Portable Vertical Antenna
Counterpoise Kit
(CHA COUNTERPOISE KIT)
Operator’s Manual
Nevada - USA
WWW.CHAMELEONANTENNA.COM
VERSATILE – DEPENDABLE – STEALTH – BUILT TO LAST
Table of Contents
Introduction .............................................................................................................................................. 3
Parts of the Counterpoise Kit .................................................................................................................... 3
Counterpoise Installation .......................................................................................................................... 4
Preventive Maintenance ........................................................................................................................... 5
Recommended Accessories ...................................................................................................................... 5
Chameleon AntennaTM Products .............................................................................................................. 6
All information on this product and the product itself is the property of and is proprietary to Chameleon
AntennaTM. Specifications are subject to change without prior notice.
Introduction
Thank you for purchasing and using the Chameleon Antenna
COUNTERPOISE KIT), see plate (1). The CHA COUNTERPOISE KIT will create the ground plane needed for the MPAS
or CHA HYBRID MINI/MICRO vertical antenna. The kit contains four 25’ radials on line winders and four tent stakes
for superb portability and good performance from 3.5 to 54 MHz. Each radial has an isolation ring on one end and
a terminal lug connector, compatible with the CHA SPIKE MOUNT and Dipole Jaw Mount, on the other end. The
system will greatly increase the efficiency of any ground mounted portable vertical antenna over just a single
counterpoise wire. The CHA COUNTERPOISE KIT is an essential accessory for the MPAS and CHA HYBRID
MINI/MICRO vertical antenna systems.
TM
Portable Vertical Antenna Counterpoise Kit (CHA
Plate 1. Chameleon Counterpoise Kit.
Parts of the Counterpoise Kit
The CHA COUNTERPOISE KIT is comprised of the following components, see plates (2) and (3):
a. Line Winder – Plastic winder used to store counterpoise wire.
b. Counterpoise Wire – 25 foot wire for use as antenna counterpoise.
c. Isolation Ring – insulates Counterpoise Wire (b) from Tent Peg (e) and ground.
d. Terminal Lug – used to connect Counterpoise Wire to antenna mount ground connection.
e. Tent Peg – 9” steel wire tent peg used to hold the far end of the Counterpoise Wire to the ground.
CHA COUNTERPOISE KIT Page 3
