Cello C19100DVB User Manual

LED digital colour TV

C19100DVB

USER GUIDE

Introduction

Thank you for purchasing this TV which has been designed and manufactured to
give you many years of trouble free service.

You may already be familiar with using a similar product but please take time to read
these instructions which have been written to ensure you get the very best from your
purchase.

HDMI

HDMI (High Definition Multimedia Interface) is the next generation of digital interface.
Unlike conventional connections, it transmits uncompressed digital and audio signals
using a single cable. This TV supports high-definition video input via the HDMI
socket on the back of the TV.

Safety is important

To ensure your safety and the safety of others, please read the safety precautions
BEFORE you operate this product.

Contents

You will find the following

•TV

•UserGuide

• Quick Start Guide

• Remote Control

• 2 x AA Batteries

NOTE: If any of the items listed are damaged or missing please contact our

technical helpline on 0871 288 7345

1

Contents

1
2

3-5

8-11
12

13-17
18

19
19
20-27

28-30
31-33
34

35

36

37

Introduction
Contents

Safety Information

Unit and Accessories6-7

Remote Control
Aerial connection

Connecting external devices
Common Interface slot
Auto installation setup
Source menu
Menu settings

Multimedia Operation
Recording Operation
EPG menu

SimpleTroubleshooting

Technical Specifications

Wall Mounting

2

SAFETY INFORMATION

IMPORTANT SAFETY INSTRUCTIONS - READ CAREFULLY BEFORE USE.

Take note of the following safety information which appears on the back of the TV.

CAUTION TO PREVENT ELECTRICAL SHOCK, DO NOT REMOVE ANY
COVER SCREWS, NO USER SERVICEABLE PARTS INSIDE, REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol indicates that there are important operating maintenance instructions in
the literature accompanying this unit.

This symbol indicates that dangerous voltage constituting a risk of electric shock is

present within this unit.

Keep these instructions

• Do not use this TV near water.

• Clean only with a slightly damp cloth.

• Do not block any ventilation openings.

• Install in accordance with the supplied Quick Start Guide and this User Guide.

• Protect the power chord from being walked on or pinched, particularly at plugs, and the
point where it exits from the TV.

• Do not allow the power chord to overhang the edge of a table.

• Unplug this TV during lightening storms or when unused for long periods of time.

WARNING! TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT
EXPOSE THIS TV TO RAIN OR MOISTURE. THE TV MUST NOT BE EXPOSED
TO DRIPPING AND SPLASHING AND NO OBJECTS FILLED WITH LIQUIDS
SHOULD BE PLACED ON THE TV.

NOTE: No naked flames such as candles should be placed on the TV.

3

IMPORTANT SAFETY INFORMATION (Continued)

This unit has been produced according to all current safety regulations. The following safety
tips should safeguard users against careless use and the dangers connected with such use.

Although this appliance has been carefully manufactured and rigorously checked

prior leaving the factory, as with all electrical appliances it is possible for problems to
develop. If you notice smoke, an excessive build up of heat or any other unexpected
phenomena, you should disconnect the plug from the mains power socket
immediately.

Ensure that the unit is sufficiently ventilated! Never place next to or underneath

curtains!
The mains plug or appliance coupler is used as the disconnect device, the disconnect
device shall remain readily operarble.

This set should only be connected to a mains power supply which matches that

stated on the label on the rear of the TV – do not attempt to connect it to any other

type of supply.
The socket – outlet must be installed near the equipment and easily accessible.
To prevent overload, don’t share the same mains supply socket with too many other

items of equipment.
Apparatus with Class 1 construction shall be connected to a mains socket outlet with

a protective earthing connection.

Keep away from rodents. Rodents enjoy biting into electric flexes.
Always hold the plug when pulling out the plug from the mains supply socket. Do not

pull on the flex, the flex can become overloaded and cause a short circuit.

Set up the unit so that no one is able to trip over the flex.
Do not place heavy items on the flex, which may damage it.
Take note that the flex cannot be reached and pulled by young children, avoiding

injury.

