Microscope
Instruction Manual
Models # 4010, 4020 and 4030
Table of Contents
Introduction………………………………………………………………………. 1
Junior Microscope Model 4010……………………………………………….. 2
Junior Dissecting Microscope Model #4020………………………………... 4
Educational Microscope Model #4030………………………………………. 6
Care and Maintenance………………………………………………………….. 8
Introduction
Congratulations on your purchase of a Celestr on microscope. Celestron offers a complete lin e of
quality microscopes ranging from beginner and educational microscopes to research level
instruments. Your Celestron microscope is a precision optical instrument, made of the highest
quality materials to ensure durability and long life. Your microscope is designed to give you a
lifetime of pleasure with a minimal amount of maintenance.
The first sections of this manual will help you become familiar with the various parts of your
microscope and how they work together. Read car efully the sections on viewing s pecimens and
focusing. Tak e special notice of all precau tions regar ding using t he illum inator m irror (if applicable
to your model) to focus sunlight and regulating the focuser travel so as not to d amage specimen
slides or the objective lens.
The final section provides sim ple care and maintenance t ips for you to follow to ensure t hat your
microscope provides you with years of quality performance and enjoyment.
2
Junior Microscope – Model #4010
6
5
Figure 1
1 Eyepiece 5 Specimen Holder Clips
2 Objective Lens 6 Focus Travel Safety Screw
3 Specimen Stage 7 Stand Column
4 Illumination Mirror 8 Focus Adjustment Knob
Standard Accessories:
Your Celestron microscope (#4010) comes complete with the following standard accessories:
• 10x Eyepiece
• 20x Objective lens (200x)
• Plastic Dust Cover
Item #4010 Specifications:
Stage Plain stage with paired clips
Focuser Rack and Pinion; 30mm travel with focus stop
Objective Achromatic Objective 20x
Illuminator 42mm Plano-Convcave Mirror
Eyepiece 10x; 18mm
2
Microscope Operation
Using the Illuminator Mirror:
Your Celestron microscope has a built-in Plano-concave illumination mirror which allows you to
illuminate the specimen from the bottom. The mirror has a flat side and a concave side. The
concave side will concentrate more light onto the specimen than the flat side. To illuminate a
specimen:
1. If it is daylight, tilt the illumination mirror (4) and reflect
specimen stage (3).
WARNING: Never use the mirror to focus direct sunlight through your microscope.
Sunlight, if viewed directly can be very harmful and may permanently damage your eyes.
2. If viewing at night or indoors, away from sunlight, you can use a nearby desk or table lamp to
reflect light onto a specimen.
To control the amount of light reflecting onto the specimen:
1. Use the concave side of the illuminator mirror to focus more light on the slide. The concave
side will concentrate more light onto your specimen but will focus a smaller beam of light,
making it more sensitive to adjust.
2. If you are unable to adjust the mirrors enough to properly illuminate the specimen, you can
also tilt the stand column (7) backwards to change the position of the mirror.
indirect
sunlight through the bottom of
Viewing a Specimen
To view a specimen:
1. Carefully place a specimen slide under the specimen holder clips (5) and center the
specimen directly over the hole in the stage (3).
Your are know ready to focus and view the specimen, but first you must take some precautions
so as not to damage the specimen slide or objective lens. Your microscope is equipped with a
focus travel safety screw (6) which allows you to regulate the range of travel on the focuser. This
assures that the objective lens will not accidentally come in contact with the specimen slide,
breaking the slide or scratching the objective lens. To adjust the travel on the focuser
mechanism:
1. Raise the objective lens away from the specimen stage (3) by rotating the focuser knob (8)
backwards.
2. Unthread the focus travel safety screw (6) about 2/3 of the way.
3. Lower the objective lens over the slide until the tip of the lens is slightly above the specimen
slide. (Be careful not to touch the objective lens to the slide).
