Champion Industries UTC-6 Specification Sheet

OPTIONS
Tank Heat
Steam
Gas
Additional Pan Washer Models:
(1M) 3/05 Printed in U.S.A.
DG008
Project
LD-10 UTM-10 SD-20 LD-20
Champion Industries, Inc.
P. O. Box 4149, Winston-Salem, NC 27115
Tel: 800/532-8591 Fax: 336/661-1979
2674 N. Service Road,
Jordan Station, Ontario, Canada L0R 1S0
Tel: 800/263-5798 Fax: 905/562-4618
www.championindustries.com
Item No. Quantity
MODEL UTC-6 WASHER
STANDARD FEATURES
Fits under a standard countertop
External wash hose and spray gun
Heavy-duty stainless steel construction
Moisture resistant control gauges
Drop-down door system and drain table
Digital control & information center
Self-contained water heating
Fresh hot water sanitizing rinse
Recirculating wash water
Easy to remove filter baskets
Adjustable wash and rinse cycle times
MODEL UTC-6
Pot, Pan and
Easily removable filter basket
Digital control & information center
Pot, Pan and Utensil Washer
MODEL UTC-6
MODEL UTC-6 WASHER
Due to an ongoing value analysis program at Champion, specifications contained in this catalog are subject to change without notice.
Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 800/532-8591 • Fax: 336/661-1979 • www.championindustries.com
Dimensions shown in inches
SPECIFICATIONS
Machine Construction
12, 14, 16 & 18 gauge Stainless steel.
Door
Stainless Steel drop-down door for easy loading and unloading.
Spray Arm Assembly
STAINLESS STEEL spray arm assembly with stainless steel jets, removable end caps and hand operated quick release mechanism for easy cleaning and reassembly.
Filter
Perforated, removable, Stainless Steel baskets.
Water Pump
2 Hp, 208/240 or 480 volt, 1 phase or 3 phase 60 cycle with output of 100 gallons per minute at 35 to 45 P.S.I.
Digital Control & Information Center
110 volt control circuit with push pad operation of “power on”, “stop” and “short, medium or long wash cycles”. A digital display indicates “time remaining” for each cycle. LED’s indicate wash, rinse and unload functions. A buzzer is also included to provide an audible indication of time to unload. A programmable controller allows the push pad to be used as a “diagnostic center” by displaying “error codes” for ease of troubleshooting.
Gauges
Special moisture resistant design measure wash temperature, rinse temperature, wash pressure.
Wash Tank
Stainless Steel with electric heater, thermostatically controlled, low water protected, sloped to drain with a 14-gallon capacity
Rinse Tank
Stainless Steel with 3 kW 208/240 or 480 volt electric booster heater to provide 180°F/190°F hot sanitizing rinse.
Racks
Stainless Steel built to match specific washing requirements.
Washer Automatic washing machine designed to wash all pots, pans and utensils commonly
used in baking and cooking operations.
Cabinet 47-1/4" wide x 24" deep x 32-7/8" high. Door Opening 28-1/2" wide x 19" high. Wash
Area: 26-1/2" wide x 19" high x 17-1/2" deep. Constructed of 12, 14 & 16 gauge, type 304 #3 finish, Stainless Steel. All seams tig-welded, cleaned and polished.
Door Front-loading, drop-down door designed for easy loading and unloading. Door opens
to create a convenient, space-saving drain table. Door is interlocked with limit switch to prevent machine operation while door is open.
Recirculating Wash Tank Heated by one (1) 6 kW 208/240 at 480 volt electric immersion heater, thermostatically
controlled wash temperature and low water protection system. 14 gallons, sloped to drain.
Wash Tank Filter Perforated, Stainless Steel basket type designed for increased effectiveness and
easy cleaning without emptying wash tank.
Wash Tank Drain 1/14 hp, 120 volt, single phase drain pump for automatic operation and remote & Overflow Pump connection hook-up.
Wash Pump 2 hp, 208/240 or 480 volt, 3 phase or 1 phase, 60 cycle. Close coupled; 50 gallons
per minute at 35 to 45 psi.
Rotating Wash Water driven, quick release, Stainless Steel ball bearing assembly. Complete with Hub Assembly two Stainless Steel arms, high velocity wash jets and removable end caps for quick
and easy cleaning without the use of tools.
Sanitizing Rinse Tank Stainless Steel 4 gallon capacity, with one (1) 3 kW 208/240 or 480 volt electric
booster heater to provide 180°-190°F hot sanitizing rinse. Uses 2.5 gallons per 15 second cycle.
Water Supply Valve Size 1/2" brass material, solenoid type, automatic.
Final Rinse Piping Type 304 Stainless Steel tubing with brass compression fittings and piping brass or
optional Stainless Steel full cone rinse jets.
Control and 110 volt control circuit with push pad operation of “Power On,” “Stop” and “Short, Information Center Medium or Long wash cycles.” A digital display indicates “Time Remaining” for each
cycle. LED’s indicate wash, rinse and unload functions. A buzzer is also included to provide an audible indication of time to unload. A pre-programmed circuit board allows the push pad to be used as a “Diagnostic Center” by displaying “Error Codes” for ease of troubleshooting. Moisture resistant gauges measure Wash Temperature, Wash Pressure and Rinse Temperature.
Wash Down Spray Hose Externally mounted spray hose with insulated handle for pre-rinse of heavily soiled
items and easy cleaning and maintenance of machine.
Champion Industries, Inc.
P. O. Box 4149, Winston-Salem, NC 27115
Tel: 800/532-8591 Fax: 336/661-1979
www.championindustries.com
Champion Industries, Inc. 2674 N. Service Road, Jordan Station, Ontario, Canada L0R 1S0 Tel: 800/263-5798 Fax: 905/562-4618
(1M) 3/05 Printed in U.S.A.
SPECIFICATIONS
MODEL UTC-6
POT, PAN &
UTENSIL WASHER
Steam Exhaust Vent Steam exhaust vent 4" diameter, consisting of 16 gauge rolled Stainless Steel collar,
bolted to the side of the machine. Machine pre-wired with control timer for the addition of a fan.
Optional Exhaust Fan Draft inducer fan, side mounted on exhaust duct, to extract excess steam after final
rinse cycle. Rated for 300 CFM @ .05" static pressure. 1/10 Hp, 110 volt motor, 1550 RPM.
Electric Enclosure Constructed of Stainless Steel, UL approved.
Racks Standard rack is a combination utensil rack with hold-down lid and bun/sheet
pan insert designed to hold 6 pans, constructed of Stainless Steel. Alternative racks can be customized to hold a customer's specific items.
Connections Water Inlet: 120°F, 3/4" NPT
Water Drain and Overflow: 3/4" NPT Electrical: Two point connection through knock out on electrical enclosure.
Weight Crated: 400 lbs.; Uncrated: 350 lbs.
NOTE: All weights are approximate. Weights will vary depending on the number of options included with the machine.
240 Volt 3 phase
480 Volt 3 phase
240 Volt 1 phase
208 Volt 3 phase
Elec. Spec.
Certifications
UL and UL Sanitation Listed (all). CUL Listed (electric and steam only).
Running Amps Service Breaker
Champion Industries, Inc.
P. O. Box 4149, Winston-Salem, NC 27115
Tel: 800/532-8591 Fax: 336/661-1979
www.championindustries.com
Champion Industries, Inc. 2674 N. Service Road, Jordan Station, Ontario, Canada L0R 1S0 Tel: 800/263-5798 Fax: 905/562-4618
SPECIFICATIONS
MODEL UTC-6
POT, PAN &
UTENSIL WASHER
31
48
28
14
40
60
35
25