Do not set up the unit near to heat sources. The casing and the flex could be

damaged by the impact of heat.

The screen is made of plastic and can break if damage is done to it. Be careful when

collecting sharp edged plastic splinters to avoid injury.

Avoid placing the unit on any surfaces that may be subject to vibrations or shocks.
To protect the unit during a thunderstorm unplug the AC power cable and disconnect

the aerial. Caution: Do not touch the aerial (RF) connector.

When you leave your home for long periods of time, unplug the AC power cable for

safety reasons.

The unit becomes warm when in operation. Do not place any covers or blankets on

the unit in order to prevent overheating. The ventilation holes are not to be blocked.
Do not set up near radiators. Do not place in direct sunshine. When placing on a
shelf leave 5 cm (2”) free space around the whole unit.

Do not allow water or moisture to enter the TV. Do NOT use in wet or moist areas

such as Bathrooms, steamy kitchens or near swimming pools.

Do not use this unit when moisture condensation may occur

Any repairs must be carried out by qualified personnel only.
Do not open this unit. A non – expert attempting to repair the unit could be dangerous

and potentially cause a fire hazard.

4

IMPORTANT SAFETY INFORMATION (continued)

Liquids spilt into the unit can cause serious damage. Switch the set OFF and

disconnect the mains power supply, then consult a qualified service person before

attempting to use the unit again.
Do NOT remove the safety covers. There are no useable or serviceable parts inside.

Youmayinvalidatethewarranty.Qualifiedpersonnelmustonlyservicethis

apperatus.
Do NOT tap or shake the screen, you may damage the internal circuits. Take good

care of the remote control, do not drop.
Never place hot objects or open flame sources on or close to the TV.
High temperatures can melt plastic and lead to fires.

To clean the TV use a soft dry cloth. Do NOT use solvents or petrol based fluids. For

stubborn stains, you may use a damp cloth with dilute detergent.

Headphone Warning

Loud music can damage your hearing irreversibly, therefore do not set the volume to a high
level when listening through headphones, particularly for lengthy listening periods.

Where to install

Locate the television away from direct sunlight and strong lights, soft indirect lighting is
recommended for comfortable viewing. Use curtains or blinds to prevent direct sunlight
falling on the screen. Place the TV on a sturdy platform of which the surface should be flat
and steady. This will prevent it from falling over.
Make sure the television is located in a position where it cannot be pushed or hit by objects,
as pressure will break or damage the screen, and so that small objects cannot be inserted
into the ventilation slots or openings in the cabinet.

LED Screen

The LED display panels are manufactured using an extremely high level of precision
technology, however sometimes some parts of the screen may be missing picture elements
or have luminous spots. This is not a sign of malfunction.

5

Unit and Accessories

LED Indicator

Remote Control
Window(keep clear)

The functions of the TV buttons are described below.

MENU

VOL
CH

TV/AV

Power

Press to skip through the channels.

Press to display the input source menu.

6

Unit and Accessories (continued)

TV set Remote Control

Power cable

Converter cable

for YPBPR video

Batteries

Mains adaptor

Remote Guide

Remote Guide

QUICK START
GUIDE

Warranty Card

7

USER GUIDE

User GuideQuick Start Guide Warranty Card

Remote control

Functions of remote control buttons

Dependant on the model of theTV some keys will have no function

Only used on TVs with Internet Player*.
In this mode the remote does not control

iViewer

the TV.
Press

If you have set the remote to work a
Satellite receiver, the remote controls only
the Satellite receiver and not the TV when
you press

Press to control the TV again.

to control the TV again.

HOLD TEXT

Used on TVs with DVD* or PVR

Used on TVs with PVR or Internet Player*

Used on TVs with PVR or Internet Player*

*Dependant on Model

8

Remote control (continued)

Dependant on the Model of the TV some keys will have no function

Source Menu
TV (Analogue)
DTV ( Freeview )

Menu


Sound

Setting

Language
Reset

*

Function

DVD setup
FTI

Channel

Favourite list
USB

Guide(DTV)

Press to enter, press again to exit.

