Page 1
OPERATING INSTRUCTIONS
CERAMIC TOWER HEATER
For model: CELCT180
Page 2
1. Use only the voltage specified on the rating
label of the appliance.
2. Keep all objects at least 1 metre from the
front, sides and rear of the appliance. Do not
place appliance close to radiant heat source.
3. Do not operate in areas where petrol, paint or
other flammable liquids are used or stored.
4. Do not insert or allow foreign objects to enter
any ventilation or exhaust opening, as this
may cause an electric shock, fire or damage
to the appliance. Do not sit on the appliance.
5. Do not operate this appliance with a
damaged cord, plug or after the appliance
malfunctions or has been dropped or
damaged in any manner. Return to a
qualified electrical person for examination,
electrical service or repair.
6. This appliance is intended for household use
only and not for commercial or industrial use.
7. Use this appliance only as described in this
manual. Any other use is not recommended
by the manufacturer and may cause fire,
electrical shock or injury.
8. The common cause of overheating is
deposits of dust or fluff in the appliance.
Ensure these deposits are removed regularly
by unplugging the appliance and vacuum
cleaning the air vents and grills.
9. Do not use abrasive cleaning products on
this appliance. Clean with a damp cloth (not
wet) rinsed in hot soapy water only. Always
remove plug from the mains supply before
cleaning.
10.Do not connect the appliance to mains
supply until completely assembled and
adjusted.
11.Switch off and use handles provided when
moving.
12.Do not operate with cord set coiled up as a
heat build up is likely, which could be
sufficient to become a hazard.
13.The use of an extension cord, power board
or external timer is not recommended with
this unit.
14. Do not remove plug from power socket until the
appliance has been switched off.
15. Do not remove plug from power socket by
pulling cord; always grip plug.
16. Always unplug appliance when not in use.
17. Do not locate the heater directly below any
power socket during operation.
18. Do not twist, kink or wrap the cord around the
appliance, as this may cause the insulation to
weaken and split. Always ensure that all cord
has been removed from any cord storage area
and is unrolled before use.
19. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge, unless they are
supervised or have been given instruction
concerning the use of the appliance by a person
responsible for their safety..
20. Do not use this appliance in the immediate
surrounds of a bath, a shower, or a swimming
pool or other liquids. The appliance must not be
immersed in any liquids.
21. When the appliance has been unpacked, check
it for transport damage and ensure all parts have
been delivered. If parts are missing or the
appliance has been damaged, contact the
Celsius Customer Services Team.
22. If your appliance does not work, or is not
working properly, contact the place of purchase
or the Celsius Customer Services Team. Repair
work on the appliance by unqualified persons
can cause serious risk to the user.
23. There are no user serviceable parts installed in
the unit.
24. Do not place the unit in wardrobes or other
enclosed spaces as this may cause fire hazards.
25. This unit is not supposed to be used in or around
locations where foodstuffs, works of art or
delicate articles of science, etc are stored.
26. Indoor use only.
27. Children should be supervised to ensure that
they do not play with the appliance.
28. Ensure heater is on a flat, stable, heat-resistant
surface.
WARNINGS AND SAFEGUARDS
Page 3
OVERVIEW OF YOUR CERAMIC TOWER HEATER
Your Celsius Ceramic Tower Heater is designed to provide direct personal heating. The heater is equipped
with various heat settings and a fan option to ensure your precise heating needs are met.
OPERATING YOUR HEATER
Always choose a safe location for the heater, keeping in mind the safety precautions outlined. Ensure all
packaging has been removed from the unit before use. This appliance requires no installation, it should be
used solely as a portable appliance.
CONTROL PANEL
The control switch positions are:
1 – No function on this model 4 – Heat setting
2 – Oscillate 5 – Timer
3 – Power On/Off 6 – No function on this model
1
2
3
4
5
6
Page 4
CONTROL PANEL (continued)
The heater can be operated by the controls located on the heater or with the remote control.
2. Oscillate Button – This button turns the heater oscillation function on and off.
3. On/Off Button – This button turns the heater on and off.
Note: the fan will run for up to 1 minute when you switch it off to cool the element, this is normal.
