Challenge M0E-12ET-410 User Manual
CHALLENGE
18V Li-ion Cordless Hedge Trimmer
Original Manual
M0E-12ET-410
Important - Please read these instructions fully before starting assembly and using.
These instructions contain important information that will help you get the best from your hedge
trimmer, ensuring it is assembled correctly and safely.
If you need help or have damaged or missing parts, call the Customer Helpline on 01904 727508
prior to returning product to store.
Aug 2017 Rev B
Contents
Introduction ......................................................................................................................................................3
Safety Information .............................................................................................................................................3
Parts list ........................................................................................................................................................... 11
Assembly.........................................................................................................................................................12
Operation.........................................................................................................................................................15
Maintenance and Storage...............................................................................................................................17
Troubleshooting...............................................................................................................................................18
Technical Data.................................................................................................................................................19
Recycling and Disposal....................................................................................................................................20
Guarantee........................................................................................................................................................21
2
Customer Helpline 01904 727508
www.coreservice.co.uk
Introduction
Thank you for purchasing a CHALLENGE hedge trimmer. We hope you are completely satised with your
new product and hope you will enjoy using this tool for many years. Your M0E-12ET-410 Hedge Trimmer
has been designed for trimming light foliage and is intend for domestic use only.
Intended Use
This Li-ion hedge trimmer M0E-12ET- 410 is intended for trimming hedges, bushes and shrubs. Observe
the technical data for the maximum cutting capacity. Do not cut nonplant material or branches exceeding the
stated maximum capacity. For safety reasons it is essential to read the entire instruction manual before rst
operation and to observe all the instructions there in.This product is intended for private domestic use only,
not for any commercial trade use. It must not be used for any purposes other than those described.
Safety Information
Important - Please read these instructions fully before starting assembly
General Power Tool Safety Warnings
Read all instructions. Failure to follow all instructions listed below may
result in electric shock, re and/or serious injury. The term “power tool” in all
warnings listed below refers to your mains operated power tool.
1. Read the instruction carefully. Be familiar with the controls and the
correct use of the appliance. Read and understand the operator’s manual
and observe the warnings and instruction labels afxed to the appliance.
2. Users. Never allow children or people unfamiliar with these instructions
to use the appliance. Local regulations may restrict the age of operator.
Never operate the tool under the inuence of alcohol, medication or drugs.
3. Use appropriate tool. This device is only intended for trimming hedge
outdoors and only designated for use on private property. Do not force
small tools or attachments to do the job of a heavy duty tool.
4. Keep work areas clean. Cluttered areas can cause accidents.
5. Consider work area environment. Do not expose the tool to high
humidity or rain. Do not use the tool in damp and wet conditions.Keep the
work area well lit. Do not use the tool where there is a risk of causing re
or explosion, e.g. in the presence of ammable liquids and gases.
6. Keep all bystanders, children, and pets away. The operator or user
is responsible for accidents or hazards occurring to other people or the
property.
7. Dress appropriately. Do not wear loose clothing, hair or jewelry, as these
can be caught in moving parts. Preferably wear non-slip footwear when
working outdoors. Wear protective hair covering to keep long hair out of
the way.
Customer Helpline 01904 727508
www.coreservice.co.uk
3
4
Important - Please read these instructions fully before starting assembly
General Power Tool Safety Warnings
Safety Information
8. Head protection. Always use safety glasses and gloves. Use a face or
dust mask whenever the operations may produce dust or ying particles.
Wear ear protection whenever the sound level seems uncomfortable.
9. Do not overreach. Keep proper footing and balance at all times.
10. Stay alert, watch what you are doing. Use common sense when
operating the appliance. Do not operate the tool when you are tired.
11. Grip the tool securely. Operator should have one hand on the main
handle, the other on the front handle. Keep nger off trigger until ready to
use.
12. Remove adjusting keys and wrenches. Always check that adjusting
keys and wrenches are removed from the tool before operating the
tool.
13. Risk of cut. Do not try to grasp or remove trimmings when the
product is running. Only remove trimmings when the product is switched
off and disconnected from the power supply.
14. Disconnect the battery. Disconnect battery from the tool when not in use
or when servicing or cleaning.
15. Check for damaged parts. Before further use, carefully check the tool
for damage.Check for alignment of moving parts, binding of moving parts,
breakage of parts, mounting and any other condition that may affect its
operation. Do not use the tool if any parts are damaged or defective. Have
any damaged or defective parts repaired or replaced by an authorized
service agent. Never attempt any repairs yourself.
16. Store idle tools. When not in use, tools should be stored in a dry, locked-
up place out of reach of children.
17. Maintain tools with care. Keep tools clean and in good condition for
better and safer performance. Follow the instructions for maintenance and
changing accessories. Keep handles and switches dry, clean and free
from oil and grease.
18. Have your tool repaired by an authorized service agent. This tool
is manufactured in accordance with the relevant safety regulations. To
avoid danger, electrical appliances must only be repaired by qualied
technicians.
Customer Helpline 01904 727508
www.coreservice.co.uk
Safety Information
Additional safety instructions for batteries and chargers
Batteries
WARNING!
