Electric Hedge Trimmer
Artikel-Nr.: 3403627
Ident-Nr.: 01017
Komponenten / Ersatzteile
Position Artikel-Nr. Beschreibung
1 340363301001 Blade block
11 340363301011 Scabbard
13 340363301013 Switch
29 340363301029 Wiggly spring
901 340363301901 blade
CXHT 661
EH-Art.-No.: 34.036.27
Operating Instructions Hedge Trimmer
" WARNING! PLEASE READ THESE INSTRUCTIONS
BEFORE OPERATING THIS UNIT"
"KEEP THIS MANUAL FOR FUTURE REFERENCE”
쏾
2
Helpline No: UK 0151 649 1500 / IRE 189 094 6244
Read and follow the operating instructions and safet
information before using for the first time.
Always wear PPE (Personal Protective Clothing).
Wear ear protection!
Ꮯ
Beware of electrical voltage
Ꮨ
Wear eye protection!
3
Helpline No: UK 0151 649 1500 / IRE 189 094 6244
Read the complete operating manual with due care
and keep it in a safe place. If you give the unit to any
other person, hand over this operating manual as well!
Table of contents page
1. General safety regulations 6
2. Items supplied 8
3. Layout 8
4. Explanation of the sign 8
5. Technical data 8
6. Mains connection 8
7. Start-up and operation 8
8. Notes on working practice 9
9. Maintenance, care and storage 9
10. Troubleshooting 9
11. Waste disposal 9
12 Ordering replacement parts 9
4
Helpline No: UK 0151 649 1500 / IRE 189 094 6244
1
4
5
2
햲
3
1
2
3
5
4
햴
5
Helpline No: UK 0151 649 1500 / IRE 189 094 6244
8
10
9
7
6
6
Helpline No: UK 0151 649 1500 / IRE 189 094 6244
GB
General safety regulations for electric tools
CAUTION: Read all safety regulations and
instructions.
Any failures made in following the safety regulations
and instructions may result in an electric shock, fire
and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.
The term “electric tool” used in the safety regulations
refers to electric tools operated from the mains power
supply (with a power cable) and to battery operated
electric tools (without a power cable).
1. Workplace safety
앬 Keep your work area clean and well illuminat-
ed. Untidy or unlit work areas can result in accidents.
앬 Do not use this tool in a potentially explosive
environment containing combustible liquids,
gases or dust.
Electric tools generate sparks, which can in turn
ignite dust or vapors.
앬 Keep children and other persons away from
the electric tool while it is being used.
Allowing yourself to get distracted can cause you
to lose control of the tool.
2. ELECTRICAL SAFETY
앬 The toolʼs connector plug must be able to fit
into the socket outlet. Do not modify the plug
in any way! Do not use adapter plugs in
conjunction with electrically grounded tools.
Unmodified plugs and matching socket outlets
reduce the risk of an electric shock.
앬 Avoid touching grounded surfaces, such as
those of pipes/tubes, heaters, cookers and
refrigerators.
There is an increased risk of getting an electric
shock if you are electrically grounded.
앬 Keep the tool away from rain and moisture/wet
conditions.
Penetration of water into an electric tool increases
the risk of an electric shock.
앬 Do not use the cable to carry the tool, hang it
up or pull the plug out of the socket. Keep the
cable away from sources of heat, oil, sharp
edges and moving tool parts.
Damaged or tangled cable increases the risk of an
electric shock.
앬 If you intend to use an electric tool outdoors,
ensure that you only use extension cable that
is approved for outdoor applications.
Using extension cable that is approved for outdoor
applications reduces the risk of an electric shock.
앬 If operation of the electric tool in a damp envi-
ronment can not be avoided, use a earth-leakage circuit-breaker. The earth-leakage circuit-
breaker reduces the risk of an electric shock.
3. PERSONAL SAFETY
앬 Be alert, work conscientiously and exercise
appropriate caution when using the electric
tool. Do not use the tool if you are tired or are
under the influence of drugs/medication or
alcohol.
One moment of carelessness or lack of attention
when using the electric tool can cause serious
bodily injury!
앬 Always wear personal protective equipment
(PPE), including safety goggles.
Wearing personal protective equipment such as a
dust mask, non-slip footwear, protective headgear
and ear muffs (depending upon the type of electric
tool and the particular application) reduces the risk
of sustaining injury.
앬 Make sure that the tool cannot start up acci-
dentally. Ensure that the electric tool is
switched off before you connect the tool to the
power supply and/or insert the battery, or pick
up or carry the tool.
Physically touching the switch with your finger
when carrying the tool or connecting the tool to
the power supply switched on can lead to
accidents.
앬 Remove adjusting tools/wrench(es) prior to
switching on the power tool.
A tool or wrench that is positioned inside a rotating
power tool part can cause injury.