Stop

For DVD , iPlayer*

Reverse - DVD &SD1*, SD2*, PVR

Picture Mode

Displays picture and aspect function

Pause/Play

DVD , iPlayer*, SD1* und SD2*

PVR and Time shift

Display the Playback list on
(red card)
Display the Recorded list

Display the Playback list on SD2*
(green card)

*

Back

Exit from any Menu

*

*

*

SD1 (red card)*
SD2 (green card)*
AV
Scart 1
Scart 2
S-Video*
HDMI 1
HDMI 2*
YprPb
DVD
Iplayer *
VGA

, PVR, SD1*and SD2*.

SD1*

*Dependant on Model

Help

*

*

iViewer

This displays a page that gives telephone
numbers for service.
Press to enter, press again to exit.

Quick Start

Searches all ATV and DTV channels by a
single key (can take up to 10 Mins).

Info-Taste

In DTV mode shows Now / Next.

2nd Press

Extended programme Info.

Whilst Recording*

Shows details of the recording and space
available on the card.

DVD Eject

Fast forward - DVD &SD1*

Sound - changes the sound

Next - DVD , iPlayer*, PVR

Previous- DVD , iPlayer*, PVR

Soft Keys

The action they perform is shown on the
menu and changes for each menu .

*

DVD Disc Menu

*

*

, SD2*, PVR

*

*

Subtitles

*

DVD and DTV mode only.

A

Displays the red recording list.
(The programmes you have booked to be
recorded).

Displays the timer schedule list.

HOLD TEXT

9

Teletext / MHEG5

(You can not record this)

B*

Displays the green recording list.
(The programmes you have booked to be
recorded).

Remote control (continued)

Dependant on the model of TV some keys will have no function

*Dependant on Model

iViewer

HOLD TEXT

DVD

10

Remote control (continued)

Installing Batteries in the Remote Control

1. Remove the battery compartment cover at the rear of the remote
control by pushing the retaining clip forward and pulling up.

2. Install the supplied batteries, ensuring the polarity matches what
is shown in the battery compartment.

3. Replace the battery compartment cover.

Using the Remote Control

S

To use the remote control point it at the TV and press the required buttons. You must
be within 6 meters and at an angle of less than 30 degrees from the center of the TV.

NOTE: Sunshine or other strong light sources may interfere with the signal from the
remote control. In this situation turn the TV away from the light source.

WARNING! DO NOT LEAVE BATTERIES IN THE REMOTE CONTROL FOR
EXTENDED PERIODS AS THEY CAN LEAK OR CORRODE CAUSING DAMAGE
TO THE REMOTE CONTROL. CHECK THEM PERIODICALLY AND REPLACE
THEM AS REQUIRED.

WARNING! DO NOT MIX BATTERY TYPES. WHEN INSERTING BATTERIES,
REPLACE ALL BATTERIES AT THE SAME TIME. DO NOT MIX OLD AND NEW
BATTERIES.

WARNING! EXHAUSTED BATTERIES MUST BE TREATED WITH CARE AND
DISPOSED OF ACCORDING TO ANY SAFETY OR RECYCLING REGULATIONS
IN FORCE IN YOUR LOCAL AREA, NEVER DISPOSE OF BATTERIES INTO
GENERAL WASTE, OR FIRE.

WARNING! NEVER EXPOSE BATTERIES TO EXCESSIVE HEAT SUCH AS
SUNSHINE, FIRE OR THE LIKE.

11

Aerial connection

WARNING! ENSURE THE TV AND ALL ANCILLARY EQUIPMENT IS
UNPLUGGED FROM THE MAINS BEFORE MAKING ANY CONNECTIONS!

Connecting the TV Antenna

Connect the TV$ ntenna to the aerial socket with a 75 ohm co-axial plug. For best
results use a high gain TV aerial, preferably roof or loft mounted.