4. Thread the focus travel safely screw (6) upward until it stops against the focuser mechanism.
5. Rotate the knurled locking nut upward to lock the safety screw in place.
6. Now, turn the focus adjustment knob (8) until the specimen comes into sharp focus.
3
Junior Dissecting Microscope – Model #4020
910
2
8
7
Figure 2
1 Monocular Head 6 Base
2 Pillar Stand Safet y Screw 7 Stage Plate
3 Pillar Stand 8 Specimen Slide Holder Clips
4 Pillar Stand Locking Bolt 9 Objective Lens
5 Focus Adjustment Knob 10 Eyepiece
Standard Accessories
:
Your Celestron microscope (#4020) comes complete with the following standard accessories:
• 10x Eyepiece
• 4x Objective lens (40x)
• Plastic Dust Cover
Item #4020 Specifications:
Optical Head
Stage 60mm black/white stage plate and paired clips
Focuser Rack and Pinion,
Nosepiece Turret objective 4x
Objective 4x; Working Distance 58mm
Eyepiece 10x; 18mm
45º inclined Monocular Head; Rotatable
4
Assembling Your Microscope
Before you can view through your Celestron microscope, the monocular head assembly must be
attached to the pillar stand (3). To attach the monocular head assembly:
1. Remove the safety screw from the top of the pillar stand (3).
2. Partially unthread the pillar stand locking bolt (4) located behind the focuser assembly.
3. Place the monocular head assembly onto the pillar stand (3) and slide it halfway down the
stand.
4. Rotate the monocular head assembly until the objective lens (9) is directly over the center of
the stage plate (7).
5. Tighten the pillar stand locking bolt (4) to hold the monocular head assembly in place.
6. Thread the safety screw (2) back onto the top of the pillar stand.
Your microscope is now ready to view specimens.
Microscope Operation
To view a specimen:
1. Place the round black/white stage plate (7) into the opening on the base (6).
2. Carefully place a specimen slide under the specimen holder clips (8) and center the
specimen directly in the middle of the stage plate.
3. Illuminate the specimen slide by using a nearby desk or table lamp to reflect light onto a
specimen. Natural light can also be used if the microscope is located near a window.
Experiment with different lighting for different specimens. When using downward lighting, the
Tip:
white side of the stage plate may wash out fine detail whereas the black side will increase
contrast but may make the specimen less bright.
Focusing:
To focus on your specimen slide, turn the focus adjustment knob (5) until the specimen comes
into focus. If there is not enough travel in the focuser mechanism to reach focus, it may be
necessary to loosen the pillar stand locking bolt (4) and slightly raise or lower the entire binocular
head assembly until the image becomes sharp.
5
Educational Microscope - Model #4030
8
9
12
11
10
Figure 3
1 Eyepiece 7 Illuminator Mirror
2 Eyepiece Holder 8 Specimen Holder Clips
3 Objective Lens Rotator 9 Focus Travel Safety Screw
4 Objective Lens 10 Stand Column
5 Specimen Stage 11 Fine Focus Adjustment Knob
6 Diaphragm Dial 12 Course Focus Adjustment Knob
Standard Accessories:
Your Celestron microscope (#4030) comes complete with the following standard accessories:
• Huygens 10x eyepiece • 4x Objective lens
• Huygens 12.5x eyepiece • 10x Objective lens
• Plastic Dust Cover • 40x Objective lens
Magnification Table
Use the following table to determine the magnification of the different eyepiece/objective lens
combination of your microscope.
Objective Lens
4x 10x 40x
40x 100x 400x
50x 125x 500x
6
Eyepiece
10x
12.5x
Item #4030 Specifications
Objective Lens Achromatic Objective
Nosepiece Triple nosepiece with click stop
Stage 120mm x 110mm, with paired clips
Illuminator 50mm Plano-Concave
Diaphragm Disc diaphragm with five aperture sizes
Focuser Course focus; Fine focus adjustments
Assembling Your Microscope
Before you can view through your Celestron microscope, the eyepiece and objective lenses must
first be attached.
