Page 1
SELF-WATERING POT PLANT
WITH LED GROW LIGHT
CTPTPLHYDRA
Page 2
Page 3
For best results, ensure you read the following before planting anything:
• Fertilizer/water injection hole: Replace water every 2-3 weeks
• Attention to water shortage: According to the growth habits of plants, timely
supplement plants with appropriate water
• Applicable plants: Suitable for any plants
• Nutrient solution: This product is not suitable for nutrient solution and seeds, please
buy it yourself and use it according to the nutrient solution instructions
• Try to keep the environment ventilated and keep the ambient temperature of most
plants within 30 degrees
• Ensure that the product is used in normal environment
• Do not knock over the product when it is working
• This product has no waterproof function, do not over-water.
• The germination stage of seeds has high requirements on the environment, such
as the quality of seeds, environmental temperature, humidity and nutrients in
planting media.
These factors will affect the success rate of seedlings, so the stage of seedling
emergence is best completed under the guidance of professional company or
personnel. Purchasing seedling transplants can make the success rate higher.
Page 4
Planting basin
LED light pole
Adapter
Planting pot User guide
Page 5
1
ON/OFF switch
6
Basin body
2
LED chip 5730
7
Fertilizer fill holes
3
Rotary screw
8
Power indicator
4
Planting medium
9
Adapter port
5
Planting pot
Page 6
to Use
How
1. Ensure all components/accessories are present before beginning.
2. Open the planting pot grill, remove out the cotton pad and remove the planting
medium.
3. Pour the water into the basin body and put it into the planting pot.
4. Plug in the power and turn on the ON/OFF switch.
Page 7
ON/OFF switch
Mode
Description
Press once Natural Light Mode
Press twice Growing Mode
Press three times Reading Mode
*blue light promotes the growth of stems and leaves,
Usage
Wide
The pot plant can be placed in any location, such as bedroom, kitchen, living room, office,
windowsill, etc. Plant your favourite vegetables, flowers, fruits and herbs.
Herbs: Basil, rosemary, thyme, musk, mint.
Vegetables: lettuce, chili, spinach, baby spinach, onion, leek, salad, coriander, green pepper,
peas.
Melons: tomatoes, cucumbers, potatoes, cherries.
Flowers: Roses, baby's breath, lilies, chrysanthemums, daffodils.
the red light is for flower's blooming.
Full spectrum light
16 hours working
8 hours sleep
Blue and Red light*
16 hours working
8 hours sleep
White light
Long-press to adjust brightness
Page 8
Material
ABS + Aluminium Alloy
Power
8.5W
Input
AC 100-240V - 50/60 HZ
Output
DC 12.6V / 1A
LED Quantity
Red (8pcs) + Blue (2pcs) + White (8pcs)
Colour Temperature
5500K
Red Light Wavelength
660 nm
Blue Light Wavelength
460-470 nm
Working Life
35,000 hours
Page 9
Nothing grows out of seedlings
Possible causes: seed quality, growing methods and environment.
Solution: Buy good seeds, control the temperature of the environment, and keep well
ventilated.
Transplantation does not grow
Possible causes: Seedlings have been damaged during transplantation or proper
transplantation methods and environmental controls have not been followed.
Solution: Understand the transplantation method of plants before transplantation and
operate according to the method to control the planting environment: environmental
temperature, etc.
Stems are slender
Possible cause: Inadequate nutrition.
Solution: Supplement nutrient solution.
The leaves turn yellow or wither
Possible causes: inadequate nutrition, high ambient temperature, poor ventilation, poor
water quality, etc.
Solution: Replenish the nutrient solution, keep the environment ventilated, reduce the
ambient temperature, and change the water regularly.
Page 10
Page 11
Page 12
Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
