1 Preface
Thank you for purchasing this cellular phone.
To guarantee your cellular phone works properly, please follow the instructions in this manual to prevent
any possible incidents or malfunctions.
Follow all safety warnings to avoid injury or property damage.
Screen displays and illustrations in this user’s manual are designed to help you to operate your phone.
We continuously strive to improve our products. Therefore, we reserve the rights to revise this user
manual or withdraw it at any time without prior notice. We provides this manual “as is” and does
not accept, except as required by the applicable law, liability for any error, omission or discrepancy
between this manual and the product.
1 Preface ------------------------------------------------------------------------------------------------------------------------------1
2 Introduction -----------------------------------------------------------------------------------------------------------------------4
2.1 UNPACKING ................................................................................................................................................4
2.2 PHONE DISPLAY.......................................................................................................................................... 5
2.3 KEY ........................................................................................................................................................... 6
2.4 ICONS & SYMBOLS ...................................................................................................................................... 7
3 Getting Started -----------------------------------------------------------------------------------------------------------------10
3.1 INSERTING THE SIM CARD ......................................................................................................................... 10
3.2 TURNING THE PHONE ON ........................................................................................................................... 11
3.3 CHARGING THE BATTERY........................................................................................................................... 11
3.4 INSERTING A T-FLASH CARD ...................................................................................................................... 12
3.5 IMPORTANT PASSWORD .............................................................................................................................12
3.6 KEYPAD LOCK AND UNLOCK .......................................................................................................................12
4 Text Entry ------------------------------------------------------------------------------------------------------------------------13
4.1 INPUT METHOD ......................................................................................................................................... 13
4.2 ENTERING SYMBOLS ................................................................................................................................. 13
4.3 ZI ENGLISH INPUT ..................................................................................................................................... 13
4.4 MULTI-TAP ENGLISH INPUT......................................................................................................................... 15
4.5 NUMERIC INPUT ........................................................................................................................................ 15
4.6 OTHER LANGUAGE INPUT METHOD ............................................................................................................. 15
5 Calling-----------------------------------------------------------------------------------------------------------------------------16
5.1 MAKE A CALL............................................................................................................................................ 16
5.2 MAKING AN INTERNATIONAL CALL ............................................................................................................... 16
Contents
MAKING AN EMERGENCY CALL ...................................................................................................................17
5.3
5.4 MAKING A SECOND CALL (NETWORK DEP ENDENT)....................................................................................... 17
5.5 MAKING A CONFERENCE CALL (NETWORK DEPENDENT) ............................................................................... 17
5.6 SWITCHING CALLS (NETWORK DEPENDENT) ................................................................................................ 18
5.7 CALLING HANDS-FREE .............................................................................................................................. 18
5.8 ANSWERING A CALL .................................................................................................................................. 18
5.9 REJECTING A CALL ....................................................................................................................................18
5.10 ANSWERING A SECOND CALL (NETWORK DEPEND ENT)............................................................................... 18
5.11 ENDING A CALL....................................................................................................................................... 19
6 Function Menu -----------------------------------------------------------------------------------------------------------------20
6.1 HOW TO USE ........................................................................................................................................... 20
6.2 MAIN MENU.............................................................................................................................................. 20
6.3 PHONEBOOK............................................................................................................................................. 21
6.4 MESSAGE CENTER ....................................................................................................................................26
6.5 CALL HISTORY .......................................................................................................................................... 34
6.6 SETTINGS................................................................................................................................................. 36
6.7 MULTIMEDIA ............................................................................................................................................. 43
6.8 FILE MANAGER ......................................................................................................................................... 51
6.9 FUN & GAME ............................................................................................................................................ 52
6.10 USER PROFILES...................................................................................................................................... 53
6.11 ORGANIZER ............................................................................................................................................54
6.12 SERVICES .............................................................................................................................................. 56
6.13 EXTRA ................................................................................................................................................... 57
2
STK SERVICES....................................................................................................................................... 63
6.14
6.15 USB INTERFACE .....................................................................................................................................63
7 Precautions---------------------------------------------------------------------------------------------------------------------- 65
8 Troubleshooting ---------------------------------------------------------------------------------------------------------------68
9 Safety Information and Notices------------------------------------------------------------------------------------------- 72
12 MONTH LIMITED WARRANTY------------------------------------------------------------------------------------------- 78
3
2 Introduction
2.1 Unpacking
Make sure you have each item
Phone
User manual
Charger
Headset
Battery
The items supplied with your phone may vary, depending on your country or service provider.
