CAR SEAT/
ENGLISH
STROLLER
INSTRUCTION
MANUAL
English PM-0624AB 3/98
Do not use this 4-in-1
System until you read and
understand these
instructions!
ENGLISH
IMPORTANT INFORMATION
Thank you for selecting this 4-in-1 System Pro Sport Plus
Car Seat/Stroller which has many uses:
• Infant car seat
• Carrier
• Car seat/Stroller
• Stroller
❃ Need Help?
If you need help with this product, call toll-free
1-800-837-4044 from anywhere in the U.S. or Canada.
Outside these areas please call 330-963-2800 8:00 AM
until 6:00 PM E.S.T. Monday through Friday.
Or write us at: Century Products Company
Macedonia, OH 44056-2096
9600 Valley View Road
Attention: Consumer Relations Department
Please have the following information available. See label
on leg of stroller.
Date of Purchase:
Model Number:
Manufacture Date:
❃ Safety First Check List
✔ Read and understand instruction booklets for stroller
and car seat before using.
✔ Use the SmartFit
product only with Century Assura™ Premiere or
SmartFit™ Infant Car Seat.
™
Adjustable Base provided with this
✔ Never leave child unattended.
Table of Contents
Page
1 Important Information
2 Stroller Warnings
❃ Car Seat/Stroller Assembly
3 Opening Stroller
3 Front Wheel Assembly
3 Lock Footrest
3 Rear Wheel Assembly
❃ Car Seat/Stroller Usage
4 To Attach Car Seat Adapter
4 To Attach Car Seat
4 To Remove Car Seat
❃ Stroller Usage
5 To Remove Car Seat Adapter
5 Canopy Positions
5 To Attach Napper Bar
5 Seat Back Positions
5 To Secure Child
✔ Use with only one (1) child at a time.
✔ Do not use accessories other than those provided by
Century.
NOTE: All warnings and instructions apply whether stroller
is being used with or without napper bar.
❃ Weight & Height Limit
•
Car Seat/Stroller Use:
- Less than 9 kg. (20 lbs.)
- Less than 60 cm. (27 inches)
• Stroller Use:
- Up to 15.9 kg. (35 lbs.)
- Up to 101 cm. (40 inches)
❃ No Tools Required for Assembly
Save instruction manual
for future reference.
❃ Special Information
6 Folding and Storing
6 Maintenance
- Cleaning
- Dented Wheels
7 Replacement Parts
8 Replacement Parts Order Form
1
WARNINGS
ENGLISH
Never leave child unattended.
Always keep child in view,
even when sleeping.
• Children may become
entangeled in harness straps
and suffocate, even when
sleeping.
• Stroller may roll away, crash
and seriously injure child,
even with brakes engaged.
Avoid serious injury from falling
or sliding out. Always use seat belt.
Avoid serious injury or strangulation, DO NOT place
child in stroller seat when car seat adapter is
attached. Remove adapter assembly BEFORE using
stroller seat.
DO NOT allow children to play,
hang or pull down on car seat
or stroller handle.
• Stroller may tip over.
• Car seat handle may break.
Push stroller at normal walking
speed only. Fast walking,
jogging or running can cause
loss of control and injure child.
DO NOT pull or carry stroller on
stairs or escalators with child in
it because child could fall out
and be injured.
DO NOT lift car seat/stroller unit
by car seat handle. Handle may
break.
DO NOT allow child to climb unassisted into stroller
as stroller may fall over injuring child.
DO NOT overload basket.
Maximum basket weight is
10 lbs. (4.5 kg.). Stroller may
become unstable and fall over
injuring child.
DO NOT hang anything on
handlebar or canopy as stroller
could fall over and injure child.
2
ENGLISH
CAR SEAT/STROLLER ASSEMBLY
❃ Lock Footrest:
1 Push footrest down so that frame
tube is centered between three
(3) tabs on bottom of footrest
and snaps into place.
Tabs
Stroller Right
Side
❃ Opening Stroller:
1 Stand stroller upright and pull tab
up to release latch.
2 Spread handle and rear legs until
both fold locks “click” into position.
Stroller Left
Side
❃ Rear Wheel Assembly:
1 Remove axle protectors from ends of axle and discard.
2 Rotate brake lever to the unlocked
position and slide wheel onto each
end of axle rod with brake ribs
facing in.
Brake Ribs
3 Attach wheel to axle:
• Snap wheel retainer onto grooved end of axle. Make sure
large end of wheel retainer is towards wheel.
