Programming Instructions
for the OMEGA ACTIVE System
- For Offline-Programming -
Translated
programming instructions
version 1.41, 11/2014
Preface
2
2
Preface
These Programming Instructions will help you programming
the OMEGA ACTIVE system and using it
as intended,
safely, and
advantageously.
Any person who
programs,
operates, or
disposes of
the OMEGA ACTIVE system must have read and understood
the entire contents of these Programming Instructions and
other required user manuals, operating and fitting instructions.
Depending on the configuration of your locking system, you
may require other user manuals, operating or fitting
instructions for an overall understanding of the system.
These Programming Instructions should always be kept within
your reach. Always keep these Programming Instructions
within reach for reference during the entire service life.
OMEGA ACTIVE Programming Instructions
Notes on the layout
3
Notes highlighted with this symbol contain additional
information on the efficient use.
Notes on the layout
In these Programming Instructions, a number of elements are
highlighted with defined layout features so you can identify at
a glance whether a passage contains
standard text,
a list, or
individual steps in a sequence of actions.
OMEGA ACTIVE Programming Instructions
Contents
4
4
Contents
Preface .......................................................................... 2
Notes on the layout ....................................................... 3
For your safety .............................................................. 6
Basic safety instructions ......................................... 6
Notes on the handling of batteries .................................. 9
Explanation of the safety notes .................................... 10
Intended use ............................................................. 11
Remarks ................................................................... 11
Manufacturer ............................................................. 11
Service ..................................................................... 11
Description .................................................................. 12
Correct door operation ................................................ 15
Transport notes
For locking cylinder .................................................... 16
For electronic shields .................................................. 17
Example of a system overview .................................... 18
Manual programming .................................................. 20
Basic programming routine ......................................... 22
Granting authorizations ............................................... 23
Deleting authorizations ............................................... 27
Optional Master media ................................................ 30
Online programming .................................................... 38
........................................................... 15
OMEGA ACTIVE Programming Instructions
Contents
5
Opening locking devices .............................................. 41
Opening locking cylinder ............................................. 41
Opening wall terminals ................................................ 43
Opening electronic shields ........................................... 45
Programming with the RF-Stick
................................... 47
Trouble-shooting ......................................................... 55
Concise programming guide ........................................ 57
Defining the SYSTEM-MASTER ...................................... 57
Authorizing a PROGRAM-MASTER ................................. 58
Authorizing a locking medium ...................................... 59
Deleting the authorization of a PROGRAM-MASTER .......... 60
Programming of optional media .................................... 61
Turn on Online mode (RF-INI-MASTER) ......................... 62
Turn on and off Online mode (RF-INI-MASTER)............... 62
No Connection found .................................................. 62
Deleting the authorization of a locking medium ............... 63
Deleting the authorization of all locking media ................ 64
OMEGA ACTIVE Programming Instructions
For your safety
6
6
For your safety
Basic safety instructions
Observe all warnings and notes in these Programming
Instructions when you
assemble,
program, and
use
components of the system.
To prevent danger to life and limb, the following safety
instructions must be observed:
Danger to life
Do not use the ACTIVE-locking cylinder for doors with anti-
panic function, such as escape doors, for which a knob
cylinder is not permitted. People may not be able to open
the door in emergencies and may be injured or killed.
Only use the ACTIVE-locking cylinder for door locks for
which knob systems are permitted. In case of doubt, please
contact the manufacturer of the door or the door lock and
satisfy yourself that the locking cylinder is suitable for your
door system.
Make sure that the effects of your programming do not
expose any persons to any risk of injury or other hazards.
Satisfy yourself that your programming translates into the
desired function.
Make sure that all required system components work
perfectly.
OMEGA ACTIVE Programming Instructions
For your safety
7
Danger of explosion
Live parts of the system components may cause an
explosion. Do not use any components of the system in
potentially explosive atmospheres.
Danger of suffocation
Never allow children to play with packaging material and/or
plastic bags. There is a risk that children pull them over
their head and suffocate.
Danger of poisoning
Always keep the system components out of reach of
children. There is a risk that children swallow small parts
such as batteries or screws.
Danger of property damage
To prevent property damage, the following safety instructions
should be observed:
Always have repairs performed by properly qualified
personnel.
Only use accessories and spare parts recommended by
CEStronics.
Only use the proper or described tools for the system
components.
Do not drop any system components on the floor, on hard
surfaces or on hard objects.
Protect the electronic parts of your system components
against water and other liquids.
The system components contain highly sensitive electronic
parts that may be damaged or destroyed through static
charges. Do not disassemble any system components in
rooms with built up static charge.
OMEGA ACTIVE Programming Instructions
For your safety
8
8
Do not store the locking cylinder without inserting a charged
battery.
Danger through environmental conditions
Do not use the system components in corrosive
atmospheres (chlorine, ammonia, lime water).
Only use the system components in rooms in which the
humidity does not exceed 95 %.
Do not use the system components in rooms with a high
level of dust formation.
Do not use the system components near sources of heat.
The outside knob may only be exposed to temperatures
between–25 °C and +70 °C.
The inside knob may only be exposed to temperatures
between 0 °C and +50 °C.
Danger of malfunctions
The reading units of the system components must not be
covered with metallic material.
Satisfy yourself when installing the Access Point that both
the Access Point and all other system components are in
perfect working order. Malfunctions of the Access Point and
other system components may compromise the functioning
of the entire system.
If necessary, use uninterrupted power supply (UPS)
systems to ensure an uninterrupted operation of your
locking system.
OMEGA ACTIVE Programming Instructions
For your safety
9
Notes on the handling of batteries
Keep batteries out of reach of children. If a battery was
swallowed, consult a physician without delay.