4
2.2 Phone Display
5
2.3 Key
Key Function
Pick-Up Press to answer a call or dial a call after you enter a phone number. In idle mode, press to
Hang-Up Press to end a call. Press and hold to turn the phone on/off. W ithin a menu, press to return
Left Soft
Key
Right Soft
Key
OK In idle mode, press to enter the main menu. Within a menu, press to confirm and/or select
Numeric
key
view the call logs.
to idle mode.
In idle mode, press to enter the Main menu. Press to access the option listed directly
above it on the display.
In idle mode, press to access the Live. Press to access the option listed directly above it
on the display. Within a menu, press to return to the previous screen.
the option listed above it.
Press to enter the corresponding number, letter or symbol located on the key. Within a
menu, press to access the corresponding menu option.
6
* Press the * Key twice quickly to enter ‘+’ to make an international call. Press and hold the *
# In idle mode, press and hold to toggle between Silent mode and general mode. Press to
Navigatio
n Key
key to toggle between *, +, P, and W. Press to enter symbol when editing text.
switch input modes when entering text.
Within a menu, press Up, Down, Left or Right to scroll through menu options. In idle mode,
press Left to enter the User Profiles menu; press Right to enter the Tone Setup menu;
press Up to access the FM Radio menu; press Down to enter the Phone Book List.
Note: “Press” in this manual, means to press and release the key; “press and hold” means to press
and hold the key for at least 2 seconds.
2.4 Icons & Symbols
In idle mode, network and battery icons are displayed all the time. The rest of the icons appear if the
feature is available and do not appear if the feature is unavailable. If the network symbol is not displayed,
the network is currently unavailable. You may be in a bad reception area.
Icon Description
Network - The left portion indicates whether your phone is already registered with a
network and the right portion indicates signal strength (from no signal to strongest).
7
To log on GPRS - The icon will be displayed only when you have logged onto GPRS.
Battery - Indicates battery level. When charging, a scrolling icon will be displayed. The
more bars, the stronger the charge.
MMS - Indicates you have one or more unread MMS messages.
SMS - Indicates you have one or more unread SMS messages.
Push message - Indicates that you have received new push message.
Message full- if the icon is flashing, it indicates that the memory is full.
Voicemail- Indicates voice messages that have not been heard.
Miss call - Indicates there is a missed call.
Call Divert - Indicates that “Divert All Voice Calls” is activated.
Lock - Indicates that the keypad is locked.
Alarm - Indicates that the alarm clock is on.
Headset - Indicates that headset profile is activated.
Alert type is “Ring”.
Alert type is “Vibration only”.
Alert type is “Vibration and Ring”.
8
Alert type is “Vibration then Ring”.
Bluetooth is activated.
Chat room 1 or 2 is activated.
9
3 Getting Started
Please read the safety instructions in the "Safety Information and Notices" section before use.
Before using your phone, you must insert a valid SIM card supplied by your GSM operator or retailer. The
SIM card contains your subscription information, your mobile telephone number and a small quantity of
memory in which you can store phone numbers and messages.
You can also insert a memory card. This provides you with expanded memory capability, which allows
you to store additional music, photo and video files separate from the phone's built-in memory.
3.1 Inserting the SIM Card
3.1.1 Remove the back cover
Make sure the phone is switched off. You need to remove the back cover of your phone before you can
insert the SIM card. Hold the phone with the front facing downwards; press and pull the back cover down;
lift the back cover up to remove it.
3.1.2 Remove the battery
Put your fingers on the black holder located on the right bottom of the battery slot and lift the battery up to
remove it.
3.1.3 Insert the SIM card
Make sure that the clipped corner of the SIM card is facing the correct direction (clipped corner at right
bottom) and the metallic contacts are facing downwards. Slide the SIM card into the card slot until it stops.
A small icon beside the slot will prompt you the correct direction.
