Page 1
Features
With overflow.
Modern design.
Material
White ceramic bathroom sink.
Installation
Wall mounted installation.
Semi recessed installation.
Configurations
Bella B
CeraStyle 074800-U
Wall Mounted/Semi Recessed Bathroom Sink
Single Hole.
Nameek’s One-Year Limited Warranty
See website for warranty information details.
USA/Canada: 215.256.4197
Nameek’s reserves the right to make revisions without notice to product specifications.
For more information, go to www.nameeks.com
Page 2
19.3”
16.3”
Bella B
CeraStyle 074800-U
Wall Mounted/Semi Recessed Bathroom Sink
1.38”
9.8”
13.4”
1.75”
28.3”
11.2”
2.8”
16.3”
Technical Information
Bowl type: Single
Installation: Wall mounted
Semi recessed
Drain hole: 1.75”
Faucet hole: 1.38”
Hole configurations: 1
Weight: 34.5 lbs
28.3”
19.7”
7.3”
4.7”
9.8”
13.4”
Notes
Install this product according to the installation
instructions.
Includes mounting hardware.
USA/Canada: 215.256.4197
Nameek’s reserves the right to make revisions without notice to product specifications.
For more information, go to www.nameeks.com