앬 Avoid abnormal working postures. Make sure
you stand squarely and keep your balance at
all times.
This way, you will be able to have better control
over the tool in unexpected situations.
앬 Wear suitable clothes. Never wear loose fitting
clothes or jewelry. Keep hair, clothes and
gloves away from moving parts.
Loose clothing, dangling jewelry and long hair can
be caught by moving parts.
앬 If dust extraction and dust collection devices
can be mounted, ensure that these are
connected and are properly used.
The use of a dust extraction system can reduce
the danger posed by dust.
7
Helpline No: UK 0151 649 1500 / IRE 189 094 6244
GB
4. Using the treatment of electric tools
앬 Do not overload your tool. Only use suitable
electric tools to perform your work.
Using the right electric tool allows you to work
better and safer within the toolʼs quoted capacity
range.
앬 Do not use an electric tool whose switch is
defective.
An electric tool that no longer can be switched on
or off is dangerous and must be repaired.
앬 Pull the plug out of the socket and/or remove
the battery before making any adjustments to
the tool, changing accessories or put the tool
down.
This precaution eliminates the possibility of
inadvertently starting the tool.
앬 When not in use, store electric tools out of the
reach of children. Do not allow those persons
to use this tool who are unfamiliar with it or
who have not read these instructions.
Electric tools are dangerous when they are used
by inexperienced persons.
앬 Take good care of your tool. Check that
moving parts properly function and do not jam,
that parts are not broken off or damaged in any
way and that the tool can be used to its full
capacity. Have damaged parts repaired prior to
using the tool.
The cause of many accidents can be traced back
to poorly maintained electric tools.
앬 Keep your blades sharp and clean.
Properly maintained blades with sharp edges jam
less frequently and are easier to use.
앬 Make sure to use electric tools, accessories,
attachments, etc. in accordance with these
instructions. Take the conditions in your work
area and the job in hand into account.
Using electric tools for applications other than
those intended can lead to dangerous situations.
5. SERVICE
앬 Have your tool repaired only by authorized
specialists using original replacement parts.
This will ensure that your tool remains safe to use.
Safety instructions for hedge trimmers
Read the safety instructions and operating instructions carefully and follow them.
1. Before carrying out any work on the hedge trimmer, pull the mains plug, for example
- Damage to the cable
- Cleaning the blades
- Checking in the event of faults
- Cleaning and maintenance
- Putting down without supervision
2. This machine can cause serious injuries. Read
the operating instructions carefully for details of
the correct handling, preparation, maintenance,
starting and shutting down the machine. Make
yourself familiar with all the adjustable parts and
how to use the machine correctly.
3. The hedge trimmer must be held in both hands.
4. Check the connection cable for signs of damage
and ageing before use.
5. The hedge trimmer may only be used if the connection cable is undamaged.
6. Check the cutter at regular intervals for signs of
damage and have any repair work to the cutting
tool carried out correctly and then ask your electrician.
7. If the cutter blocks, for example due to thick
branches, etc. the hedge trimmer must be
stopped immediately – pull the plug and only
then may the cause of the blockage be removed.
8. Always place the cover over the cutter when
transporting and storing the machine.
9. Only use cables and plug equipment that is
approved for outdoor use.
- Connection cable HO7RN-F 2x1.0 with molded
plug.
- Extension cable HO7RN-F 3G1.5 with splashproof plug with earth contact and protective contact coupling.
- We recommend that you use a leakage current
protection device or a residual current circuit
breaker with a maximum trip current of 30 mA
with electric tools. Ask your electrician.
10. Check and service the hedge trimmer properly at
regular intervals. Only replace damaged blades
in pairs. If the trimmer is damaged by dropping or
striking, you must have it checked by an expert.
11. Do not use the machine if it has a damaged or
excessively worn cutter.
12. Make yourself familiar with your surroundings
and watch for possible dangers that you may not
be able to hear due to the noise generated by the
machine.
13. Never try to work with an incomplete machine or
a machine with unapproved modifications.
14. Do not use the hedge trimmer when people are
nearby, particularly children or animals.
15. Children are not allowed to use the hedge trimmer.
16. Always ensure that all the handles and safety
equipment is fitted when the hedge trimmer is in
use.
17. Keep all body parts away from the blade.
8
Helpline No: UK 0151 649 1500 / IRE 189 094 6244
GB
Never attempt to remove the cuttings with the
blades running or to hold material you wish
to cut. Always switch off the device before
attempting to remove any jammed cuttings. A
memory of inattentiveness when using the hedge
trimmer may result in serious injuries.
18. Hold the hedge trimmer by the handled when
the blades are at a standstill, always close the
safety cover when transporting or storing the
hedge trimmer. Handling the machine with care
will reduce the risk of injury from the blades.
