OPERATOR’S MANUAL
SENTINEL
Commodore-T®
Centurio Design
P.O. Box 1911, D-48007 Muenster (Germany)
Tel: +49 (0)251- 323-55868 | Fax: +49 (0)251-323-55869
E-Mail: [email protected] | Skype: CenturioDesign
Web: CenturioDesign.com | Blog: CenturioBlog.com
STAY ALSO IN TOUCH W ITH US VIA
Vine® | Facebook® | Instagram® | Tw itter®
| Periscope® | Pinterest® | Y outube®: @CenturioDesign
| TAG YOUR CENTURIO DESIGN® PHOTO ONLY W ITH:
#CenturioDesign
ABOUT US
Centurio Design®, the light system specialist from
Muenster (Münster) / Germany focus of outdoor / action
spor ts and law enforcement light. Centurio Design® is
alw ays w orking in other w ays than other companies or
competitors. Usually, companies go from the civilian
sector into the law enforcement- or defense market. In
our case, Centurio Design® is exactly the opposite.
Centurio Design® has managed to place it’s quality
products in various civilian markets, such as in motor
spor ts, outdoor sports and martial arts. In all three
areas,wehave begun torebuild ex isting products or have
developed new products for these markets.
Why didwe choose the name Centurio? We searched
for a name w hich reflects the origin and meaning of our
company. A Centurio w as a rank in the ancient Roman
Army. This army w as know n for its forw ard planning,
including its attention to detail, related to strategy and
organization. We chose our name to reflect this ideal. We
are extremely proud of the name because we feel it
encompasses the spirit of E urope w ithin our Company.
We, as a European based Company, embrace the lifestyle
of the European Union. Wehave Company members from
other areas of the w orld as we expand to encompass
many nations and all new members accept and adopt to
the E.U. ideals westrive to maintain.
PRODUCT A ND SERVICE DISTCRIPTION
The Concept of the Sentinel Commodore-T®
The Sentinel Commodore-T® Anglehead Flashlight is the
big brother of Sentinel® Commodore Anglehead
Flashlight. The Sentinel® Commodore-T and the
Sentinel® Commodore are almost identical, the
differences consist of:
• Sentinel® Commodore-T uses 3 CR123 batteries,
therefore the light body is longer by the size of
one battery.
• The light head of the Sentinel® Commodore is
about tw ice as long as the Sentinel EDC® allow ing
for better grip and stability during use.
The Sentinel Commodore-T® Anglehead Flashlight is a
concept of Centurio Design® and is the connection
betw een the EDC/Law -Enforcement and Military market.
We brought back the a nglehead design of the “TL-194
military jungle flashlight” and introduced some of those
features into the Sentinel® Commodore-T T he clip is
able to be used w ith MOLLE w ebbing for secured hands-
free attachment on MOLLE v ests and compatible
equipment. The top-positioned button enables operation
w ithoutremovingfrom the v estor w ebbing gear.
We have remained loyal to our classic “Lightning LessLethal Weapons® (LLLW®)” line and connect luminosity
and self-defense in a flashlight w hich can be used by
law -enforcement or private security officers or Military
and T actical and Surv ival Specialists and also law -
abiding citizensw ho like to ow nand to carry legala selfdefense dev ice. It´s anglehead design provides personal
illumination anywhere, anytime simply w ith a push of
it´s top-positioned button, now updated w ith our
exclusive strobe and BlueZeus® technology .
More at our w ebsite CenturioDesign.com under
"RESOURCES" y ouw ill find a new quanti tative of
information.
Under "COMPANY" y ou w ill find our Frequently Asked
Questions, FAQ or shortly FA Qs, a compilation of
frequently asked or most frequently asked questions
and the corresponding answ ers. Among Centurio
Design® products, processes, technologies, and product
safety training. Under "E-SCHOOL" covers even more
for you. Information thatwehave previously shared only
on payment from our coursesw ith you, youw ill find now
onlin e and free of charge. Under "SERVICE" y ou also
find our new Centurio Design® Instructor Development
School (IDS), since you can not live from your
know ledge, we know how hard the times are, we open
this IDS possible like to expand your trainer activities, or
to start a new addition to w ork and to earn something.
Centurio Design® been right out of the training business
and train only so-called "Master Instructor" w how orks
and operating independently and like to train customers
on our products and techniques.
ABOUT US, BRANDS AND CONTACT US
Manual ID: S-Commodore-T-03-16 (ENGL)
OFFICIAL BRANDS/LOGOS
LightShield® X-Light® FireChicken®
Page 2
USING, TECHNICAL, CLEANING DETAILS ELEMENTS OF YOUR CENTURIO DESIGN PRODUCT SPECIFICATIONS
The Flashlight is made of high quality Aircaft
Aluminum, anyway you must serviced then from
time to time. Please alw ays use the following
information's.
BATTERY REPLACEMENT
Unscrew the tailcap and insert new batteries w ith
positive ends towards LED head assembly. Replace
tailcap and hand tighten. Press tailcap pushbutton
sw itch to test. Note: If batteries are inserted w ith
positive ends towards the tailcap, the unit w ill not
light. Damage w ill not occur. Reinsert batteries w ith
positive ends towardsthe LED assembly.
WARNING
Lithium batteries can explode or cause burns if
disassembled, shorted, recharged. exposed to w ater,
fire, or high temperatur es. Do not place loose
batteries in a pocket, purse or other container
containing metal objects, mix w ith used or other
battery types, or store w ith hazardous or
combustible materials. Store in cool, dry, v entilated
area. Follow applicable law s and regulations for
disposal.
MAINTENANCE
Clean and lubricate threads w ith a clean cloth and
apply thin coat ofsilicon-based lubricant torubber O-
rings. The Centur io Design® Flashlight has threaded
parts. Werecommend all threaded parts w ith an oil
which contains little w ater regularly collect. Please
use exception cloths that has no fluff balls. Note: Do
not use petroleum-based lubrication on Centurio
Design O-rings. A fter prolonged exposure to
moisture, the bezel and batteries should be removed,
inspected, and dried if necessary.
• Material: Precision-machined, Anodized
Aircraft Aluminum Construction
• The Sentinel Commodore-T® use a mini
version of the JC Impact Ring®.
• The clip is made to fit on MOLLE straps
• Size: 145 mm x 25mm
• Length of Light neck: 55mm
• Weight: 130 grams (w ithout batteries)
• 199 grams (w ith batteries)
• Bulb: Shock-Isolated Bulb
• Quadruple O-ring Seals for Extreme Weather
Resistance
• Illumination: CREE LED Bulb
• Power Supply: 3 x CR123A 3V Lithium Batteries
• Operating Range: -40 °C to +60 °C
• Color: Black
• Lumens : 343
FLASHLIGHT MODES:
Pressing the pushbutton sw itch
• Tap ones and quick you get
“Constant light beam”
• Hold = LLLW emergency/defensive
strobe
CAUTION: The Flashlight has a high-output lighting
device and should not be left on unattended. External
surface temperature w ill rise during prolonged
operation; this is a normal operating phenomenon.
DEFECTS AS TO QUALITY (WARRANTY TERMS)
Thisw arranty is by the E.U. law s of 24 months. Thisw arranty does not
apply in the case of, for example, Misappropriation, technological
changes,misuse, damage caused by leaking batteries or poor
maintenance. Batteries, light bulbs, w ear parts and colored
Eloxalbeschichtungen are also excluded from this guarantee.
The completw arranty terms you find online at our Website:
www.CenturioDesign.com/WARRA NTY
