ChallengerOptics CO-OLS-4761 Operating Manual

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

Features / Specications / 02

Optical Light Source

- 8 Channel CWDM

Operating Manual

ChallengerOptics

CO-OLS-4761

020119

1 Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

2 Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

3 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

4 Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

5 Meter Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1 Features

2 Specications

- CWDM wavelengths from 1470 to 1610nm

- High output stability: < 0.15dB Std

- BPON, GPON and EPON compatible

- Output -3 dBm

- Selectable modulated output: 270Hz, 1KHz & 2KHz

- Small size, easy for eld applications,

light weight, about 0.2Kg

- Auto power shut-o

- Auto Laser shuto above 60 degrees C

- Rechargeable battery, Battery level indicator

Measured Wavelengths CWDM - 1470nm to 1610nm, +/- 1nm. Other wavelengths available

Source Type DFB LD

Output Stability Over 1 hour (after 15 min warmup) < 0.15dB

Output power -3 dBm

Spectral Width <1nm

Functions λ-key: wavelength selection, ON/OFF: power switch;

Modulated output on/o Auto-O: enable/disable switch;

Battery level indicator, Auto o @ 60° C

Modulation Frequencies 270Hz, 1KHz & 2KHz

Optical Connector SC / APC

Operating Temperature 5° ~ +122° F (-15° ~ +50° C)

Battery / Power Rechargeable Lithium-Polymer – 8 hrs

Weight 0.44 lbs (200 g)

Dimensions ht / w / d 6 x 3 x 1.75 inches

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

Accessories / Meter Care / 04Operation / 03

Press to turn on. The output of the
rst wavelength in dBm is displayed. The
unit is in Auto-O mode, as indicated by a
cross on the power symbol. Press again, and
the power turns o.

The auto-o feature can be disabled by pressing the switch,
as indicated by the power symbol without a cross.

Press switch for modulated output at 270Hz, 1K, or 2KHz

Press switch to select other wavelengths

Auto OFF

Hz

λ

3 Operation

4 Accessories

5 Meter Care / Laser Saftey

ON/OFF

Description Quantity
Body 1 ea
Rubber Boot 1 ea
USB Data cable 1 ea
Charger 1 ea
USB Drive (User’s Manual) 1 ea

Charge laser source with provided USB power adapter, the red indicator LED will
illuminate until charging has been completed.

Do not subject the CO-OLS-4761 to strong impact.
The CO-OLS-4761 is not water resistant or waterproof
Do not disassemble.
Always properly clean the ber interfaces before taking a measurement.
Always replace the Dust Cap for dust protection.

LASER SAFETY The Tunable Laser Source has been congured to provide

laser radiation in the C Band of operation. (1530-1565nm) This unit has been
designed to comply with 21 CFR (Code of Federal Regulations) 1040.10 and

1040.11, for Class 1M emission limits. Although Class 1 levels are not considered
to be hazardous, we suggest limiting exposure by never looking directly into
the optical aperture. Also, do not under any circumstance view or inspect the
laser output bers, connectors or the ber under test through collimating or
focusing optics unless the unit is turned o, batteries are removed and the
power adapter is disconnected.

Power switch

Wavelength selection

Modulation Indicator

Auto o – Enabled/disabled

ON/OFF

Hz

λ

Auto OFF
