User Manual
Technical Support :
Tel:
+86 755 2724 7963
Fax:
+86 755 2724 7835
E-mail:
service@ce-link.com
Address:
CE-LINK ELECTRONICS TECHNOLOGY
Room 1008, XingHe Tower
ShaJing Town, ShenZhen City
CHINA
HDMI EXTENDER BY CAT-5e/6 HCL0101
WWW.CE-LINK.COM
１
Table Of Contents
1.0 Introduction………………………………..…………...……....2
2.0 Specifications……………………………….…………….……4
3.0 Package Contents………………………………………….…..5
4.0 Panel Descriptions…………………………………….…….…5
5.0 Connect and Operate...........................................................6
6.0 Troubleshooting……………………………………….…….…7
7.0 Limited Warranty…………………………………………….....7
HDMI EXTENDER BY CAT-5e/6 HCL0101
WWW.CE-LINK.COM
２
HDMI EXTENDER (By CAT-5e/6 cable)
Model No. HCL0101
Dear customer
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or adjusting
this product. Please keep this manual for future reference.
1.0 INTRODUCTION
CE-Link’s HCL0101 HDMI Extender by CAT-5e/6 uses two pieces of CAT-5e/6
cables to extend the HDTV display up to 30 merters for 1080p using Cat6 cable.
It not only breaks the limitation of the HDMI cable transmission length，but also
CAT-5e/6 has more flexibility and convenience in cable construction.
It is equipped with HDMI (high definition multimedia interface) connectors and is
capable of supporting DVI (digital visual interface) equipment when used with an
HDMI to DVI Adapter, providing greater flexibility and options when integrating
several home theater components.
HCL0101 offers solutions for residential consumers: HDTV retail and show site,
HDTV, STB, DVD and Projector factories, noise, space and security concerns,
data center control, information distribution, conference room presentation, school
and corporate training environments.
1.1 BENEFITS
1) The length of HDMI cable is fixed and unchangeable after it is produced.
Because the HDMI connector can only be soldered or terminated by the
professional workers in factory, the users can not reduce or increase by
themselves. However CAT-5e/6 cables are available everywhere and be
processed easily by the user or installer.
2) Because the header of the long HDMI cable is big, using it must in hidden
method. What's more, it is not easy to bend the HDMI cable and to pull it
through the in-wall tube or tray. However, CAT-5e/6 cable has no such
problems.
3) Using HCL0101, the transmission distance can be up to 60 meters for 480p
while using CAT-5e/6 cable. For the general HDMI cables, they must be
customized when the length is over 10 meters.
HDMI EXTENDER BY CAT-5e/6 HCL0101
WWW.CE-LINK.COM
３
1.2 LIABILITY STATEMENT
Every effort has been made to ensure that this product is free of defects. China
Electronics Technology Limited cannot be held liable for the use of this hardware
or any direct or indirect consequential damages arising from its use. It is the
responsibility of the user of the hardware to check that it is suitable for his/her
requirements and that it is installed correctly. All rights reserved. No parts of
this manual may be reproduced or transmitted by any form or means electronic or
mechanical, including photocopying, recording or by any information storage or
retrieval system without the written consent of the publisher.
China Electronics Technology Limited reserves the right to revise any of its
hardware and software following its policy to modify and/or improve its products
where necessary or desirable. This statement does not affect the legal rights of
the user in any way.
All third party trademarks and copyrights are recognized. The CE-LINK logo is
the registered trademarks of China Electronics Technology Limited.
1.3 FEATURES
The series of the HDMI Extender have many features that enable them to perform
in a superior manner. Among those features you will find:
l One pair as a full functional module, no need of setting.
l CAT-5e/6 cable can substitute HDMI cable to achieve long distance
transmission.
l Follow the standard of IEEE-568B.
l Transmission distance can be up to 30 meters for 1080p while using CAT-6
cable.
l Compact size.
l Signaling rates up to 1.65Gbps in support of 1080P display.
l HDCP compliant.
HDMI EXTENDER BY CAT-5e/6 HCL0101
WWW.CE-LINK.COM
４
2.0 SPECIFICATIONS
Signal Inputs/Output
Input Video Signal 0.5 -1.0 volts p-p
Input DDC Signal 5 volts p-p (TTL)
Maximum Single Link Range 1920X1200, 1080P
Output Video HDMI 1.2a
Video format supported
DTV/HDTV 1080P/1080i/720P/576P/480P/576i/480i
Transmission distance
Using CAT6 Cable 30M for1080p
Using CAT5e/6 Cable 60M for 480p
Resolutions(HDTV)
Interlaced(50&60Hz) 480i,576i,1080i
Progressive(50&60Hz) 480p,576p,720p,1080p
Mechanical
Size(W-H-D) 45mmW x 25mmH x 81mmD
Weight(Net) 0.246KGs
Power Consumption 5Watts (max.)
