Page 1
Firebowl
Firebowl
with Screen
with Screen
For Outdoor
Use Only
06501328
04201101
CAUTION
THIS UNIT IS HEAVY!
DO NOT assemble without a helper.
CAUTION
Some parts may contain sharp edges – especially as
noted in manual. Wear protective gloves if necessary.
CAUTION
Read and follow all safety statements, warnings,
assembly instructions and use & care directions before
attempting to assemble.
WARNING
All surfaces can be hot during use. Use protection as
required to prevent burning.
WARNING
Do not use this unit on or near combustible surfaces or
structures such as wood decks, dry leaves or grass, vinyl
or wood siding, etc. SEE OWNER’S MANUAL FOR
IMPORTANT SAFETY INFORMATION.
WARNING
NEVER LEAVE FIRE UNATTENDED!
Do not allow small children near flame. Hot embers can
fly out in breezy conditions. Adequate fire extinguishing
material should be readily available.
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off carbon
monoxide, which has no odor. NEVER burn charcoal
inside homes, vehicles or tents.
06501328 • 42804201 • 12-04-07
Page 2
STOP!
Missing a part?
No need to go back to the store!
The store where you made your purchase
does not stock parts for this item. If you
need parts, whether they are missing or
damaged, call the Customer Service toll
free Help Line.
Call us and we
will gladly ship
The part you need.
Call Our Help Line
1-800-241-7548
To insure your satisfaction
and for follow-up service,
register your product
online at:
www.grillregistration.com
Tools required for assembly: Straight or Phillips screwdriver • Adjustable wrench
Page 3
PARTS DIAGRAM
MODEL No. 06501328
E
F
C
A
KEY
ITEM DESCRIPTION QTY
29001275 FIREBOWL RING KIT
A
29001278 LEG KIT
B
29001089 FIREBOWL
D
B
C
55710180 ASH CATCHER KIT
D
E
10000179 LIFT BOLT F/ FIRE SCREEN
29100803 MESH FIRE SCREEN ASSEMBLY
F
...
42804201 ASSEMBLY INSTRUCTIONS
...
55710181 HARDWARE BAG
PARTS LIST
1
4
1
1
1
1
1
1
HARDWARE LIST
Hardware is shown actual size. You may have spare hardware after assembly is complete.
#10-24x1/2”
Screw
Qty: 11
1/4-20
Keps Nut
1Qty:
#10-24
Keps Nut
11Qty:
Page 4
PRODUCT ASSEMBLY
Make sure leg is on the outside of the firebowl ring, attach each leg to support bar using two #10-24x1/2” screws
from the outside and two #10-24 keps nuts on the inside. Do not fully tighten until all four legs are attached.
Firebowl Ring
Firebowl Ring
Support Bar
Leg
Leg
Attach ash catcher to bottom of firebowl using three #10-24x1/2” screws and three #10-24 keps nuts.
Firebowl
Ash Catcher
Page 5
Attach lift bolt to fire screen with one 1/4-20 keps nut.
3
Lift Bolt
Fire Screen
4
Place firebowl into firebowl ring assembly, then place fire screen onto firebowl
Fire Screen
Firebowl
Firebowl Ring
Page 6
USE & MAINTENANCE
It is recommended that coals and ashes are removed from your fireplace between each use. Coals and ash that build up
can restrict air flow to the fire. MAKE SURE COALSANDASHARE COOLTOTHETOUCH BEFORE REMOVING.
If your fireplace gets wet, be sure to dry it. Wet ashes can promote rust formation. It is recommended that your fireplace be
covered when not in use. NEVER COVERAHOTOR WARMFIREPLACE. Allow it to cool first.
This fireplace is not intended to be used for a primary heat source. Do not overfill it.
Steel and Cast Iron Surfaces
The temperatures produced by wood-burning, outdoor fireplaces can vary with the type and amount of combustible being
used. While formulated to withstand high temperatures, painted surfaces can fade, peel, and eventually rust due to the
extreme, damaging heat that wood-burning fires can produce.
Comparable to the patina effect of copper and bronze, rust is the natural occurrence that results on surfaces that are not
protected by paint or porcelain and are exposed to air and moisture. High-temperature paint can be used if the rustic
appearance of your outdoor fireplace is not desired.
Outdoor fireplaces that feature a porcelain coating are still susceptible to rust spots on the screens. Fireplace mesh
screens can not be porcelain coated and will require touch-up with paint that is rated for use in high-temperature
applications.