10
3.1.4 Install the battery
With the metallic contacts of the battery facing the metallic contacts in the battery slot, press the battery
down into its slot until it locks into place.
3.1.5 Install the back cover
Align and hook the back cover to the top of the battery slot and then press the back cover down until it
locks into place.
3.2 Turning the Phone on
To turn the phone on, press and hold the Hang Up key. Enter the PIN code if required (the 4 to 8 digit
secret code of your SIM card). It is preconfigured and provided to you by your network operator or retailer.
If you enter an incorrect PIN code 3 times in succession, your SIM card will be locked. To unlock it, you
must obtain the PUK code from your network operator.
3.3 Charging the Battery
Your phone is powered by a rechargeable battery. The new battery is partially charged. A sound alert will
warn you when the battery level becomes low.
Make sure the battery is not removed. To charge the battery, plug in the connector at the left side of your
phone (USB interface) and then plug the other end into an AC power socket.
Note: the nominal voltage of battery is 3.7 VDC; the charge restriction voltage is 4.2 VDC.
The battery symbol indicates the charging status.
During charging, the charge indicators will scroll; it takes about 3 hours to fully charge the battery.
When all the scroll bars are steady, the battery is fully charged. You can then disconnect the charger.
11
Talking time and stand-by time can go up to 6 hours and 560 hours respectively. Depending on the
network conditions, user settings and method of use, the actual results may vary. The only way to turn off
the charger is to unplug it, so it is advisable to use an easily accessible AC power socket. If you do not
intend to use your phone for several days, we recommend that you remove the battery. If the battery is
powerless, the battery icon will reappear after a few minutes of charging.
3.4 Inserting a T-Flash Card
Open the T-Flash cover on the right side of your phone.
With the metal contacts facing to the metal contacts in the slot, gently slide the SD card into the slot and
press it down until the card locks into place. If you want to get the T-Flash card out, gently press the
T-Flash card, then you can remove it from your phone.
3.5 Important Password
Phone lock password is 1122.
3.6 Keypad Lock and Unlock
Go to Settings > Security Setup > Auto Keypad Lock to select the time for keypad lock.
In idle mode, if the time expires, the keypad will be locked automatically.
Press the Right Soft Key [Unlock] and then the # Key to unlock the keypad.
12
4 Text Entry
4.1 Input Method
Your mobile phone supports several input methods, which include:
♦ Zi English (
♦ Multi-Tap (
to enter. Press once to get the first letter on the key, press twice quickly to get the second letter
and so on until the letter you want is displayed on the screen.
♦ Numeric (123): Enter numbers.
During text editing, you can press the # Key to switch input modes or press the Left Soft Key [Option] and
select Input Method to select different input modes; the icon under the title bar will display your current
input mode.
Note: Depending on the user requirements, there may be other language input methods available,
such as Spanish. The input method is similar to English input.
4.2 Entering Symbols
In any input mode, press the * Key to open the symbols input screen. Press the Navigation Key Up or
Down to scroll through the symbols. Press the OK Key to confirm the symbol input.
4.3 Zi English Input
ABC/ abc): Enter English text using Zi editor;
abc/ ABC): Press the keys that are marked with the corresponding letter you wish
13
4.3.1 What is it?
Zi Text Input is an intelligent editing mode for messages, which includes a comprehensive dictionary. It
allows you to quickly enter text. You need to press once on the key corresponding to each letter needed
to spell a word: keystrokes input will be analyzed.
4.3.2 How to use it
Letters and symbols represented by each key are as follows:
2 to 9 To input letters
1 To input symbol
0 To input space
◀/▶
▲/▼ To browse the last or next available word.
Left Soft Key (Select) To confirm the letter or word
Right Soft Key (Clear) Short press to clear a letter, long press to clear all entries
# Switch between input mode
* To activate punctuation mode
Example: How to enter the word "HOME"
1. Press the # Key to switch to
2. Press 4 6 6 3, the first word “GOOD” appears;
3. Press ▼ to browse and select “HOME”;
To confirm the letter or word
ABC;
14
4. Press the Left Soft Key [Select] or ▶ to confirm “HOME”.
4.4 Multi-tap English Input
If you wish to use Multi-tap English input mode, press the # key to select " ABC" or “ abc”. This
method requires multiple key presses to reach the desired character: the letter "h" is the second letter on
the 4 key, so you must press 4 twice to enter "h". Using this mode requires you to press a key as many
times as needed to enter the desired letter.