• To improve picture quality in a poor signal area, purchase
and install a signal amplifier.

• If the antenna needs to be split for two TVs, use a 2-Way
Signal Splitter (not supplied).

Headphone out

Coax

YPbPr Video L-in R-in RF

Connecting external devices

This instruction manual shows the simplest and most effective way of
connecting your TV to ancillary equipment. Alternate methods are listed below.

HDMI Lead

You can connect this TV to a compatible device using a HDMI lead. This method will
give the best picture.

Connect the cable from the HDMI equipment to the TV HDMI socket.

SCART Lead

You can connect this TV to a compatible device using a SCART lead. The
connection uses component video signals,
content of the video are sent on separate signals.

VGA Cable

You can use your TV as a monitor for your personal computer by using a VGA cable.
Sound from your personal computer may also be played through the TV.

i.e. the red, green and blue (RGB)

12

Connecting external devices (continued)

POWER USB HDMI2 HDMI1 SCART PC-IN VGA

Common Interface

TV Signal

YPbPr Video L-in R-in RF

Headphone out

Coax

USB device

Satellite Box
or Blue Ray DVD

Output to

Audio amplifier

13

Connecting external devices (continued)

CONNECTIONS

Name Function Description

POWER Connect to power supply

Connect to USB device for multimediaUSB

HDMI1/2 Connect to the HDMI socket of your DVD or Satellite Box

Connect to the scart input / output of external devicesSCART

PC audio in PC audio input

VGA Connect to the PC VGA output to display PC graphics

COAX

Headphone

YPbPr Connect to the YPbPr output on external devices

RF

CI

Output to audio amplifier
Connect Headphone

Connect to the video output of external devices Video

Connect to antenna or cable source

CI slot (pay as you view card slot)

Caution:

Before connecting external devices:

Make sure to disconnect the appliances from the power supply in order to avoid any
potential damage from occurring.
Make sure to establish the required connection.
Make sure that the connectors are properly and correctly attached before connecting
the appliances to the power supply.

14

Connecting external devices (continued)

PC connection

As PCs are sometimes still supplied with a ‘conventional’ CRT monitor, you may need to
adjust the display settings of your PCs graphics card, otherwise the pictures may not appear
correctly. Switch on your PC (still with your original monitor connected) no w select
the screen resolution, and select 60Hz refresh rate. Switch off your PC, then connect it to
your TV while both appliances are still switched off.

VGA, HDMI PC Connection

Use a PC-VGA cable (not supplied) to connect the TV to your PC. You can also use an
HDMI cable to connect to your PC (if your PC Graphic card supports HDMI). When the HDMI
cable is used, the PC audio cable is no longer required. If you use the HDMI to DVI cable,
you will need to use the PC audio cable. Connect all cables carefully and do not bend or
break the connector pins.

When using the VGA cable

Switch on the TV
SwitchonthePC
Select PC/VGA as input source

When using the HDMI cable

Select HDMI as input source

( All illustrated cables are not supplied)

VGA cable

HDMI to DVI cable

Audio cable

HDMI to HDMI

15

Connecting external devices (continued)

Connecting Video camera and Video recorder

Video camera

Connect the AV cable to the TV and to the video camera.
Turn on both video camera and the TV.
Select AV/CVBS source
You can now see the playback picture from the video camera.

Note:

To connect the video camera using other cables, refer to the video camera
instruction manual.

Video recorder

Co

nnect the Scart cable to the TV and video recorder.
Turn on both video recorder and the TV.
Select Scart source
You can now see the playback picture from the video recorder.

Note:

To connect the video recorder using other cables, refer to the video recorder
instruction manual.

Video recorder

Scart cable

Video camera

AV cable

All illustrated cables are not supplied

16

Connecting external devices (continued)

Connecting an audio system

You can supply the TV sound to the stereo system (A) with the Scart socket. Use a special
scart cable SCART to RCA. (Please consult your hi-fi instructions for details). If you have a
surround sound amplifier/decoder (B) Use the Scart cable or the special scart cable Scart to
RCA.

