Century AUTOMATE User Manual

AUTOMATE

™

Li-ion Solar Charging Power Panel

SOLAR

POWERED

FEATURES:

• Plug n’ play for all AUTOMATE Li-ion motors & rechargeable battery packs

• Sleek design allows for unobtrusive placement behind most headrails

• Parallel wiring options support large shades

• Monosilicon/crystal technology allow for up to 30% more efficiency than alternatives

• Low light harvesting technology supports power generation in varied conditions

AUTOMATE | Li-ion Solar charging power panel provides supplemental power to all Li-ion
wirefree motors or rechargeable battery packs.

The monosilicon/crystal solar panel provides power in varied conditions including low
light situations. Panels can also be wired in parallel to provide additional power for
larger applications.

Users can refer to the AUTOMATE Solar Guide for direction related to regional solar
conditions and expected performance.

INSTR. MTSOPLAN-B V1.2 JUL 2017

2 | Automate™ Programming Instructions | MTSOPLAN-B ROLLEASE ACMED

CONTENTS

KIT COMPONENTS

1 INSTALLATION 5

2 DIMENSIONS 7

3 TROUBLE SHOOTING 8

1

3

2

5

4

6 7

1. Solar Panel

2. Solar Panel Mounting Bracket

3. PV Voltage Regulator

4. Double Sided Adhesive Tape x 2

5. Cable Tie x 2

6. Alcohol Wipe x 2

7. Installation Instructions

3 | Automate™ Programming Instructions | MTSOPLAN-B ROLLEASE ACMED

SAFTEY INSTRUCTIONS

WARNING: Important safety instructions to be read before installation.

Incorrect installation can lead to serious injury and will void manufacturer’s liability and warranty.

CAUTION

• Do not expose to moisture or extreme temperatures.

• Do not allow children to play with this device.

• Use or modification outside the scope of this instruction manual will void warranty.

• Installation and programming to be performed by a suitably qualified installer.

• For use with Li-ion motors only.

• Do not cut power cables.

• Use only Rollease Acmeda hardware.

• Do not expose the Solar panel to water or install in humid or damp environments.

• Do not drill into motor body.

• The routing of cable through walls shall be protected by isolating bushes or grommets.

• Ensure power cable and aerial is clear and protected from moving parts.

• If cable or power connector is damaged do not use.

Important safety instructions to be read prior to operation.

• It is important for the safety of persons to follow the enclosed instructions. Save these instructions for future reference.

• Persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge

should not be allowed to use this product.

• Keep remote controls away from children.

• Frequently inspect for improper operation. Do not use if repair or adjustment is necessary.

Do not dispose of in general waste.
Please recycle batteries and damaged electrical products appropriately.