Always insert new batteries. Never insert old and new
batteries at the same time.
Never mix the battery types. Always replace batteries by
batteries of the same or an equivalent type.
Before inserting the batteries, check that the terminals in
the device and at the batteries are clean. Clean them if
necessary.
Observe the correct polarity (+/-) when inserting the
batteries.
Never attempt to recharge non-rechargeable batteries.
There is a risk of explosion!
Never short-circuit the batteries.
Always store new batteries at a cool, dry place. Direct heat
may damage the batteries. Do not expose any batterypowered devices to strong sources of heat.
Never throw any batteries into a fire.
Always remove leaked batteries immediately from the
device.
Clean the terminals before inserting new batteries. There is
a danger of acid burns!
Remove flat batteries from the device.
Replace flat batteries by new batteries within one hour.
Be sure to send back the batteries to orderly disposal.
OMEGA ACTIVE Programming Instructions
For your safety
10
10
ATTENTION
ATTENTION notes warn against possible property
or environmental damage.
Explanation of the safety notes
These Programming Instructions include safety notes of the
following types:
OMEGA ACTIVE Programming Instructions
For your safety
11
Intended use
The individual components of the OMEGA ACTIVE system serve
to unlock and lock doors with locks for which the use of knob
systems are permitted. These system components are
exclusively intended and may only be used for that purpose.
Any other use is considered to be improper and may result in
property damage or even personal injury.
CEStronics GmbH does not accept any liability for any damage
resulting from improper use.
Remarks
This Programming instructions are only valid for:
CEStronics OMEGA ACTIVE-System
Manufacturer
The manufacturer of the OMEGA ACTIVE-System is:
CEStronics GmbH
Friedrichstr. 243
42551 Velbert
Tel: +49 (0) 2051-204-0
Fax: +49 (0) 2051-204-105
www.ces.eu
Service
For support in case of service please contact your CEStronics
partner.
OMEGA ACTIVE Programming Instructions
Description
12
12
Description
The OMEGA ACTIVE system is a system for securing buildings
and inner rooms using state-of-the-art technologies.
The system operation is simple, safe and intuitive, irrespective
of the level of implementation.
Equipment variants
Depending on the equipment of your locking system, the
system comprises:
wall terminals, shields and locking cylinders. These
components are the locking devices that grant or refuse
access through your doors.
the optional CP100 programmer. This accessory provides
an alternative means of programming your locking devices.
With the optional RF-stick, you can manually program your
access devices (locking cylinder, IES shield, wall terminal)
by radio transmission.
Access Points. These are optional interfaces between your
PC with the OMEGA software and your locking devices.
an optional PC with OMEGA ACTIVE software. This software
allows you to manage and program the entire wireless
locking system.
OMEGA ACTIVE Programming Instructions
Description
13
Scope
The system is suitable for scaling over a wide range:
as a manual system with simple manual programming via
Master media at the locking device;
as a medium-scale locking system with the entire
programming being performed at your PC with the OMEGA
software and transmission of the data to the individual
locking devices via the RF-Stick by radio transmission;
as a large-scale locking system with the entire programming
being performed at your PC with the OMEGA software and
immediate transmission of the data via the linked Access
Points. Virtually no time is lost by going to the individual
devices for manual programming.
You can additionally use the CP100 programmer to program
locking devices without a wireless link. In this case, the
CP100 serves as your data communicator between your PC
and the locking device.
The OMEGA ACTIVE system is based on active transponders.
Unlike passive transponders such as are used in the 125 kHz
series, this allows reading distances of about 70 cm in all three
dimensions.
This means that it is no longer necessary for you to take the
locking medium into your hand.
All OMEGA ACTIVE transponder media can be used as
authorized locking media for your locking devices.
The OMEGA ACTIVE locking devices additionally comprise a
reader for 125 kHz locking media, such as Hitag and EM 4102,
so that also your locking media of the OMEGA 125 kHz series
can be read.
Your locking devices can only be operated with authorized
locking media.
OMEGA ACTIVE Programming Instructions
Description
14
14
You can authorize a locking medium for your locking devices
with Master media, with RF-Stick, the CP100 programmer or
the OMEGA software and radio transmission.
Access is granted if you move with an authorized locking
medium into the reading range of your locking devices. The
reader modules in the locking devices detect an authorized
locking medium and
if the locking device is a locking cylinder, the outside knob is
coupled with the follower and the door can be opened by
rotating the outside knob;
if the locking device is a WT-A-I or WT-A-II wall terminal,
the relay is pulled up and the connected door can be
opened.
Further features of the system:
Convenient operation
Reliable function
Protection against sabotage
Logging of all relevant events
Communication protected against interception
Fast reaction
Control of special functions
Diagnostic functions for trouble-shooting
Integration in existing third-party systems possible.
OMEGA ACTIVE Programming Instructions
Correct door operation
15
NOTICE
Damaging the double knob cylinder by false
door operation possible.
Use only the door handle for opening and
closing the door, like shown in the illustration.
Correct door operation
Don’t open the door with the key:
Don’t open the door with the knob:
OMEGA ACTIVE Programming Instructions
Correct door operation
16
16
cylinders at least 5 cm
apart.
cylinders together with ID
cards or locking media.
cylinders with the reader
fitted.
Transport notes
For locking cylinder
Locking cylinders may interact if they are placed too close to
one another or too close to locking media. This will discharge
the battery.
To prevent interaction between cylinders during transport,
please observe the following notes:
OMEGA ACTIVE Programming Instructions
Correct door operation
17
shields at least 5 cm
apart.
shields together with ID
cards or locking media.
shields with the reader
fitted.
