Central Brass
C O M P A N Y
MODEL NOS.
Certified to
ANSI/NSF 61 Section9
Brecksville, Ohio 44141
Phone: (216) 883-0220 Fax: (440) 526-6399
www.CentralBrass.com
O-Ring Compression 1/4-Turn Compression
0047-SA 0047-SA-Q
The wall mounted sink tting is designed with a solid
cast brass body with replaceable seats. The anges
are all brass and have 1/2-inch female pipe connec-
tions. The inlet supply location is adjustable by rotating
the ange to obtain a three inch center variation. The
6-inch spout has a water saving aerator that limits the
ow. The stems are all brass with a double O-Ring seal
and rubber seat washer. The canopy handles are zinc
die cast with a chrome plated nish. The faucet and
anges are polished and copper, nickel, and chrome
plated.
0047-SA 0047-SA-Q
SINK FIXTURE
Flow Rate: 2.0 GPM @ 60 psi
ADA Compliant and Meets ASME A112.18.1M
ANSI/NSF 61/Section 9 Certied
Installation Drawing
06-20-2008
Page 2
Central Brass
C O M P A N Y
MODEL NOS.
0047-SA 0047-SA-Q
Brecksville, Ohio 44141
Phone: (216) 883-0220 Fax: (440) 526-6399
www.CentralBrass.com
Handle variations available
ELS - Sufx
Wrist 4-inch
EL - Sufx
Elbow 6-inch
G-4147 (4-inch)
G-4149 (6-inch)
Spout variations available
A1 - Sufx
8-inch Brass Tube Spout
A2 - Sufx
10-inch Brass Tube Spout
A3 - Sufx
12-inch Brass Tube Spout
A4 - Sufx
14-inch Brass Tube Spout
H - Sufx replaces A for hose end
SINK FIXTURE
Sufx Options
& Accessories
Drinking water products tested and certied by
NSF International to ANSI/NSF Standard 61,
Section 9. Each product required to meet the
standard proudly exhibits the NSF logo.
Faucets with lever, wrist or elbow handles with compression
or ceramic stem cartridges are
ADA compliant.
A6 - Sufx
8-inch Brass D-Spout
H - Sufx replaces A for hose end
5-1/16"
SU-365-CA
8-inch
(Available in 5-inch)
8.19"
3-61/64"
SU-363-MA
14-inch
A9 - Sufx
5-inch Cast Brass Spout
H - Sufx replaces A for hose end
1/64"
5"
Cast Brass Spout
Extension
Accessory
2-1/2"
SU-2775-R-02
7-inch
7"
1-3/4"
SU-2923-A
5-inch
GSA - Sufx
4 3/32 Swivel Gooseneck Spout
GRA - Sufx
4 3/32 Rigid Gooseneck Spout
H - Sufx replaces A for hose end
9-13/16"
4-1/16"
O
9
5-5/8"
SU-157-GSA
4 3/32 -inch Swivel
Availavle in Rigid
KSA - Sufx
5 1/2 Swivel Gooseneck Spout
KRA - Sufx
5 1/2 Rigid Gooseneck Spout
H - Sufx replaces A for hose end
O
2
9-15/16"
SU-157-KSA
5 1/2 -inch Swivel
Availavle in Rigid
5-9/16"
5-3/4"
06-20-2008
Page 3
Central Brass
C O M P A N Y
MODEL NO.
0047-SA
Brecksville, Ohio 44141
Phone: (216) 883-0220 Fax: (440) 526-6399
www.CentralBrass.com
# Part # Description
1 2831-CP Brass Faucet Body
2 263-BC Bronze Seat
3 1028-Y Nylon Gasket
4 104 Brass Seat Washer Screw
5 901-WNN Seat Washerq
6 453-FL Brass Left Thread O-Ring Stem
6 453-FR Brass Right Thread O-Ring Stem
7 1038-453 O-Ring
8 453-EWC Brass Left Threat O-Ring Bonnet
8 453-EWH Brass Right Thread O-Ring Bonnet
SINK FIXTURE
Parts Breakdown
# Part # Description
9 523-C Handle Indexed “C”
9 523-H Handle Indexed “H”
10 107-F Brass Phillips Head Screw
11 1038-KN O-Ring
12 166-FN Stainless Steel Snap Ring
13 PF-782-D Brass Spout Nut
14 PF-2924 Brass Swivel Spout
15 30-M Female Aerator
16 390 Flange
17 2806 Brass Offset Arm
18 PF-2843-49 Brass Hex Spout Nut
19 PF-256-L Brass Spud
20 940-TRN Washer
21 SU-453-EL Left O-Ring Stem Assembly
21 SU-453-ER Right Thread O-Ring Assembly
22 SU-2806 Brass Flange Assembly
The parts listed in the parts breakdown above may not be
offered separately as replacement parts. Please review the
Replacement Parts page for the authorized replacement parts
that are available for this item.
06-20-2008
