OWNER’S MANUAL & OPERATING INSTRUCTIONS
4000 PSI / 4.0 GPM
Trigger Start
™
PRESSURE WASHER
MODEL NUMBER
71353
10006 Santa Fe Springs Road
SAVE THESE INSTRUCTIONS
Important Safety Instructions
are included in this manual.
MADE IN CHINA
REV 71353-20130325
www.championpowerequipment.com
Santa Fe Springs CA 90670
USA / 1-877-338-0999
Have questions or need assistance?
Do not return this product to the store!
WE ARE HERE TO HELP!
Visit our website:
www.championpowerequipment.com
for more info:
• Product Info & Updates
• Frequently Asked Questions
– or –
Call our Customer Care Team Toll-Free at:
• Tech Bulletins
• Product Registration
1-877-338-0999
*We are always working to improve our products. Therefore, the enclosed product may differ slightly from the image on the cover.
TABLE OF CONTENTS
71353
4000 PSI / 4.0 GPM
Trigger Start
™
PRESSURE WASHER
Introduction ............................. 1
Pressure Washer ........................ 1
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
This Booklet ........................... 1
Manual Conventions ........................ 2
Safety Rules ............................. 3
Controls and Features ....................... 5
Pressure Washer ........................ 5
Utility Panel ............................ 6
Trigger Start Operation ................... 7
To activate the Trigger Start feature ........ 7
To start the engine using the
Trigger Start feature .................. 7
To stop the engine using the
Trigger Start feature .................. 7
Parts Included .......................... 8
Assembly ............................... 9
Remove the Pressure Washer from the
Shipping Carton ........................ 9
Install the Wheel Kit ...................... 9
Install the Support Leg .................... 9
Connect the Battery ...................... 9
Install the Handle ........................9
Attach the Hose Hanger .................. 10
Attach the Gun Holder ................... 10
Install the Hoses ....................... 10
Attach the Pressure Gun ............... 10
Connect to Garden Hose ............... 10
Attach the Detergent Hose .............. 10
Add Engine Oil ........................ 11
Add Fuel ............................. 12
Operation .............................. 13
Pressure Washer Location ................. 13
Before Starting the Engine ................ 13
Starting the Engine ...................... 13
To activate the Trigger Start feature ......... 13
To start the engine using the
Trigger Start feature ................... 13
Distance from Cleaning Surface ............ 14
High Pressure Wash ..................... 14
Low Pressure Wash ..................... 14
Detergent Use ....................... 14
System Flush ....................... 14
Depressurize System .................... 15
Operating Tips ......................... 15
Stopping the Engine ..................... 15
To stop the engine using the
Trigger Start feature ................... 15
Maintenance and Storage ................... 16
Engine Maintenance ..................... 16
Oil ............................... 16
Spark Plugs ........................ 16
Air Filter ........................... 17
Pump Oil ........................... 17
Cleaning ............................. 17
Adjustments ........................ 17
Maintenance Schedule ................. 17
Pressure Washer Maintenance .............. 17
Cleaning Spray Nozzle ................. 18
Storage ............................ 18
Engine Storage ........................ 18
Engines Stored for Less than 30 days .........18
Engines Stored for Over 30 days ............ 18
Battery .............................. 19
Charging the Battery ..................... 19
Disconnecting the Battery ................. 19
Pressure Washer Storage ................. 20
Winter Storage ........................ 20
Winterize the pump ...................... 20
Specifications ........................... 21
Engine Specifications .................... 21
Pressure Washer Specifications ............. 21
Fuel ................................ 21
Oil ................................. 21
Spark Plugs .......................... 21
Maintenance Valve Clearance .............. 21
Troubleshooting .......................... 22
Pressure Washer Parts Diagram ............. 23
Pressure Washer Parts List ................ 24
Engine Parts Diagram ................... 25
Engine Parts List ....................... 26
Warranty ............................... 27
Warranty Qualifications ................... 27
Repair/Replacement Warranty .............. 27
Do not return the unit to the place of
purchase ............................ 27
Warranty Exclusions ..................... 27
Normal Wear ....................... 27
Installation, Use and Maintenance ......... 27
Other Exclusions ..................... 27
Limits of Implied Warranty and
Consequential Damage ................... 27
Contact Information ..................... 27
Address ........................... 27
Customer Service .................... 27
Technical Service .................... 27
INTRODUCTION
ENGLISH 71353
Introduction
Congratulations on your purchase of a Champion Power
Equipment pressure washer. CPE designs and builds
pressure washers to strict specifications. With proper
use and maintenance, this pressure washer will bring
years of satisfying service.
Pressure Washer
This unit is a gasoline engine driven pressure washer. It is
designed for use in cleaning with or without detergent and
is suitable for decks, patios, house siding, vehicles, lawn
furniture, barbecue grills, gardening tools and more.
Record the model and serial numbers as well as date and place of purchase for future reference. Have this
information available when ordering parts and when making technical or warranty inquiries.