For electronic shields
Electronic shields may interact if they are placed too close to
one another or too close to locking media. This will discharge
the battery.
To prevent interaction between shields during transport, please
observe the following notes:
OMEGA ACTIVE Programming Instructions
Example of a system overview
18
18
SYSTEM-MASTER
PROGRAM-MASTER
Locking media
Locking devices
Prepare an overview or a locking plan for your
programming. This will enable you to determine at
any time which PROGRAM-MASTER you used to
authorize which locking medium.
Example of a system overview
OMEGA ACTIVE Programming Instructions
Example of a system overview
19
ATTENTION
Danger of abuse in case of a lost Master
medium.
If a Master medium is lost, have the locking
cylinder and/or the access terminal initialized by
properly skilled personnel.
Always keep all Master media at a safe place.
Prevent manipulation of the locking system by a
potential finder.
During an initialization, all authorizations for the
locking cylinder or access terminal are deleted.
In the above example, the SYSTEM-MASTER was used to
authorize the PROGRAM-MASTERS no. 1, no. 2 and no. 3.
The PROGRAM-MASTER no. 1 was used to authorize the
locking media no. 1 and no. 2. The locking medium no. 1 was
authorized for the wall terminal no. 1 and the locking cylinder
no. 2. The locking medium no. 2 was authorized for the wall
terminal no. 3.
The PROGRAM-MASTER no. 2 was used to authorize the
locking media no. 3 and no. 4. The locking medium no. 3 was
authorized for the wall terminal no. 3. The locking medium
no. 4 was authorized for the locking devices no. 4, no. 5 and
no. 6.
The PROGRAM-MASTER no. 3 was used to authorize the
locking media no. 5 and no. 6. The locking medium no. 5 was
authorized for the locking cylinder no. 6. The locking medium
no. 6 was authorized for the shield no. 7.
OMEGA ACTIVE Programming Instructions
Manual programming
20
20
Manual programming
For manual programming, you require the following
components:
1. your locking medium of choice
2. your locking device of choice (locking cylinder, shield or
wall terminal)
3. SYSTEM-MASTER
4. PROGRAM-MASTER
OMEGA ACTIVE Programming Instructions
Manual programming
21
Programming is the same for wall terminals and
locking cylinders. In these Programming
Instructions, the locking cylinder is taken as an
example for the description of the programming.
The locking media (1) allow you to operate OMEGA ACTIVE
locking devices (2). In addition to OMEGA ACTIVE locking
media, you can also use 125 kHz locking media.
The locking devices (2) grant or refuse the free access.
The SYSTEM-MASTER (3) is used to authorize the PROGRAM-
MASTER (4) for the locking system. Each system has one and
only one SYSTEM-MASTER and a maximum of ten PROGRAMMASTERS. The PROGRAM-MASTER (4) serves to authorize
locking media (1) for your locking device.
OMEGA ACTIVE Programming Instructions
Basic programming routine
22
22
ATTENTION
If a Master medium is damaged, it may no
longer work.
Make sure that your Master media are not
damaged.
Basic programming routine
The programming of the various authorizations is based on the
following routine:
1. First, you authorize the SYSTEM-MASTER for your locking
device. You can subsequently also authorize the SYSTEMMASTER for further locking devices.
2. You then authorize one or several PROGRAM-MASTER for
your locking device.
3. Finally, you authorize the locking media for one or several
locking devices.
During the programming, various acoustic and visual signals
are given.
The SYSTEM-MASTER allows you to authorize up to ten
PROGRAM-MASTERS for your locking system.
The SYSTEM-MASTER cannot be used to authorize locking
media but only to authorize PROGRAM-MASTERS and optional
Master media (see also page 23).
The locking media for a locking device can only be authorized
with a PROGRAM-MASTER.
One locking medium can also be authorized for several locking
devices.
OMEGA ACTIVE Programming Instructions
Basic programming routine
23
ATTENTION
Danger of accidental deletion of
authorizations.
Only hold the respective media in front of the
reader for as long as is indicated in the
instructions.
You can only define one SYSTEM-MASTER for a
locking cylinder and/or access terminal. If you hold
another SYSTEM-MASTER in front of the reader,
you will hear four short beeps and the LED will
flash red four times.
Granting authorizations
Defining the SYSTEM-MASTER
To define the SYSTEM-MASTER for the locking device, proceed
as follows:
Hold the SYSTEM-MASTER in front of the reader.
Rotate the outside knob of the locking cylinder by at least
one notch or touch the proximity sensor.
The LED signals green as long as the SYSTEM-MASTER is
within reading range.
Remove the SYSTEM-MASTER for a short moment.
When the SYSTEM-MASTER has left the reading range, this is
signalled with a short beep.
To confirm, hold the SYSTEM-MASTER again in front of the
reader for a short moment.
Remove the SYSTEM-MASTER.
The LED signals green as long as the SYSTEM-MASTER is again
within the range of the reader. When you leave this range, this
is signalled with a long beep. This completes the programming
of the SYSTEM-MASTER.
OMEGA ACTIVE Programming Instructions
Basic programming routine
24
24
Authorizing a PROGRAM-MASTER
With this SYSTEM-MASTER, you can now authorize up to ten
PROGRAM-MASTERS. Proceed as follows:
Hold the SYSTEM-MASTER in front of the reader.
Rotate the outside knob of the locking cylinder by at least
one notch or touch the proximity sensor.
The LED signals green as long as the SYSTEM-MASTER is
within reading range. When you leave this range, this is
signalled with a short beep.
Hold the PROGRAM-MASTER in front of the reader for a
short moment.
