAUVET® Europe Ltd. General Information
Address: Unit 1C Brookhill Road Industrial Estate Pinxton, Nottingham, UK NG16 6NT Voice: +44 (0)1773 511115
Technical Support
Email: uktech@chauvetlighting.com
World Wide Web
Circus™ 2.0 IRC User Manual (Rev. 1) Page 17 of 17
World Wide Web
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
