Table of Contents
Introduction ..................................... 1
Accessories................................................ 1
This Booklet.............................................. 1
Manual Conventions.........................2
Safety Rules......................................3
Controls and Features.......................5
Winch........................................................ 5
Mounting..........................................6
Mounting the Winch.................................6
Operation .........................................7
General Tips for Safe Operation............... 7
Self Recovery ............................................ 7
Winching Techniques A-Z........................8
Maintenance.....................................9
Lubrication ...............................................9
Cable Assembly Replacement ..................9
Specifications .................................10
Performance Specifications.................... 10
Winch Diagram........................................11
Winch Parts List ..................................... 12
Solenoid Diagram................................... 13
Solenoid Parts List.................................. 14
Troubleshooting ............................. 15
Warranty ........................................ 16
Warranty Qualifications .........................16
Repair/Replacement Warranty..............16
Do not return the unit to the place of
purchase..................................................16
Warranty Exclusions...............................16
Normal Wear.......................................16
Installation, Use and Maintenance.....16
Other Exclusions.................................16
Limits of Implied Warranty and
Consequential Damage...........................16
Contact Information...............................17
Address................................................17
Customer Service ................................ 17
Technical Service................................. 17
Notes ..............................................18
Introduction
Introduction
Congratulations on your purchase of a
Champion Power Equipment winch. CPE
designs and builds winches to strict
specifications. With proper use and
maintenance, this winch will bring years of
satisfying service.
This Booklet
Every effort has been made to ensure the
accuracy and completeness of the
information in this manual. We reserve the
right to change, alter and/or improve the
product and this document at any time
without prior notice.
Accessories
Champion Power Equipment manufactures
and sells accessories designed to help you
get the most from your purchase. To find out
more about our covers, tree savers, hooks,
fairleads, etc., please visit our web site at
www.championpowerequipment.com
Record the model and serial numbers as well as date and place of purchase for future reference.
Have this information available when ordering parts and when making technical or warranty
inquiries.
Champion Power Equipment Support
(877) 338-0999
Model Number
10012
Serial Number
Date of Purchase
Purchase Location
1
Manual Conventions
Manual Conventions
This manual uses the following symbols to
help differentiate between different kinds of
information. The safety symbol is used with
a key word to alert you to potential hazards
in operating and owning power equipment.
Follow all safety messages to avoid or reduce
the risk of serious injury or death.
CAUTION
CAUTION indicates a potentially hazardous
situation which, if not avoided,
minor or moderate injury.
may
result in
CAUTION
DANGER
DANGER indicates an imminently hazardous
situation which, if not avoided,
or serious injury.
will
result in death
WARNING
WARNING indicates a potentially hazardous
situation which, if not avoided,
death or serious injury.
could
result in
CAUTION used without the safety alert symbol
indicates a potentially hazardous situation which,
if not avoided,
may
result in property damage.
NOTE
If you have questions regarding your winch, we
can help. Please call our help line at (877) 338-
0999.
2
Safety Rules
Safety Rules
WARNING
Read this manual thoroughly before operating
your winch. Failure to follow instructions could
result in serious injury or death.
WARNING
Do not exceed the rated capacity.
DANGER
Do not use this winch for lifting or moving people
or animals.
WARNING
Do not move the vehicle to pull a load (towing)
on the winch cable. This could result in cable
breakage.
WARNING
Disconnect the remote control and battery leads
when not in use.
WARNING
Avoid “shock loads” by using the control switch
intermittently to take up the slack in the wire
rope. “Shock loads” can far exceed the rate
capacity for the wire rope and drum.
DANGER
Keep yourself and others a safe distance to the
side of the cable when under tension.
DANGER
Never step over a cable or near a cable under
load.
WARNING
The wire rope may break before the motor stalls.
For heavy loads at or near rated capacity, use a
pulley block/snatch block to reduce the load on
the wire rope.
WARNING
When re-spooling the cable, ensure that the
cable spools in the under-wind position with the
cable entering the drum from the bottom, not the
top.