Installing the Eyepiece:
1. Remove the 10x eyepieces from its container.
2. Slide the narrow end of the eyepiece barrel into the eyepiece holder at the top of the
microscope.
Installing the Objective Lenses:
1. Remove the three objective lenses from their individual containers. Unscrew the container lids
from the threaded portion of the objective lenses.
2. Thread the end of the 4x objective lens into one of the holes on the objective lens rotator (3). It
may be necessary to lower the specimen stage (5) by turning the coarse focus knob (12).
3. Now turn the objective rotator to the next opening and thread each of the remaining objective
lenses into the remaining holes.
Your microscope is now ready to view specimens.
Microscope Operation
Using the Illuminator Mirror:
Your Celestron microscope has a built-in Plano-concave illumination mirror which allows you to
illuminate the specimen from the bottom. The mirror has a flat side and a concave side. The
concave side will concentrate more light onto the specimen than the flat side. To illuminate a
specimen:
1. If it's daylight, tilt the illumination mirror (7) and reflect
specimen stage (5).
WARNING: Never use the mirror to focus direct sunlight through your microscope. Sunlight,
if viewed directly can be very harmful and may permanently damage your eyes.
2. If viewing at night or indoors, away from sunlight, you can use a nearby desk or table lamp to
reflect light onto a specimen.
To control the amount of light reflecting onto the specimen:
1. Use the concave side of the illuminator mirror to focus more light on your specimen. The
concave side will concentrate more light onto your specimen but will focus a smaller beam of
light, making it more sensitive to adjust.
indirect
sunlight through the bottom of
7
2. The amount of light can also be controlled by rotating the five-aperture size diaphragm dial (6)
underneath the specimen stage.
3. If you are unable to adjust the mirrors enough to properly illuminate the specimen, you can also
tilt the stand column (10) backwards to change the position of the mirror.
Viewing a Specimen
To view a specimen:
2. Press downward on the back portion of the spring-loaded specimen holder clips (8) to raise the
front of the clips off of the specimen stage (5).
3. Place a specimen slide under the specimen holder clips (8) and center the specimen directly
over the hole in the center of the specimen stage (5).
Your are know ready to focus and view the specimen, but first you must take some precautions so
as not to damage the specimen slide or objective lens. Your microscope is equipped with a focus
travel safety screw (9) which allows you to regulate the range travel on the focuser. This assures
that the objective lenses will not accidentally come in contact with specimen slide, breaking the slide
or scratching the objective lens. To adjust the travel on the focuser mechanism:
7. Raise the objective lens away from the specimen stage (5) by rotating the course focuser knob
(12) backwards.
8. Unthread the focus travel safety screw (9) about two-thirds of the way.
9. Turn the objective lens rotator (3) until the 40x lens is over the specimen.
10. Lower the objective lens over the slide until the tip of the lens is slightly above the specimen
slide. (Be careful not to touch the objective lens to the slide).
11. Thread the focus travel safely screw (9) upward until it stops against the focuser mechanism.
12. Rotate the knurled locking nut upward to lock the safety screw in place.
Focusing:
Now that the specimen slide is placed directly under the objective lens, use the course focus knob
(12) to focus on the specimen.
• Always start with the lowest power (4x objective lens and 10x eyepiece) and switch to higher
power by rotating the objective lens rotator (3). Be cautious not to let the objective lens touch
the specimen slide when changing to higher power.
• Use the fine focus knob (11) to change the depth of field on the specimen you are observing.
• If you run out of downward travel before reaching sharp focus, you can unscrew the focus travel
safety screw (9) to allow for more downward travel. Once again be careful not to let the
objective lens touch the specimen slide.
8
Care and Maintenance
Your Celestron microscope is a precision optical instrument and should be treated with care at all
times. Follow these maintenance suggestions and your microscope will need very little
maintenance throughout its lif etime.
• Always place the plastic cover over the microscope when not in use or when being stored.
• When moving your microscope, carry it by the stand column. Never pick it up by the
eyepiece housing or focuser knobs.
