20L DEHUMIDIFIER
Model: CELDH200
OPERATING INSTRUCTIONS
This Dehumidifier is rated to extract 20L per day in an environment of 80% humidity and temperature of 30°C. This is the world-wide standard for rating dehumidifiers. In New Zealand we do not have climatic conditions with humidity and high temperature and accordingly this product will not extract 20L per day. Extraction levels will be lower.
Page 2
4. Do not insert or allow foreign objects to enter
any ventilation or exhaust opening, as this may cause an electric shock, fire or damage to the appliance. Do not sit on the appliance.
6. This appliance is intended for household use
only and not for commercial or industrial use.
cleaning the air vents and grills.
12. Do not operate with cord set coiled up as a
heat build up is likely, which could be sufficient to become a hazard.
16. Always unplug appliance when not in use.
17. Do not locate the Dehumidifier directly below any power socket during operation.
18. Do not twist, kink or wrap the cord around the
appliance, as this may cause the insulation to weaken and split. Always ensure that all cord has been removed from any cord storage area and is unrolled before use.
19. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities or lack of experience and knowledge, unless they are supervised or have been given instruction
concerning the use of the appliance by a
person responsible for their safety.
20. Do not use this appliance in the immediate surrounds of a bath, a shower, or a swimming pool or other liquids. The appliance must not be immersed in any liquids.
21. When the appliance has been unpacked, check it for transport damage and ensure all parts have been delivered. If parts are missing or the appliance has been damaged, contact
the Celsius Customer Services Team.
22. If your appliance does not work, or is not working properly, contact the place of purchase or the Celsius Customer Services Team. Repair work on the appliance by unqualified persons can cause serious risk to the user.
23. There are no user serviceable parts installed in the unit.
24. Do not place the unit in wardrobes or other enclosed spaces as this may cause fire hazards.
25. This unit is not supposed to be used in or around locations where foodstuffs, works of art or delicate articles of science, etc are stored.
26. Indoor use only.
27. Children should be supervised to ensure that they do not play with the appliance.
28. Ensure Dehumidifier is on a flat, stable, heat­resistant surface.
29. It is important that you do not cover this Dehumidifier
WARNINGS AND SAFEGUARDS
Celsius – New Zealand
Monday – Friday 8am-5pm Phone +64 (0)9 917 4000 Phone 0800 232 633 [email protected]
Celsius – Australia
Monday – Friday 8am-5pm Phone +61 (0)3 9336 4423
Phone 1300 465 324
[email protected]
SUPPORT AND TECHNICAL ADVICE
Page 3
COMPONENTS
Water Tank
Handle
Control Panel
Filter
Continuous Dehumidify Drain
Air Outlet
Front Cover
Air Guide Louvre
Power Cord
CONTROL PANEL
Page 4
Always choose a safe location for the Dehumidifier, keeping in mind the safety precautions outlined. Ensure all packaging has been removed from the unit before use. This appliance requires no installation, it should be used solely as a portable appliance
OPERATION
Leave the appliance to stand for one hour after transport or after the unit has been on its side before connecting it to the mains supply to let the refrigerant settle. Ensure that the water tank is positioned correctly. Plug into power supply; 1 beep signal will sound. To turn on the Dehumidifier, press the STANDBY button. The OPERATION light will illuminate.
The unit will be in FAN mode and will run continuously in this mode until turned off. The Relative
Humidity (RH) cannot be adjusted in this mode, it is preset at 55%.
Press the MODE button to toggle between FAN, LOW, HIGH, and AUTO.
In LOW and HIGH modes, your desired humidity can be set with the up and down arrows. The unit ranges from 30% to 80% RH in 5% increments (or continuous; CO).
When the AUTO mode is set, the unit will run continuously; the RH cannot be adjusted in this mode.
Press the STANDBY button again to turn the unit off.
NOTE: When the sensor detects an ambient humidity level 1% lower than the current set level, the compressor will turn off and the fan will continue to run. Once the ambient humidity level increases to 5% higher than the current set level, the compressor will turn back on and continue to dehumidify.
This Dehumidifier is designed to provide an optimum performance. It is not recommended to operate in ambient temperature exceeding 35°C or lower than 5°C.
Ensure all external windows and doors are closed before turning on the unit.
CARE AND CLEANING
Do not attempt to dismantle the Dehumidifier. There are no user serviceable parts. For service or repair, contact an authorised electrical service technician.
To clean the air filter: Switch the unit off and remove plug from socket. Remove the filter. Clean the filter with a vacuum or with water. Air dry the filter. Ensure the filter is completely dry before placing back in the unit.
Never use unit without the air filter in place.