Copper and other Metallic Surfaces
Copper, chrome and other metallic surfaces often found on outdoor fireplaces will patina, change color,and blacken with
exposure to outdoor conditions, heat, and smoke. Cleaning these surfaces regularly after each use with an appropriate
metal polish can help reduce these effects.
If you notice any of these surface conditions before the outdoor fireplace is used, contact the Char-Broil Service Center for a
replacement of the defective component. Manufacturing defects are covered under Char-Broil's 90 Day Limited Warranty.
WARNING
This product will become hot when used - take care
when touching.
This product is intended to be used to cook or
•
heat food.
Allow to cool before touching.
•
ONLY
•
Only load between 4 or 5 logs at a time.
•
OVER FILL
use untreated wood as fuel in this product.
NOT
DO NOT
.
CALIFORNIA PROPOSITION 65
This product is produced with or contains
chemicals known to the State of California to
cause cancer, birth defects, or other reproductive
harm.
Page 7
LIMITED WARRANTY
Manufacturer warrants to the original consumer-purchaser only that this product shall be free from defects in workmanship and materials after correct assembly
and under normal and reasonable home use for the periods indicated below beginning on the date of purchase.
The manufacturer reserves the right to require that defective parts be returned, postage and or freight pre-paid, by the consumer, for review and examination.
90 Day LIMITED Warranty
Upon consumer supplying proof of purchase as provided herein, Manufacturer will repair or replace the parts listed below which are proven defective during the
applicable warranty period. Parts required to complete such repair or replacement shall be free of charge to you except for shipping costs. The original consumer-
purchaser will be responsible for all shipping charges of parts replaced under the terms of this limited warranty.
This limited warranty is applicable in the United States and Canada only, is only available to the original owner of the product and is not transferable.
Manufacturer requires reasonable proof of your date of purchase. Therefore, you should retain your sales slip or invoice and register your new product immediately.
Defective or missing parts subject to this limited warranty will not be replaced without registration or proof of purchase. Register online at or
complete and return via mail the Product Registration Card located on the last page of the Use & Care manual included with this product and retain your sales receipt
for proof of purchase.
This limited warranty applies to the functionality of the product ONLY and does not cover cosmetic issues such as scratches, dents, corrosion or discoloring by
heat, abrasive and chemical cleaners or any tools used in the assembly or installation of the appliance, surface rust, or the discoloration of stainless steel surfaces.
The warranty for your grill covers manufacturing defects. Surface rust, corrosion, or powder paint chipping on metal parts that does not affect the structural integrity of
the product is not considered a defect in workmanship or material and is not covered by this warranty.
This limited warranty will not reimburse you for the cost of any inconvenience, food, personal injury or property damage.
If an original replacement part is not available, a comparable replacement part will be sent. You will be responsible for all shipping charges of parts replaced
under the terms of this limited warranty.
ITEMS MANUFACTURER WILL NOT PAY FOR:
1. Service calls to your home.
2. Repairs when your product is used for other than normal, single-family household or residential use.
3. Damage resulting from accident, alteration, misuse, abuse, fire, flood, acts of God, improper installation, installation not in accordance with electrical or plumbing
codes, or use of products not approved by the manufacturer.
4. Any food loss due to product failures.
5. Replacement parts or repair labor costs for units operated outside the United States or Canada.
6. Pickup and delivery of your product.
7. Repairs to parts or systems resulting from unauthorized modifications made to the product.
8. The removal and/or reinstallation of your product.
9. Shipping cost, standard or expedited, for warranty and replacement parts.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
Repair or replacement of defective parts is your exclusive remedy under the terms of this limited warranty. Manufacturer will not be responsible for any
consequential or incidental damages arising from the breach of either this limited warranty or any applicable implied warranty, or for failure or damage resulting from
acts of God, improper care and maintenance, grease fire, accident, alteration, replacement of parts by anyone other than Manufacturer, misuse, transportation,
commercial use, abuse, hostile environments (inclement weather, acts of nature, animal tampering), improper installation or installation not in accordance with local
codes or printed manufacturer instructions.