• Snap wheel retainer cap over wheel retainer.
Hub
Cap
Retainer
Cap
Wheel
Retainer
Brake Lever
Wheel
❃ Front Wheel Assembly:
1 Hold swivel wheel assembly upright
(tab pointing down).
2 Tilt stroller slightly back and push
wheel assembly up onto leg until it
locks in place.
Repeat steps 1 & 2 for opposite leg.
.
CAUTION: After wheel
assembly is complete, pull on
3
wheels to check that they are
locked into place.
Tab
CA UTION:
- Failure to install retainer cap may cause wheels to
come off of stroller.
- After wheel assembly is complete, pull on wheels
to check that they are locked into place.
• Line up hub cap tabs with slots in wheel and snap hub
cap into place.
WARNING
Prevent possible choking hazard: discard axle
protectors and polybag which contained rear wheel
parts.
CAR SEAT/STROLLER USAGE
ENGLISH
❃ T o Attach Car Seat Adapter:
1 Step down on brake lever to lock
brakes.
2 Release both levers on sides of
seat back.
NOTE: Stroller seat back MUST
be in reclined position to use
car seat adapter.
3 With release handle of car seat
adapter facing away from stroller,
align both sides of adapter bracket
with top of stroller handle grip
buttons.
❃ T o Attach Car Seat continued
3 Push in red button on each handle
hub and rotate handle back until
it “clicks” and locks just behind
car seat.
Red Button
4 Pull up on both handle hubs to be
sure car seat is locked in car seat
adapters.
NOTE: Car seat comes with a level indicator which is used
for vehicle installation only.
WARNING
Avoid serious injuries from falls. Be sure:
• Harness straps are used to restrain child.
• Car seat handle is in locked carrying position when
lifting or carrying child.
• Car seat is locked into adapter before each use.
4 Rotate adapter bracket into
handle grip opening and snap
into place.
Repeat for opposite side.
Pull on adapter to be sure
adapter is locked.
❃ T o Attach Car Seat:
1 Step down on brake lever to lock
brakes.
• Stroller is fully set up and locked before using.
• Brakes are locked when attaching and removing car
seat from stroller frame.
❃ T o Remo ve Car Seat From Stroller:
1 Step down on brake lever
to lock brakes.
2 Push red buttons on car seat
handle and rotate handle up
until it “clicks” into the locked
carrying position (upright).
Do not lift car seat from car seat
adapter until you have checked
that handle is locked.
2 With car seat facing stroller handle and
stroller canopy in closed position,
place round car seat handle hubs
into curved slots of car seat
adapter. Both sides must
“click” into position.
3 Pull release lever and lift car seat out
of car seat adapter.
Release Lever
4
ENGLISH
STROLLER USAGE
❃ T o Remo ve Car Seat Adapter:
WARNING
STRANGULATION HAZARD! Remove car seat adapter
BEFORE using as a stroller seat.
❃ To Attach Napper Bar:
(Stroller can be used with or without Napper Bar.)
1
Align napper bar (flat side down)
with slots in lower part of handle
bracket.
1 Squeeze tab in adapter bracket
to unlock bracket.
2 Pull adapter bracket out of handle
grip opening.
Repeat for opposite side.
3 Lift car seat adapter away from stroller frame.
Store car seat adapter for future use.
❃ Canopy Positions:
2 Push napper bar into slots. Pull
napper bar to be sure it is locked.
3 To remove: push buttons on fold lock
and pull napper bar out
❃ Seat Back Positions:
• Seat back has two (2) positions:
- Upright
- Semi-reclined
1 For upright position: Lift seat back
forward until seat back pins hook
into seat back latches.
CAUTION: Be sure seat back is
latched onto seat back pins by
pushing down on seat back.
2 For Semi-reclined position: Squeeze
both levers on sides of seat back and
pull seat back down.
1 Canopy has three (3) positions:
Closed
Halfway Opened
WARNING
Prevent serious injuries:
• Make sure child is clear of any
moving parts when adjusting
stroller.
• DO NOT place parcels on top of
canopy.
5
(for use with
car seat)
Fully Opened
(for use as
stroller only)
❃ T o Secure Child:
WARNING
Avoid serious injury from falling or sliding out:
• Always use seat belt to restrain child, even when
sleeping.
• To prevent child from standing or sliding out of
stroller, be sure waist strap is always SNUG and on
child.
• Periodically check waist strap to be sure it is snug
around child’s waist.
1 Secure child with harness system.
• Pull waist straps around child’s waist
and place crotch strap between
child’s legs.
