CeoTronics CT-DECTCASE User Manual

CT-DECT Conference (4)
CT-DECT Conference (8)
US-Version

Base Station for up to 4 CT-DECT Transmitter/Receiver
Devices
Base Station for up to 8 CT-DECT Transmitter/Receiver
Devices

Operating Instructions

Example

English

Contents

1. Important safety instructions ........................................................................................................... 5

2. Description...................................................................................................................................... 6

2.1 Overview.................................................................................................................................. 6

2.2 Purpose ................................................................................................................................... 7

2.3 Pin assignment of connectors.................................................................................................. 7

2.3.1 12-pole jack »Audio/Data« (standard pin assignment) ...................................................... 7

2.3.2 3-pole jack »Power Supply«.............................................................................................. 8

2.4 Dimensions.............................................................................................................................. 8

3. Commissioning and operation......................................................................................................... 8

3.1 Handling of plug connections with retaining ring ...................................................................... 8

3.2 Connecting and switching on the base station CT-DECT Conference (4) or (8)....................... 8

3.3 Switching on the CT-DECT units standard............................................................................... 9

4. Safekeeping – storage .................................................................................................................... 9

5. Maintenance ................................................................................................................................... 9

5.1 Visual inspections .................................................................................................................... 9

5.2 Cleaning .................................................................................................................................. 9

6. On-air subscription of base station CT-DECT Conference (4) or (8) and CT-DECT units standard..

..................................................................................................................................................... 10

6.1 General.................................................................................................................................. 10

6.2 Preliminary works................................................................................................................... 11

6.3 On-air subscription to CT-DECT Conference (4).................................................................... 12

6.3.1 On-air subscription of a CT-DECT device standard with subscription button »S1« ......... 12

6.4 On-air subscription to CT-DECT Conference (8).................................................................... 12

6.4.1 On-air subscription of a CT-DECT device standard of group 1 with subscription button

»S1« ............................................................................................................................... 12

6.4.2 On-air subscription of a CT-DECT device standard of group 2 with subscription button

»S2« ............................................................................................................................... 13

6.5 After the subscription ............................................................................................................. 13

2

Important Information for Users of the

CT-DECT transceivers

The CT-DECT transceiver modul has been tested for electromagnetic compatibility and is
compliant with the european DECT-Standard.

CT-DECT transceivers that are not intrinsically safe (explosion-protected) and therefore do
not have any special hazardous duty marking must never be used in potentially explosive
atmospheres. Unprotected CT-DECT transceivers can trigger explosions unintentionally in
these areas.

CeoTronics does not assume any liability for damage to property and personal injuries of any
kind that can arise through the above mentioned or any other incorrect use of the CT-DECT
transceivers.

3

Important Notes for operation of the CT-DECT System in the USA

Please note that any changes or modifications not expressly approved by the party
responsible for compliance will void the user’s authority to operate the equipment.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.

NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

. Reorient or relocate the receiving antenna.
. Increase the separation between the equipment and receiver.
. Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

. Consult the dealer or an experienced radio/TV technician for help.

This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment.To comply with FCC RF exposure compliance requirements, the antenna used for
this transmitter must be installed to provide a separation distance of at least 20 cm from all
persons and must not be co-located or operating in conjunction with any other antenna or
transmitter.

4

1. Important safety instructions

For the use of the device notice the national safety and accident prevention regulations
and the following safety instructions shown in italics in this instruction manual.

 Before using CeoTronics products read completely the appropriate operating instructions. If in doubt,

ask our technical staff.

 If repair work of any kind needs to be done to CeoTronics products, arrange for it to be performed

only by the company CeoTronics or by a specialized workshop that is authorized by CeoTronics. In
all other cases our warranty and liability for the product shall lapse.

 Do not store CeoTronics products outside or in damp ambient conditions. At all times keep them

clean, dry and at normal air humidity. CeoTronics products must not be stored in areas with a
temperature of over +80° C (+176° F), e.g. in the summertime on the parcel shelf of a car. If not
stated otherwise, the following temperature ranges are allowed for CeoTronics products: -10 to
+55° C (+14 to +131° F) for operation, -40 to +80° C (-40 to +176° F) for storage.

 Do not immerse a CeoTronics product into water, if it is not expressly specified for this purpose.
 When using CeoTronics products that are equipped with connection leads ensure that the latter do

not get caught up in operational machinery or wheels!

 CeoTronics products that are not intrinsically safe (explosion-proof) and therefore have no special

explosion-proof designation must never be operated in potentially explosive environments (e.g.
when refuelling cars, aircraft etc.). Devices that are not explosion-proof can unintentionally trigger off
explosions in such areas!

 Connect CeoTronics accessories to a device or disconnect them from a device only when the device

is switched off.

 If you are a cardiac pacemaker carrier, before operating a transmitter/receiver ask the manufacturer

of your cardiac pacemaker for information about any impairment that might be caused due to
high frequencies.

 When on board an airplane always keep a transmitter/receiver switched off. Operation of the

transmitter/receiver could affect the safety of the airplane and it is therefore prohibited. Never
operate electronic devices on board an airplane without the express approval of an authorized
member of the cabin crew.

 Do not leave CeoTronics products lying around loose in cars, e.g. on the parcel shelf. Stow these

products in a suitable, safe place in the car so that they do not present a danger to you or to other
occupants of the car, if emergency braking is effected.

 When driving a car, do not use the radio because it may distract you from the other traffic. Never use

a CeoTronics product that will impair your hearing.

 Keep CeoTronics products out of the reach of children and any other persons who are not familiar

with the handling and operation thereof.

 Packaging materials, e.g. filling materials and plastic bags are not toys and have to be kept out of

the reach of children. There is a risk of children ingesting them and choking !

 Safe operation requires clean devices. Ensure that the devices are clean and in good condition at all

times.

 CeoTronics products may only be used for the specific application envisaged.
 Should equipment, supplied by CeoTronics, be definitely put out of service you may return it to

CeoTronics. We ensure recycling and/or disposal of outdated equipment in compliance with the
applicable environment protection law.

 Keep these operating instructions for later use.

The device is not conceived for the usage in the external area. If the device is to be used
nevertheless in the external area, then it must be protected by suitable measures from
influences of the weather.

5
