CHALLENGE
7066432
250W Grass Trimmer (Model: GT2317)
Original Manual
After Sales Support
UK/Ireland
0343 515 1906
Important - Please read these instructions fully before starting assembly
These instructions contain important information that will help you get the best from
your mower, ensuring it is assembled correctly and safely.
If you need help or have damaged or missing parts, call the Customer Helpline
on 0343 515 1906.
Apr 2017
Contents
Customer Helpline 0343 515 1906
Safety Information .......................................................................................................................................... 3
Warnings Symbols .......................................................................................................................................3
Safety Warning .............................................................................................................................................4
Precautionary Measures ..............................................................................................................................7
In the Box .......................................................................................................................................................10
Parts ............................................................................................................................................................10
Assembly ........................................................................................................................................................10
Step 1 - Assemble the Housing and Handle ............................................................................................11
Step 2 - Fitting the Guard ..........................................................................................................................11
Operating Instructions & Tips .......................................................................................................................12
Extension Lead ..........................................................................................................................................12
Starting and Stopping................................................................................................................................12
Cutting ........................................................................................................................................................13
Maintenance ...................................................................................................................................................14
Fitting a New Spool of Cutting Line ..........................................................................................................14
Spool Storage ............................................................................................................................................15
Winding New Line onto a Spool ...............................................................................................................16
Troubleshooting .............................................................................................................................................17
General Troubleshooting ...........................................................................................................................17
Technical Data ................................................................................................................................................17
Technical Data Table ..................................................................................................................................17
Disposal ..........................................................................................................................................................17
Disposal and Recycling .............................................................................................................................17
Getting Help ...................................................................................................................................................17
2
Important - Please read these instructions fully before starting assembly
Customer Helpline 0343 515 1906
Safety Information
Warnings Symbols
The following warning symbols appear throughout this
assembly manual and indicate the appropriate safety
measures you should take when assembly and operating
the trimmer.
Take extra care, beware of hazards.
Read instruction manual.
Wear ear and eye protection.
Do not use the machine in the rain or leave it outdoors
when it is raining.
Disconnect the mains plug if the cord is damage or
entangled
Keep bystanders away
Noise level specication Lwa in dB.
Insulation protection class II
Do not dispose of electrical equipment in domestic waste.
Conforms to all relevant safety standards.
3
Important - Please read these instructions fully before starting assembly
Customer Helpline 0343 515 1906
Safety Information
Warnings Symbols (continued)
IMPORTANT! When using this equipment, the following
safety precautions must be followed to avoid injuries and
damage.
• Read all operating instructions carefully and comply with
them. It is important to understand these instructions
and to acquaint yourself with the machine, its correct
usage and all safety requirements.
• Keep this manual in a safe place so that the information
is available at all times.
• If you give the equipment to any other person, give them
these operating instructions as well.
We accept no liability for damage or accidents which result
from non-compliance with these instructions.
Safety Warning
WARNING! Be extra careful when using mains-powered
appliances. Basic safety precautions, including the
following, should always be followed to reduce the risk of
re, electric shock and personal injury.
• Before use, check the supply and extension cord
for signs of damage or ageing. If the cord becomes
damaged during use, disconnect the cord from the
supply immediately. DO NOT TOUCH THE CORD
BEFORE DISCONNECTING THE SUPPLY. Do not use
the appliance if the cord is damaged or worn.
• Read the instructions carefully. Be familiar with the
controls and proper use of the equipment.
• Keep the extension cord away from the cutting elements.
• Wear eye protection.
4
Important - Please read these instructions fully before starting assembly
Customer Helpline 0343 515 1906
Safety Information
Safety Warning(continued)
• Never allow children or people unfamiliar with these
instructions to use the trimmer.
• Avoid using the trimmer if bystanders, especially children
or pets, are nearby.
• Use the trimmer only in daylight or good articial light.
• Never operate the trimmer with damaged guards or
shields or without guards or shields in place.
• Switch on the motor only when yours hands and feet are
a safe distance from the cutting means.
• Never t metal cutting elements to this trimmer.
• Use only the manufacturer’s recommended replacement
parts and accessories.
• Always disconnect the trimmer from the mains when
leaving the trimmer unattended.
• Disconnect the trimmer from the mains before carrying
out maintenance or cleaning work.
• Inspect and maintain the trimmer regularly. Have the
trimmer repaired only by an authorized repairer.
• Take care against injury from the line cutter on the
grass guard for controlling the cutting line length. After
adjusting or extending new cutter line, always return the
trimmer to its normal operating position before switching
on.
• Always ensure that the ventilation openings are kept
clear of debris.
• When not in use, store the trimmer out of the reach of
children.
• If the supply cord is damaged, it must immediately be
replaced by a qualied service agent to avoid further risk
of electrocution or injury.
5
Important - Please read these instructions fully before starting assembly
Customer Helpline 0343 515 1906
Safety Information
Safety Warning (continued)
• Ensure you are familiar with the controls and proper use
of the equipment
• Before use, always check the supply and extension cord
for signs of damage or ageing.