• Snap both buckle tongues into
buckle on crotch strap.
• Pull on waist straps to be sure they
are buckled and snug.
2 Adjust length of waist straps by loosening
or tightening as shown. Double check to
make sure strap does not slip out of buckle
tongues.
Buckle T ongue
SPECIAL INFORMATION
ENGLISH
❃ Folding and Storing:
1 Step down on brake lever to lock
brakes.
2 Remove car seat from stroller
frame (see page 4).
NOTE: Car seat adapter may
remain on stroller when
folding.
❃ Folding and Storing continued:
IMPORTANT:
• When folding stroller , turn stroller
front wheels to straddle frame.
• DO NOT allow front wheels to rest
on frame. Doing so will cause wheels
to warp and they will not roll correctly.
6 Engage latch on side of stroller to
retain stroller in folded position.
3 Place seat back in its most
reclined position.
4 Release fold locks on each side
by grasping handle grips and
pressing on both buttons.
NOTE: This can be done with the
napper bar attached.
5 Continue pushing buttons
and lift handle to fold stroller.
MAINTENANCE
Cleaning:
• Wipe fabric and frame with damp cloth and mild
soap. DO NOT USE abrasives, solvents, strong
detergents, or household cleaners; they can
weaken plastic.
• DO NOT machine wash or dry seat pads that
have boards in them.
• Comfort pad is removable and machine washable.
Machine wash in cold water, machine dry on cool
setting to prevent shrinkage. DO NOT wash with
other clothes.
• When replacing comfort pad, make sure harness straps
are threaded correctly through slots in comfort pad.
• Loop front of comfort pad over leg rest and fasten tabs.
WARNING
To avoid serious injury to child, periodically check
anchoring straps beneath seat pad to ensure they are
secured to frame.
❃ Dented Wheels:
Sometimes wheels become “dented” from shipment or
normal use. You may try the following procedure for
repairing the dented wheel before calling our Consumer
Relations Department.
• Blow warm air from hair dryer over dented area for
1 to 3 minutes.
6
ENGLISH
REPLACEMENT PARTS
PARTS LIST PRICE
A. Front Wheel Assembly
2-Preassembled Wheels (11-65X)
$ 7.50
PART
A
B. Rear Wheel Kit
1-Wheel, Wheel Retainer Clip & Retainer
Cap (11-65X)
C. Hub Cap Set (2) (11-65X)
D. Seat Pad (11-65X)
E. Comfort Pad (11-65X)
F. Canopy Pad (11-65X)
4.95
2.75
13.00
9.50
6.50
B
C
D
E
F
G. Canopy Frame (11-65X)
H. Car Seat Adapter with Brackets (11-65X)
I. Mesh Basket (11-65X)
J. Napper Bar (11-652 ONLY)
K. Instructions & Parts Order Form
NOTE: Prices Subject To Change
7
Add-On Chart
$5.00 = Canada
2.65
G
6.95
H
7.50
I
4.50
J
FREE
K
Shipping & Handling Chart
$ .01 to $5.00 = $4.00
$ 5.01 to $50.00 = $5.00
$50.01 to $200.00 = 10% of Order Total
$200.01 and over = 5% of Order Total
ENGLISH
REPLACEMENT PARTS ORDER FORM
Please fill out and return this form to address shown on back of page.
A. F ront Wheel Assembly $
B. Rear Wheel Kit $
C. Hub Cap Set $
D. Seat Pad $
E. Comfort Pad $
F. Canopy Pad $
G. Canopy Frame $
H. Car Seat Adapter with Brackets $
I. Mesh Basket $
J. Napper Bar $
K. Instructions & Parts Form F R E E
Subtotal Amount $
Shipping & Handling (see chart page 7) $
Outside USA (see add-on chart page 7) $
Total Amount of Order $
**IMPORTANT**
We must have this information to process your
order. See label on right rear leg of stroller.
Model Number:
Manufacturer Date:
Charge to credit card Visa MasterCard
Card Number:
Expiration Date:
Cardholder’s Name:
Check Enclosed
Please make checks payable in U.S. currency to:
Century Products Company
SHIP TO:
Customer Name:
Street Address:
City, State, Zip:
Area Code: Telephone Number:
PM-0624AB 3/98
8
ENGLISH
Send order with check, money order, or charge card number,
in an envelope to:
Century Products Company
9600 Valley View Road
Macedonia, OH 44056-2096
Attention: Consumer Relations Department
You put more than your trust in us.
™
Loading...