Accessories
Champion Power Equipment manufactures and sells
accessories designed to help you get the most from
your purchase. To find out more about our accessories,
please visit our website at:
www.championpowerequipment.com
This Booklet
Every effort has been made to ensure the accuracy and
completeness of the information in this manual. We reserve
the right to change, alter and/or improve the product and
this document at any time without prior notice.
Champion Power Equipment Support
1-877-338-0999
Model Number
71353
Serial Number
Date of Purchase
Purchase Location
For O il Typ e see ‘Add Engine Oil‘ section. For Fuel Typ e see ‘Add Fuel‘ section.
1 REV 71353-20130325
71353 ENGLISH
MANUAL CONVENTIONS
This manual uses the following symbols to help differentiate between different kinds of information. The safety symbol
is used with a key word to alert you to potential hazards in operating and owning power equipment.
Follow all safety messages to avoid or reduce the risk of serious injury or death.
DANGER
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in death
or serious injury.
WARNING
WARNING indicates a potentially hazardous
situation which, if not avoided, could result in
death or serious injury.
CAUTION
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in minor
or moderate injury.
CAUTION
CAUTION used without the safety alert symbol
indicates a potentially hazardous situation which, if
not avoided, may result in property damage.
NOTE
If you have questions regarding your pressure
washer, we can help. Please call our help line at
1-877-338-0999
REV 71353-20130325 2
SAFETY RULES
ENGLISH 71353
WARNING
Read this manual thoroughly before operating your
pressure washer. Failure to follow instructions could
result in serious injury or death.
WARNING
The engine exhaust from this product contains
chemicals known to the state of California to cause
cancer, birth defects, or other reproductive harm.
DANGER
Engine exhaust contains carbon monoxide, a
colourless, odourless, poison gas. Breathing carbon
monoxide will cause nausea, dizziness, fainting or
death. If you start to feel dizzy or weak, get to fresh
air immediately.
Operate pressure washer outdoors only in a well
ventilated area.
DO NOT operate the pressure washer inside
any building, including garages, basements,
crawlspaces and sheds, enclosure or compartment,
including the pressure washer compartment of a
recreational vehicle.
DO NOT allow exhaust fumes to enter a confined
area through windows, doors, vents or other
openings.
DANGER CARBON MONOXIDE, using a pressure
washer indoors CAN KILL YOU IN MINUTES.
DANGER
WARNING
Sparks can result in fire or electrical shock.
When servicing the pressure washer:
Disconnect the spark plug wire and place it where it
cannot contact the plug.
DO NOT check for spark with the plug removed.
Use only approved spark plug testers.
WARNING
Running engines produce heat. Severe burns can
occur on contact. Combustible material can catch
fire on contact.
DO NOT touch hot surfaces.
Avoid contact with hot exhaust gases.
Allow equipment to cool before touching.
Maintain at least three feet of clearance on all
sides to ensure adequate cooling.
Maintain at least five feet of clearance from
combustible materials.
WARNING
DO NOT let water in the pump freeze.
See Storage section in the manual for instructions
regarding winter storage.
If water has frozen in the pressure washer, thaw the
pressure washer in a warm room before starting.
DO NOT pour hot water on or into the pump;
internal parts will be damaged and your warranty
will be voided.
Rotating parts can entangle hands, feet, hair,
clothing and/or accessories.
Traumatic amputation or severe laceration can result.
Keep hands and feet away from rotating parts.
Tie up long hair and remove jewelry.
Operate equipment with guards in place.
DO NOT wear loose-fitting clothing, dangling
drawstrings or items that could become caught.
WARNING
This product contains a button battery. If
swallowed, it could cause severe injury or death in
just 2 hours. Seek medical attention immediately.
3 REV 71353-20130325
WARNING
NEVER spray flammable liquids or use pressure
washer in areas containing combustible dust, liquids,
or vapour.
NEVER operate this machine in a closed building or
in or near an explosive environment.
• DO NOT remove fuel tank cap or ll fuel tank while
engine is hot or running (allow engine to cool two
minutes before refueling). Always fill the tank slowly.
• Never disconnect the high pressure discharge hose
from the machine while the system is pressurized.
71353 ENGLISH
SAFETY RULES
DANGER
Fuel and fuel vapours are highly flammable and
extremely explosive.
Fire or explosion can cause severe burns or death.
Unintentional startup can result in entanglement,
traumatic amputation or laceration.
When adding or removing fuel:
Turn the pressure washer off and let it cool for at
least two minutes before removing the fuel cap.
Loosen the cap slowly to relieve pressure in the tank.
Only fill or drain fuel outdoors in a well-ventilated area.
DO NOT pump gas directly into the pressure washer
at the gas station. Use an approved container to
transfer the fuel to the pressure washer.
DO NOT overfill the fuel tank.
Always keep fuel away from sparks, open flames,
pilot lights, heat and other sources of ignition.
DO NOT light or smoke cigarettes.
