Page 1
Libri
10.5"
bedside sconce reading light
right model, brushed aluminum
Left mo del, aluminum xture, h ardwired with walnut w all mount plug-in backplate mo unting kit
Left model, aluminum xture, hardwired with
walnut J- box plug-in back plate mounting kit
Left model, aluminum xture, hardwired with
aluminum J- box plug-in back plate mounting kit
1.5"
Dimensi ons: 10.5" x 1.5" x 1.2"
Materials: aluminum, polymer, optional solid
wood mounting
Produc t weight: 1 lb
Light source: integrated LED
Light outp ut: 160 Lumens (source)
Light colo r: 2700 K
Color accu racy: 90+ CRI
Power usag e: 2 W
Automatic O N/OFF when arm is pul led away
from wall
Specifications subject to change
MATERIAL & FINISH OPTIONS
Libri par t # 03-160-
Direction
left model L
right model R
Finish
brushed aluminum (CM-006) A
white (CM- 060) Y
Installation
corded (plug-in) C
hardwired* H
Alternat e voltage / plug st yles available
J-box centered behind fixture
DIRECTION
left mod el (L) right model (R)
INSTALLATION
*Hardwired installation requires room in the
J-box f or the included e xternal power a dapter
(2" x 1" x 1.25"). Typicall y mounting kit is us ed.
See moun ting options on thi s page
1.2"
The Libri is ab out function and e ase: an
extremely articulate directional task light in a
discrete and st urdy form that is very i ntuitive
to use.
Nick Sheridan,
Designer
MOUNTING OPTIONS
Mountin g kits are sold sep arately from the
Libri x ture.
No Mounti ng kit is require d if the Libri xtu re is
to be insta lled using the Dir ect Mount optio n.
1/2" hole required on mounting
surface for cord passage
Direct Mo unt
Direc t mount option is use d when mounting
direct ly to a headboard. T here is no backp late
and the cord m ust be fed throug h a hole in the
headboard directly behind where the xture is
mounted a nd plugged into a wal l outlet using
the inclu ded AC adapter.
Libri Mounting Kit
sconce backplate
J-box B ackplate: Mounti ng Kit (3)
J-box b ackplate is typ ically
used whe n mounting to a J-b ox.
Hardwired installation requires
room in the J -box for the inc luded
exter nal power adapter
(2"x1" x 1.25").
Wall Mount Plu g-in Backplat e:
Mounting K it (1, 2)
Wall mount p lug-in backpl ate is
used whe n mounting direc tly to the
wall and pl ugging into a wall ou tlet.
The wall m ount is an elongate d
recta ngle that allows the c ord to
exit discreetly below the xture.
MOUNTING KIT OPTIONS
Mountin g Kit Part # 03-160-10-
Direction
wall moun t plug-in, lef t 1
wall moun t plug-in, righ t 2
J-box b ackplate 3
Finish
brushed aluminum (CM-006) A
walnut (CM-001) W
white (CM-060) Y
4.5"
5.25"
2"
23.5"
WARNING. California Prop osition 65 Warning fo r California Consu mers. This prod uct can expose y ou to chemicals incl uding wood dust an d lead which are kno wn to the State of Calif ornia to cause cance r
or birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
94 9.715.15 34
|
CERN OG RO UP. COM
©2018 Cerno, L.L.C. All Ri ghts Reserved |
Oc tobe r 2018