(

A)

(B)

Scart to RCA cable

All illustrated cables are not supplied)

Scart cable

Connecting a DVD player

Connect a DVD player using either a SCART cable or the HDMI cable.
(only if your external equipment supports HDMI).

HDMI to HDMI

When using the SCART cable

Switch on the TV
Switch on the DVD player
Select SCART as input source

SCART

(All illustrated cables are not supplied)

17

When using the HDMI cable

Select HDMI as input source

USER GUIDE

Common Interface Slot

USING YOUR COMMON INTERFACE SLOT

Common Interface

The Common Interface (CI) slot is designed to accept the Conditional Access
Module (CAM) and Smart Card in order to view the pay TV programmes and
additional services. Contact your Pay Per View TV service provider to get more
information about the modules and subscriptions.

NOTE: Conditional Access Module and Smart Cards are sold separately.

WARNING! SWITCH OFF YOUR TV BEFORE ANY MODULE IS INSERTED INTO THE

COMMON INTERFACE SLOT, THEN ADD THE SMART CARD TO THE CAM.

1. Turn on the TV and ensure ‘DTV’ Source is selected.

2. If the CAM is detected the TV will display the following message on the
screen. "Common Interface Module inserted" wait for a few moments
until the card is activated.

3. Select the relevant digital Pay Per View channel.

4. Detailed information on the Smart Card in use is displayed

5. Press the Ok button to access the card menu. Refer to the Module
Instruction Manual for setting details.

6. When the module is removed, the following message will appear on the
screen. "Common Interface module removed".

18

Auto installation setup

Power On / Off the TV

Press the power button on the LED TV or the button on the remote control, the standby
indicator will light green.
To turn off the LED TV
Press the power button on the LED TV or the button on the remote control, the standby
indicator will light red.

When you initially turn on the TV you will see the first time installation menu as below:

Ensure that the aerial is plugged into the TV,
Make sure your Remote is in TV mode (by
pressing button), switch on the TV by
pressing . You will see the first time
installation menu.

Press the button on the remote control to
start the tuning procedure. This process will
find all available ATV and DTV channels and
store them.

TV

By pressing the Quick Start button the first
time installation can be recalled at any time.

Source Menu

You can select the input source menu by pressing the Source button on the remote control or
the TV / AV button on the TV.

Source

DTV

ATV

SCART

YPBPR

PC

HDMI1

HDMI2

AV

USB

OK

19

Bas c Use

Menu Settings

1. Turn the TV on.

2. Press the MENU button on the Remote Control.

3. Use the and buttons to navigate through the menu.

4. Press the EXIT button to exit the Menu.

TV SETTINGS MENU

Allows you to search channels and set up a variety of channel options.
(Select DTV source for example)

(Select DTV source for example)

Allows you to customize the sound options and effects.
(Select DTV source for example)

OPTIONS MENU:

Allows you to setup a variety of setup options.

(Select DTV source for example)

EXTRAS MENU:

Allows you to setup a variety of time options.
(Select DTV source for example)

LOCK MENU:

Allows you to set up a variety of lock and setup options.

(Select DTV source for example)

Restore Setting

20

Menu Settings (continued)

1. TV SETTINGS menu

Application

Description

Auto Scan

Press the OK button to enter the menu, and select
the Country and Tuning mode for the TV, then
press OK button to start the auto tuning.

DTV Manual Tuning

Press the OK button to enter the DTV Manual Tuning menu,
select a DTV channel, press the OK button to start searching.

ATV Manual Tuning
Press the OK button to enter the ATV Manual Tuning menu.

Storage To: Select a position for storing the programme.
System: Select a TV system for searching.
Current CH: Select the channel you want to manually tune.

Search: Press / buttons to manually search.

Fine Tune: Press / buttons to fine-tune.
Frequency: Displays the current frequency.

Note: Press the RED button to save your settings

21

Menu Settings (continued)

Programme Edit
Press the OK button to enter the Programme Edit menu as below.

