Model 6010-B 1/3” COLOR
Vari-FOCAL Bullet Camera
Mounting hole
1/4" - 20
1-1/4"
4"
Specifications May Change Without Notice.
Zoom ring
BNC
(Video)
DC Jack
(Power)
234 Fischer Ave.
Costa Mesa, CA 92626
Image Sensor
Effective Pixels
Horizontal Resolution
Synchronizing System
Scanning System
Video Output
S/N Ratio
Minimum Illumination
BLC
Shutter Speed
Gamma Correction
White Balance
Gain Control (AGC)
Smear Effect
MTBF
Power Source
Operating Current
Lens
Operating Temperature
Humidity
Output Terminal
Dimensions
Weight
380 TV Lines, Weatherproof
Standard 4-9mm, Vari-FOCAL Lens
Strong, metal structure, easy to install.
Specifications
1/3” Color CCD
NTSC: 512 (H) x 492 (V)
380 TV Lines
Internal
2:1 Interlaced
1V p-p 75 Composite
More than 48dB (AGC off)
0.2 Lux @ F2.0
Automatic
NTSC: 1/60 ~1/100,000
0.45
2100 K~8200 K Auto°°
Automatic
0.005%
80,000 hours
9~12 VDC Regulated
90mA
4-9mm (69°) Vari-FOCAL Lens
14°F ~ 122 F (10 C ~ 50 C)°° °
Less than 90% RH
4’ Cable with BNC - Female for Video, DC Jack - Male for Power
1-1/4” (D) x 4” (L)
5.1 oz
500-000
CHANNEL VISION
Limited Warranty
Channel Vision Technology will repair or replace any defect in material or workmanship which
occur during normal use of this product with new or rebuilt parts, free of charge in the USA, for
two years from the date of original purchase. This is a no hassle warranty with no mail in warranty
card needed. This warranty does not cover damages in shipment, failures caused by other products
not supplied by Channel Vision Technology, or failures due to accident, misuse, abuse, or
alteration of the equipment. This warranty is extended only to the original purchaser, and a
purchase receipt, invoice, or other proof of original purchase date will be required before
warranty repairs are provided.
Mail in service can be obtained during the warranty period by calling (800) 840-0288 tool free. A
Return Authorization number must be obtained in advance and can be marked on the outside of
the shipping carton.
This warranty gives you specific legal rights and you may have other rights (which vary from state
to state). If a problem with this product develops during or after the warranty period, please
contact Channel VisionTechnology, your dealer or any factory-authorized service center.