THIS LIMITED WARRANTY IS THE SOLE EXPRESS WARRANTY GIVEN BY THE MANUFACTURER. NO PRODUCT PERFORMANCE SPECIFICATION OR
DESCRIPTION WHEREVER APPEARING IS WARRANTED BY MANUFACTURER EXCEPT TO THE EXTENT SET FORTH IN THIS LIMITED WARRANTY. ANY
IMPLIED WARRANTY PROTECTION ARISING UNDER THE LAWS OF ANY STATE, INCLUDING IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE OR USE, IS HEREBY LIMITED IN DURATION TO THE DURATION OF THIS LIMITED WARRANTY.
Neither dealers nor the retail establishment selling this product has any authority to make any additional warranties or to promise remedies in
addition to or inconsistent with those stated above.
Manufacturer's maximum liability, in any event, shall not exceed the documented purchase price of the product paid by the original consumer. This warranty
only applies to units purchased from an authorized retailer and or re-seller.
NOTE: Some states do not allow an exclusion or limitation of incidental or consequential damages, so some of the above limitations or exclusions may not
apply to you. This limited warranty gives you specific legal rights as set for herein. You may also have other rights which vary from state to state. In the state of
California only, if refinishing or replacement of the product is not commercially practicable, the retailer selling this product or the Manufacturer will refund the purchase
price paid for the product, less the amount directly attributable to use by the original consumer-purchaser prior to discovery of the nonconformity. In addition, in the
state of California only, you may take the product to the retail establishment selling this product in order to obtain performance under this limited warranty.
If you wish to obtain performance of any obligation under this limited warranty, you should write to:
Char-Broil Consumer Relations
P. O. Box 1240
Columbus, GA 31902-1240
Consumer returns will not be accepted unless a valid Return Authorization is first acquired by calling 1-800-232-3398 and then clearly marked on the outside of the
package and the package is shipped freight/postage pre-paid to the address above.
www.charbroil.com
Certified Grill Parts And Accessories®, Char-Broil and Design®, Char-Broil (Gas Grill Briquettes)®, Char-Diamonds®, Cooking Zone and Design®, Diamond Flame®, Executive Chef®, Faststart®, Flare Fighter®, FlavorMaster®, Gas Grill
Silouette and Design®, H2O Smoker®, Lava Flame®, MasterFlame®, MasterFlame Precision Cooking System®, PowerSpark®, Quantum®, PrecisionFlame and Design®, Sierra® and TruFlame® are registered Trademarks of the W.C. Bradley
Company. Thermos® is a registered trademark of the Thermos Company and its affiliates.
Artisan Collectiion by Char-Broil™, C3 and Design™, Char-Broil and Design™, Flame Design™, FlavorTents™, Grill 2 Go™, Grillin’ Stick™, Keeper of the Flame™, Keepers of the Flame™, Natural Grip™, Outdoor Cooking Collection and
Design™, Patio Bistro™, PrecisionFlame™, Pro-Check™, QuickSet Grills and Design™, SmokerTents™, The Big Easy™. The Minute Grill™, The Edge™, The Tuscan Collection™, and The Urban Grill™ are Trademarks of the W.C. Bradley
Company. Universal Grill Parts and Design™ is a trademark of the Thermos Company and its affiliates.
Protected under one or more of the following U.S. Patents: 4,598,692; 4,624,240; 4,747,391; 4,747,391; 4,817,583; 4,924,846; 4,989,579; 5,003,960; 5,076,256; 5,076,257; 5,090,398; 5,109,834; 5,224,676; 5,277,106; 5,421,319; 5,441,226;
5,452,707;5,458,309; 5,566,606; 5,579,755; 5,582,094; 5,613,486; 5,649,475; 5,706,797; 5,711,663; 5,765,543; 5,931,149; 5,996,573; 6,095,132; 6,135,104; 6,173,644; 6,279,566; 6,397,731; 6,418,923;6,439,222; 6,523,461; D282,619; D339,714;
D341,292; D343,337; D358,059; D361,466; D364,535; D372,637; D373,701; D377,735; D383,035; D397,910; D405,643; D405,643; D406,005; D406,009; D413,043; D413,229; D413,229; D414,982; D415,388; D416,164; D416,441; D417,587;
D422,516; D423,274; D423,876; D428,303; D435,396; D463,004; D438,059; D438,060; D438,427; D439,110; D442,505; D443,179; D443,354; D447,384; D447,385; D447,909; D448,610; D448,614; D448,615; D448,616; D448,975; D449,492;
D451,759; D456,202S; D460,313; D461,359 and D477,501. Canada: 87743; 87744; 92607; 92608 and 1,316,424. Other Patents Pending. ©2006 W. C. Bradley Co., All Rights Reserved.