19. Keep the cable away from the cutting area.
Whilst you are working the cable may be covered
in the branches which means that you might cut
through it by accident,
20. Look in the hedge for concealed objects, such as
wire fences, before starting work.
21. If the connection lead has to be replaced, this
work must be carried out by the manufacturer or
one of its agents to prevent safety risks.
2. Items supplied (see Fig. 1)
- 1 hedge trimmer
- 1 cutter guard (7)
3. Layout (see Fig. 1)
1. Cutter
2. Hand guard
3. Guide handle with switch button
4. Handle with switch buttons above and below
5. Cable strain relief clip
6. Power cable
7. Cutter guard
8. Impact guard
Important! You must never use the hedge trimmer without wearing gloves.
4. Explanation of the sign (see Fig. 3)
1. Warning
2. Keep out of the rain and protect from getting wet.
3. Read the operating instructions before using for
the first time.
4. Pull the plug from the power supply immediately
if the cable gets damaged or severed.
5. Wear goggles and ear protection.
5. Technical data
Voltage 230-240 V ~ 50Hz
Power consumption 600 W
Cutting length 590 mm
Blade length 660 mm
Tooth spacing 20 mm
Cuts/min 3200/min
Sound power level LWA 96 dB(A)
Sound pressure level LPA 88,6 dB(A)
Vibration aw 3,3 m/s
2
Weight 4,0 kg
6. Mains connection
The machine can only be run on single-phase alternating current with 230 V ~ 50Hz a.c. voltage. Before
you use the machine for the first time, check that the
mains voltage is the same as the operating voltage
shown on the machine rating plate.
7. Start-up and operation
Important! This hedge trimmer is designed for the
trimming of hedges, bushes and shrubs. If it is used
for any other purpose not expressly permitted by
these operating instructions there may be a risk of
damage to the hedge trimmer or serious injury to the
user. The hedge trimmer comes with a two-hand
safety switch. It only works if the switch on the guide
handle (Fig. 2 / Item 1) is pressed with one hand and
either the switch on top of the handle (Fig. 2 / Item 2)
or the switch below the handle (Fig. 2 / Item 3) is
pressed with the other hand.
Releasing any of the switches will bring the hedge
trimmer to a stop.
Please watch out for the cutters as they slow
down to a standstill.
- Please check that the cutters work properly.
The twin-bladed cutters rotate in opposite directions, thus guaranteeing high cutting performance and smooth operation.
- Before use, fasten the extension cable in the
cable strain relief clip (see Fig. 4).
- When working outdoors, use extension cables
that are approved for the purpose.
9
Helpline No: UK 0151 649 1500 / IRE 189 094 6244
8. Notes on working practice
쎲 The hedge trimmer can be used not only for trim-
ming hedges but for trimming shrubs and bushes
as well.
쎲 For optimum trimming performance, guide the
blade teeth at an angle of approx. 15° to the
hedge (see Fig. 5).
쎲 Since the blades cut on both sides and run in
opposite directions to each other, you can trim in
both directions (see Fig. 6).
쎲 To achieve a hedge with a uniform height it is
recommended that you stretch a piece of string
along the edge of the hedge for guidance. Then
simply cut away all twigs projecting above the
line (see Fig. 7).
쎲 The sides of the hedge should be trimmed with
arc-type movements from below upwards (see
Fig. 8).
9. Maintenance, care and storage
쎲 Always switch off the machine and pull the plug
before you start to clean the machine.
쎲 For optimum results at all times you should regu-
larly clean and lubricate the blades. Remove any
deposits with a brush and apply a light film of oil
(see Fig. 9).
Use biologically degradable oil.
쎲 Clean the plastic body with gentle domestic clea-
ning agent and a damp cloth. Never use aggressive media or solvents.
쎲 It is imperative that you prevent water from pene-
trating the machine. Never spray the machine
down with water.
쎲 For storage purposes the hedge trimmer can be
fastened to the wall with suitable screws and
dowels (see Fig. 10).
10. Troubleshooting
쎲 The machine does not start: Check that the
power cable is correctly connected and check
the mains fuses. If the machine still does not
work even with connected voltage, please
contact the helpline.
11. Disposal
Important!
The hedge trimmer and its accessories are made of
a diversity of materials such as, e.g. metal and plastic.
Defective parts must be disposed of as special
waste. Ask your specialist dealer or local authority for
details about where they can be disposed of!