The LED signals green as long as the PROGRAM-MASTER is
within reading range. When you leave the range, this is
signalled with a short beep.
If you wish to authorize additional PROGRAM-MASTERS,
hold them successively in front of the reader, proceeding as
described above.
To complete the process, hold the SYSTEM-MASTER in front
of the reader for a short moment.
The LED signals green as long as the SYSTEM-MASTER is again
within the range of the reader. When you leave the range, this
is signalled with a long beep. This completes the authorization
of the PROGRAM-MASTER(S).
OMEGA ACTIVE Programming Instructions
Basic programming routine
25
Authorizing a locking medium
Any authorized PROGRAM-MASTER can be used to authorize
locking media. Proceed as follows:
Hold the PROGRAM-MASTER in front of the reader.
Rotate the outside knob of the locking cylinder by at least
one notch or touch the proximity sensor.
The LED signals green as long as the PROGRAM-MASTER is
within reading range. When you leave the range, this is
signalled with a short beep.
Hold the locking medium in front of the reader for a short
moment.
The LED signals green as long as the locking medium is within
reading range. When you leave the range, this is signalled
with a short beep.
If you want to authorize additional locking media, hold them
successively in front of the reader, proceeding as described
above.
To complete the programming, again hold the PROGRAM-
MASTER in front of the reader.
The LED signals green as long as the PROGRAM-MASTER is
again within reading range. When you leave the reading
range, you hear a long beep and the programming is complete.
You can now use any authorized locking medium to unlock the
locking device.
OMEGA ACTIVE Programming Instructions
Basic programming routine
26
26
Authorizing optional Master media
Rotate the outside knob of the locking cylinder by at least
one notch or touch the proximity sensor.
Hold the SYSTEM-MASTER in front of the reader.
The LED signals green as long as the SYSTEM-MASTER is
within reading range. When you leave this range, this is
signalled with a short beep.
Hold the Master media in front of the reader for a short
moment.
The LED signals green as long as the PROGRAM-MASTER is
within reading range. When you leave the range, this is
signalled with a short beep.
If you wish to authorize additional Master media, hold them
successively in front of the reader, proceeding as described
above.
To complete the process, hold the System-Master in front of
the reader for a short moment.
The LED signals green as long as the System-Master is again
within the range of the reader. When you leave the range, this
is signalled with a long beep. This completes the authorization
of the optional Master media(s).
OMEGA ACTIVE Programming Instructions
Basic programming routine
27
Deleting authorizations
Deleting the authorization of a PROGRAM-MASTER
To delete the authorization of a PROGRAM-MASTER, you
require the SYSTEM-MASTER. When you delete the
authorization of the PROGRAM-MASTER, all the authorizations
of locking media that were granted with that PROGRAMMASTER are deleted as well. Proceed as follows:
Rotate the outside knob of the locking cylinder by at least
one notch or touch the proximity sensor.
Hold the SYSTEM-MASTER in front of the reader.
The LED signals green as long as the SYSTEM-MASTER is
within reading range. When you leave the range, this is
signalled with a short beep.
Now hold the PROGRAM-MASTER in front of the reader.
The LED signals green as long as the PROGRAM-MASTER is
within reading range. After about ten seconds you hear two
short beeps.
Now remove the PROGRAM-MASTER from the reader.
To complete the deletion process, hold the SYSTEM-MASTER
in front of the reader again.
The LED signals green as long as the SYSTEM-MASTER is again
within the range of the reader. When you leave the range, this
is signalled with a long beep. The authorization of the
PROGRAM-MASTER has now been deleted.
OMEGA ACTIVE Programming Instructions
Basic programming routine
28
28
Deleting the authorization of a locking medium
You can delete the authorization of individual locking media or
of all locking media. For this purpose, you require the
PROGRAM-MASTER that was originally used to grant the
authorization.
To delete the authorization of individual locking media,
proceed as follows:
Rotate the outside knob of the locking cylinder by at least
one notch or touch the proximity sensor.
Hold the PROGRAM-MASTER in front of the reader.
The LED signals green as long as the PROGRAM-MASTER is
within reading range. When you leave the range, this is
signalled with a short beep.
Hold the locking medium the authorization of which you
want to delete in front of the reader until you hear two short
beeps.
The LED signals green as long as the locking medium is within
reading range.
After you have heard the signal, remove the locking
medium from the reader.
If you want to delete the authorization of additional locking
media, hold them successively in front of the reader.
To complete the deletion process, again hold the PROGRAM-
MASTER in front of the reader for a short moment.
The LED signals green as long as the PROGRAM-MASTER is
again within reading range. When you leave the reading range
you hear a long beep and the authorization of the locking
medium or media has been deleted.
OMEGA ACTIVE Programming Instructions
Basic programming routine
29
You can also delete all authorizations of locking media that
were granted with a given PROGRAM-MASTER.
Proceed as follows:
Rotate the outside knob of the locking cylinder by at least
one notch or touch the proximity sensor.
Hold the PROGRAM-MASTER in front of the reader.
The LED signals green as long as the PROGRAM-MASTER is
within reading range. After about ten seconds you hear two
short beeps. Now all authorizations granted by this PROGRAMMASTER for this locking cylinder and/or access terminal have
been deleted.
Remove the PROGRAM-MASTER from the reader.
Deleting the authorization of optional Master media
In the deletion process, the authorizations of the Master
medium are deleted.
Proceed as follows:
Hold the SYSTEM-MASTER in front of the reader.
The LED signals green as long as the SYSTEM-MASTER is
within reading range. When you leave the range, this is
signalled with a short beep.
Now hold the optional master media in front of the reader.