When starting the pressure washer:
DO NOT attempt to start a damaged pressure
washer.
Make certain that the gas cap, air filter, spark plug,
fuel lines and exhaust system are properly in place.
Allow spilled fuel to evaporate fully before
attempting to start the engine.
Make certain that the pressure washer is resting
firmly on level ground.
WARNING
Rapid retraction of the starter cord will pull hand and
arm towards the engine faster than you can let go.
Unintentional startup can result in entanglement,
traumatic amputation or laceration.
Broken bones, fractures, bruises or sprains could result.
When starting engine, pull the starter cord slowly
until resistance is felt and then pull rapidly to avoid
kickback.
DANGER
Keep clear of nozzle.
DO NOT point the pressure wand at a person, an
animal or yourself.
Always wear safety glasses or goggles and
protective equipment (hearing protection, gloves,
rubber boots, protective clothing) when operating or
performing maintenance.
• Never put hand or ngers over the spray tip while
operating the unit.
• Never try to stop or deect leaks with any body part.
• Always engage the trigger safety latch in the safe
position when spraying is stopped even if only for a
few moments.
When operating the pressure washer:
DO NOT move or tip the pressure washer during
operation.
DO NOT tip the pressure washer or allow fuel or oil
to spill.
When transporting or servicing the pressure washer:
Make certain that the fuel shutoff valve is in the off
position and the fuel tank is empty.
Disconnect the spark plug wire.
When storing the pressure washer:
Store away from sparks, open flames, pilot lights,
heat and other sources of ignition.
CAUTION
NEVER run the unit dry.
Be sure the water supply is completely turned on
before operating the unit.
CAUTION
Improper treatment or use of the pressure washer can
damage it, shorten its life and void your warranty.
Use the pressure washer only for intended uses.
Operate only on level surfaces.
DO NOT expose pressure washer to excessive
moisture, dust, or dirt.
DO NOT allow any material to block the cooling slots.
DO NOT use the pressure washer if:
– Equipment sparks, smokes or emits flames
– Equipment vibrates excessively
REV 71353-20130325 4
ENGLISH 71353
CONTROLS AND FEATURES
Read this owner’s manual before operating your pressure washer. Familiarize yourself with the location and function
of the controls and features. Save this manual for future reference.
Pressure Washer
10
1
2
3
9
8
7
6
4
(1) Fuel Tank – 6.2 L (1.64 gal.)
(2) Choke – Used to start the engine.
(3) Air Filter – Protects the engine by filtering dust
and debris from the intake air.
(4) Recoil Starter – Used to start the engine.
(5) 25.4 cm (10 in.) Never Flat Wheels
5
(6) Battery
(7) Utility Panel – See Utility Panel section.
(8) High Pressure Hose Hanger – Used to hold the
high pressure hose when not in use.
(9) Gun Holder – Used to the hold gun when not
assembled and in use.
(10) Handle
5 REV 71353-20130325
71353 ENGLISH
1:1
Utility Panel
1 2
CONTROLS AND FEATURES
(1) Ignition Switch – Used to start or stop the
pressure washer.
(2) Trigger Start Switch – Enables /disables starting
electrically.
(3) Garden Hose Connection – Used to connect the
water supply to unit.
3
REV 71353-20130325 6
CONTROLS AND FEATURES
ENGLISH 71353
Trigger Start™ Operation
This pressure washer is equipped with a patent pending
system that allows the operator to start and stop the
engine using the pressure washer gun. When working
at any distance from the machine, just pull the trigger
to start the engine and release the trigger to stop the
engine. There is no need to return to the machine to start
and stop the engine.
To activate the Trigger Start feature:
1. Connect and turn “ON” the water supply.
2. Make sure the fuel valve is in the “ON” position.
3. Move the Ignition Switch to the “ON” position.
4. Move the Trigger Start Switch to the “Enable”
position.
Only when the Trigger Start feature is active can the
engine can be started or stopped using the trigger of the
gun.
To start the engine using the Trigger Start feature:
1. Pull and hold the trigger of the gun.
2. The engine will attempt to start approximately 3
seconds after water begins to flow out of the gun.
To stop the engine using the Trigger Start feature:
1. Release the trigger of the gun
2. The engine will turn “OFF” approximately 15
seconds after the trigger is released.
NOTE
If the trigger is released and then pulled before 15
seconds has elapsed, the engine will continue to run.
This allows the unit to continue running while the
operator stops washing momentarily to move the unit
or the object being washed.
Note : When the Trigger Start switch is in the “disabled”
position, the gun trigger will not start or stop the engine.
The water supply must be connected and turned “ON” for
the Trigger Start feature to function.
Note : Extension hoses may be added without affecting
this feature.
NOTE
There is no need to manually choke the engine. The
Engine Control Module automatically chokes the
engine during startup. If the engine fails to start on
the first attempt, it will automatically try again up
to six (6) times, without need of extra pulling of the
trigger.
7 REV 71353-20130325
