24" Barstool
>>assembly instructions
Congratulations on your latest purchase.
Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you’ll be on your way to transforming your
room in no time. Good luck --though we’re confident you won’t need it.
before you begin
1. Check for damaged or missing parts. Customers can email or call to order missing supplies.
2. Use the carton as a working surface to prevent product damage during assembly.
3. Gather all tools prior to assembly.
2
table of contents
..............................................
introduction
hardware
parts list
assembly
2
4
5
6 - 12
QUESTIONS?
Just email or c all parts and s ervice. For f ast service , have the styl e number and ar ticle numbe r ready when ca lling.
3
hardware
............................................................................
(A) x 4
5/16" x 90mm
round hex screw
(D) x 2
1/4" x 45mm
round hex screw
(E) x 2
1/4" x 20mm
round hex screw
(B) x 2
5/16" x 70mm
round hex screw
(F) x 10
Φ 8mm lo ck washer
(C) x 4
5/16" x 60mm
round hex screw
(G) x 10
Φ 22mm fl at washer
(H) x 4
Φ 6mm lo ck washer
(I) x 4
Φ 15mm fl at washer
4
(J) x 2
plug
(K) x 1
dowel 10x40mm
(L) x 1
5mm Ba ll end
Hex wrench
(M) x 1
4mm Ba ll end
Hex wrench
ITEM DESCRIPTI O N QUANT I T Y
............................................................................
1
2
3
4
chair back
seat cushion
front leg
bar
1
1
1
2
1
2
4
4
3
5
step 1.
............................................................................
1 2
3
.
elcro
he v
n t
Ope
G
L
2
F
C
(C) x 4
5/16" x 60mm
round hex screw
6
Please do not assemble with power tools.
(F) x 4
Φ 8mm lo ck washer
(G) x 4
Φ 22mm fl at washer
(L) x 1
5mm Ba ll end
Hex wrench
step 2.
............................................................................
1 2
4
4
I
H
E
M
(E) x 2
1/4" x 20mm
round hex screw
7
(H) x 2
Φ 6mm lo ck washer
Please do not assemble with power tools.
(I) x 2
Φ 15mm fl at washer
(M) x 1
4mm Ba ll end
Hex wrench
step 3.
............................................................................
1
1
(B) x 2
5/16" x 70mm
round hex screw
K
(F) x 2
Φ 8mm lo ck washer
2
(G) x 2
Φ 22mm fl at washer
Do not tighten these two bolts
until the next step.
(K) x 1
dowel 10x40mm
L
B
F
G
(L) x 1
5mm Ba ll end
Hex wrench
Please do not assemble with power tools.
8
step 4.
............................................................................
1
Now you may tighten all 6 bolts.
L
A
F
G
(A) x 4
5/16" x 90mm
round hex screw
9
Please do not assemble with power tools.
(F) x 4
Φ 8mm lo ck washer
(G) x 4
Φ 22mm fl at washer
(L) x 1
5mm Ba ll end
Hex wrench
step 5.
............................................................................
1
Use plugs to cover the holes.
2
I
H
J
D
M
(D) x 2
1/4" x 45mm
round hex screw
10
(H) x 2
Φ 6mm lo ck washer
Please do not assemble with power tools.
(I) x 2
Φ 15mm fl at washer
(J) x 2
plug
(M) x 1
4mm Ba ll end
Hex wrench
step 6.
............................................................................
1
Close the velcro.
11
step 7.
............................................................................
A friendly reminder from us:
Please keep the Allen wrench.
After a period of time, there may be a chance the
KD furniture may become loose, please use an
Allen wrench to tighten the loose bolts.
Level the furniture, use leveling feet if needed.
12
Adjustable leveling feet
( This pa rt i s already a tt ached on th e en d cap of 4 legs . )