Delete: Select a channel and press the RED button to delete it.
Move: Select an ATV channel, and press the YELLOW button, then youuse and

buttons to change the position of the programme, press YELLOW again to confirm the
change. Press menu to exit and your new changes will be saved.
Skip: Select a channel and press the BLUE button, this will label the channelAs long as the
channel has a skip label it will be skipped when searching through the channels with
the CH+/- buttons.
Rename: Select an ATV channel and press the or button to change the name of the
channel by using the buttons.

Signal Information

Displays the digital

CI Information

Please contact your “pay perview” provider who can supply a viewing card and cam unit with
instructions for their use.

TV-signal information (DTV mode only).

22

Menu Settings (continued)

2. PICTURE menu

Description

Picture Mode: Choose from Standard, Dynamic, User and Mild.

Note: Contrast, Brightness, Colour and sharpness are only available and can be adjusted in

the User mode option in the Picture Mode Settings.

Contrast: Controls the difference between the brightest and darkest regions of the picture.

Brightness: Controls the overall brightness of the picture.

Colour: Control the colour.

Sharpness: Increase this setting to see crisp edges in the picture; decrease it for soft edges.

Tint: Controls the tint ( NTSC mode only).

Color Temperature: Choose from Medium, Cool, User and Warm.

Red: Controls the red colour of the picture.

Green: Controls the green colour of the picture.

Blue: Controls the blue colour of the picture.

Aspect Ratio: Choose from Auto, 4:3, 16:9, Zoom1, Zoom2, Just Scan and Panorama.

Noise Reduction: Choose interference noise modes from Off, Low, Middle, High and Default.

23

Menu Settings (continued)

3. SOUND menu

Application

Description

Sound Mode: Allows you to select among: Standard, Music, Movie, Sports and User.

Treble(Can be adjusted when the sound mode is set to User): Controls the relative intensity of

higher pitched sounds.

Bass (Can be adjusted when the sound mode is set to User): Controls the relative intensity of

lower pitched sounds.

Balance: To adjust the balance of the left and right speakers audio output, or turn off the volume of the

left or right speaker.

Auto Volume: This feature automatically adjusts the audio level when the TV is turned on.

This function is activated by selecting “On”.

Surround Sound: Turn on/off the surround sound function by selecting “off” or “surround”.

24

Menu Settings (continued)

4. EXTRAS menu

Description

Sleep Timer: Allows you to setup the sleep timer: 10min, 20min, 30min, 60min, 90min,

120min,180min, 240min and off.

PC Setup (PC mode only) : Press the OK button to enter the submenu to adjust the

Horizontal / Vertical position or Size and Phase of the picture.

Note: The options Schedule List, Recorded List, Timer Record and PVR File System are

described on pages 29 -31.

25

Menu Settings (continued)

5. OPTIONS menu

Restore Setting

Description

OSD Language: Allows you to select the on screen display menu language.

Audio Language (can only be selected in DTV mode): Select the audio language.

Subtitle Language(can only be selected in DTV mode): Select the subtitle language.

Menu Time Out: Allows you to setup the length of time that the on screen display is

visible: 5s, 10s, 15s, 20s, 25s, 30s, 35s, 40s.

Country: This is defaulted to UK, but can be changed by using the Auto tune function.

Restore Setting: Press the OK button to restore the factory default settings.

26

Menu Settings (continued)

6. LOCK menu

Description

Lock System: Turn on/off the Lock System function.

Note: Enter your password to operate this menu.(the default password is 0000)

Set Password: If the Password has been changed you must enter the current

password.

New Enter the new password.

Confirm: Enter the new password.

Lock Channel: You must enter the password to view channels that have been locked. Use
and buttons to select the channel and press the GREEN button on the remote control to
lock the channel.

Parental Guidance: Control your childs viewing using the Parental Guidance mode.

27

Multimedia Operation

Basic Operation

1). Press the SOURCE button on the remote control to display the input source menu, select the
USB source with the buttons and press the OK button to enter the Multimedia menubelow.