Warranty
Limited Warranty 1 Year Parts and Labor
Environmental
Operating Temperature
0 to +70℃
Operating Humidity 10% to 85 % RH (no condensation)
Storage Temperature
-10℃ to +80℃
Storage Humidity 5% to 95 % RH (no condensation)
Power Requirement
External Power Supply 5V DC@2A
Regulatory Approvals
Converter Unit FCC,CE,UL
Power Supply UL,CE,FCC
Accessories Adapter
AC Power Adapter US standard, UK standard and so on
User Manual
Note: 1:In order to achieve the high transmission quality, please choose the shielded
CAT-5e or CAT-6 cable.
2:The cables with lower quality will not achieve the perfect transmission effect
and long distance.
3:Theoretically the function of the product is normal when adopt short distance
transmission.
If the product cannot transmit long distance, this is to say, there are quality problems
in the transmission cables.
HDMI EXTENDER BY CAT-5e/6 HCL0101
WWW.CE-LINK.COM
５
3.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the shipping carton:
1) Main unit NO. 1 Sender
2) Main unit NO. 2 Receiver
3) 5VDC Power Supply.
4) User’s Manual
Note: Please retain the original packing material in the case of needing to
return the unit. If you find any items are missing,contact China Electronics
Technology Limited immediately. Please have the model number, serial
number and invoice available for reference when you call.
4.0 PANEL DESCRIPTIONS
Sender
Receiver
HDMI EXTENDER BY CAT-5e/6 HCL0101
WWW.CE-LINK.COM
６
1) HDMI input.
2) CAT-5e output2.
3) CAT-5e output1.
4) HDMI output
5) CAT-5e input1
6) CAT-5e input2
7) Power Input
5.0 CONNECT AND OPERATE
1) Connect the HDMI input sources such as：HD-DVD、PS3、STB etc.
2) Connect two CAT-5E cables to both the output of the sender and input of the
receiver.
3) Connect the HDMI output( such as : HD-LCD、HD-DLP)into receiver.
4) Plug the power into the receiver.
Attention: Insert / Extract cable gently.
5.1 CONNECTION DIAGRAM
DC 5V
CAT-5e/6 cable
Sender Receiver
CAT-5e/6 cabl
HDMI signal source
such as STB
Display Such as
LCD TV
HDMI EXTENDER BY CAT-5e/6 HCL0101
WWW.CE-LINK.COM
７
6.0 TROUBLESHOOTING
If the product doesn’t appear to be functioning, make certain that there are four
points you should pay attention.
First, check the connection between the Hdmi cable and the extender correctly.
They all should be connected with a length 6 feet or less. (In other words, make
certain that the problem is not caused by long cables ).
Second, mearsure the cable length you are attempting to use between the sender
and the receiver.They all should connected correctly by Cat-6 cable for
1080p.then,they can reach the length of 30M. And if use cat5e/6 cable for
480p,they can reach 60M.
If the signal is present under those conditions,make certain that the power is
present to the product. If it is, all cables should be premium quality.
Lastly, inspect the cables and connectors for damage.
7.0 LIMITED WARRANTY
Should any consumer product from China Electronics Technology Limited fail due
to defects in materials or workmanship within one year from the date of the
original sale to the end-user, China Electronics Technology Limited guarantees
that we will replace the defective product at no cost. Freight charges for the
replacement unit will be paid by the customers. A copy of the invoice showing
the item number and date of purchase (proof-of-purchase) must be submitted with
the defective unit to constitute a valid in-warranty claim.
Units that fail after the warranty period has expired may be returned to the factory
for repair at a nominal charge, if not damaged beyond the point of repair. All
freight charges for out-of-warranty returns for repair are the responsibility of the
customer.Units returned for repair must have a Return Authorization Number
assigned by the factory.
This is a limited warranty and is not applicable for products which,in our opinion,
have been damaged, altered, abused, misused, or improperly installed. China
Electronics Technology Limited makes no other warranties either expressed or
implied, including limitation warranties as to merchantability or fitness for a
particular purpose. Additionally, there are no allowances or credits available for
service work or installation performed in the field by the end user.
Notice
China Electronics Technology Limited reserves the right to make changes in the
hardware, packaging and any accompanying documentation without prior written
notice.
