REMOTE CONTROL
The is the installer’s master remote for Channel Vision’s whole-
3
A0503
house intercom system. It is designed to control every possible function
of the intercom. Installers can use this remote to teach a learning remote
control the IR codes needed for their specific system.
Features:
!
Easily controls your whole-house intercom system
!
No programming necessary
!
Compatible with: P-0930 and ST-2000
Using the A0503 remote control...
The A0503 is designed to allow you to control your intercom system without
having to touch the buttons on the intercom station. Simply point the A0503
remote control at the IR sensor located at the bottom of the ST-2000 and press
the desired button on the remote control.
A
1
Station Call Buttons
The intercom system can have up to 4 hubs with 6 stations each,
providing a total of 24 possible stations (or Zones). The 6 station
call buttons on the ST-2000 are always Zone A. When the
ST-2100 station expanders are used, Zone B, C,&DontheA0502
remote will control their 6 call buttons.
CVHANNEL ISION
ZONE
ABCD
1
1
1
2
2
2
3
3
3
4
4
4
5
5
Mon
Activates monitor
function of the
intercom station
DND
Activates DND
function of the
intercom station
6
MON
DND
6
MODEL
A0503
5
6
PAG E
ANS/END
Page
Activates paging function
of the intercom station
Ans/End
Answers or Ends an
incoming call on the
intercom station
Monitor
DND Answer/End
Page
ST-2000