Do not use any attachments or accessories not recommended by the
manufacturer of this tool.The use of attachments or accessories not
recommended can result in serious personal injury.
1. Never attempt to open for any reason.
2. Do not expose to water.
3. Do not incinerate the battery pack even if it is severely damaged or is
completely worn out. The battery pack can explode in a re.
4. Do not store in locations where the temperature may exceed 40oC.
5. Do not leave the battery pack in the charger when the charging is
nished, otherwise battery leakage may occur.
6. Charge only at room temperature.
7. Charge only by using the charger provided with the tool (see technical
data).
8. Before charging, make sure that the battery is dry and clean.
9. Use only the correct type of battery for the tool (see technical data).
10. When dispose of batteries follow the instructions given in the section
"protecting the environment".
11. Under extreme conditions, battery leakage may occur. When you notice
liquid on the battery, proceed as follows:
• Carefully wipe the liquid off using a cloth.
• Avoid skin contact.
• Dispose of battery in an environmental friendly way.
12. In case of skin or eye contact, follow the instructions below.
13. The battery uid, a 25-30% solution of potassium hydroxide, can be
harmful. In case of skin contact, immediately rinse with water. Neutralize
with a mild acid such as lemon juice or vinegar. In case of eye contact,
rinse abundantly with clean water for at least 10 minutes. Consult a
physician.
14. Don’t let any metal objects contact the electrode plate on battery pack.
NOTE: The batteries in your battery pack are the Lithium-Ion type. Do
not dispose of battery packs/batteries into household waste, re or water.
Battery packs/batteries should be collected, recycled or disposed of in an
environmental-friendly manner.
Customer Helpline 01904 727508
www.coreservice.co.uk
5
6
Safety Information
Chargers
1. Charger’s plug must match the outlet. Never modify the plug in any way.
Unmodied plug sand matching outlets will reduce risk of electric shock.
2. Use your charger only to charge batteries of the type supplied with your
tool. Other batteries could burst, causing personal injury and damage.
3. Only 2 battery packs are allowed to be charged continuously in order to
prevent over heating of charger, necessary rest time is required to let the
charger cool down before further charging.
4. When charging is nished, unplug the charger from mains socket outlet
and takeaway the battery pack from the charger, do not leave the battery
pack in the charger.
Additional safety instructions for hedge trimmers
5. Never carry the charger by its cord or pull it to disconnect from the
socket. Keep the cord away from heat, oil and sharp edges.
6. Never attempt to charge non-rechargeable batteries.
7. The cord of the charger is not changeable, do not continue to use if the
cord is damaged.
8. Do not expose to water or rain, do not use in wet condition.
9. Do not open the charger.
10. Do not probe the charger.
11. Intended for indoor use only.
1. THIS TOOL CAN CAUSE SERIOUS INJURIES. Read instructions
carefully for the correct handling, preparation, maintenance, starting and
stopping of the tool. Be familiar with all controls and proper use of the
tool.
2. Only use the tool in daylight or good articial light.
3. Never allow children to use the tool.
4. Beware of overhead power lines.
5. Avoid operating while people, especially children are nearby.
6. Dress properly! Do not wear loose clothing or jewellery which can be
caught in moving parts. Use of sturdy gloves, non-skid footwear, and
safety glasses is recommended.
7. If the tool stalls, immediately switch it off. Remove the battery before
attempting to remove any obstructions.
8. Remove the battery before checking, maintenance or working on the
tool.
9. While operating the tool always be sure of a safe and secure operating
Customer Helpline 01904 727508
www.coreservice.co.uk
Safety Information
Additional safety instructions for hedge trimmers
position especially when using steps or a ladder.
10. Do not attempt to repair the tool.
11. Do not operate the tool with a damaged or excessively worn cutting
device.
12. Always wear ear protection, goggle and helmet during operating.
13. Always ensure that all guards are tted when using the tool. Never
attempt to use an incomplete tool or a tool with unauthorized
modications.
14. Always use two hands to operate the tool.
15. When transporting or storing the tool, always t the blade sheath.
16. Always be aware of your surroundings and stay alert for possible hazards
that you may not hear due to the noise of the tool.
17. Do not carry the tool with your hands on the switch unless the battery has
been removed.
18. If you have not used a hedge trimmer before, preferably seek practical
instruction by an experienced user in addition to studying this manual.
19. Never touch the blades while the tool is running.
20. Never attempt to force the blades to come to a standstill.
21. Do not put the tool down until the blade has come to a complete standstill.
22. Regularly check the blades for damage and wear. Do not use the
machine when the blades are damaged.
23. Take care to avoid hard objects (e.g. metal wire, railings) when trimming.
Should you accidentally hit any such object, immediately switch the tool
off and check for any damage.
24. Should the tool start to vibrate abnormally, immediately switch it off and
check for any damage.
25. Always be aware of falling debris when cutting the higher sides of a
hedge.
26. Be aware of the cutting blade; always wear gloves to protect your hands
from cut.
NOTE: Do not switch the hedge trimmer on and off frequently over a short
period of time, and in particular do not play with the ON/OFF switch
Customer Helpline 01904 727508
www.coreservice.co.uk
7
Loading...