• If the cord becomes damaged during use, disconnect
the plug from the mains supply immediately. Do not
touch the cord before disconnecting the plug from the
mains supply.
• Never use the lawn trimmer if the mains cords are
damaged or worn.
• Warning, cutting elements continue to rotate after the
motor is switched off.
• Keep extension cords away from cutting elements at all
times.
• For the safe operation of this machine, it should always
be used together with a residual current device (RCD)
with a tripping current of not more than 30 mA.
ATTENTION! Danger. The cutting line continues to rotate
for a few moments after the motor is switched off.
SAVE THESE INSTRUCTIONS FOR USE AT A LATER
DATE
6
Important - Please read these instructions fully before starting assembly
Customer Helpline 0343 515 1906
Safety Information
Precautionary Measures
Work area
• Do not expose the appliance to rain. Do not use the
appliance in damp or wet conditions.
• Only use the appliance in daylight or good articial light.
Personal protection
• Wear stout shoes or boots to protect your feet. Do not
operate the appliance wearing open-toed sandal or
when barefoot.
• Wear long trousers to protect your legs.
Using your appliance
• Be sure that the appliance is switched off before
connecting it to the mains supply.
• Stay alert at all times. Watch carefully what you are
doing. Use common sense.
• Do not operate the appliance when you are tired.
• If the appliance begins to vibrate abnormally, switch it
off and remove the plug from the socket. Allow rotating
parts to stop and inspect the appliance for damage and
loose part.
• Never pull the cord to disconnect the plug from the
socket. Keep the cord away from heat, oil and sharp
edges.
• If the main cable becomes damaged during use. Switch
the appliance off and disconnect the plug from the
mains immediately. Do not touch the main cable before
disconnect from the mains.
Safety of others
• Do not allow children or any person unfamiliar with these
instructions to operate the appliance.
7
Important - Please read these instructions fully before starting assembly
Customer Helpline 0343 515 1906
Safety Information
Precautionary Measures (continued)
• Do not allow children, bystanders or animal to come near
the work area or to touch the appliance or mains cable.
• Remember that the operator maybe held responsible for
the accidents or hazards occurring to other people or
their property.
After use
• Switch off, remove the plug from the socket and ensure
that moving parts have stopped rotating before leaving
the appliance unattended and before changing, cleaning
or inspecting any parts of the appliance.
• When not in use, the appliance should be stored in a
dry place. Children should not have access to stored
appliances.
Inspection and repairs
• Before use, check the appliance for damaged or
defective parts. Check for misalignment and seizure
of moving part, broken parts, damage to guards and
switches or any other conditions that may affect its
operation.
• Do not use the appliance if any part is damaged or
defective. Do not use the appliance if the switch does
not turn it on and off.
• Never use the appliance when any guard or housing
element is damaged or not in place.
• Ensure that the appliance will operate properly and
perform its intended function.
• Have any damaged or defective parts repaired or
replaced an authorized repair agent.
• Before use, check the mains cable for signs of damage,
ageing or wear.
8
Important - Please read these instructions fully before starting assembly
Customer Helpline 0343 515 1906
Safety Information
Precautionary Measures (continued)
• Do not use the appliance if the mains cable is damaged
or defective.
• If the mains cable is damaged or defective it must
immediately be repaired by an authorised repair agent to
avoid any further hazard.
• Never attempt to remove or replace any parts other than
those specied in this manual.
General safety during usage
This tool is double insulated; therefore no earth wire
is required. Always check that the power supply
corresponds to the voltage on the rating plate.
• Before using the appliance, check that your cutting path
is free from sticks, stones, wire and any other dangerous
objects that may cause damage or be projected
• Only use the appliance in the correct position, with the
cutting line near the ground. Never switch the appliance
on in any other position.
• Switch on the appliance only when hands and feet are at
a safe distance from the cutting line.
• Avoid any body contact with the cutting line while the
appliance is running.
• Do not work on steep slopes, be sure of your footing. Be
aware that freshly cut grass is damp and slippery.
• Use only the appropriate of cutting line. Never use metal
cutting line or shing line.
• After extending new cutting line, always return the
appliance to its normal operating position before
switching on.
• Take care to keep the mains cable away from the cutting
line. Always be aware of the position of the cable.
9
10
Customer Helpline 0343 515 1906
In the Box
Parts
1
Built-In Cord
Retainer
2
Spare spool holder
1
3
Safety Guard
4
line spool
7
6
This 10m extend
cable is shared with
mower/trimmer
5
Motor Housing
6
ON/OFF switch
7
Upper handle
1
2
5
3
4
11
Customer Helpline 0343 515 1906
Assembly
Step 1 - Assemble the Housing and Handle
2
WARNING! Before assembly, make sure that the tool is switched off and unplugged.