The exterior may be cleaned with a soft, dry cloth. If the unit is extremely dirty wipe the device with a slightly damp (not wet) cloth. Never spray the unit with water.
OPERATING YOUR DEHUMIDIFIER
Page 5
TIMER
When the Dehumidifier is running, you can set the Timer to turn the unit off after 1-12 hours. In order to do this, press the TIMER button and use the up and down arrows to set the length of time (displayed in the LED display), after which you want the unit to switch off.
When your desired time is displayed press the TIMER button again. The LED screen will revert back
to the relative humidity setting and the TIMER light will illuminate on the control panel to indicate the timer has been set. The Timer will operate in any mode.
AIR GUIDE
When the appliance is on, press the air guide louvre manually to select the angle at which you want the air to blow out from the unit.
Do not operate with the Air Guide Louvre closed.
DEFROST
When the Dehumidifier is operating in low temperatures (under 12°C) the unit will go into a defrost cycle once an hour. This is to remove any ice that has accumulated on the interior of the unit as a result of its operation. The DEFROST light will illuminate on the control panel when this occurs.
WARNING: Keep all objects at least 1 metre from the front, sides and rear of the appliance.
To store the unit, remove the plug from the socket and empty the container. Allow the water tank and
the Dehumidifier to dry completely. Clean the air filter. Store the device in a dust-free location, preferably covered with a sheet of plastic.
IMPORTANT! NEVER COVER THIS DEHUMIDIFIER
Do not use this Dehumidifier with a programmer, remote-control system, separate Timer or any other device that switches the Dehumidifier on automatically.
Page 6
WATER DRAINAGE
When the water container is full: An alarm signal will sound. The Tank Full light will illuminate on the control panel.
The Dehumidifier will stop automatically.
Empty the water tank and replace it in the correct position; the Dehumidifier will continue dehumidifying again.
It is possible to connect a drainage tube (not supplied) to the device for permanent water drainage. If this option is desired, you will need to purchase a suitable tube from your local hardware retailer
(Celsius does not hold tubes as spare parts).
Connect the drainage hose to the drain spout and ensure that the end of the hose is lower than the drain opening, otherwise the water will not drain and flooding may occur. Also ensure the water tank is in position (in the unit) otherwise the continuous drainage will not
operate.
Place the end of the drainage hose in a drainage outlet. When you no longer wish to use the permanent water drainage, disconnect the drainage tube from the unit.
Page 7
TECHNICAL SPECIFICATION
Model: CELDH200 Supply: 220-240VAC 50Hz Wattage: 330-440W Unit Capacity: 20L/day max (30°C/80%RH) Tank Capacity: 2.0L Refrigerant: R134a/180g
PROOF OF PURCHASE
To receive warranty retain receipt as proof of purchase. (Refer to back of booklet).
Problem Cause Solution
The Dehumidifier will not turn on
The power is not connected
Insert plug into mains power supply and turn unit on
The Dehumidifier is not extracting water
The water tank is full
Remove the water tank and
empty water
The water tank is not in its correct position
Remove water tank and replace it correct position
The air filter is clogged
Clean the air filter as per instructions in user manual
The temperature or relative humidity in the room is too low
It is normal for the Dehumidifier not to operate in low humidity or low temperatures
The Dehumidifier operates,
but reduces the relative
humidity in the room by small amounts
The room which the Dehumidifier is operating in is too large
Recommend using a Dehumidifier with a larger capacity
There are too many sources
of humidity
Recommend using a Dehumidifier with a larger capacity
The room has too much ventilation
Reduce the number of ventilation sources (i.e. close windows, doors, etc.
TROUBLESHOOTING
Page 8
Thank you for purchasing this Celsius product. Your product is warranted against faults and manufacture when used in normal domestic use for a period of one year. In non-domestic use Celsius limits the voluntary warranty to three
months.
Celsius undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault
during the warranty period.
This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried out by anyone other than a qualified electrical service technician.
PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY. The benefits given to you by this warranty are in addition to other rights and remedies available to you under law in
relation to the goods or services to which this warranty relates. In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).
One Year Warranty
Celsius One Year Warranty (IMPORTANT: Please complete and retain this warranty card) Name
Address
Place Of Purchase Date Of Purchase
Name Of Product Model Number
Attach a copy of the purchase receipt to this warranty card
Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.
Celsius – New Zealand
PO Box 100-707 N.S.M.C Auckland
Phone +64 (0)9 917 4000
Phone 0800 232 633 [email protected]
Celsius – Australia
PO Box 574
South Morang
Victoria, 3752
Phone +61 (0)3 9336 4423
Phone 1300 465 324
[email protected]