DTV

ATV

SCART

YPBPR

PC

HDMI1

HDMI2

AV

USB

Select

2). Insert the USB device, Whe name of the device will be displayed on the screen.

MAINS MENU
PHOTO MUSIC MOVIE TEXT

Disk C:)

USB device list

MAINS MENU
PHOTO MUSIC MOVIE TEXT

Select

Navigation options

Information of the USB device

3). Press / button to select the files on the USB device (PHOTO, MUSIC, MOVIE, TEXT) to view
or play.

Return to

Preview

main menu

Up Folder

File Information

Press / / / buttons to select and the OK button to activate the file or open folder. Press
button to play the files in full screen mode. When in full screen mode press the OK button to
show the navigation option menu on the bottom of the screen or press stop button to return to files.

28

Multimedia Operation (continued)

1. Photo

Photo viewing

Press / buttons to select the option on the menu, and press the OK button to activate.

Repeat: Select the repeat mode from Repeat All, Repeat 1, Repeat None.
Music: Play/Pause the background music of your choice.
Playlist: Display the playlist on the screen and select the photo of your choice.
Info: Display the information of the file.
Rotate: Rotate the photo clockwise/counterclockwise.
Zoom In/Out: Zoom In/Out of your photos.
Move View: Move the photo in Zoom out mode.

2. Music

Listen to music

Press / buttons to select the option on the menu, and press the OK button to activate.
Press / buttons to select the music, and press the OK button to play.

Repeat: Select the repeat mode from Repeat All, Repeat 1, Repeat None.
Search: Program the music to play from the time you set.

Press the OK button to display the time table, and select the position with the buttons,
set the time using the numeral buttons on the remote, select “OK” and press the OK button to search.
Screen Saver: Press the BLUE button to enter the Screen Saver mode, press again to exit.

29

Multimedia Operation (continued)

3. Movie

Watch a film

Press / buttons to select the option on the menu, and press OK button to activate.

Repeat: Select the repeat mode from Repeat All, Repeat 1, Repeat None.
Set A-B: Select and play the preferable part of the file by setting A and B at the beginning and end.
Press OK button to cancel.
Playlist: Display the playlist on the screen.
Info: Display the information of the movie file.
Slow: Play the movies at slow speed, press button to cancel and resume at normal speed.
Step: Step quickly through the movie by using this option
Search: Program the movie form the time you set.
Zoom In/Out : Zoom In/Out of the movie screen.
Aspect Ratio: Select the aspect ratio of the on screen display.
Move View: View the film in Zoom out mode.

4. Text

View text files

Press / buttons to select the option on the menu, and press the OK button to activate.

Prev/Next page: Turn to previous/next page of the text.
Prev./Next: Turn to previous/next file.
Stop: Stop auto turning pages.
Music: Play/pause the background music of your choice.
Playlist: Display the playlist on the screen.
Info: Display the information of the text file.

30

Recording Operation

PVR settings

Press the MENU button, and select EXTRAS menu.

1). Schedule List

Display the recorder schedule list.

2). Recorded List

INFO: Display the information of the programmes you have recorded.
RED button: Delete the recording you select.

31

Recording Operation (continued)

3). Timer Record

Set the timer record

The TV will record the programme automatically according
to your settings.

TITLE: Select the channel you want to record.
MODE: Select the record mode.
Start Time: Select the start recording time.
End Time: Select the end recording time.

Press the OK button to save the setting and exit the menu

there will be a hint on the screen.

4). PVR File System

Setup the PVR File system before you start recording.

Select Disk: Select the device for the Recorded files.
Check PVR File System
USB Disc: Displays the USB state.
Format: Format the USB device
Time Shift Size: Displays the size of the USB device
Speed: Displays the speed of the USB device

32

Recording Operation (continued)

5) Start Recording

Record and Time shift function buttons

Recording: Press to start recording.
PAUSE: Press to enter the timeshift mode, press again to play the recording.
Stop: Press to stop recording or timeshift.