Step 2 - Fitting the Guard
3 4
3. Place the guard onto the tool as shown
4. Secure the guard with 2 screws
WARNING! Never use the tool unless the guard is properly tted
12
Customer Helpline 0343 515 1906
Operating Instructions & Tips
Extension Lead
5
Connect the extension lead socket to the plug on the mower. Hook the cord of the extension lead
through the cord retainer. This helps to prevent accidental disconnection during usage.
Starting and Stopping
6
To prevent cord disconnection, hook the mains lead through the tension strain-relief insert in the
handle.
• Connect the extension lead to the device, then to the mains supply.
• Hold the device rmly with both hands. Do not place the cutter head on the ground.
• To switch on, press the on/off switch- the lawn trimmer always runs at full speed.
• To switch off, release the switch.
CAUTION! After switching the device off, the cutter head still continues to rotate for some seconds.
Remember to rst disconnect lead with the main supply, then with the device.
Hold the tool as show Fig 6
13
Customer Helpline 0343 515 1906
Operating Instructions & Tips
Cutting
• Gently swing the trimmer from side to side.
• When cutting long grass, work in stages, cutting from the top of the grass down. This helps to
prevent the grass from wrapping itself around the cutter head. Keep away from hard objects and
delicate pants.
• If the tool starts running slowly, reduce the load.
• In order to achieve optimum cutting results, only cut dry grass
WARNING! The On/Off switch must never be clamped in the on position. The motor must switch off
after releasing the switch. If the switch is not working correctly, do not use the trimmer.
14
Customer Helpline 0343 515 1906
Maintenance
You tool has been designed to operate over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool care and regular cleaning.
WARNING! Before performing any maintenance, switch off and unplug the tool.
Regularly clean the ventilation slot in your tool using a soft brush or dry cloth.
Regularly clean the cutting line and spool using a soft brush or dry cloth.
Regularly use a blunt scraper to remove grass and dirt from the underneath of the guard.
Fitting a New Spool of Cutting Line
7 8
Unplug the tool
• Depress the tab on the side of the spool cover and remove the spool cover 1 from the housing
3
.Remove the empty spool 2 from the housing.
• Remove any dirt and grass from the spool cover and housing. Insert the new spool and push It
into the boss in the housing.
1
2
4
3 3
1
2
4
• Unclip the end of cutting line 4 and guide the line into eyelet in the housing. The line should
protrude approx. 10cm from the housing.
• Align the tabs on the spool cover with the outlets in the housing.
Push the cover onto the housing until it snaps securely into place.
WARNING! If a cutting line protrudes beyond the trimming blade, cut it off so that it just reaches the
blade.
15
Customer Helpline 0343 515 1906
Maintenance
Spool Storage
9
A spare cutting line spool can be stored in the recess below the rear handle. If you store your spare
spool here it will always be ready to hand when the line on the spool being used runs out.
10 11
12
16
Customer Helpline 0343 515 1906
Maintenance
Spool Storage (continued)
10. To store a spare spool, push it into the recess as shown.
11. Turn the spool as illustrated to lock it in place.
12. The spool should sit securely in the recess and will always be conveniently available when the line
on the spool runs out.
To remove it, turn it the spool in the opposite direction and pull it back out.
Winding New Line onto a Spool
13
5
4
6
• You may wind new cutting line onto an empty spool. Replacement packs of cutting line are
available from your retailer. Use 1.5mm line
• Remove the empty spool from the tool as described above.
• Remove any remaining cutting line from the spool.
• First feed 1cm of cutting line 4 into eyelet 5 in the bottom section of the spool as show
• Wind the cutting line onto the spool in the direction of the arrow 6. Make sure to wind the line on
neatly and in layers. Do not criss-cross.
• Lock the cutting line into a slot on the edge of spool.
• Insert the spool into the cutter head assembly as described above. Do not forget to release the
cutting line from the slot on the edge of the spool.
WARNING! Only use the appropriate type of cutting line.
17
Customer Helpline 0343 515 1906
Troubleshooting
General Troubleshooting
If your tool seems not to operate properly, follow the instruction below. If this does not solve the
problems, please contact your local repair agent.
WARNING! Before proceeding, switch off and unplug Tool runs slowly.
Check that the spool housing can rotate freely. Carefully clean it if necessary.
Check that the cutting line does not protrude more than 8cm from the spool housing. If it does, cut it
off so that it just reaches the line trimming blade.
Technical Data
Technical Data Table
Specification Value
Voltage 230-240V~, 50Hz
Power input 250W
Motor speed 13000min
Cutting width 23 cm
Line diameter 1.5 mm
Line length 1 x 5 m
Weight 1.3 kg
Sound pressure level (dB) 86 dB(A)
Sound uncertainly value (dB) 3 dB
Sound power level Lwa (dB(A)) 96 dB(A)
Vibration value (m/s2) 4.3m/s2 K=1.5m/s
-1
2
Disposal
Disposal and Recycling
Do not dispose with household waste.
Recycle products and components according to local legal requirements.
Getting Help
After sales helpline number: 0343 515 1906
Loading...