• Clean the outside of the microscope with a slightly damp cloth.
• Always unplug the microscope (models with electric illuminators) before cleaning.
• Never wipe optical surfaces with cloth or paper towels.
• Clean dust off optical surfaces with an air blower or camels hair brush.
• Clean dirt off optical surfaces by wiping with a piece of clean cotton.
• Never disassemble or clean internal optical surfaces.
9
CELESTRON ONE YEAR WARRANTY
A. Celestron International (CI) warrants this microsc ope to be free from defects in materials and workmanship for one
year. CI will repair or replace such product or part thereof which, upon inspection by CI, is found to be defective in
materials or workmanship. As a condition to the obligation of CI to repair or replace such product, the product must
be returned to CI together with proof-of-purchase satisfactory to CI.
B. The Proper Return Authorization Number must be obtained from CI in advance of return. Call Celestron at (310)
328-9560 to receive the number to be displayed on the outside of your shipping container.
All returns must be accompanied by a written statement setting forth the name, address, and daytime telephone
number of the owner, together with a brief description of any claimed defects. Parts or product for which
replacement is made shall become the property of CI.
The customer shall be responsible for all costs of transportation and insurance, both to and from the factory
of CI, and shall be required to prepay such costs.
CI shall use reasonable efforts to repair or replace any microscope covered by this warranty within thirty days of
receipt. In the event repair or replacement shall require more than thirty days, CI shall notify the customer
accordingly. CI reserves the right to replace any product which has been discontinued from its product line with a
new product of comparable value and function.
This warranty shall be void and of no force of effect in the event a covered product has been modified in
design or function, or subjected to abuse, misuse, mishandling or unauthorized repair. Further, product
malfunction or deterioration due to normal wear is not covered by this warranty.
CI DISCLAIMS ANY WARRANTIES, E XPRESS OR IMPLIED, WHETHER OF MERCHANTABILITY OF FITNES S
FOR A PARTICULAR USE, EXCEPT AS EXPRESSLY SET FORTH HEREIN.
THE SOLE OBLIGATION OF CI UNDER THIS LIMITED WARRANTY SHALL BE TO REPAIR OR REPLACE THE
COVERED PRODUCT, IN ACCORDANCE WITH THE TERMS SET FORTH HEREIN. CI EXPRESSLY DISCLAIMS
ANY LOST PROFITS, GENERAL, SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES WHICH MAY RESULT
FROM BREACH OF ANY WARRANTY, OR ARISING OUT OF THE USE OR INABILITY TO USE ANY CI
PRODUCT. ANY WARRANTIES WHICH ARE IMPLIED AND WHICH CANNOT BE DISCLAIMED SHALL BE
LIMITED IN DURATION TO A TERM OF ONE YEAR FROM THE DATE OF ORIGINAL RETAIL PURCHASE.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limit ation on how l ong
an implied warranty lasts, so the above limitations and exclusi ons may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from st ate to state.
CI reserves the right to modify or discontinue, without prior notice t o you, any model or style microscope.
If warranty problems arise, or if you need assistance in using your microscope contact:
Celestron International
Customer Service Department
2835 Columbia Street
Torrance, CA 90503
Tel. (310) 328-9560
Fax. (310) 212-5835
Monday-Friday 8AM-4PM PST
This warranty supersedes all other product warranties.
NOTE: This warranty is valid to U.S.A. and Canadian customers who have purchased this product from an
Authorized CI Dealer in the U.S.A. or Canada. Warranty outside the U.S.A. and Canada is valid only to customers
who purchased from a CI International Distributor or Authorized CI Dealer in the specific country and please
contact them for any warranty service.
10
Celestron International
2835 Columbia Street
Torrance, CA 90503
Tel: 310-328-9560
Fax: 310-212-5835
Web site: http://www.celestron.com
Copyright 1998 Celestron International
All right reserved
(Products or instructions may change
without notice or obligation).
05-98
Printed in China
5
Loading...
