DuraShield
™
DuraShield
A simple solution to reduce unwanted infiltration, and add
comfort to your employee’s work environment to increase
productivity and discourage trespassing.
The DuraShield Bug, Bird and Wire Mesh Door System is a cost
effective way to provide ventilation and natural sunlight to
buildings while maintaining a bird and insect free environment
and a barrier from unwanted pedestrian traffic flow.
The DuraShield Solid Vinyl Roll-up Door is an affordable
choice when ventilation is not as much of a concern
as sealing out dust, noise, pollution and temperature
differential. Increase productivity by improving your
employees work environment.
™
Bug and Bird
Screen Door
The DuraShield door systems are custom manufactured for
Dock Doors Truck Entrances Ramp Entry Ways
Warehouses Processing Plants Processing Plants
Distribution Centers
The DuraShield door system is designed for easy installation
and operation. They can be placed on the inside or outside
of a building with either in-jamb mounting, face-of-wall
mounting, or inside standoff mounting. Both the in-jamb and
inside standoff use strips of vinyl coated nylon material or
brush seals to completely enclose the header and sides.
Wire Mesh
Security Door
Durable, yet lightweight, the extruded deep channel aluminum track system tightly
secures the panel in the opening. The aluminum track flairs out at the top of the
guide curtain material for easy, smooth and consistent operation.
Solid Vinyl
Roll-up Door
New Casing Door
System -
solution for external face of
wall, internal face of wall for
metal buildings, or in front of
coiling steel doors. Installation
is easy with only four parts to
put together. The side panels
and hood are prefabricated
from the factory, saving you
time and money.
Face of Wall
Mount
The perfect
In-Jamb
Mount
Inside Standoff
Mount
Each door includes round ¾” diameter horizontal fiberglass stiffeners for draft resistance
and horizontal stability. An optional 1” diameter metal tube is available for wider openings
or high wind load applications. The stiffeners are inside a bright yellow, vinyl coated nylon
pocket which adds visibility and increases safety.
The bottom pocket also uses the bright yellow, vinyl coated nylon and a hem chain for
added weight preventing crawling critters from getting free passage at the floor contact
point. Uneven or slanting floors are not a problem! Additional weight along with a lockable
bottom bar is available.
2
DuraShield
Bug and Bird Screen Doors
• Doors are constructed with a durable vinyl encapsulated woven polyester
mesh that is resistant to mildew and color fading.
• The Bug Screen door material utilizes 17 x 11 scrim count plain weave and
11.7 oz. per square yard of material in your choice of standard colors.
• The Bird mesh standard material utilizes netting, a special oval shape weave
with 9 holes per square inch and 15 oz per square yard of material in your
choice of colors.
• Extruded aluminum “C” channel guide track is 1” wide x 4” deep.
• Safety yellow and black strips are standard on the interior
edge of the panel.
• ¾” diameter fiberglass wind load rods are standard on smaller size doors
and 1” diameter metal tube is standard on larger size doors.
• The roller tube is 3” – 6” in diameter and is dependent upon the
size of the door.
• Manual roll-up doors are available with either a chain hoist or
springload system.
• Motor operation uses either in-tube motor for small doors or an external
jackshaft motor for larger doors (see pictures below).
• Exterior wall mount protective hood is available as an option.
• Lock down system with a solid bottom bar is also available as an option.
Bird Shield Bug Shield
Chain Hoist
Springload
DuraShield
Wire Mesh Security Door
• Stop trespassing, but let in natural sunlight and fresh air with the
DuraShield aluminum or stainless steel wire mesh security door.
• 15 gauge aluminum with a ½” coil wire mesh is standard, 18 gauge
aluminum with ¼” coil, 16 gauge stainless steel with ½” coil, or 19
gauge stainless steel with ¼” coil is available as an option.
• Heavy duty extruded aluminum “C” channel guide track is
1.25” wide x 4” deep.
• Safety yellow and black strips are standard on the interior
edge of the panel.
• Horizontal stiffeners are constructed with ¾” fiberglass wind load rods
and are inserted into specially constructed coils for horizontal stability,
visibility and increased safety.
• The roller tube is 3” – 6” in diameter and is dependent upon
the size of the door.
• All wire mesh doors come standard with in-tube motor for small
doors or external motor for larger doors.
• Lock down system with a solid bottom bar is standard.
• Exterior wall mount protective hood is available as an option.
Visibility looking
out is unhindered.
But visibility
looking in is
limited.
In-tube Motor External Motor
Wire mesh
offers more
security and
protection
3
DuraShield
DuraShield
Solid Vinyl Roll-Up Door
• Doors are constructed with a 22 oz. durable coated nylon reinforced
vinyl that is resistant to color fading and can be washed down.
An optional, heavy duty 40 oz. is available.
• Optional vision panel is constructed with clear PVC vinyl and is the
full width of the panel.
• Heavy duty extruded aluminum “C” channel guide track is 1” wide
x 4” deep, dependent upon the size of the door.
• Safety yellow and black strips are standard on the interior edge of
the panel.
• ¾” diameter fiberglass wind load rods are standard on smaller size
doors and 1” diameter metal tube is standard on larger size doors.
• The roller tube is 3” – 6” in diameter and is dependent upon the
size of the door.
• Your choice of manual roll-up with a chain hoist or optional motor
operation with in tube motor for small doors and external motor
for larger doors.
• Exterior wall mount protective hood is available as an option.
• Lock down system with a solid bottom bar is also available
as an option.
™
DuraShield
Sliding Door
• Available in your choice of materials - bug, bird or vinyl.
• Designed for injamb mount, face of wall mount or inside standoff
mount.
Colors available for Bug Screen and Vinyl Doors
Black
Color shown may differ from actual color. Consult factory for exact color.
Curtain Walls are
now available!
Contact us for
more information.
Yellow
Chase Industries, Inc. / Cincinnati / Redmond / North Little Rock
800.543.4455 / 513.860.5565 / fax 800.245.7045 / www.chasedoors.com
In our continuing effort to improve our products, some specifications or descriptions may change. We reserve the right to make such changes without notice or recourse.
Blue
Brochure DSB1010 Printed in U.S.A.
Gray
Beige
Orange
Green
Red
