Chandler Limited Little Devil Compressor User Manual

Little Devil Compressor - Designed by Wade Chandler Goeke
Prior to sending in your gear for repair, please contact our shop at the number below. We will assist you in trouble­shooting the problem and if needed, we will issue you an RMA# to send in the gear.
Chandler Limited, Little Devil and the Little Devil Flame Logo are trademarks of Chandler Limited Inc. All rights reserved.
COMPATIBILTY­The Little Devil Compressor is tested and proven to have no start up or power errors in these racks-
API 500v 10-slot with L200 PSU API 500-6B Lunchbox API 500-6B HC “new version” Lunchbox
BAE 11-slot with power one supply BAE 6-slot portable with power one supply BAE 6-slot with Avedis designed supply
Emperical Labs 2-slot (awesome rack and worth the money!) A-Designs 2-slot
Purple Sweet 10
As of the release of this product we have not yet tested with the Radial Workhorse.
POWER SUPPLY RECOMMENDATIONS­With ANY 500 modules (not just the Devils) we recommend using a rack with external supply. We feel a power supply in such close proximity to the right hand slots of the rack can cause hum and noise oor issues with many modules by many manufacturers. For this reason we mainly recommend the API 500v rack with external L200 supply and the BAE 11-slot with external supply.
NOTES on BAE racks­We recommend adding a wire from Earth to power supply common on all BAE racks. In many cases hum can be avoided and Earth to common is standard procedure on most electronic equipment.