To enter the word «home» in Multi-tap input mode “
6(MNO), 6 (MNO), 3(DEF), 3 (DEF).
abc”, press key 4(GHI), 4 (GHI), 6(MNO), 6(MNO),
4.5 Numeric Input
Press the # Key to select "123" then you can enter the numbers.
4.6 Other Language Input Method
Depending on the user requirements, there may be other language input methods available, such as
Spanish. The input method is similar to English input.
Zi Spanish (
Multi-Tap Spanish (
to enter. Press once to get the first letter on the key, press twice quickly to get the second letter and so on
until the letter you want is displayed on the screen.
ES/ es ): Enter text using Zi smart editor.
ES/ es): Press the keys that are marked with the corresponding letter you wish
15
5 Calling
5.1 Make a Call
Note: You can make a call only when the network name appears on the screen.
1. Enter the phone number.
2. Press the Pick-Up Key to dial the number.
5.1.1 Mute or unmute a call
During a call, press the Left Soft Key [Options] and select Mute on or off. If you select Mute on, the
microphone will be deactivated. When you switch from one call to another, muting will be cancelled.
5.1.2 Adjusting speaker/earpiece volume
During a call, press the Navigation Key Up/ Down to increase or decrease the volume.
5.1.3 Call recording
During a call, press the Left Soft Key [Option] and select Sound Recorder to record the conversation.
When you end the call, the recording will stop and will automatically be saved in the AMR or WAV format
under File Manager > Audio .You can also press the Right Soft Key [Stop] from the recording menu to
end the recording.
Note: in most countries, recording telephone conversations is subject to legislation. We advise you to
notify the caller if you intend to record your conversation and only do so if they agree.
5.2 Making an International Call
1. Press the * Key twice quickly until "+" appears on the screen.
16
2. Enter the country code.
3. Enter the area code (normally without the 0 before it) followed by the phone number.
4. Press the Pick-Up Key to call directly.
5.3 Making an Emergency Call
You can make an emergency call anytime, regardless of whether the cellular phone has been registered
on the network. In idle mode, enter the emergency call number (specific number in the caller's country)
then press the Pick-Up Key.
If there is no SIM card, pressing the Right Soft Key [SOS] can also bring you to the emergency call
screen displaying the confirmation. Press the Left Soft Key [Yes] to directly make an emergency call.
5.4 Making a Second Call (Network Dependent)
You can make a second call by putting the current call on hold:
1. During a call with the first caller, enter the second caller’s number using the keypad.
2. Press the Pick-Up key to dial the second party’s number. The first caller will be automatically placed on
hold. This is a system-dependent feature, please contact your service provider for more details.
5.5 Making a Conference Call (Network Dependent)
Your phone supports multi-party calls of up to five members.
When there is a call waiting while you are already on the phone, you can carry out the following
operations to establish the multi-party call:
1. Press the Pick Up Key to answer the second call. The first call will be put on hold automatically.
2. Select Conference from Option menu. The two calls will be combined and a conference call is
17
established. During the multi-party call, you can answer a new incoming call or add a new member to the
call by dialing the new member (the ongoing multi-party call will be put on hold automatically).
Once the call is established, select Conference from Option menu to add the new member to the
multi-party call (you can add up to five members).
This is a network-dependent feature, please contact your service provider for more details.
5.6 Switching Calls (Network Dependent)
When you have one active call and one call on hold, you can press the Left Soft Key [Option], and then
select Swap to switch between the 2 calls.
5.7 Calling Hands-Free
During a call, press the Right Soft Key [H-free].
Note: When the headset is plugged into the phone, you cannot activate hands-free mode.
5.8 Answering a Call
Press the Pick-Up Key to answer a call.
5.9 Rejecting a Call
Press the Hang-Up Key to reject a call.
5.10 Answering a Second Call (Network Dependent)
If you have activated Call waiting, a new incoming call screen is shown to inform you when there is a
second incoming call. You can:
1. Press the Pick-Up Key or select Answer from [Option] to answer the second call. The current call will
be put on hold automatically.
18
2. Press the Hang-Up key or the Right Soft Key [Reject] to reject the second call.
5.11 Ending a Call
Press Hang-Up key or select End from Option to end a call.
19
6 Function Menu
6.1 How To Use
6.1.1 Select Menu
Press the Left Soft Key [Menu] to enter main menu in idle mode.
Press the Navigation Key Up/Down to change menus and press the Left Soft Key [Ok] to enter the
selected menu.
Note: The functions described below only appear when a SIM card is inserted. If you power on
your phone without a SIM card, you will have limited access to menu functions when you press the
Left Soft Key [Option]. Press the Right Soft Key [SOS] to make an emergency call. The aim of this
function is to allow you to dial emergency number by keypad when you do not have a SIM card.
You can exit a menu and return to idle mode by pressing the Right Soft Key [Back] or the Hang-Up Key.
6.2 Main Menu
Phone Book Message Center Call History
20
Settings Multimedia File Manager
Fun & Games User Profiles Organizer
Services Extra STK Service
6.3 Phonebook
Your phone features two phonebooks. The SIM phonebook is located on your SIM card and the number
of entries you can store depends on the SIM card. The second phonebook (Smart phonebook) is
integrated in the phone memory and the maximum number of name cards you can store is 500. The
21
entries in the two phonebooks are combined, sorted and displayed as a list. When you add a new contact
to your phonebook, the new contact will only be added to the storage location you have selected.
6.3.1 View
In the phonebook, select a contact and press the Left Soft Key [Options] to access the following
operations:
♦ View: View the details of the selected contact, it will list all the detail content of every field.
♦ Edit: Edit the selected contact.
♦ Delete: Delete the selected contact.
♦ Copy: If it is stored in the phone, choose this option to copy the selected contact to the SIM card;
if it is stored in the SIM card, choose this option to copy it to the phone.
♦ Move: Same as copy, only the original contact will be deleted.
♦ Duplicate: Duplicate the contact in the same memory.
♦ Send vCard: Send the vcard by SMS, MMS, Bluetooth, or save to file.
♦ Print: Print the vcard using a printer which has Bluetooth function.
6.3.2 Quick Search
Enter the first letter of the entry you want to search for in the search bar; press the # Key to switch
between the input methods. The maximum number of the letters is five.
6.3.3 Search Entry
Enter the name of the entry you want to search, press the # Key to switch between the input methods.
After entering a name, press the Left Soft Key [Option] to choose Search, the cellular phone will display
22
the entry after searching.
6.3.4 Add new entry
To create a new SIM/phone contact:
Press the Navigation Key Up/Down to select a field.
♦ Name: Press the Left Soft Key [Edit] to enter the name.
♦ Number: Enter the phone number.
After entering a name and number, press the Right Soft Key [Done] or the Left Soft Key [Ok] to save.
Press the Navigation Key Up/Down to select a field.
♦ Name: Press the Left Soft Key [Edit] to enter the name.
♦ Number: Enter the phone number, press the Right Soft Key [Clear] to erase incorrect numbers.
♦ Home Number: Enter the phone number, press the Right Soft Key [Clear] to erase incorrect
number.
♦ Compan y Name: Press the Left Soft Key [Edit] to enter the name.
♦ Email Address: Enter the Email address.
♦ Office Number: Enter the Office number.
♦ Fax Number: Enter the Fax number.
♦ Birthday: Enter the birthday, press the Navigation Key Left/ Right to move cursor to left or right.
♦ Associate Picture: Press the Navigation Key Left or Right to select a picture and then press the
To SIM
To Phone
23
Left Soft Key [View] to view the selected picture. If select “From File”, you can enter File Manager
to choose a picture for the new entry.
♦ Associate Video: Press the Navigation Key Left or Right to select a video. If select “From File”,
you can enter File Manager to choose a video for the new entry.
♦ Associate Sound: Press the Navigation Key Left or Right to select a sound; the selected sound
will play after a few seconds.
♦ Caller Group: Press the Navigation Key Left or Right to select a group.
After editing, you can press the Right Soft Key [Done] to save.
6.3.5 Copy All
You can copy all contacts from the Phone to the SIM card or from the SIM card to the Phone by selecting
From Phone or From SIM.
6.3.6 Delete
This feature allows you to delete contact(s):
♦ From Phone: Enter the phone unlock password. The default password is 1122.
♦ From SIM: Enter the phone unlock password. The default password is 1122.
♦ One By One: Select which individual contacts to delete.
6.3.7 Caller Group
Five groups are available to edit, you can press the Navigation Key Up/Down to modify following fields:
name, associated sound, associated video, associated picture and member list.
6.3.8 Extra Number
24
This menu allows you to keep a list of useful numbers such as Owner number, Service dial number and
SOS number.
6.3.9 Settings
♦ Memor y Status: Press to view the SIM and phone memory status, which lists the used memory
and total memory of contacts.
♦ Preferred Storage: Press to select the preferred storage: SIM card or phone.
♦ Fields: Press the Left Soft Key [On] or [Off] to activate or deactivate the different fields for the
phone contact, including Home number, Company name, Email address, Office number, Fax
number, Birthday, Associate picture, Associate video, Associate sound and Caller group. If one
field is set off, it will disappear when you view a contact or edit a contact.
♦ Name List Filter: Press to select the phonebook you want to manage, SIM only, phone only or
both. If select “SIM Only”, it will only show the contacts stored in SIM.
♦ My vCard: Select to choose Edit, Send by SMS, MMS, Bluetooth or Save to file.
Note: You can save your vCard to your phone or memory card and then find it in the menu of File
Manager.
♦ vCard Version: Select to view the vCard version, 2.1 or 3.0.
6.3.10 Caller Picture
This menu allows you to associate a picture from File Manager to a new contact or a selected contact.
6.3.11 Caller Ring Tone
This menu allows you to associate a ring tone to a new contact or a selected contact. Press the
25
Navigation Key Up or Down to select a sound, the selected sound will play after a few seconds.
6.3.12 Caller Video
This menu allows you to associate a video from File Manager to a new contact or a selected contact.
6.4 Message Center
The menus described in this section allow you to send/receive messages and manage your message.
Only devices that have compatible features can receive and display multimedia messages. The
appearance of the message may vary depending on the receiving device.
6.4.1 Messages
To write a message, please refer to the Text entry section of this manual for detailed information.
After entering text, you can access the following options by pressing Left Soft Key [Option]:
♦ Done: Press to confirm entered text and select from the following Send Options:
Send Only: Select to open the number editor and enter your number, or press the Left
Soft Key [Search] to search a contact in the phonebook. Press the Left Soft Key [Ok] to
send the message.
Save and Send: Press to save the message to Sent box and send the message.
Save To Drafts: Press to save the message in Draft box.
Send To Many: Press to send the message to more than one recipient. Select Edit List to
add or delete recipient in a list and then select Send Now to send the message to all the
recipients in the list.
Writing an SMS message
26
Send By Group: Press to send the message to the group you selected.
♦ Use Template: Press to select a template and insert it into pre-written message.
♦ Insert Object: Press to select picture, animation or melody and insert in message, “My Picture”,
“My Animation”, “My Melody” are shortcuts to the File Manager menu.
♦ Format Text: Press to adjust text size, style, alignment or select a new paragraph.
♦ Insert PHB Number: Press to select a contact in the phonebook and insert the contact’s number
into the message.
♦ Insert PHB Name: Press to select a contact in the phonebook and insert the contact’s name into
the message.
♦ Insert Bookmark: Press to select a bookmark and insert it to the message.
♦ Input Method: Press to select input method.
1. In idle mode, press the OK Key to enter the main menu.
2. Select Message Center > Messages > Write Message > Multimedia Message. The MMS editing
screen will appear.
3. You can edit To, Cc, Bcc, Subject fields. Press the Navigation Key Up or Down to move to the field,
and then press Left Soft Key [Edit] to edit the field. When moving to “Edit Content” field, you should
press the Left Soft Key [Edit] to enter the MMS content editor.
Note: you can send the MMS to E-mail by entering an E-mail address in the To, Cc, or Bcc field.
4. Enter the MMS content in the MMS content editor then press Left Soft Key [Options] to access the
Writing an MMS message
27
Loading...