To re-spool correctly, and while wearing gloves,
keep a slight load on the cable while pushing the
remote button to draw in the cable. Walk toward
the winch not allowing the cable to slide through
your hands. Do not let your hands get within 12”
of the winch while re-spooling. Turn off the
winch and repeat the procedure until a few feet
of cable is left. Disconnect the remote control
and finish spooling by rotating the drum by hand
with the clutch disengaged. Keep hands clear of
the fairlead and drum while the winch is under
power.
WARNING
Do not use as a hoist. Do not use for overhead
lifting.
3
Safety Rules
CAUTION
Use gloves to protect hands when handling the
cable. Never let the cable slide through your
hands.
CAUTION
Do not wrap the cable around any object and
hook it back onto itself.
CAUTION
Apply blocks to the wheels of the vehicle when
on an incline.
CAUTION
CAUTION
If the motor stalls, do not maintain power to the
winch.
Electric winches are designed and made for
intermittent use and should not be used in
constant duty applications.
CAUTION
Never release the free-spool clutch when there is
a load on the winch.
CAUTION
Use hook strap when handling the hook for
spooling or unspooling the wire rope.
Duration of winching pulls should be kept as
short as possible.
If the motor becomes uncomfortably hot to the
touch, stop winching immediately and let it cool
down for a few minutes. Do not pull for more
than one minute at or near the rated load.
4
Controls and Features
Controls and Features
Read this owner’s manual before operating your winch. Familiarize yourself with the location and
function of the controls and features. Save this manual for future reference.
Winch
Motor (1): 2.2HP motor requires a 650CCA
12 volt battery and provides power to the
planetary gear mechanism.
Winch Drum (2): The winch drum is the
cylinder on which the wire rope is stored. It
can feed or wind the rope depending on the
remote winch switch.
Wire Rope (3): 5/16” x 95’ galvanized
aircraft cable designed specifically for load
capacity of 8,000lbs. The wire rope feeds
onto the drum in the “under wind” position
through the roller fairlead (4) and is looped
at the end to accept the clevis hook pin (11).
Roller Fairlead (4): When using the
winch at an angle the roller fairlead acts to
guide the wire rope onto the drum and
minimizes damage to the wire rope from
abrasion on the winch mount or bumper.
Planetary Gear System (5): The
reduction gears convert the winch motor
power into extreme pulling forces. This
system allows high torque while maintaining
compact size and light weight.
Braking System (6): Braking action is
automatically applied to the winch drum by
a separate mechanical brake when the winch
motor is stopped and there is a load on the
wire rope.
Free spooling Clutch (7): The clutch
allows the operator to manually disengage
(“Out”) the spooling drum from the gear
train, free spool. Engaging the clutch (“In”)
locks the winch into the gear system.
Solenoid (8): Power from the vehicle
battery flows through the weather sealed
solenoid switch before being directed to the
winch motor.
Remote Switch (9): Power switch with 12’
cord has a comfort grip and dual switches
for powering the rope in or out of your
winch drum. The 12’ cord allows you to
stand clear of the wire rope when the winch
is under load.
Universal Flat Bed Mounting Channel
(10): A flat bed mounting channel that can
be mounted to most flat surfaces such as
trailers, step bumpers, truck beds, etc. The
mounting channel also has holes to accept
your roller fairlead (4).
Clevis Hook (11): Provides a means for
connecting the looped ends of cables to an
anchor.
Snatch Block (12): Used properly, the
snatch block can double the pulling power of
winch, or change your pulling directly
without damaging the wire rope.
D-Shackle (13): Provides a means for
connecting the looped ends of cables, straps
and snatch blocks. The pin is threaded for
easy removal.
5
Mounting
Mounting
This CPE 8,000 lb winch is designed with a
10” x 4.5” bolt pattern that is standard in
this class of winch. Many winch mounting
kits are available that utilize this bolt pattern
for the most popular trucks, SUV’s and
ATV’s. If you cannot find a kit locally,
contact CPE and we will provide you with
the name of a dealer near you.
If you will utilize the CPE mounting channel
you must ensure that it is mounted on a flat
surface so that the three major sections
(motor, drum and gear housing) are
properly aligned. Proper alignment of the
winch will allow even distribution of the full
rated load.
3. Place the Mounting Channel on the
winch, making sure the winch is
centered in the middle of the mounting
channel. Disengage the clutch by moving
the Cam Ring to the “Out” position.
Release the wire rope and pull through
the slot in the front of the channel.
