Chaney Instrument 00782TXA1 User Manual

Instruction Manual

Specification:

- Indoor and outdoor temperatures displayed on the main LCD readout

- Temperature measurement range:

Indoor main unit: 32F – 122F (0 ºC ~ +50 ºC)
Wireless remote unit: -4 F – 130F (-20 ºC ~ +55 ºC)

- Temperature resolution: 0.1 degree

- Transmission range : up to 100ft. in an open area

Instruction manual:

ATTENTION:
For the fist installation, insert the batteries in the display unit and then in the remote sensor

Battery installation:
Display unit
Insert 2 fresh “AAA” alkaline batteries into the display unit. (Batteries not included)
Remote sensor
Insert 2 fresh “AAA” alkaline batteries into the remote sensor. (Batteries not included)

Getting started:

Indoor Display unit
When the batteries are put into the display unit, it will display the indoor temperature .The outdoor
reading “----”

Remote sensor
When the batteries are placed into the remote sensor, it will signal the temperature to the display unit.
The display unit will then be able to display the outdoor temperature. You may need to push the Reset
button on the back of the display unit.

Reset button

Reset button

Battery Icon Description:
The battery icon will display when the batteries are full.

The battery icon will display and the temperature readings will be blinking when the batteries
are low capacity.

When to replace the Batteries:

For the remote sensor:
When the battery icon of the outdoor window displays continuously the remote sensor batteries
are low and need to be replaced.
Replace the batteries in the Remote sensor and then you MUST press the RESET button on the Indoor
Display unit (receiver).
When the battery icon of the Indoor display unit (receiver) displays please replace the batteries in
the Display unit (receiver).

Antenna Icon Description:
The antenna icon of the indoor window will display waving as

signal from the remote sensor.

The antenna icon of the outdoor window will display
successfully receive the data from the remote sensor.

for 0.5 second when the receiver had

when the receiver is receiving RF

When the outdoor window displays “- - -”, and the antenna icon of the indoor window displays
continuously, the receiver maybe do not either receive any data from remote sensor or the remote sensor
is located to far away from display unit (out of range). You MUST be press the RESET button on the
Indoor unit (receiver).