The LED signals green as long as the PROGRAM-MASTER is
within reading range. After about some seconds you hear two
short beeps.
Now remove the optional master media from the reader.
When you leave the reading range you hear two short beeps
and the authorization of the optional master media has been
deleted.
OMEGA ACTIVE Programming Instructions
Optional Master media
30
30
Optional Master media
Optional Master media allow you to set additional functions
manually without requiring additional aids such as a PC or
programmer.
Each optional Master medium only performs one defined
additional function.
SYSTEM-MASTER
With the SYSTEM-MASTER, you define the allocation to a
locking system. The SYSTEM-MASTER grants all authorizations
on the highest level. For each locking system, there is one and
only one valid SYSTEM-MASTER.
With the SYSTEM-MASTER, you can authorize up to ten
PROGRAM-MASTERS. In its basic version, a locking system
requires one SYSTEM-MASTER and one PROGRAM-MASTER
each to program your locking devices. The SYSTEM-MASTER is
also used to authorize the following additional Master media
for your locking cylinders and wall terminals:
TIME-MASTER
RELEASE-MASTER
BLOCK-MASTER.
OMEGA ACTIVE Programming Instructions
Optional Master media
31
For further information on the programming of the
SYSTEM-MASTER and PROGRAM-MASTER, please
refer to page 23.
For further information on the programming of the
optional Master media, please refer also to the
"Concise programming guide" as from page 26.
PROGRAM-MASTER
The PROGRAM-MASTER is used to authorize and delete the
authorization of your locking media.
OMEGA ACTIVE Programming Instructions
Optional Master media
32
32
TIME-MASTER
With the TIME-MASTER, you set the opening time of the
locking cylinder or access terminal. During the opening time,
your locking device allows free access.
For locking cylinders or shields, this is the period during
which the knob is coupled with the follower time.
For wall terminals, this is the period during which the relay
is pulled up.
To set the opening time of your locking devices with the TIMEMASTER, proceed as follows:
Rotate the outside knob of the locking cylinder by at least
one notch or touch the proximity sensor.
Hold the TIME-MASTER in front of the locking cylinder, the
IES shield or the wall terminal.
When the locking device detects the TIME-MASTER, it starts
beeping at one-second intervals. The number of beeps
determines the opening time.
Example:
5 x Beeper = 5 seconds opening time
OMEGA ACTIVE Programming Instructions
Optional Master media
33
RELEASE-MASTER
With the RELEASE-MASTER, you can set locking cylinders,
shields or wall terminals into enable condition. In enable
condition, no locking media are read and the locking devices
are permanently open.
The cylinder or shield allows permanent access.
The relay of the wall terminal is permanently pulled up.
To set the enable condition:
Rotate the outside knob of the locking cylinder by at least
one notch or touch the proximity sensor.
Hold the RELEASE-MASTER for about two seconds in front of
your locking device (Confirmation: 1 x short signal).
Deactivate enable condition:
Rotate the outside knob of the locking cylinder by at least
one notch or touch the proximity sensor.
Hold the RELEASE-MASTER for about five seconds in front of
your locking device (Confirmation: 2 x short signal).
In response, your locking cylinder uncouples and/or the relay
of the wall terminal drops. The enable condition is also
terminated when you hold the BLOCK-MASTER in front of your
locking cylinder or wall terminal as described below.
OMEGA ACTIVE Programming Instructions
Optional Master media
34
34
The optional transponder cards RF-INI-MASTER
and RF-TRACE-MASTER do not require
authorization with a SYSTEM-MASTER. Their
function is performed immediately when they are
within range of a reader.
The function is deleted by holding the respective
card again within range of the reader.
BLOCK-MASTER
With the BLOCK-MASTER, you can set your locking devices
permanently into blocked condition. In blocked condition all
locking media are rejected.
The locking cylinder is permanently blocked and prevents
access.
The relay of the wall terminal is permanently dropped.
To set the blocked condition:
Rotate the outside knob of the locking cylinder by at least
one notch or touch the proximity sensor.
Hold the BLOCK-MASTER for about two seconds in front of
your locking device (Confirmation: 1 x short signal).
Deactivate blocked condition:
Rotate the outside knob of the locking cylinder by at least
one notch or touch the proximity sensor.
Hold the BLOCK-MASTER for about five seconds in front of
your locking device (Confirmation: 2 x short signal).
OMEGA ACTIVE Programming Instructions
Optional Master media
35
RF-INI-MASTER
The RF-INI-MASTER is used to switch your locking cylinder or
wall terminal into RF (radio) mode. In this mode, the locking
device attempts to establish a connection with the OMEGA
server to receive new programming jobs. Also, the stored
events at the locking device are transmitted. Programming
jobs and events are transmitted cyclically.
To set the RF mode (Online mode) of your locking devices
with the RF-INI-MASTER, proceed as follows:
Turning the outer knob of the cylinder to at least a notch
point or touch the proximity sensor.
Keeping the RF INI MASTER about two seconds before your
locking device.
As a result, you get a short green signal and a short sound.
Turning the outer knob of the cylinder to at least a notch
point or touch the proximity sensor.
Keeping the RF INI MASTER again longer before your
locking device.
As result you get the green signal for about five seconds, as
well as an acoustic signal.
The online mode is now turned on.
OMEGA ACTIVE Programming Instructions
Optional Master media
36
36
To put your locking device in the offline mode, proceed as
follows:
Turning the outer knob of the cylinder to at least a notch
point or touch the proximity sensor.
Keeping the RF INI master before the locking device, until
the following signaling is finished.
As a result, you get the green signal for about five seconds, as
well as an acoustic signal. After a brief pause given again two
short acoustic signals. Then the green signal goes out and the
acoustic signal is terminated.