4. Attach using the 4 x M10 Cap Screws
with Lock Washers (Part# 800021 &
Part# 800022) into the hole.
5. Attach the clevis hook and hand strap.
6. Connect the battery leads. FOR WINCH
TO FUNCTION PROPERLY: Connect
the red (positive) lead from the solenoid
to the positive (+) terminal of the
vehicles 12 volt battery. Connect the
black (negative) lead from the solenoid
to the Negative (-) terminal of the
battery.
Mounting the Winch
1. Insert 2 x M10 Nuts with Lock Washers
(Part# 800021 & Part# 800022) to the
mounting channel hole and attach the
Roller Fairlead to the mounting channel
with the 2 Lock Washers and Nut M10
(Part# 800023 & Part# 800024)
provided.
CAUTION
Mounting bolts must be SAE grade 5 or better
and torque to 34 ft. lbs.
2. Turn the winch up-side-down; insert 4
Flat Washers with Nut M10 (Part#
800023 & Part# 800024) into the holes
of the winch.
CAUTION
Battery cables should not be drawn taut. Leave
some slack for cable movement.
7. Attach the hand held remote lead to the
winch and test for proper operation.
8. Check for proper drum rotation. Pull
and turn the clutch knob to the “out”
position (Free spooling). Pull out some
cable from the drum, and then turn the
clutch knob to the “In” position to
engage the gears. Press the cable out
button on the power switch. If the drum
is turning and releasing more cable then
your connections are accurate. If the
drum is turning and collecting more
cable then reverse the leads on the
motor. Repeat and check rotation.
6
Operation
Self Recovery
Operation
General Tips for Safe
Operation
Your 10012 winch is rated at 8,000 lbs.
capacity in first layer (max) when spooling
the first rope layer on the drum. Overloads
can damage the winch, motor and/or wire
rope. For loads over 5,000 lbs. we
recommend the use of the pulley
block/snatch block to double the wire rope
line. The will aid in two ways:
a) reduce the number or rope layers on the
drum, as well as,
b) reduce the load on the wire rope by as
much as 50%.
When doubling the line back to the vehicle,
attach to the frame or other load bearing
part.
The vehicle engine should be kept running
during operation of the winch to minimize
battery drain and maximize power and
speed of the winch. If the winch is used for a
considerable time with the engine off the
battery may be drained and too weak to
restart the engine.
Get to know your winch before you actually
need to use it. We recommend that you set
up a few test runs to familiarize yourself
with rigging techniques, the sounds your
winch makes under various loads, the way
the cable spools on the drum, etc.
Inspect the wire rope and equipment before
each use. A frayed or damaged rope shall be
replaced immediately. Use only
manufacturer’s identical replacement rope
with the exact specifications.
Inspect the winch installation and bolts to
ensure that all bolts are tight before each
operation.
Store the remote control inside your vehicle
in a place that it will not be damaged.
Any winch that appears to be damaged in
any way, is found to be worn, or operates
abnormally MUST BE REMOVED FROM
SERVICE UNTIL REPAIRED. It is
recommended that the necessary repairs be
made by a manufacturer’s authorized repair
facility.
Pull only on areas of the vehicle as specified
by the vehicle manufacturer.
Only attachments and/or adapters supplied
by the manufacturer are to be used.
Locate a suitable anchor such as a strong
tree trunk or boulder. Always use a sling as
an anchor point.
Your winch is equipped with a roller fairlead
to help guide the wire rope and to reduce
binding on short side pulls.
Do not winch from an acute angle as the
wire rope will pile up on one side of the
drum causing damage to wire rope and the
winch.
Short pulls from an angle can be used to
straighten the vehicle. Long pulls should be
done with the wire rope at a 90° angle to the
winch/vehicle.
When pulling a heavy load, place a blanket
or jacket over the wire rope five or six feet
from the hook.
In the event of a broken cable it will dampen
the snap back. For additional protection
open the hood of the vehicle.
For pulls over 5,000lbs., we recommend the
use of the snatch block/pulley block to
double line the wire rope.
This reduces the load on the winch and the
strain on the rope by approximately 50%
7
Operation
Winching Techniques A-Z
a. Take time to assess your situation and
plan your pull.
b. Put on gloves to protect your hands.
c. Disengage the clutch to allow free-
spooling and also save battery power.
d. Attach the hook strap to the clevis hook.
e. Pull out the wire rope to your desired
anchor point using the hook strap.
f. Secure the clevis hook to the anchor
point: Sling, chain or snatch block. Do
not attach the hook back onto the wire
rope.
g. Engage the clutch.
h. Connect the remote control to the
winch. If you are going to control the
winch from inside your vehicle then pass
the remote through an open window to
avoid the wires being pinched in the
door.
i. Start your engine to ensure power is
being replenished to the battery.
j. Power in the wire rope guiding the wire
under tension to draw up the slack in
the wire. Once the wire is under tension
stand well clear. Never step over the
wire rope.
k. Double check your anchors and make
sure all connections are secure.
l. Inspect the wire rope. Make sure there
are at least 5 wraps of wire rope around
the winch drum.
m. Drape a blanket or jacket over the wire
rope approximately 5 to 6 feet from the
hook. Open the hood for added
protection.
n. Clear the area. Make sure all spectators
all well back and that no one is directly
in front or behind the vehicle or anchor
point.
o. Begin winching. Be sure that the wire
rope is winding evenly and tightly
around the drum. The vehicle that is
being winched can be slowly driven to
add assistance to the winching process.
Avoid shock loads; keep the wire rope
under tension.
p. The vehicle to be winched should be
placed in neutral and the emergency
brake released. Only release the brake
pedal when under full tension. Avoid
shock loads to the winch. This can
damage the winch, rope and vehicle.
q. The winch is meant for intermittent use.
Under full load with a single line rig do
not power in for more than a minute
without letting the motor cool down for
a few minutes and then resume the
winching operation.
r. The winching operation is complete
once the vehicle is on stable ground and
is able to drive under its own power.
s. Secure the vehicle. Be sure to set the
brakes and place the vehicle in park.
t. Release the tension on the wire rope.
The winch is not meant to hold the
vehicle for long periods of time.
u. Disconnect the wire rope from the
anchor.
v. Rewind the wire rope. Make sure that
any wire already on the drum has
spooled tightly and neatly. If not, draw
out the wire and re-spool from the point
where the rope is tight.
w. Keep your hands clear of the winch
drum and fairlead as the wire rope is
being drawn in.
x. Secure the hook and hook strap.
y. Disconnect the remote control and store
in a clean, dry place.
z. Clean and inspect connections and
mounting hardware for next winching
operation.
8
Maintenance
Maintenance
The owner/operator is responsible for all
periodic maintenance.
WARNING
Never operate a damaged or defective winch.
WARNING
Improper maintenance will void your warranty.
Complete all scheduled maintenance in a
timely manner. Correct any issue before
operating the winch.
NOTE
For service or parts assistance, contact our help
line at (877) 338-0999.
Lubrication
All moving parts within the Electric Winch
having been Lubricated using high
temperature lithium grease at the factory.
No internal lubrication is required.
Lubricate Cable Assembly (4) periodically
using a light penetrating oil.
Cable Assembly
Replacement
It is recommended that any modifications be
performed by a manufacturer’s authorized
repair facility, and that only manufacturersupplied parts be used
1. Move Cam Ring to the “Out” position.
2. Extend Cable Assembly to its full length.
Note how the existing cable is connected
to the inside of the drum.
3. Remove old Cable Assembly and attach
new one.
4. Retract Cable Assembly onto drum
being careful not to allow kinking.
9
Specifications
Specifications
Performance Specifications
Rated Pull 8,000 lbs (3629 kg)
Gear Reduction Ratio 210:1 (DC 12V)
Motor Permanent Magnet
2.2 HP/1.6 KW (DC 12V)
Drum Size 2.48” (D) x 9” (L)
63 mm (D) x 228 mm (L)
Cable 5/16” (D) x 95’ (L)
8 mm (D) x 29 m (L)
Weight 65.1 lbs. (29.6 kg)
Height 10.63 inches (27 cm)
Width 6.25 inches (16 cm)
Length 20.9 inches (53 cm)
Bolt Pattern 10” x 4.5”
254 mm x 114.3 mm
Line speed and Motor Current (First layer)
Line pull Max
(12VDC)
Max Current amps 40 110 190 270 350
Cooling Time minutes 5 5 5 5 5
Line pull and cable capacity
Layers of cable on drum 1 2 3 4
Max pulling capacity per layer
per layer
* Use double line and snatch block for pulling loads over 5,000lbs / 2272kgs.