12. Ordering replacement parts
Please quote the following data when ordering replacement parts:
앬 Type of machine
앬 Article number of the machine
앬 Identification number of the machine
앬 Replacement part number of the part required
For our latest prices and information please go to
www.isc-gmbh.info
Helpline Numbers:
UK: 0151 649 1500
IRE: 189 094 6244
GB
10
Helpline No: UK 0151 649 1500 / IRE 189 094 6244
k
erklärt folgende Konformität gemäß EU-Richtlinie
und Normen für Artikel
t
declares conformity with the EU Directive
and standards marked below for the article
p
déclare la conformité suivante selon la
directive CE et les normes concernant lʼarticle
verklaart de volgende conformiteit in overeenstemming met de EU-richtlijn en normen voor
het artikel
m
declara la siguiente conformidad a tenor de la
directiva y normas de la UE para el artículo
O
declara a seguinte conformidade de acordo
com a directiva CE e normas para o artigo
U
förklarar följande överensstämmelse enl. EUdirektiv och standarder för artikeln
q
ilmoittaa seuraavaa Euroopan unionin direktiivien ja normien mukaista yhdenmukaisuutta
tuotteelle
erklærer herved følgende samsvar med EUdirektiv og standarder for artikkel
T
заявляет о соответствии товара
следующим директивам и нормам EC
B
izjavljuje sljedeću uskladjenost s odredbama i
normama EU za artikl.
Q
declarå urmåtoarea conformitate cu linia directoare CE μi normele valabile pentru articolul.
Z
ürün ile ilgili olarak AB Yönetmelikleri ve
Normlar∂ gere©ince aμa©∂daki uygunluk aç∂kla
mas∂n∂ sunar.
z
‰ЛПТУВИ ЩЛУ ·ОfiПФ˘ıЛ Ы˘МКˆУ›· Ы‡МКˆУ· МВ
ЩЛУ √‰ЛБ›· ∂∂ О·И Щ· ЪfiЩ˘Ф БИ· ЩФ ЪФ˚fiУ
C dichiara la seguente conformità secondo la
direttiva UE e le norme per lʼarticolo
l
attesterer følgende overensstemmelse i
henhold til EU-direktiv og standarder for produkt
j
prohlašuje následující shodu podle směrnice
EU a norem pro výrobek.
A
a következő konformitást jelenti ki a termékekre vonatkozó EU-irányvonalak és normák szerint
X
pojasnjuje sledečo skladnost po smernici EU
in normah za artikel.
deklaruje zgodność wymienionego poniżej
artykułu z następującymi normami na
podstawie dyrektywy WE.
W
vydáva nasledujúce prehlásenie o zhode podľa
smernice EÚ a noriem pre výrobok.
e
деклаpиpа следното съответствие съгласно
диpективите и ноpмите на ЕС за пpодукта.
1
заявляє про відповідність згідно з Директивою
ЄС та стандартами, чинними для даного товару
.
deklareerib vastavuse järgnevatele EL direktiivi
dele ja normidele
G
deklaruoja atitikti pagal ES direktyvas ir normas
straipsniui
4
izjavljuje sledeçi konformitet u skladu s odred
bom EZ i normama za artikl
H
Atbilstības sertifikāts apliecina zemāk minēto preču
atbilstību ES direktīvām un standartiem
E
Samræmisyfirl‡sing sta›festir eftirfarandi samræmi
samkvæmt reglum Evfrópubandalagsins og stö›lum
fyrir vörur
Konformitätserklärung
ISC-GmbH · Eschenstraße 6 · D-94405 Landau/Isar
Hedge Trimmer CXHT 661
Art.-Nr.: 34.036.27 I.-Nr.: 01017 Archivierung: 3403630-05-4175500
Subject to change without notice
98/37/EC
73/23/EEC_93/68/EEC
97/23/EC
2004/108/EC
90/396/EEC
89/686/EEC
87/404/EEC
R&TTED 1999/5/EC
2000/14/EC_2005/88/EC:
95/54/EC:
97/68/EC:
X
X
X
X
EN 50144-1; EN 50144-2-15; EN 55014-1; EN 55014-2; EN 61000-3-2; EN 61000-3-3;
KBV V
LWM= 93 dB; LWA= 96 dB
Landau/Isar, den 25.09.2007
Gottelt
Product-Management
Weichselgartner
General-Manager
11
Helpline No: UK 0151 649 1500 / IRE 189 094 6244
The reprinting or reproduction by any other means, in whole or in part,
of documentation and papers accompanying products is permitted only
with the express consent of ISC GmbH.
Technical changes subject to change
t For EU countries only
Never place any electric tools in your household refuse.
To comply with European Directive 2002/96/EC concerning old electric and electronic equipment and its
implementation in national laws, old electric tools have to be separated from other waste and disposed of
in an environment-friendly fashion, e.g. by taking to a recycling depot.
Recycling alternative to the demand to return electrical devices:
As an alternative to returning the electrical device, the owner is obliged to cooperate in ensuring that the
device is properly recycled if ownership is relinquished. This can also be done by handing over the used
device to a returns center, which will dispose of it in accordance with national commercial and industrial
waste management legislation. This does not apply to the accessories and auxiliary equipment without
any electrical components which are included with the used device.
EH 09/2007
Loading...