The offline mode is now turned on.
OMEGA ACTIVE Programming Instructions
Optional Master media
37
Further information on trouble-shooting with radio
transmissions can be found on page 55.
RF-TRACE-MASTER
The RF-TRACE-MASTER serves to verify the quality of the radio
frequency (RF) link between the OMEGA server and your
locking devices.
Flashing green LED: strong RF link
Flashing red LED: faulty RF link
Alternately or simultaneously flashing red and green LEDs:
weak RF link.
The RF-TRACE-MASTER serves to verify the quality of the radio
frequency (RF) link between the OMEGA server and your
locking devices.
To verify the quality of the RF link to your locking devices,
proceed as follows:
Hold the RF-TRACE-MASTER for about two seconds in front
of your locking device.
The function is performed immediately.
If the green LED of your locking cylinder or wall terminal
flashes, the RF link is OK.
If the red LED of your locking cylinder or wall terminal
flashes, the RF link is not OK and must be checked.
If the red and the green LEDs flash alternately or
simultaneously, the RF link is weak and should be checked
to ensure full functionality and reliability.
OMEGA ACTIVE Programming Instructions
Online programming
38
38
Online programming
You can also control and manage your locking systems via a
radio frequency link. This allows a convenient management
and programming of the entire locking system.
The following components are required for wireless
programming (see also next page):
State-of-the-art PC (1, 2) with Windows 7™, Windows 8™,
Windows Server 2008™ or Windows Server 2013™ (XP™
and Windows Server™ 2003 are no longer supported).
1 GHz processor, at least 1 GB RAM, at least 1 GB free hard
disk memory
Network card (TCP/IP)
CD-ROM drive for software installation
One free USB port to use the RF-Stick (optional)
An existing Internet connection to use the OMEGA
Quicksupport
Monitor with a resolution of 1024 768 pixel
OMEGA ACTIVE Access Points (No. 3, maximum ten locking
devices per Access Point).
OMEGA Software
At least one locking device (No. 4).
A valid license for the ACTIVE client.
The RF-Stick (5) can be used either instead of Access Points
(3) or in addition to Access Points.
OMEGA ACTIVE Programming Instructions
Online programming
39
Setting up a
Online radio network
Setting up a system for
manual programming
For further information, please refer to the User
Manual of the CEStronics Suite which is available
free of charge at www.ces.eu.
OMEGA ACTIVE Programming Instructions
Online programming
40
40
To set the RF mode (Online mode) of your locking devices
with the RF-INI-MASTER, proceed as follows (see also page
62):
Turning the outer knob of the cylinder to at least a notch
point or touch the proximity sensor.
Keeping the RF INI MASTER about two seconds before your
locking device.
As a result, you get a short green signal and a short sound.
Turning the outer knob of the cylinder to at least a notch
point or touch the proximity sensor.
Keeping the RF INI MASTER again longer before your
locking device.
As result you get the green signal for about five seconds, as
well as an acoustic signal.
The online mode is now turned on.
To put your locking device in the offline mode, proceed as
follows:
Turning the outer knob of the cylinder to at least a notch
point or touch the proximity sensor.
Keeping the RF INI master before the locking device, until
the following signaling is finished.
As a result, you get the green signal for about five seconds, as
well as an acoustic signal. After a brief pause given again two
short acoustic signals. Then the green signal goes out and the
acoustic signal is terminated.
The offline mode is now turned on.
OMEGA ACTIVE Programming Instructions
Opening locking devices
41
Opening locking devices
Opening locking cylinder
Passive locking media (125 kHz series)
Rotate the outside knob by some notches.
Within two seconds, hold your authorized locking medium
(1) in front of the outside knob (2) of the locking cylinder.
The reader module in the outside knob identifies the locking
medium. Green LEDs in the light ring of the locking cylinder
signal the enabled status.
The outside knob is coupled with the follower.
Rotate the outside knob to open the door.
Release the knob immediately after the door has been
opened. You do not have to turn the knob back into its
original position.
OMEGA ACTIVE Programming Instructions
Opening locking devices
42
42
Active locking media (OMEGA ACTIVE series)
Move with your authorized locking system (1) into the
reading range of the locking cylinder. This range is about
70 cm. You do not have to hold your locking medium in
your hand.
The reader module in the outside knob identifies the locking
medium.
Rotate the outside knob by some notches.
The locking cylinder sends a short signal to signal the enable
status. During the opening time you can open the door.
During this opening time, the locking cylinder does not respond
to any other locking media.
To open the door lock, rotate the outside knob in the
corresponding direction (2).
Release the knob immediately after the door has been
opened. You do not have to turn the knob back into its
original position.
If you are using a locking medium that is not authorized to
enable this locking cylinder, the light ring of the locking
cylinder flashes red four times and you hear four successive
beeps. In this case, the outside knob is not coupled with the
follower. The outside knob rotates freely but the door lock
cannot be operated.
OMEGA ACTIVE Programming Instructions
Opening locking devices
43
Opening wall terminals
Passive locking media (125 kHz series)
To perform the locking or unlocking operation, hold your
authorized locking medium (1) in front of the reader (2) for
about one second.
The green LED in the wall terminal goes on to signal enable
status and the connected door system opens.
During the set opening time you can pass through the door.
During this opening time, the wall terminal and/or long-range
reader does not respond to any other locking media.
OMEGA ACTIVE Programming Instructions
Opening locking devices
44
44
Active locking media (OMEGA ACTIVE series)
Move with your authorized locking medium (1) into the
reading range. This range is about 60 – 150 cm for the wall
terminals (2).
The green LED of the wall terminal or the long-range reader
goes on to signal enable status and the connected door system
opens.
During the set opening time you can pass through the door.
During this opening time, the wall terminal and/or long-range
reader does not respond to any other locking media.
If you are using a locking medium that is not authorized to
enable the wall terminal and/or long-range reader, the red LED
of the wall terminal or the long-range reader flashes four times
and you hear four successive beeps. In this case, no coupling
is established with your connected door system and you do not
have access.
OMEGA ACTIVE Programming Instructions
Opening locking devices
45
1.
Touch the proximity
sensor (1).
2.
Within two seconds,
hold your authorized
locking medium (2) in
front of the outside
shield (3) of the IES.
Opening electronic shields
Passive locking media (125 kHz series)
The reader module in the outside shield detects the locking
medium. The green LED and a short beep of the reader
module signal the enabled status.
The handle is coupled with the lock.
Use the handle of the outside shield to open the door.
If you are using a locking medium that is not authorized to
enable the IES, the light at the IES flashes red four times and
you hear four successive beeps. In this case, the handle is not
coupled with the lock. You can operate the handle but this will
not unlock the lock.
OMEGA ACTIVE Programming Instructions
Opening locking devices
46
46
sensor (1).
Active locking media (OMEGA ACTIVE series)
Move with your authorized locking medium (2) into the
reading range of the IES. This range is about 70 cm. You
do not have to hold your locking medium in your hand.
The reader module in the outside shield identifies the locking
medium. The green LED and a short beep of the reader
module signal the enabled status.
The handle is coupled with the lock.
Use the handle of the outside shield to open the door.
OMEGA ACTIVE Programming Instructions
Opening locking devices
47
RF-Stick
(Part no. 248601V)
Includes the RF-Stick and a CD-ROM
only, for the functional extension of
existing online and offline systems
RF-Stick Set
(Part no. 248605V)
Includes the OMEGA ACTIVE RF-Stick,
RF-STICK MASTER, OMEGA ACTIVE
SYSTEM MASTER, a CD-ROM with the
CEStronics software suite as backup
medium and a USB stick with program
files and licences
RF-Stick
Programming
Package
(Part no. 248604V)
Includes a netbook with pre-installed
CEStronics software suite with single-user
licence, OMEGA ACTIVE RF-Stick, RFSTICK MASTER, OMEGA ACTIVE SYSTEM
MASTER, USB stick with licence file and
data files, CD-ROM with the CEStronics
software suite as backup medium
Programming with the RF-Stick
The optional RF-Stick permits the wireless manual
programming of your locking devices (locking cylinder, IES
fitting, wall terminal). The maximum radio range of the RFStick is 10 metres.
The RF-Stick is available in three different packages:
OMEGA ACTIVE Programming Instructions
Opening locking devices
48
48
An RF-STICK-MASTER authorizes RFSticks.
The RF-Stick is always tied to your system
licence.
One locking device can manage up to ten
RF-STICK-MASTERs.
The RF-Stick is an advancement of the CP 100 programmer
(which can still be used).
The RF-Stick is used to trigger the programming process. For
this purpose, your locking device must know the RF-Stick, i.e.
the RF-Stick must have been authorized for the programming
at your locking device.
To authorize the programming, you always need the RFSTICK-MASTER.
The maximum number of RF-STICK-MASTERs is limited to ten
per system.
The RF-Stick is inserted in your PC. To use it, you must install
it with the supplied drivers of the OMEGA software.
As an alternative, you can also install the RF-Stick on a
netbook which will make you independent of your office PC and
will allow you to program your locking devices locally, provided
the OMEGA software has been installed without errors.
OMEGA ACTIVE Programming Instructions
Opening locking devices
49
Loading new data files from the USB stick
The commissioning process differs depending on the package
supplied:
In case of the RF-Stick package (Part no. 248601V), you
continue using your existing system and your existing
software installation. You may only have to install the
drivers for the RF-Stick, see also page 52.
In case of the RF-Stick Set package (Part no. 248605V),
you receive a complete set for a new installation of the
software suite with licences and data files as well as all
required authorization Masters.
In case of the RF-Stick Programming Package (Part no.
248604V), you receive a netbook with the pre-installed
CEStronics software suite and a single-user licence as well
as all required authorization Masters.
OMEGA ACTIVE Programming Instructions
Opening locking devices
50
50
The procedure described below only applies to
new first-time software installations.
Please refer also to the chapter on importing
locking systems in the OMEGA ACTIVE software
operating instructions. These are available free of
charge at www.ces.eu.
If you insert the RF-Stick again, the loading
process will not be repeated. The loading process
is only executed once.
Before you can work with the RF-Stick and the OMEGA
Software Suite, your data files (= system data; database)
must be loaded. The data files are delivered to you together
with the licence file on the supplied USB stick.
If you have purchased an RF-Stick Set package or an RF-Stick
Programming Package, these data files must be imported.
If you have purchased a RF-Stick package, you continue using
your already existing data and you do not have to import
anything.
To import the data files for the first time, proceed as follows:
Start OMEGA ACTIVE Client until the login window appears.
Do not log in.
Insert the USB stick into a free USB port.
The data files are loaded automatically.
Wait until the loading process has been completed, which is
signalled with "Finished".
Now log in at OMEGA Software-Suite.
Continue with your desired editing.
OMEGA ACTIVE Programming Instructions
Opening locking devices
51
To work with the RF-Stick, proceed as follows:
Authorize the RF-STICK-MASTER at your locking device:
OMEGA ACTIVE Programming Instructions
Opening locking devices
52
52
Insert the RF-Stick in a free USB port of your PC (or
netbook).