lbs 0 2000 4000 6000 8000
kgs 0 907 1814 2722 3629
FPM 13 9.8 8.2 6.0 4.3 Line speed
MPM 3.9 3.0 2.5 1.8 1.3
lbs 8000 6500 5500 4800
kgs 3629 2948 2495 2177
ft 19.6 42.6 68.9 95 Cable capacity
m 6 13 21 29
10
Specifications
Winch Diagram
11
Specifications
Winch Parts List
No Parts# Description Qty
1 800100 Gear Carrier Assembly -Input 1
2 800200 Gear Carrier Assembly -Intermediate 1
3 800300 Gear Carrier Assembly -Output 1
4 800400 Cable Assembly 1
5 800500 Motor/End Bearing Assembly 1
6 800600 Break Assembly 1
7 800700 Up-setting Solenoid Assembly 1
8 800800 Switch Assembly 1
9 800900 Drum Assembly 1
10 800001 Screw M4 x 12 6
11 800002 Cover - Gear Housing 1
12 800003 Gasket 1
13 800004 Thrust Washer 2
14 800005 Thrust Disc 1
15 800006 Gear-Input Sun 1
16 800007 Thrust Washer 1
17 800008 Bushing - Drum 2
18 800009 Gear -Intermediate Sun 1
19 800010 Bushing Shaft 1
20 800011 Gear-Output Sun 1
21 800012 Cap Screw M6 x 10 1
22 800013 Hexagonal Shaft 1
23 800014 Cap screw M6 x 20 6
24 800015 Retainer - Ring Gear 1
25 800016 Gear - Ring 1
26 800017 Cam Ring 1
27 800018 Locking Ring 1
28 800019 Spring 6
29 800020 End Bearing 1
30 800021 Cap Bolt M10 x 35 6
31 800022 Washer - Flat Ø10 6
32 800023 Nut M10 6
33 800024 Lock Nut M6 6
34 800025 Cap Screw M 6 x 25 4
35 800026 Cap Screw M 6 x 10 4
36 800027 Mounting channel 1
37 800028 Roller Fairlead 1
38 800029 Snatch Block 1
39 800030 Strap 1
40 800031 D-Shackle 1
12
Specifications
Solenoid Diagram
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
20
21
3
22
23
24
25
26
27
28
29
13
Specifications
Solenoid Parts List
No Parts# Description Qty
1 800701 Connect Wire (I) 1
2 800702 Wire Assembly Battery (Red) 1
3 800703 Strap Copper (I) 2
4 800704 Connector Protector 1
5 800705 Connector Female Molded 1
6 800706 Screw M 5 x 14 2
7 800707 Wire Assembly (Black) 1
8 800708 Nut M8 16
9 800709 Washer-Flat Ø8 14
10 800710 Connect Wire (II) (Yellow) 1
11 800711 Lock Washer Ø8 12
12 800712 Connect Wire (III) 1
13 800713 Strap Copper (II) 1
14 800714 Connect Wire (IV) 1
15 800715 Solenoid 2
16 800716 Washer-Flat Ø5 6
17 800717 Lock Washer Ø5 6
18 800718 Screw M5 x 10 4
19 800719 Connect Wire (V) (Red) 1
20 800720 Washer-Flat Ø5 2
21 800721 Nut M5 4
22 800722 Wire Assembly (Black) 1
23 800723 Wire Assembly Battery (Black) 1
24 800724 Left Side 1
25 800725 Screw M8 x 16 6
26 800726 Solenoid Cover 1
27 800727 Bracket 1
28 800728 Tie Bar 1
29 800729 Right Side 1
14
Troubleshooting
Troubleshooting
Problem Cause Solution
Motor does not turn on
Motor runs but Cable drum
does not turn
Motor runs slowly or
without normal power
Motor overheating Winch running time too long Allow winch to cool down periodically.
Motor runs in one direction
only
Switch Assembly not connected properly Insert Switch Assembly all the way into
Loose battery cable connections Tighten nuts on all cable connections.