B: Displays the list of programmes scheduled for recording.
A:

Displays

1) Recording menu

When you press REC button, the screen will display the recording menu as below:

the list of programmes already recorded on the USB

Simple mode

device

.

Full mode

Note: a. display and exit full mode by pressing the REC or Exit buttons.
b. Press the STOP button to stop the recording and exit the recording mode.
c. Press the PLAY button to play the programme you are recording from the beginning.

2) Timeshift menu

Press PAUSE button to enter the Timeshift mode, and the picture will be paused, the
recording will begin.

Note: a. Display and exit the navigation menu by pressing the Exit button.
b. Press the STOP button to exit the Timeshift mode.
c. Press PLAY button to play the programme you are recording from the beginning.

33

EPG menu

Display the programme guide by pressing the GUIDE button.
Press the BLUE button to highlight the top of the table in yellow, press the / to select
CHANNEL or TIME.

LENNAHCybtsilemmargorPEMITybtsilemmargorP

Press / button to highlight the date, now
press the / buttons to select the date
you want to view (7 day EPG)

You can select a programme for recording using the / buttons.

Record: Press R button to display the Recorded Mode menu, and set the timer record. When
the programme starts it will be recorded to the USB device.

Remind: Press the GREEN button to display the remind menu, and set the time. When the
programme starts the TV will automatically switch to this programme.

Schedule: Press the YELLOW button to display the schedule list.

To Top: Press the BLUE button to return to and highlight the top of the table.

Press the / buttons to highlight the channel
option, press / buttons to select the channel
you want to view.

34

USER GUIDE

Simple Troubleshooting

If the TV display or performance fails check the TV in accordance with the following instructions. If the
TV still fails to function correctly contact your dealer for assistance.

SYMPTOM REMEDY

GENERAL

Dead. No LED Lit No power to the TV.

Dead Led lit red Set still in standby.

No signal.

Blue screen.

Noisy, snowy,

ghosting picture

No sound

Remote control does
not work

(TV)

Incorrect source
selected.

Poor aerial signal.

Sound "Mute".

Volume set too low.

External leads not
connected "if used".

Remote are not in the
correct status

Check all connections to the TV.

Press either the Power button or on the Remote
control.

Press Source button to select correct source.

If using an indoor aerial, try moving the

aerial. Check aerial connections.

Turn sound "Mute" OFF.

Check volume settings.

Check all external leads are connected.

Ensure remote is in
TV mode by pressing
TV button.

If none of the suggestions seem to work, try switching your TV off and then on again. If this

does not work contact our technical helpline

0871 288 7345.

NOTE: The TV must only be repaired by a qualified registered service person. Never

attempt to remove the back cover as the TV has dangerous voltages inside that may cause

fatality or fire.

35

TECHNICAL SPECIFICATIONS

Specifications of the TV that you have just purchased may vary from the information in this

table due to technical innovations.

TV Specifications

TV System PAL / BG / DK / I

Audio System BG / DK / I

Screensize 19”(Diagonal)

Resolution 1366 x 768Pixels(RGB)

Aerial input 75 (unbalanced)

Audio output power 2 x 3W

Power requirements

Power consumption < 60W

Standby power consumption <1W

Weight 2.75 kg

12V 5A

Remotecontrol specifications

Type Infrared
Control distance 5m
Controlangle 30 degrees(Horizontal)
Batteries 2 x 1.5V,SizeAA
Dimensions 60 x204 x32mm
Weight 140g(without batteries)

36

Wall Mounting

1. The stand must first be removed. Place the TV face down.

2. Remove the two screws on the back of the TV to release the stand.

3. Remove and store the stand and screws.

4. Use four machine screws to mount the TV on the bracket.

This unit is VESA-Compliant and designed to be wall mounted with a VESA­Compliant 100 mm x 100 mm mounting kit. Mount this unit according to the
instructions of the wall bracket (not supplied)

100mm

100mm

4 Mounting holes

Screw size MB4 x 10

37