The driver should be installed automatically. If it is not, install
the driver manually (you will need administrator rights for your
PC):
Start the hardware recognition of your operating system to
install the driver from this path.
To do so, select "Control Panel" "Devices and Printers"
"Add device".
For the hardware installation open the following file path:
C:\Programs\Omega\Driver\Active\RfStick\
Follow the instructions of your operating system for the
installation.
The installation is now complete and you can start using the
RF-Stick.
Launch the OMEGA ACTIVE software and log in.
After a few seconds the two status messages "System ready"
and "RF-Stick ready" appear in the status line.
If these two status messages do not appear, repeat the
driver installation or call your system administrator for
trouble-shooting.
After the two status messages have appeared:
Edit your locking system as desired.
You will then see a new status message "Programming
required".
Go to the "Other" menu and select "Program changes".
OR select "Programming" in the upper menu bar and click
on "Reprogramming all devices".
You will now see two new status messages in the status line
"Programming running" and "RF-Stick ready for programming".
OMEGA ACTIVE Programming Instructions
Opening locking devices
53
To ensure a fault-free data transmission, there
must not be any obstacles interfering with the
radio transmission between your locking device
and the RF-Stick, otherwise the transmission will
be aborted.
If the distance between the RF-Stick and the
locking device is too long (longer than 10 m), the
locking device will signal the lacking connection
with a long beep and red LEDs.
The progress of the data transmission
can be observed in the "Programming
status" window.
Hold the RF-STICK-MASTER within reading range of your
locking device.
If required, wake up your locking device by slightly turning
the outside knob (for IES fittings: put your finger on the
reading sensor).
When the locking device has detected the RF-STICK-MASTER,
it signals this with a long beep and the green LEDs will go on
for about five seconds.
When the transmission starts, the green LEDs start flashing
and continue to flash until the data transmission is finished.
After the data transmission has been finished, the
programming job is deleted from the "Programming status"
list.
OMEGA ACTIVE Programming Instructions
Opening locking devices
54
54
Signal
Action
Green LEDs (about 2 sec.)
+
Short beep
RF-STICK-MASTER held within
range: authorization successful
Long beep
RF-STICK-MASTER held again
within range:
authorization cancelled
Green LEDs (about 5 sec.)
+
Long beep
Transmission cancelled
Green LEDs, short flashing
+
Green LEDs (about 2 sec.)
+
Short beep
Data transmission in progress
+
Acknowledgement of the end of the
data transmission
Red LEDs (about 5 sec.)
+
Long beep
Connection lost, data transmission
cancelled
Signal
Action
Green LED
Connection with OMEGA-Server
established
Red LED, flashing
No connection with OMEGA-Server
established
Red LED, flashing
+
Green LED, flashing
Data transmission in progress
Signals of the locking cylinder with inserted RFStick
Signalling of the RF-Stick
OMEGA ACTIVE Programming Instructions
Trouble-shooting
55
Symptom
Possible cause and remedy
No RF connection
can be established.
The OMEGA Software Suite has not
been installed completely.
Check the functioning of the
OMEGA server.
The network configuration is not set
correctly.
Check the network settings of your
PC.
The power supply of Access Points is
interrupted.
Check the power supply of your
Access Points.
Locking devices are outside the radio
frequency range of Access Points.
Check the permitted distance.
Limit the trouble-shooting with the
optional RF-TRACE-MASTER (see
page 37):
- Is there a fault at the locking
devices
- or at your PC network?
The locking devices
do not open when a
locking medium is
placed in front of
them.
You have used an unauthorized
locking medium.
Use an authorized locking medium.
Trouble-shooting
OMEGA ACTIVE Programming Instructions
Trouble-shooting
56
56
Symptom
Possible cause and remedy
The locking devices
do not open when a
locking medium is
placed in front of
them.
The battery is empty.
Replace the battery of the locking
cylinder or the locking medium by a
new battery.
Check the power supply to the wall
terminal.
The locking medium is too far away
from the locking device.
Hold the locking medium in the
reading range of the locking
devices.
The locking cylinder is not
programmed.
Program the authorizations for the
respective locking device (see page
57).
There is an interruption in the output
of the wall terminal.
Check the output and the
connected devices of the wall
terminal.
The reading units are shielded by
metallic objects or materials.
Remove metallic objects or material
from the reading units.
If the trouble still cannot be eliminated, please contact your
CEStronics partner.
OMEGA ACTIVE Programming Instructions
Concise programming guide
57
Concise programming guide
This programming overview again shows all programming
procedures.
Defining the SYSTEM-MASTER
OMEGA ACTIVE Programming Instructions
Concise programming guide
58
58
Authorizing a PROGRAM-MASTER
OMEGA ACTIVE Programming Instructions
Concise programming guide
59
Authorizing a locking medium
OMEGA ACTIVE Programming Instructions
Concise programming guide
60
60
Deleting the authorization of a PROGRAM-MASTER
When the authorization of the PROGRAM-MASTER is deleted,
all the authorizations of locking media that were granted with
that PROGRAM-MASTER are deleted as well.
OMEGA ACTIVE Programming Instructions
Concise programming guide
61
The programming sequence is the same for all
optional media. The medium "XY-MASTER" is used
below as an example for all optional media.
Programming of optional media
OMEGA ACTIVE Programming Instructions
Concise programming guide
62
62
Turn on Online mode (RF-INI-MASTER)
Turn on and off Online mode (RF-INI-MASTER)
No Connection found
OMEGA ACTIVE Programming Instructions
Concise programming guide
63
Deleting the authorization of a locking medium
OMEGA ACTIVE Programming Instructions
Concise programming guide
64
64
Deleting the authorization of all locking media