4. Heat Setting Button – This button sets the desired heat setting. Press the button once for low heat, twice
for high heat. Please note that when the heater is turned on it will automatically be on the “fan only”
mode until changed.
5. Timer Button – The timer function allows you to set the length of operation from 1 hour - 8 hours. On any
heat or fan setting press this button to set a desired time for the unit to operate before turning off
automatically (i.e. if you would like the heater to run for 4 hours and then turn off , press the Timer Button
until the light below the 4 is displayed on the control panel and the unit will run for 4 hours then turn off).
6. Note: Buttons 1 & 6 have no function on this model.
Remote control
Install two “AAA”(not included) batteries as shown below.
All the functions performed with the remote control work identically to the manual controls.
IMPORTANT! NEVER COVER THIS HEATER!
Page 5
TECHNICAL SPECIFICATIONS
Model No: CELCT180
Power Supply: 230-240V, 50Hz
Power: 2000W
PROOF OF PURCHASE
To receive warranty retain receipt as proof of purchase.
CLEANING YOUR HEATER
The heater requires regular cleaning to ensure trouble free operation:
• Unplug the heater from the mains supply before cleaning.
• Ensure that the heater has been allowed to cool down completely before cleaning.
• Use a damp cloth (not wet) to wipe the exterior of the heater to remove dust and dirt.
• Use a vacuum cleaner to remove dust and fluff from around the grills.
• Never use solutions such as benzene, thinners or polishing agents.
• Ensure the heater is dry before plugging back into the mains supply.
IMPORTANT! NEVER COVER THIS HEATER!
SUPPORT AND TECHNICAL ADVICE
North Shore City, Auckland, New Zealand
Monday – Friday 8am-5pm
Phone: 0800 232 633
Website: www.celsius.co.nz
SAFETY DEVICE
This appliance has three protection devices:
The first device will automatically turn the appliance off if the appliance is not in the appropriate operating
position.
The second device, automatically disconnects & reconnects the appliance at a preset temperature.
The third device disconnects the appliance permanently in case of overheating, by means of a thermal fuse.
(It is non resettable)
Page 6
Your Celsius product has been inspected and tested and is guaranteed subject to the
following for a period to one year from the date of purchase against defects in
workmanship and materials. During this period, such defects will be rectified by
repair or replacement of the product purchased. Your product contains no user
serviceable components and this warranty becomes invalid if in our opinion the
product has been misused, abused, incorrectly installed, tampered with, connected
to an electrical supply not corresponding with the name plate specification, or
subjected to power surges. The warranty does not include any labour or other
associated expense that may be involved in removal or installation of the product.
Normal wear and tear is expressly excluded.
If your Celsius product fails to operate satisfactorily, please return it to the retailer
from whom it was purchased. To obtain a repair or replacement product under this
warranty, you will need to produce satisfactory evidence of date of purchase. The
completed warranty and purchase receipt must be presented with the product. The
warranty should be filled out at the time of purchase. It is in your interest to make
sure this is done.
If the product is to be replaced (cannot be repaired) then that replacement will be of
the same or similar product or accessory excluding packaging, instruction card etc.
Where a replacement product is supplied, this shall be guaranteed for the balance of
the original warranty period.
Any model that is no longer available will be replaced by a model of a value and with
such features as we consider appropriate in the circumstances. Celsius is not
responsible for freight forwarding charges, losses or damage in transit.
If service is required after the warranty period has expired, the product should be
returned to a qualified electrical technician. Service outside of the warranty period
will be at your cost.
Consumers Guarantee Act (1993).
In accordance with the above act consumers are advised that: The manufacturer
does not undertake that repair facilities and parts are necessarily available for this
product.
If any of the provisions of the foregoing are contrary to any relevant legislation, then
that provision shall be deemed to be excluded from the warranty and the rest of the
provisions will continue to apply.
ONE YEAR WARRANTY
IMPORTANT: PLEASE RETAIN THIS WARRANTY CARD
NAME:
ADDRESS:
PURCHASED FROM:
SUBURB:
DATE OF PURCHASE:
NAME OF PRODUCT:
MODEL No:
