Cellon Communications Technology PCD2005 Users Manual

1.1 Phone Display

1 Introduction

We continuously strive to improve our products. Therefore, we reserve the rights to revise this
user manual or withdraw it at any time without prior notice.

1.2 Key

Key Function

Dial /
Answer Key

End / Power
Key

Left Soft Key In idle mode, press to enter the Messages. Press to access the option listed directly

Right Soft
Key

OK Key In idle mode, press to enter the Main menu

Press to answer a call or dial a call after you enter a phone number. In idle mode, press
to view the call log.

Press to end a call. Press and hold to turn the phone on/off. Within a menu, press to
return to idle mode.

above it on the display.

In idle mode, press to access the WAP. Press to access the option listed directly above it
on the display. Within a menu, press to return to the previous screen.

 2

Numeric key Press to enter the corresponding number, letter or symbol located on the key. Within a

menu, press to access the corresponding menu option.

* Press the * Key twice quickly to enter ‘+’ to make an international call. Press and hold

the * Key to toggle between *, +, (pause character) P, and (wait character) W. Press to
enter symbol when editing text.

# In idle mode, press and hold to activate or deactivate the silent mode.

Press to switch input modes when entering text.

Navigation
Key

Within a menu, press Up, Down, Left or Right to scroll through menu options.

Note: “Press” in this manual, means to press and release the key; “press and hold” means to
press and hold the key for at least 2 seconds.

1.3 Icons & Symbols

Icon Description

 3

Network - The left portion indicates whether your phone is already registered with a
network and the right portion indicates signal strength (from no signal to strongest).

To log on GPRS - The icon will be displayed only when you have logged onto GPRS.

Battery - Indicates battery level. When charging, a scrolling icon will be displayed. The
more bars, the stronger the charge.

MMS - Indicates you have one or more unread MMS messages.

Message - Indicates you have one or more unread messages.

Push message-Indicates that you have received new push message.

Voicemail- Indicates voice messages that have not been heard.

Missed call - Indicates there is a missed call.

Call Divert - Indicates that “Divert All Voice Calls” is activated.

Alarm-Indicates that the alarm clock is on.

Headset-Indicates that headset profile is activated.

Alert type is “Ring”.

 4

2 Getting Started

Please read the safety instructions in the "Safety Information and Notices" section before use.

2.1 Inserting the SIM Card

Remove the back cover(1), remove the battery (2), and insert the SIM card (3)

(1) (2) (3)

Install the battery and back cover

 5

2.2 Turning the phone on

To turn the phone on, press and hold the End / Power key. Enter the PIN code if required.

2.3 Charging the Battery

1. Ensure the battery is inserted in the handset. To charge the battery, plug in the charger connector
at the bottom of your phone (USB interface) and then plug the other end into an AC power socket.

2. The battery symbol indicates the charging status. While charging, the charge indicators will scroll.
When all the scroll bars are steady, the battery is fully charged.

3. Disconnect the charger from the phone.

 6

4. Disconnect the charger from the AC power socket.

Note: If the battery is powerless, the battery icon will reappear after a few minutes of charging.

2.4 Inserting a T-Flash Card

1. Lift up the T-Flash card cover on the right side of the SIM card slot. Pull the cover down if it is
locked and then lift. A word “OPEN” will prompt you in the correct direction.

2. With the metal contacts facing down, gently slide the T-Flash card into the slot.

3. Press and pull the cover up to lock it. A word “Lock” will prompt you in the correct direction.

2.5 Important Password

Phone lock password is 1122.

 7

 8

3 Text Entry

3.1 Input Method

During text editing, you can press the # Key to switch input modes or press the Left Soft Key [Option] and

select Input Method to select different input modes.

3.1.1 Entering Symbols

In any input mode, press the * Key to open the symbols input screen.

3.2 Smart Input Method

2 to 9 Press to input letters

1 Press to input symbol

0 Press to input space

◀/▶

▲/▼ Press to browse the last or next available word.

Left Soft Key (Select) or
the OK Key

Right Soft Key (Clear) Press to clear a letter, press and hold to clear all entries

Press to confirm the letter or word, or move the cursor to left or right.

Press to confirm the letter or word

 9

# Switch between input mode

* Press to activate punctuation mode

Example: How to enter the word "HOME"

1. Press the # Key to switch to

2. Press 4 6 6 3, the first word “GOOD” appears;

3. Press ▶ to browse and select “HOME”;

4. Press the Left Soft Key [Select] or OK Key to confirm “HOME”.

ABC;

3.3 Multi-tap Input

Using this mode requires you to press a key as many times as needed to enter the desired letter.
To enter the word “casa” in Multi-tap input mode “

(ABC) once, press key 7 (PQRS) four times, press key 2 (ABC) once.

abc”, press key 2 (ABC) three times, press key 2

3.4 Numeric Input

Press the # Key to select " 123" then you can enter the numbers.

 10

4 Calling

4.1 Making a Call

Note: You can make a call only when the network name appears on the screen.

1. In idle mode,enter the phone number.

2. Press the Dial / Answer Key to dial the number.

3. Press the End / Power Key to end the call.

Note: During a call, press the Navigation Key Up/Down to adjust the volume.

You can press the Left Soft Key [Option] to choose Sound Recorder.

Note: in most countries, recording telephone conversations is subject to legislation. We advise you to
notify the caller if you intend to record your conversation and only do so if they agree.

4.2 Making an International Call

1. Press the * Key twice quickly until "+" appears on the screen.

2. Enter the country code.

3. Enter the area code (normally without the 0 before it) followed by the phone number.

4. Press the Dial / Answer Key to call directly.

 11

4.3 Answering or Rejecting a incoming Call

1. Press the Dial / Answer Key to answer a call.

2. Press the End / Power key to reject a call.

 12

5.1 Main Menu

Call center STK Service Fun & Games

Multimedia Phonebook Messages

Organizer Services Settings

5.2 Call Center

5.2.1 View Call History

5 Function Menu

1. Select Menu > Call center > Call history.

2. Press the Navigation Key to view different call logs.

3. Choose a particular number and press the Dial Key to call the number directly.

 13

5.2.2 Adjust Call Settings

1. Select Menu > Call center > Call settings.

2. Now you can set the call waiting, call divert, and so on.

5.3 STK Service

Note: The submenus of this feature depends on the operator and different operators may
provide different services (some SIM cards do not support STK), which cannot be modified.

Please contact your operator.

5.4 Fun & Games

Your cellular phone provides you with several games.

You can also adjust the game settings when you enter the game menu.

5.5 Multimedia

 14