Solenoid malfunctioning Tap solenoid to loosen contacts. Apply 12
Defective Switch Assembly Replace Switch Assembly.
Defective motor Check for voltage at armature port with
Water has entered motor Allow to drain and dry. Run in short bursts
Cam Ring (clutch) not engaged Move Cam Ring to the "In" position. If
Insufficient current or voltage Battery weak, recharge. Run winch with
Loose or corroded battery cable
connections.
Defective Switch Assembly Replace Switch Assembly.
the connector.
volts to coil terminals directly. A clicking
indicates proper activation.
Switch pressed. If voltage is present,
Replace motor.
without load until completely dry.
problem persists, a qualified technician
needs to check and repair.
vehicle motor running (Battery should be
minimum 650 CCA)
Clean, Tighten, or replace.
Tap Solenoid to loosen contacts. Defective or stuck Solenoid
Repair or Replace solenoid.
15
Warranty
Warranty
CHAMPION POWER EQUIPMENT
ONE YEAR LIMITED WARRANTY
Effective September 1, 2006. Replaces all
undated warranties and all warranties dated
before September 1, 2006.
Warranty Qualifications
Champion Power Equipment (CPE) will
register this warranty upon receipt of your
Warranty Registration Card and a copy of
your sales receipt from one of CPE's retail
locations as proof of purchase.
Please submit your warranty registration
and your proof of purchase within ten (10)
days of the date of purchase.
Repair/Replacement
Warranty
CPE warrants to the original purchaser that
the mechanical and electrical components
will be free of defects in material and
workmanship for a period of one (1) year
from the original date of purchase (90 days
for commercial & industrial use).
Transportation charges on product
submitted for repair or replacement under
this warranty are the sole responsibility of
the purchaser. This warranty only applies to
the original purchaser and is not
transferable.
Do not return the unit to the
place of purchase
Contact CPE's Technical Service and CPE
will troubleshoot any issue via phone or email. If the problem is not corrected by this
method, CPE will, at its option, authorize
evaluation, repair or replacement of the
defective part or component at a CPE
Service Center. CPE will provide you with a
case number for warranty service. Please
keep it for future reference. Repairs or
replacements without prior authorization, or
at an unauthorized repair facility, will not be
covered by this warranty.
Warranty Exclusions
This warranty does not cover the following
repairs and equipment:
Normal Wear
Winches need periodic parts and service to
perform well. This warranty does not cover
repair when normal use has exhausted the
life of a part or the equipment as a whole.
Installation, Use and
Maintenance
This warranty will not apply to parts and/or
labor if this winch is deemed to have been
misused, neglected, involved in an accident,
abused, loaded beyond the winch’s limits,
modified, installed improperly or connected
incorrectly to any electrical component.
Normal maintenance is not covered by this
warranty.
Other Exclusions
This warranty excludes:
Cosmetic defects such as paint, decals, etc.
Accessory parts such as storage covers.
Failures to due acts of God and other force
majeure events beyond the manufacturer’s
control.
Problems cause by parts that are not original
Champion Power Equipment parts.
Limits of Implied Warranty
and Consequential Damage
Champion Power Equipment disclaims any
obligation to cover any loss of time, use of
this product, freight, or any incidental or
consequential claim by anyone from using
this winch. THIS WARRANTY IS IN LIEU
OF ALL OTHER WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE
A unit provided as an exchange will be
subject to the warranty of the original unit.
The length of the warranty governing the
exchanged unit will remain calculated by
reference to the purchase date of the original
unit.
This warranty gives you certain legal rights
which may change from state to state. Your
16
Warranty
state may also have other rights you may be
entitled to that are not listed within this
warranty.
Contact Information
Address
Champion Power Equipment, Inc.
Customer Service
10006 Santa Fe Springs Rd.
Santa Fe Springs, CA 90670
Customer Service
Mon – Fri 8:30 AM – 5:00 PM (PST/PDT)
Toll Free: 1-877-338-0999
Fax no.: 1-562-236-9429
Technical Service
Mon – Fri 8:30 AM – 5:00 PM (PST/PDT)
Toll Free: 1-877-338-0999
tech@championpowerequipment.com
17
Notes
Notes
18
Loading...
